Whirlpool GBD307PRB00 Bedienungsanleitung

LOWER OVEN PARTS

For Models:GBD307PRQ00, GBD307PRB00, GBD307PRS00, GBD307PRT00

(Designer White) (Black) (S.Steel) (Biscuit)

30" BUILT−IN ELECTRIC

DOUBLE OVEN

CONVECTION−UPPER

SELF−CLEAN (GOLD LINE)

6−06 Litho in U.S.A. (cre) Part No. 8186315 Rev.A

LOWER OVEN PARTS

28186315

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature Parts

8303647 Installation

Instructions

8303645 Use & Care Guide

(Oven)

8302068 Tech Sheet (Oven)

4449237 Cookbook, WP Conv.

3191638 Safer Cooking Tips

9759133 Safer Cooking Tips

2 Trim, Side

8302919 RH White

8302920 LH White

8302921 RH Biscuit

8302922 LH Biscuit

8302917 RH Black

8302918 LH Black

8303209 LH S.Steel

8303210 RH S.Steel

8281236 Screw

3 Hinge Receiver

4455605 Left Hand

4455606 Right Hand

4 4448520 Bumper, Door

5 4452490 Spacer, Foam

6 8302349 Divider, Vent

4449809 Screw

7 4455865 Top, Chassis

4449809 Screw

9 4452158 Tube, Vent

3196176 Screw

10 4452165 Lens, Light

11 4452368 Oven Light Assy

12 4452166 Bulb, Light

14 9759060 Frame, Front

4449040 Screw

4450118 Nut

15 4455382 Gasket, Door

18 4452152 Bracket, Mounting

19 4451478 Support, Insulation

25 4455641 Side, Chassis

(R.H. & L.H.)

4449809 Screw

26 4452234 Back, Chassis

4449809 Screw

27 Liner, Oven

(Not serviceable)

29 4455636 Sensor

4449154 Screw

32 8300154 Insulation,

Bottom Vent

33 9760677 Deflector (Btm)

4449154 Screw

37 9759242 Thermostat (TOD)

(Temp.) SPST

4449809 Screw

43 9759713 Base, Chassis

4449809 Screw

49 4448933 Retainer, Gasket

4449154 Screw

50 4451747 Cover, Back

4449809 Screw

51 Trim, Bottom

8302948 White

8302947 Black

8302949 Biscuit

8302950 S.Steel

Screw

53 4449845 Support, Bracket

4449809 Screw

FOLLOWING PARTS

NOT ILLUSTRATED

INSULATION

4449316 Insulation, Wrap

4450365 Insulation, Back

For Models:GBD307PRQ00, GBD307PRB00, GBD307PRS00, GBD307PRT00

(Designer White) (Black) (S.Steel) (Biscuit)

UPPER OVEN PARTS

8186315

For Models:GBD307PRQ00, GBD307PRB00, GBD307PRS00, GBD307PRT00

(Designer White) (Black) (S.Steel) (Biscuit)

UPPER OVEN PARTS

48186315

Illus. Part

No. No. DESCRIPTION

3 Hinge Receiver

4455605 Left Hand

4455606 Right Hand

4 4448520 Bumper, Door

6 8302349 Divider, Vent

4449809 Screw

7 4455865 Top, Chassis

4449809 Screw

9 4452158 Tube, Vent

3196176 Screw

10 4452165 Lens, Light

11 4452368 Oven Light Assy

12 4452166 Bulb, Light

14 9759060 Frame, Front

4449040 Screw

4450118 Nut

15 4455382 Gasket, Door

19 4451478 Support, Insulation

4449809 Screw

20 4451605 Cap, Spacer

21 Rail, Side

8302793 Right Side

8302794 Left Side

4448444 Grommet

4449154 Screw

25 4455641 Side, Chassis

(R.H. & L.H.)

4449809 Screw

26 4452234 Back, Chassis

4449809 Screw

27 Liner, Oven

(Not serviceable)

29 4455636 Sensor

4449154 Screw

34 4452267 Vent, Center

3400832 Screw

37 9759242 Thermostat (TOD)

(Temp.) SPST

49 4448933 Retainer, Gasket

4449154 Screw

50 4451747 Cover, Back

4449809 Screw

53 4449845 Support, Bracket

4449809 Screw

FOLLOWING PARTS

NOT ILLUSTRATED

INSULATION

4449316 Insulation, Wrap

4450365 Insulation, Back

For Models:GBD307PRQ00, GBD307PRB00, GBD307PRS00, GBD307PRT00

(Designer White) (Black) (S.Steel) (Biscuit)

OVEN DOOR PARTS

8186315

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 8303700 Door Liner

2 Hinge, Door

8300577 R.Hand (Yellow)

8300578 L.Hand (Yellow)

4449743 Screw

3 4449259 Glass, Inner

7 9759225 Glass, Inner

12 Door Glass Assy

(Upper)

8303306 White

8303300 Black

8303310 Biscuit

8303288 S.Steel

(Lower)

