Whirlpool 8280525 Bedienungsanleitung

A Note to You ..................2

Dryer Safety......................3

Parts and Features ..........5

Checking Your Vent ..........6

Using Your Dryer ..............8

Starting your dryer ........8

Selecting a cycle

and temperature

setting ............................9

Loading........................10

Cycle descriptions ......10

Fluff Air cycle ..............13

Using the drying

rack..............................14

Caring for Your

Dryer ..............................15

Troubleshooting..............18

Assistance

or Service........................20

Warranty..........................24

1-800-253-1301

Call us with questions or comments.

8280525

27"

Electric and

Gas Dryers

www.whirlpool.com

A NOTE TO YOU

Thank you for buying a WHIRLPOOL®appliance.

The Whirlpool brand is committed to designing quality products that consistently perform for you to make your

life easier. To ensure that you enjoy years of trouble-free operation, we developed this Use and Care Guide. It is

full of valuable information about how to operate and maintain your appliance properly and safely. Please read

it carefully.

Also, complete and mail the Ownership Registration Card provided with your appliance. The card helps us

notify you about any new information on your appliance.

Please record your model’s information.

Whenever you call to request service for your

appliance, you need to know your complete model

number and serial number. You can find this informa-

tion on the model and serial number label/plate (see

diagram in the “Parts and Features” section).

Please also record the purchase date of your appliance

and your dealer’s name, address, and telephone number.

Keep this book and the sales slip together in a safe place for future reference.

Our Consumer Assistance Center number is toll free.

Model Number________________________________

Serial Number ________________________________

Purchase Date________________________________

Dealer Name ________________________________

Dealer Address ______________________________

Dealer Phone ________________________________

1-800-253-1301

To find detailed product information, the location of the nearest Whirlpool dealer or designated servicer, to

purchase an accessory item, or register your appliance on-line, please visit our Web site at

www.whirlpool.com

DRYER SAFETY

WARNING: For your safety the information in this manual must be followed to

minimize the risk of fire or explosion or to prevent property damage, personal

injury or death.

– Do not store or use gasoline or other flammable vapors and liquids in the vicinity

of this or any other appliance.

– WHAT TO DO IF YOU SMELL GAS

•Do not try to light any appliance.

•Do not touch any electrical switch; do not use any phone in your building.

•Clear the room, building or area of all occupants.

•Immediately call your gas supplier from a neighbor’s phone. Follow the gas

supplier’s instructions.

•If you cannot reach your gas supplier, call the fire department.

– Installation and service must be performed by a qualified installer, service agency

or the gas supplier.

continued on next page

You will be killed or seriously injured if you don’t

follow instructions.

You can be killed or seriously injured if you don’t

follow instructions.

Your safety and the safety of others is very important.

We have provided many important safety messages in this manual and on your appliance. Always read and

obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to hazards that can kill or hurt you and others.

All safety messages will be preceded by the safety alert symbol and the word “DANGER” or

“WARNING.” These words mean:

wDANGER

wWARNING

All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can

happen if the instructions are not followed.

DRYER SAFETY

WARNING: To reduce the risk of fire, electric shock, or injury to persons when using the

dryer, follow basic precautions, including the following:

•Read all instructions before using

the dryer.

•Do not place items exposed to cooking

oils in your dryer. Items contaminated

with cooking oils may contribute to a

chemical reaction that could cause a

load to catch fire.

•Do not dry articles that have been

previously cleaned in, washed in, soaked

in, or spotted with gasoline, dry-cleaning

solvents, other flammable, or explosive

substances as they give off vapors that

could ignite or explode.

•Do not allow children to play on or in

the dryer. Close supervision of children

is necessary when the dryer is used

near children.

•Before the dryer is removed from service

or discarded, remove the door to the

drying compartment.

•Do not reach into the dryer if the drum

is moving.

•Do not install or store the dryer where

it will be exposed to the weather.

•Do not tamper with controls.

SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

•Do not repair or replace any part of the

dryer or attempt any servicing unless

specifically recommended in this Use and

Care Guide or in published user-repair

instructions that you understand and

have the skills to carry out.

•Do not use fabric softeners or products

to eliminate static unless recommended

by the manufacturer of the fabric softener

or product.

•Do not use heat to dry articles containing

foam rubber or similarly textured rubber-

like materials.

•Clean lint screen before or after each

load.

•Keep area around the exhaust opening

and adjacent surrounding areas free from

the accumulation of lint, dust, and dirt.

