Whirlpool GR673LXS Bedienungsanleitung

COOKTOP PARTS

For Models: GR673LXSQ1, GR673LXSS1, GR673LXSB1

(White) (Stainless Steel) (Black)

5−06 Litho In U.S.A. (lwp) Part No. 8188431

30" ELECTRIC CERAN

FREESTANDING RANGE

SELF CLEAN CONVECTION OVEN

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature Parts

9763001 Owner’s Manual

9762982 Tech Sheet

9762996 Installation

Instructions

Template, Anti−Tip

9757143 English/French

9757142 English/Spanish

9762761 Brochure, Tips

Safe Cooking

W10035930

Spring, Locator

3 3196170 Screw

4 Cooktop

9763334 White

9763336 Black

7 Element, Surface

9759351 2400/1200 W − LF

8523698 1200 W − LR

8523698 1200 W − RR

9759351 2400/1200 W − RF

9762851 120 V − CR

8 8524132 Shield, Wiring

9 Bracket, Element

8272791 (2)

8273720 (1)

10 3196169 Screw

CONTROL PANEL PARTS

For Models: GR673LXSQ1, GR673LXSS1, GR673LXSB1

(White) (Stainless Steel) (Black)

8188431

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Endcap

W10009040

White Left Hand

W10009050

White Right Hand

W10009080

Black Left Hand

W10009090

Black Right Hand

2 9762095 Bracket, Console

3 Panel, Backguard

9762585 White

9762588 Stainless Steel

9762586 Black

4 Switch, Infinite

9758060 Left Front (Dual)

3148951 Left Rear

3148951 Right Rear

9758060 Right FronT (Dual)

5 8523265 Light, Indicator

6 3196068 Lens, Light

7 Knob, Infinite (4)

9757132 White

9758129 Black

8 8523280 Shield, Heat

9 Glss Swtch Membrn

9763548 White

9763549 Black

10 9756999 Cover, Rear

11 Bezel, Keep Warm

9757489 White

9758489 Black

12 9763042 Control, Range

13 3196178 Screw

14 9757613 Nameplate

15 9756366 Cover, Rear

(Console)

16 3400882 Screw

17 8272820 Switch

18 Button

9757492 White

9758491 Black

20 9762426 Cnntr Cable, Flex

21 9757358 Reflector, Light

22 Screw

3196166 White

3196168 Black

23 9757490 Support, Glass

24 3196178 Screw

CHASSIS PARTS

For Models: GR673LXSQ1, GR673LXSS1, GR673LXSB1

(White) (Stainless Steel) (Black)

8188431

CHASSIS PARTS

For Models: GR673LXSQ1, GR673LXSS1, GR673LXSB1

(White) (Stainless Steel) (Black)

8188431

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 9761300 Vent Tube Asmbly

2 8273905 Support, Corner LR

3 Panel, Side (2)

8053830 White

8053832 Black

W10010350

Seal, Oven Flange

5 8522416 Seal, Oven Door

6 9757341 Element, Broil

7 9755770 Element, Bake

(Hidden)

8 3195736 Support, Front (2)

9 3196548 Fuse, Thermal

10 9761909 Appliance Manager

11 3196037 Foot, Front (2)

12 Frame, Front

(Not Serviced)

13 8054068 Tray, Insulation

14 3196576 Clip, Panel (6)

15 9760314 Rail, Base (2)

16 9761935 Foot, Rear (2)

17 3195987 Guard, Wire

18 9757239 Rod − Dr Switch

19 3186116 Support, Oven (2)

20 3186034 Bracket, Service

21 9761958 Block, Terminal

22 9757029 Back, Main

23 9757262 Switch, Door

24 3196701 Light Socket Assy

25 311255 Bulb, Oven Light

26 9755771 Cover, Tray

27 8273902 Sensor, Oven

28 9757970 Cover

29 3196179 Screw

30 4449809 Screw

31 3400016 Screw

33 3196172 Screw

W10031780

Screw

35 3196566 Screw

36 3196168 Screw

37 3196174 Screw

38 9758238 Retainer, Side (2)

39 9760407 Brkt − Mounting

41 9761013 Latch, Door

42 3196961 Rod, Latch

43 9757241 Latch Asy, Rear

44 9758701 Spacer, Door

45 3196169 Screw

46 9755769 Tray, Hidden

Bake Element

47 9759689 Card, Insulator

48 9758525 Element,

Convection

49 9758925 Fan Motor,

Convection

50 4452226 Fan Blade

51 4452227 Nut

52 9755775 Cover, Fan

53 9755776 Bracket, Fan

54 9757311 Transformer

55 8533930 Screw

56 9757972 Cover, Box

57 9761301 Screen − Catalyst

58 3196560 Screw (2)

59 3196178 Screw

60 112432 Nut (3)

