WiBase WB-N211 Bedienungsanleitung
1
APPLICATION
1. Surveillance
2. Law enforcement
3. Hospitality
4. Logistics
5. Retail
6. Agriculture
7. Transportation
8. Smart city
9. Financial / Banking
10. Healthcare
Artificial Intelligence
Edge Computer
WB-N211 User’s Manual
Title
WiBASE TRAVIS
User Manual
Document Version
Ver. 0.10
OS Version
Linux Ubuntu
16.04
BSP Version
0.8.5V & Above
Jetpack Version
3.2.1
L4T Version
R28.2.1
WB-N211 HW
version
A1 @ CRB
2
Table of Contents
1Preface ...............................................................................................................................................3
2Revision History..................................................................................................................................4
3Introduction .......................................................................................................................................5
4Product Overview...............................................................................................................................6
4.1 Product Outlook ..............................................................................................................................................6
4.2 Mechenical Overview ......................................................................................................................................6
4.2.1 Mechenical Dimentions...............................................................................................................................6
4.3 Product I/O Definition .....................................................................................................................................7
4.3.1 Front Side ....................................................................................................................................................7
4.3.2 Rear Side......................................................................................................................................................7
4.3.3 Right Side.....................................................................................................................................................8
4.4 Preparation......................................................................................................................................................9
4.5 Operation Instructions.....................................................................................................................................9
4.6 Product Mainance and Disposal......................................................................................................................9
4.7 Safety Information.........................................................................................................................................10
4.7.1 Avoid creation of dust...............................................................................................................................10
4.7.2 DO NOT Dissembly ....................................................................................................................................10
4.8 Product Specification.....................................................................................................................................11
5NVIDIA Jetson TX2 Software ............................................................................................................13
6Quick Start with WB-N211 Software................................................................................................13
7Accessories.......................................................................................................................................13
7.1 Accessory List.................................................................................................................................................13
3
1Preface
Copyright © 2018 WiBASE Industrial Solutions Inc. All Rights Reserved.
Our report is provided solely for the benefit of the users and should not be copied, quoted or referred to in
whole or in part without our prior written consent. WiBASE Industrial Solutions Inc. (WiBASE) will not be
liable to any other party to whom our report may be shown or who may acquire a copy of our report.
Products and corporate names mentioned in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used for identification purposes only. All trademarks are
the property of their respective owners.
Every effort has been made to ensure that the contents of this manual are correct and up to date. However,
the information in this document is subject to change without notice and should not be construed as a
commitment by WiBASE. WiBASE assumes no responsibility for any errors that may appear in this document.
4
2Revision History
Revision
Date
Changes
0.1
2019/8/01
Initial Release
5
3Introduction
We create an energy-efficient AI supercomputer, Jetson TX2, for such intelligent IoT devices in different
vertical industries, such as smart cities, law enforcement, mass transit, health care and even smart factories.
Industries drives large-scale industrial and societal change. As computing evolves, new companies form, new
products are built, our lives change. Looking back at the past couple of waves of computing, each was
underpinned by a revolutionary computing model, a new architecture that expanded both the capabilities
and reach of computing. By leveraging Jetson TX2 powerful platform, operating at less than 15 W of power
outperforms the CPU operating at nearly 200W. WiBASE offer an end-to-end AI computing platform —from
GPU to deep learning software and algorithms, from training systems to AI computers, from cloud to data
center to edge device –“WB-N211”. WiBASE & NVIDIA are striving to foster WB-N211 AI computing platform
helpful everywhere.
WB-N211 integrated NVIDIA Jetson TX2 module which provide 256 CUDA cores, high performance and
powerful user experience. System OS is based on Linux Ubuntu and integrated NVIDIA JetPack & Deep
Stream SDK, so user can base on this platform to develop their own applications with WB-N211, and create
Intelligent Video Analytics (IVA) in variety of user scenarios, even if real time object recognition also can be
implement with WB-N211.
To create a better feasibility for users on WB-N211, the User Manual contains all essential information for
users to make full use of this system. This manual includes a description of the system functions and
capabilities, contingencies and alternate modes of operation, and step-by-step procedures for system access
and use. Please kindly notice this manual is only for generic user scenarios, for special used case, please
kindly contact us for further consult.
6
4Product Overview
4.1 Product Outlook
4.2 Mechenical Overview
4.2.1 Mechenical Dimentions
7
4.3 Product I/O Definition
4.3.1 Front Side
4.3.2 Rear Side
Antenna ports
System ground
DC12V Power Input
Micro SD Socket
OTG port for SW update only
MIC
IN
LINE
OUT
8
4.3.3 Right Side
Removeable 2.5inch SATA HDD/SSD Tray
9
4.4 Preparation
•Read and follow all instructions in the documentation before you operate your system.
•Do not place this product on an unstable cart, stand, or table. The product may drop, or cause severe
damage.
•This system should be operated from the type of power indicated on the marking label. Please double
check the power supply voltage within product spec before connect WB-N211.
•Under Linux Ubundtu’s system limitation, please reserve at least 1GB to make sure WB-N211 could
power on successfully.
•Micro USB OTG connector is used for software updating only. Please DO NOT plug in OTG cable or
connect to any USB host during normal operation. This will cause other USB function being
disabled.
4.5 Operation Instructions
•Connect the power to WB-N211. Please follow pin define for power connect instruction.
•Connect the USB mouse/keyboard to WB-N211
•Press the POWER key to power on WB-N211.
•After that, you shall be able to have Ubuntu running on WB-N211.
4.6 Product Mainance and Disposal
•Unplug appliances when not in use to save energy and minimize the risk of shock and fire
•Storage and Disposal in dry locations. Dispose of as ordinary dry waste per local, state, and federal
regulations. However, may not be recyclable in certain areas due to availability of community recycling
programs.
10
4.7 Safety Information
WB-N211 is designed and tested to meet the latest standards of safety for information technology
equipment. However, to ensure your safety, it is important that you read the following safety instructions.
4.7.1 Avoid creation of dust.
•Fine dust dispersed in air in sufficient concentrations, and in the presence of an ignition source is a
potential dust explosion hazard.
•Avoid heat, flames, sparks, and other sources of ignition.
•Converting operations may form combustible dust concentrations in air.
•Minimize any dust accumulation from converting operations.
•Use good industrial hygiene and housekeeping practices to minimize any dust accumulation.
4.7.2 DO NOT Dissembly
•Please DO NOT dissemble the sample. WiBASE provide options of LTE, BT/WiFi and SSD cards, however,
these functions have to be assembled in WiBASE factory.
