LOWER OVEN PARTS

For Models:RBD305PRB02, RBD305PRQ02, RBD305PRT02, RBD305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

06−08 Litho in U.S.A. (amd)(mek) Part No. W10208660 Rev. A

30" BUILT−IN ELECTRIC

DOUBLE OVEN

STD−CLEAN LOWER

SELF−CLEAN UPPER

LOWER OVEN PARTS

For Models:RBD305PRB02, RBD305PRQ02, RBD305PRT02, RBD305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208660

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature Parts

8303647 Installation

Instructions

W10162170

Use & Care Guide

8302068 Tech Sheet

Safer Cooking Tips

9762761 English

W10065852

French

2 Trim, Side

Right

W10136098

Black

W10136100

White

W10136102

Biscuit

W10166949

Stainless

Left

W10136099

Black

W10136101

White

W10136103

Biscuit

W10166948

Stainless

W10105790

Bumper, Door

5 Screw

3400832 Black

3400805 Zinc

6 Receiver, Hinge

4455606 Right

4455605 Left

7 8303099 Top Chassis

9 4452159 Tube, Vent

W10067870

Lens, Light

W10009930

Assembly, Light

12 4452166 Bulb, Light

W10130368

Frame, Front

15 4450493 Gasket, Door

16 4449809 Screw

17 4449040 Screw

18 4452152 Bracket, Bottom

Vent Mounting

19 4451478 Support, Insulation

20 4450935 Plug, Door

22 4451664 Assembly, Fan &

Bracket

23 4449154 Screw

24 4449743 Screw

25 4455641 Side, Chassis

W10161110

Back, Chassis

27 Liner, Oven

(Not serviceable)

28 3196176 Screw

W10131825

Sensor

30 9760677 Deflector, Vent

31 4451354 Fuse, Thermal

32 9759713 Base, Chassis

33 4448933 Retainer, Gasket

34 4451747 Cover, Back

35 Trim, Bottom

8303583 Black

8303584 White

8303585 Biscuit

8303582 Stainless

36 4449845 Support, Bracket

FOLLOWING PARTS

NOT ILLUSTRATED

INSULATION

4449316 Insulation, Wrap

4450365 Insulation, Back

UPPER OVEN PARTS

For Models:RBD305PRB02, RBD305PRQ02, RBD305PRT02, RBD305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208660

UPPER OVEN PARTS

For Models:RBD305PRB02, RBD305PRQ02, RBD305PRT02, RBD305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208660

Illus. Part

No. No. DESCRIPTION

1 Receiver, Hinge

4455606 Right

4455605 Left

2 4448444 Grommet, Mounting

Rail

W10105790

Bumper, Door

5 4449743 Screw

6 3196176 Screw

7 8303099 Top Chassis

9 4452158 Tube, Vent

W10067870

Lens, Light

W10009930

Assembly, Light

12 4452166 Bulb, Light

W10130368

Frame, Front

15 4455382 Gasket, Door

16 4449809 Screw

17 4449040 Screw

19 4451478 Support, Insulation

21 Rail, Side

8302793 Right

8302794 Left

23 4449154 Screw

24 9760888 Assembly, Latch

25 4455641 Side, Chassis

26 4452233 Back, Chassis

27 Liner, Oven

(Not serviceable)

W10131825

Sensor

29 4452267 Vent, Center

30 9759243 Thermostat

31 4448933 Retainer, Gasket

32 4451747 Cover, Back

33 4449845 Support, Bracket

FOLLOWING PARTS

NOT ILLUSTRATED

INSULATION

4449316 Insulation, Wrap

4450365 Insulation, Back

LOWER OVEN DOOR PARTS

For Models:RBD305PRB02, RBD305PRQ02, RBD305PRT02, RBD305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208660

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 8303700 Liner, Door

2 4449259 Glass, Inner

3 9759743 Retainer, Glass

4 Hinge, Door

9760565 Right

9760566 Left

(SS Model Only)

9760567 Right

9760568 Left

5 Assembly, Door

Glass

8303330 Black

8303339 White

8303342 Biscuit

8303314 Stainless

6 Door Handle

8302813 Black

8302814 White

8302815 Biscuit

W10136473

Bracket, Handle

8 Retainer, Door

8303389BL

Black

8303389WH

White

8303389BT

Biscuit

9 4451040 Screw

10 8303878 Seal, Door

11 4451432 Retainer, Clip

12 4448520 Bumper, Door

UPPER OVEN DOOR PARTS

For Models:RBD305PRB02, RBD305PRQ02, RBD305PRT02, RBD305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208660