•The interior of the dryer and exhaust vent

should be cleaned periodically by

qualified service personnel.

•See Installation Instructions for grounding

requirements.

PARTS AND FEATURES

The drawings in this book may vary from your dryer model. They are designed to show the

different features of all models covered by this book. Your model may not include all features.

Additional features your dryer may have:

CLEAN TOUCHTM control panel*

End of cycle signal selector (p. 9)

FINISH GUARD®feature selector* (p. 8)

FINISH GUARD®Plus feature selector (p. 8)

ACCUDRYTM electronic sensor (p. 10)

DRY MISER®automatic sensor (p. 10)

Drying rack (p. 14)

Drum light (p. 17)

* On some models

Cycle control

knob

(pp. 8-12)

Model and

serial number

label

(p. 2)

Dryer drum

(p. 16) Wide-opening

hamper door

Start button

(p. 8)

Lint screen

(p. 15)

2. Use a 4-inch exhaust hood. Smaller hoods

increase drying times.

CHECKING YOUR VENT

Your dryer must be properly installed and vented to achieve maximum drying efficiency and

shorten drying times. Use the minimum recommended installation clearances (found in your

Installation Instructions) to avoid blocking the flow of combustion and ventilation air. Install your

dryer in a well-ventilated room where the temperature is always above 45°F. Also make sure that

your dryer is leveled. Refer to your Installation Instructions for more information.

VENTING

If the dryer is not properly installed and vented, it will

not be covered under the warranty.

NOTE: Service calls caused by improper venting will

be paid for by the customer, whether it was a paid

installation or self-installed. For paid installation, call

the company that installed the vent for

adjustment.

1. Do not use plastic vent or flexible metal foil vent.

Use 4-inch heavy metal

or flexible metal vent.

Do not kink or crush

flexible metal vent. It

must be completely

extended to allow

adequate exhaust air

to flow. Check vent

after installation. Refer

to your Installation

Instructions for proper

length requirements of vent.

wWARNING

Fire Hazard

Use a heavy metal vent.

Do not use a plastic vent.

Do not use a metal foil vent.

Failure to follow these instructions can

result in death or fire.

4”

3. You can exhaust from the rear, left, right, or

bottom of the dryer.

•Exhaust from the

rear of the dryer: The

exhaust vent can be

routed up, down, left,

right, or straight out the

back of the dryer. Space

requirements are listed

in your Installation

Instructions.

CHECKING YOUR VENT

VENTING (CONT.)

6. Clean exhaust vent periodically, depending on use,

but at least every 2 years,

or when installing your

dryer in a new location.

•Disconnect vent from

the dryer and clean one

section at a time until

you reach the exhaust

hood.

•Use the hose attach-

ment on your vacuum,

or a pole or wire with a

feather duster or rag attached, to clean out lint.

•Be sure the flapper on the outside end of vent

moves freely.

•When cleaning is complete, be sure to follow the

Installation Instructions supplied with your dryer

for final product check.

4. Use the straightest path possible when routing

the exhaust vent. Use

the fewest number of

elbows and turns. Allow

room when using

elbows or making turns.

Bend vent gradually to

avoid kinking.

5. Use duct tape to seal all joints. Do not use

screws to secure vent.

Lint may catch on

screws.

wWARNING

Fire Hazard

Cover unused exhaust holes with one of the

following kits: #279818 (white), #279819

(almond), #279820 (ebony).

Contact your local dealer.

Failure to do so can result in death, fire,

electrical shock, or serious injury.

•Exhaust from left, right, or bottom of dryer: To

convert the dryer for exhaust out the right or left

side, or through the bottom, you must use one of

the following kits:

Exhaust Kit No. 279818 (white)

Exhaust Kit No. 279819 (almond)

Exhaust Kit No. 279820 (ebony)

An exhaust kit can be ordered by calling

1-800-442-9991 and following the instructions

and telephone prompts you hear.

Before using your dryer, wipe the dryer drum with

a damp cloth to remove dust from storing and

shipping.

1. Load clothes loosely into the dryer and close the

door. Do not pack the

dryer; allow space for

clothes to tumble freely.

wWARNING

Explosion Hazard

Keep flammable materials and vapors, such

as gasoline, away from dryer.

Do not dry anything that has ever had

anything flammable on it (even after

washing).

Failure to follow these instructions can

result in death, explosion, or fire.