8303307 White

8303301 Black

8303311 Biscuit

8303289 S.Steel

13 Door Handle

8302814 White

8302813 Black

8302815 Biscuit

8303164 S.Steel

14 8303167 Bracket, Handle

4451040 Screw

15 9759229 Bracket(2nd Glass)

16 9759230 Bracket(3rd Glass)

18 4451722 Insulation, door

19 4457103 Shield, Heat

4449809 Screw

20 4457132 Retainer, Glass

4449809 Screw

22 4457114 Shield, Heat

For Models:GBD307PRQ00, GBD307PRB00, GBD307PRS00, GBD307PRT00

(Designer White) (Black) (S.Steel) (Biscuit)

LATCH PARTS

68186315

Illus. Part

No. No. DESCRIPTION

1 9759481 Latch, Motorized

For Models:GBD307PRQ00, GBD307PRB00, GBD307PRS00, GBD307PRT00

(Designer White) (Black) (S.Steel) (Biscuit)

INTERNAL OVEN PARTS

8186315

Illus. Part

No. No. DESCRIPTION

1 4448988 Cover, Fan

4449154 Screw

2 4456103 Element, Broil

4449154 Screw

3 4457277 Grill, Broiler

4 4457276 Pan, Broiler

5 3181534 Rack, Roasting

6 4448717 Rack, Oven

9759322 Pad, Rack

7 4452153 Element, Bake

4449154 Screw

9 4451583 Fan, Convection

4449154 Screw

10 4452226 Blade, Fan

12 4452227 Nut

For Models:GBD307PRQ00, GBD307PRB00, GBD307PRS00, GBD307PRT00

(Designer White) (Black) (S.Steel) (Biscuit)

CONTROL PANEL PARTS

88186315

For Models:GBD307PRQ00, GBD307PRB00, GBD307PRS00, GBD307PRT00

(Designer White) (Black) (S.Steel) (Biscuit)

Illus. Part

No. No. DESCRIPTION

1 Control Panel

8302849 White

8302848 Black

8302850 Biscuit

2 Assy, Switch

8303182 Black

8303224 White

8303230 Biscuit

3 8303817 Assy, Control

4449745 Screw

8301848 Latch, Sister

Board

4 8302990 Control, Bracket

5 8302877 Trim−Panel

(Use on S.Steel

model only)

TOP VENTING PARTS

8186315

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 4451759 Assembly,

2 4455178 Elbow, Vent Top

3 4455177 Elbow, Vent Btm

4 Blower

6610168 45MM Lower Oven

4457289 65MM Upper Oven

4455191 Bracket

5 4451758 Foam, Block

6 8300642 Transformer,

Control

7 8302390 Bracket, Support

(Air Stop)

11 4449868 Block, Terminal

3400080 Screw

13 8303497 Vent,

(Control Panel)

4450038 Screw

14 Side, Control Top

4451597 Right

4451598 Left

4449809 Screw

4449154 Screw

15 9759135 Back, Control

4449809 Screw

16 4450551 Cover, Top Rear

4449809 Screw

17 4448664 Clamp

4449809 Screw

112432 Nut

18 4452367 Cover, Top Front

4449809 Screw

19 9759243 Thermostat, Oven

20 8302143 Suppressor

For Models:GBD307PRQ00, GBD307PRB00, GBD307PRS00, GBD307PRT00

(Designer White) (Black) (S.Steel) (Biscuit)

OPTIONAL PARTS

10 8186315

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

PAINT, TOUCH−UP (1/2oz.)

72017 White

261869 Cord Brown

72032 Black

PAINT, SPRAY

350930 White

261900 Citrine White

830864 Black

ADHESIVE

591014 Adhesive

Loctite (1/3 oz.)

482338 Sealer, Silastic

(3 oz.)

SPLICING WIRES−−25FT.

LENGTH

242828 Wire (12 Ga.

150 c Black)

242820 Wire (14 Ga.

150 c Black)

242821 Wire (14 Ga.

150 c Blue)

242822 Wire (14 Ga.

150 c Brown)

242830 Wire (14 Ga.

200 c Brown)

242823 Wire (14 Ga.

150 c Green)

242824 Wire (14 Ga.

150 c Orange)

242829 Wire (12 Ga.

150 c Red)

242825 Wire (14 Ga.

150 c Red)

242831 Wire (14 Ga.

200 c Red)

242826 Wire (14 Ga.

150 c White)

242827 Wire (14 Ga.

150 c Yellow)

242832 Wire (14 Ga.

200 c Yellow)

WIRING HARNESS PARTS

8301909 Harness, Wire

(Latch, Lower)

4449809 Screw

8301777 Harness, Wire

(Main)

4450953 Conduit, Double

4450800 Screw

4448664 Clamp

4449809 Screw

112432 Nut

4452222 Spacer, Harness

4454835 Tie, Cable

4451761 Support, Wiring

4454842 Tie, Cable

Miscellaneous

814381 Pin Hinge Kit

4448950 Screw, Install (4)

For Models:GBD307PRQ00, GBD307PRB00, GBD307PRS00, GBD307PRT00

(Designer White) (Black) (S.Steel) (Biscuit)