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 8303700 Liner, Door

2 Hinge, Door

9760571 Right

9760572 Left

(SS Model Only)

9760573 Right

9760574 Left

3 4449259 Glass, Inner

4 4451722 Insulation, Door

5 4457132 Retainer, Glass

6 4448520 Bumper, Door

7 9759225 Glass, Inner

11 3400832 Screw

12 Assembly, Door

Glass

8303330 Black

8303339 White

8303342 Biscuit

8303314 Stainless

13 Door Handle

8302813 Black

8302814 White

8302815 Biscuit

W10136473

Bracket, Handle

15 9759229 Bracket(2nd Glass)

16 9759230 Bracket(3rd Glass)

17 8303811 Nameplate

18 Retainer, Door

8303389BL

Black

8303389WH

White

8303389BT

Biscuit

19 4457103 Shield, Heat

20 4451040 Screw

21 8303878 Seal, Door

22 4457114 Shield, Heat (Btm)

23 4451432 Retainer, Clip

24 9759228 Glass, Inner

INTERNAL OVEN PARTS

For Models:RBD305PRB02, RBD305PRQ02, RBD305PRT02, RBD305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208660

Illus. Part

No. No. DESCRIPTION

1 9760771 Element, Broil

2 4448717 Rack, Oven

3 9760766 Element,

Conventional Bake

4 4449154 Screw

CONTROL PANEL PARTS

For Models:RBD305PRB02, RBD305PRQ02, RBD305PRT02, RBD305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208660

Illus. Part

No. No. DESCRIPTION

1 Control Panel

8302848 Black

8302849 White

8302850 Biscuit

2 Membrane Switch

8304275 Black

8304276 White

8304277 Biscuit

3 8303883 Microcomputer

W10153086

Backer, Control

Panel

5 8301848 Board, Latch

6 4449745 Screw

W10166944

Trim, Control

Panel (Stainless

Model Only)

TOP VENTING PARTS

For Models:RBD305PRB02, RBD305PRQ02, RBD305PRT02, RBD305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208660

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 4451759 Vent, Exhaust

2 Blower

4457289 65mm (Upper)

W10016550

45mm (Lower)

3 4451758 Foam, Block

4 4455178 Elbow, Vent Top

5 4455177 Elbow, Vent Bottom

6 4449809 Screw

7 4449040 Screw

8 3400080 Screw

9 4450038 Screw

11 4449868 Block, Terminal

13 8303497 Vent, Control

Panel

14 Side, Control Top

4451597 Right

4451598 Left

15 9759135 Back, Control

16 4450551 Cover, Top Rear

17 4448664 Clamp

18 4452367 Cover, Top Front

19 4454943 Plate, Fan

20 8302143 Suppressor

21 9760587 Transformer

OPTIONAL PARTS

For Models:RBD305PRB02, RBD305PRQ02, RBD305PRT02, RBD305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208660

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

PAINT, TOUCH−UP (1/2oz.)

72017 White

261869 Cord Brown

72032 Black

PAINT, SPRAY

350930 White

261900 Citrine White

830864 Black

ADHESIVE

591014 Adhesive

Loctite (1/3 oz.)

482338 Sealer, Silastic

(3 oz.)

SPLICING WIRES−−25FT.

LENGTH

242828 Wire (12 Ga.

150 c Black)

242820 Wire (14 Ga.

150 c Black)

242821 Wire (14 Ga.

150 c Blue)

242822 Wire (14 Ga.

150 c Brown)

242830 Wire (14 Ga.

200 c Brown)

242823 Wire (14 Ga.

150 c Green)

242824 Wire (14 Ga.

150 c Orange)

242825 Wire (14 Ga.

150 c Red)

242831 Wire (14 Ga.

200 c Red)

242827 Wire (14 Ga.

150 c Yellow)

WIRING HARNESS PARTS

8302154 Harness, Main

4452400 Lead, Ground

Strap

4450953 Conduit, Double

4450800 Screw

98997 Clip

4448664 Clamp

4449809 Screw

7103P027−60

Nut, Terminal

Block

4454835 Tie, Cable

4451761 Support, Wiring

4454842 Tie, Cable

Miscellaneous

4448950 Screw, Install.