2. Turn the Cycle Control knob to the recommended

cycle for the type of load

being dried, as described

in “Cycle descriptions”

later in this section.

•Use the Energy

Preferred Automatic

Setting (*) to dry most

loads.

NOTE: On some mod-

els, the Temperature

selector is part of the

Cycle Control knob.

USING YOUR DRYER

STARTING YOUR DRYER

3. If your dryer has a Temperature selector, set it to

the recommended setting for the type of fabric

being dried. The cycle descriptions on the

following pages include temperature setting

suggestions.

4. (OPTIONAL STEP) Some dryers have an On/Off

FINISH GUARD®selector or an Off/30 min. or

90 min. FINISH GUARD®Plus selector. These

features protect your clothes from wrinkling when

you do not remove them from the dryer as soon

as it stops.

•Set the FINISH GUARD selector to On to

tumble the load without heat every few minutes

up to 45 minutes after the drying cycle ends.

•The FINISH GUARD Plus selector lets you

choose up to 30 or 90 minutes of periodic

unheated tumble time after the drying cycle

ends.

•A signal will sound every few minutes while

FINISH GUARD (FINISH GUARD Plus) is

running if the Cycle Signal (End of Cycle

Signal) feature is set to On. The signal and cycle

end when you open the dryer door.

•Set the FINISH GUARD (FINISH GUARD Plus)

selector to Off if you do not want to run this

feature.

NOTE: Some dryers have a FINISH GUARD feature

that cannot be turned On or Off. See page 12.

wWARNING

Fire Hazard

No washer can completely remove oil.

Do not dry anything that has ever had any

type of oil on it (including cooking oils).

Items containing foam, rubber, or plastic

must be dried on a clothesline or by using

an Air Cycle.

Failure to follow these instructions can

result in death or fire.

5. (OPTIONAL STEP) If your dryer has a Cycle

Signal (End of Cycle Signal) selector, set the

selector to On if you want the dryer to sound a

signal when a cycle is finished.

•The signal is helpful when you are drying

permanent press, synthetics, and other items

that should be removed from the dryer as

soon as it stops.

•On some models, the End of Cycle Signal is

part of the Start button.

•On some models, the End of Cycle Signal

volume can be adjusted from Softer to Louder.

6. Push the Start button.

NOTE: Your dryer stops automatically when a

cycle ends.

STARTING YOUR DRYER (CONT.)

USING YOUR DRYER

SELECTING A CYCLE AND TEMPERATURE SETTING

The following pages describe the drying cycles on

your dryer. The descriptions include suggested

temperature settings and drying times for various

loads.

Cycle and temperature tips

•Make sure you have selected the correct cycle

and temperature for your load.

•Dry most loads using the Energy Preferred

Automatic Setting (*).

•Use an air cycle (or temperature setting), or line

dry rubber, plastic, delicate, and heat-sensitive

fabrics.

•If some types of loads in the cycle descriptions

on the following pages have more than one

suggested temperature setting, choose the

lowest setting available on your dryer.

•The last few minutes of all cycles are without

heat to make the load cooler to handle.

Drying tips

•Always follow care label directions when they are

available.

•If you use fabric softener sheets, always use

softener sheets that are labeled as dryer safe and

follow package instructions carefully.

•Remove the load from the dryer as soon as

tumbling stops to reduce wrinkling. This is

especially important for permanent press, knits,

and synthetic fabrics.

Stopping and restarting your dryer

You can stop your dryer anytime during a cycle.

To stop your dryer:

Open the dryer door or turn the Cycle Control knob

to Off.

NOTE: The Cycle Control knob should point to an

Off area when the dryer is not in use.

To restart your dryer:

Close the door, select a new cycle and temperature

(if desired), and push the Start button.

CYCLE DESCRIPTIONS

Automatic cycle(s)

Use an Automatic cycle to dry most loads.

Depending on your

model, the Automatic

cycle uses either the

electronic ACCUDRYTM

system or the auto-

matic DRY-MISER®

control that senses the

moisture in the load

and shuts off the dryer

when the selected

dryness is reached.

The Cycle Control knob does not move until the

load is almost dry. After the cool-down, the knob

automatically turns to an Off area and tumbling

stops.

•If the load is drier than you like, select a setting

closer to Less Dry the next time you dry a

similar load.

•If the load is not as dry as you like, complete

drying using a Timed cycle. Select a setting

closer to Very Dry the next time you dry a similar

load.

