Whirlpool GZ8336XLS Gebrauchsanweisung

PRODUCT MODEL NUMBERS OVERALL DIMENSIONS

VENTING REQUIREMENTS

GZ8330XL

GZ8336XL

Electrical: 120-volt, 60-Hz, AC-only, 15-amp.

electrical supply. Use copper wire only. A time-

delay fuse or circuit breaker and separate circuit is

recommended.

®Convertible Range Hood

Because Whirlpool Corporation policy includes a continuous commitment to improve

our products, we reserve the right to change materials and specifications without notice.

Dimensions are for planning purposes only. For complete details, see Installation

Instructions packed with product. Specifications subject to change without notice.

Ref. 8285188

07-20-02

3-1/4" x 10" (8.3 x 25.4 cm) vent system

Recommended standard fittings

Maximum length = 70 ft. (21.3 m)

1 - 90° elbow = 5 ft. (1.5 m)

8 ft. (2.4 m) straight = 8 ft. (2.4 m)

1 - wall cap = 0 ft. (0 m)

Length of 3-1/4" x

10" (8.3 x 25.4 cm)

system = 13 ft. (3.9 m)

3-1/4" x 10"

(8.3 x 25.4 cm)

90° elbow =

5 ft. (1.5 m)

3-1/4" x 10"

(8.3 x 25.4 cm)

flat elbow =

12 ft. (3.7 m)

3-1/4" x 10"

(8.3 x 25.4 cm)

wall cap =

0 ft. (0 m)

2 ft.

(0.6 m)

6 ft. ( 1.8 m) wall cap

3-1/4" x 10"

(8.3 x 25.4 cm)

elbow

7" (17.8 cm) vent system

90° elbow wall cap

Maximum length = 70 ft. (21.3 m)

1 - 90° elbows = 5 ft.

(1.5 m)

1 - wall cap = 0 ft.

(0 m)

8 ft. (2.4 m) straight = 8 ft.

(2.4 m)

Length of 7"

(17.8 cm) system = 13 ft.

(3.9 m)

Recommended standard fittings

6 ft. (1.8 m)

2 ft. (0.6 m)

3-1/4" x 10"

(8.3 x 25.4 cm) to

7" (17.8 cm) =

4.5 ft. (1.4 m)

90° elbow =

5 ft. (1.5 m) 45° elbow =

2.5 ft. (0.8 m) 3-1/4" x 10"

(8.3 x 25.4 cm)

to 7" (17.8 cm)

90° elbow =

5 ft. (1.5 m)

7" (17.8 cm)

wall cap =

0 ft. (0 m)

7" (17.8 cm) round

or 3-1/4" x 10"

(8.3 x 25.4 cm)

through roof

roof cap

24" (61.0 cm) to

30" (76.2 cm) above

cooking surface

Round vent: Use 7"

(17.8 cm) round damper

(purchased separately)

Vertical

roof venting

wall

cap

3-1/4" x 10"

(8.3 x 25.4 cm)

through the wall

Horizontal

wall venting

7" (17.8 cm) round

or 3-1/4" x 10"

(8.3 x 25.4 cm)

through the wall

24" (61.0 cm) to

30" (76.2 cm) above

cooking surface

29-7/8" (75.9 cm) model: GZ8330

35-7/8" (91.1 cm) model: GZ8336

7-1/2"

(19.1 cm)

(5.1 cm)

1-1/2"

(3.8 cm)

(2.5 cm)

1-1/2"

(3.8 cm)

(22.9 cm)

12"

(30.5 cm)

3/4"

(1.9 cm)

3/8"

(9.5 mm)

20"

(50.8 cm)