61 9761490 Insulation

62 3195813 Clip, Mounting

INSULATION

8272616 Insulation, Wrap

9755772 Insulation, Back

8272613 Insulation, Vent

DRAWER & BROILER PARTS

For Models: GR673LXSQ1, GR673LXSS1, GR673LXSB1

(White) (Stainless Steel) (Black)

8188431

DRAWER & BROILER PARTS

For Models: GR673LXSQ1, GR673LXSS1, GR673LXSB1

(White) (Stainless Steel) (Black)

8188431

Illus. Part

No. No. DESCRIPTION

1 3195710 Rack, Oven (2)

2 3195996 Grill, Broiler

3 3196076 Pan, Broiler

4 9761030 Drawer, Storage

5 9758200 Brkt−Mntg, Drawer

6 Rivet, Push (2)

3196814 White

7 Panel, Drawer Frnt

8053339 White

8053341 Black

8 3181534 Rack, Roasting

9 3196168 Screw

10 9756711 Heat Shield,Drwr

12 9761032 Liner, Drawer

13 9751138 Roller (2)

14 487939 Nut (2)

15 Slide, Drawer

8274190 Left Hand

8274191 Right Hand

18 8274021 Rack, Partial

19 8274022 Rack, Insert

20 Stainless Model

Only

21 9755798 Panel Stainless

22 9757237 Handle

23 8522669 Spacer, Glide

DOOR PARTS

For Models: GR673LXSQ1, GR673LXSS1, GR673LXSB1

(White) (Stainless Steel) (Black)

8188431

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Trim, Top

9761975 White

9761977 Stainless Model

9762391 Black

2 3196164 Screw

3 Handle, Door

9761978 White

6761979 Black

9761981 Stainless Steel

4 9761344 Liner, Door

5 8522414 Seal, Window

6 9758162 Glass, Inner (2)

7 3186289 Frame, Glass

8 8272618 Insulation, Door

9 9761357 Retainer, Insul.

10 9761496 Hinge, Door (2)

11 Glass, Outer

W10010660

White

W10010680

Black

W10010690

Stainless Steel

12 Trim, Side

8523166 White Left Hand

8523172 White Right Hand

8523171 Black Left Hand

8523165 Black Right Hand

9762249 Unvrsl Slvr LH

9762250 Unvrsl Slvr RH

13 3196160 Screw

14 Trim, Lower

8523175 White

8523177 Black

15 3196025 Clip, Glass (4)

W10031790

Screw

W10031780

Screw

19 9761517 Clip, Dr Mntg (2)

20 3196165 Screw

22 3196794 Bracket, Window(2)

OPTIONAL PARTS

For Models: GR673LXSQ1, GR673LXSS1, GR673LXSB1

(White) (Stainless Steel) (Black)

8188431

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

Following Parts Not Illustrated

SPLICING WIRES−−25FT.

LENGTH

242828 Wire, Black

12 Ga. 150 c

242821 Wire, Blue

14 Ga. 150 c

242822 Wire, Brown

14 Ga. 150 c

242830 Wire, Brown

14 Ga. 200 c

242823 Wire, Green

14 Ga. 150 c

242824 Wire, Orange

14 Ga. 150 c

242825 Wire, Red

14 Ga. 150 c

242831 Wire, Red

14 Ga. 200 c

242827 Wire, Yellow

14 Ga. 150 c

REFINISHING MATERIAL

799832 Kit, Porcelain

Repair (White)

242756 Touch−Up

Self−Clean(1/2 Pt)

261582 Grease

INSULATION

261514 Insulation,

Fiberglass (1−1/2"

x 24" x 120")

240132 Insulation,

Fiberglass (2−1/2"

x 22" x 120")

PAINT, TOUCH−UP (1/2oz.)

72017 White

4392899 Biscuit

511873 White Porcelain

(2 Oz.)

PAINT, PRESSURIZED SPRAY

(12 oz.)

350930 White

4392901 Biscuit

285006 Superior Black

206922 Primer (White)

PAINT, BULK (1 qt.)

799344 White (Uncut)

4392900 Biscuit (Uncut)

ACCESSORY PARTS

241430 Foil, Aluminum

Oven (18" x 25’)

3184478 Cleaner, Glass

ANTI−TIP KIT

W10017440

Anti−Tip Kit

WIRING HARNESS PARTS

Following Parts Not Illustrated

9762815 Harness, Wire

(Cooktop Left)

W10044070

Harness, Wire

(Cooktop Right)

9762964 Harns−Wire, Warm

9758438 Harness, Wire

(Main)

9758193 Harness, Wire

(Console)

9756550 Harness, Bake

Element (Hidden)

8523279 Wire, Ground

313660 Clip, Ground Wire

3196154 Screw