Loading suggestions

The chart below provides some guidelines on various types of drying loads. Load clothes loosely into the

dryer. Do not pack the dryer; allow space for clothes to tumble freely.

Heavy Work Clothes

4 jeans

4 workpants

4 workshirts

2 sweatshirts

2 sweatpants

Towels

10 bath towels

10 hand towels

14 wash cloths

Mixed Load

3 sheets (1 king, 2 twin)

4 pillowcases

3 shirts

3 bouses

9 t-shirts

9 shorts

10 handkerchiefs

Delicates

3 camisoles

1 quilted robe

4 slips

4 panties

2 bras

2 nighties

1 baby’s dress

Drying time with an Automatic cycle varies accord-

ing to the type of fabric, size of load, and dryness

setting. Your model may not have all heat settings

listed. Some general guidelines are:

•Use a high heat setting for drying heavyweight

items, such as towels and work clothes.

•Use a medium heat setting for drying medium-

weight items, such as sheets, underwear,

permanent press clothes, and some knits.

•Use a low or extra low heat setting for drying

lightweight items such as lingerie, blouses,

dresses, and some knits.

NOTE: If you have any questions about drying

temperatures for various loads, refer to care label

directions.

USING YOUR DRYER

Inhaltsverzeichnis

Andere Whirlpool Trockner Handbücher

Whirlpool

Whirlpool LE6800XS Bedienungsanleitung

Whirlpool

Whirlpool KHGV01RSS0 Bedienungsanleitung

Whirlpool

Whirlpool Gold GGW9868KL5 Bedienungsanleitung

Whirlpool

Whirlpool 3RLER5437KQ0 Bedienungsanleitung

Whirlpool

Whirlpool Gas dryer Bedienungsanleitung

Whirlpool

Whirlpool 3LWED4830FW Bedienungsanleitung

Whirlpool

Whirlpool LDR3822HQ0 Bedienungsanleitung

Whirlpool

Whirlpool AWZ 234 Bedienungsanleitung

Whirlpool

Whirlpool WGD9500TC - DUET FRONT LOAD STEAM DRYERS Bedienungsanleitung

Whirlpool

Whirlpool W10388775A Bedienungsanleitung

Whirlpool

Whirlpool CGM2751TQ - COMM GAS DRYR 3CYC 3TEMP 3LITE Bedienungsanleitung

Whirlpool

Whirlpool WGD4700Y Handbuch

Whirlpool

Whirlpool WED5800SG0 Bedienungsanleitung

Whirlpool

Whirlpool LE5721XS Bedienungsanleitung

Whirlpool

Whirlpool WGD94HEX Bedienungsanleitung

Whirlpool

Whirlpool WGD97HEDC0 Bedienungsanleitung

Whirlpool

Whirlpool WED72HEDW0 Bedienungsanleitung

Whirlpool

Whirlpool LEQ9557KQ0 Bedienungsanleitung

Whirlpool

Whirlpool Electric and Gas Dryers Bedienungsanleitung

Whirlpool

Whirlpool Gold GGQ9800PW Bedienungsanleitung

Whirlpool

Whirlpool Gas dryer Bedienungsanleitung

Whirlpool

Whirlpool PROD 06SCII Bedienungsanleitung

Whirlpool

Whirlpool WED9400ST Bedienungsanleitung

Whirlpool

Whirlpool 240-VOLT ELECTRIC DRYER Bedienungsanleitung

Beliebte Trockner Handbücher anderer Marken

Bosch

Bosch WTA79200GB Bedienungsanleitung

Amana

Amana W10233410A Bedienungsanleitung

Miele

Miele TWH 780 WP Bedienungsanleitung

Asko

Asko T760 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Bedienungsanleitung

Bosch

Bosch Logixx 10 WTB76556GB Technisches Datenblatt

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Bedienungsanleitung

Electrolux

Electrolux EW2H328R2 Bedienungsanleitung

Beko

Beko DS8433RX1M Bedienungsanleitung

Dawlance

Dawlance Spinner DS 6000 C Bedienungsanleitung

Electrolux

Electrolux TP5080TW Bedienungsanleitung

AEG

AEG TR838P4OB Bedienungsanleitung

Indesit

Indesit IDV 75 Bedienungsanleitung

Infiniton

Infiniton SD-DG85C Bedienungsanleitung

BOMANN

BOMANN WT 5019 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Bedienungsanleitung

Asko

Asko T793C Bedienungsanleitung

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Bedienungsanleitung
