Windster RA-1430C Bedienungsanleitung

Please read and save this guide through before using your range hood

Store the guide away in a safe place so that you will know where it is

when you want to refer to it

RA-1430C / RA-1490C

OPERATION

MANUAL

www.windsterhood.com

WALL HOODWALL HOOD

Table of contents

Important safety Instructions ----------------------------

Safety notes ------------------------------------------------------

Tools and materials required ----------------------------------

LED light replacement -------------------------------

Accessories -------------------------------------------------

Troubleshooting --------------------------------------------------

Maintenance and cleaning------------------------------------------

Maintenance Instruction ------------------------------

Use and care ------------------------------------------------

Parts layout diagram --------------------------------------------

Circuit diagram -----------------------------------------------

Specifications --------------------------------------------------------

Diagrams ------------------------------------------------

P. 1

P. 3

P. 6

P. 7

P. 8

P. 9

P. 1 0

P. 11

Due to sharp edge, please wear Safety Workman Gloves"

for installation, cleaning, light bulb changing and

dismantling to reduce the risk of any bodily injuries.

Safety Workman Gloves

WARNING

Read and Save These Instructions

Ducting method

A. This range hood must be flued to external air space either through the roof

(fig.2 ) or through the wall (fig.3)

Ducting through the roof Ducting through the wall

Fig. 2 Fig. 3

B. Obstruction of exhaust will cause

a. Uneven fan speed.

b. Could cause possible vibration.

Fig.1 : Optimum range hood height

CAUTION - To reduce the risk of fire and to properly exhaust air, be sure to duct

air outside. Do not vent exhaust air into spaces within walls, ceilings, attics,

crawl spaces or garages.

WARNING - To reduce the risk of fire or electric shock, do not use this fan with

any solid- state speed control device.

1. Make sure the power is off before installing, wiring or maintenance.

2. Please keep the range hood clean.

3. To get the best performance, the vertical clearance between the cook- top

and the range hood should range from 28” to 32”. (Fig.1)

A. IMPORTANT SAFETY INSTRUCTIONS

28”-32”

CAUTION - For general ventilating use only. Do not use to exhaust hazardous

or explosive materials and vapours.

WARNING - To reduce the risk of a range top grease fire:

A. Clean ventilating fans frequently. Grease should not be allowed to accumulate

on fan or filters.

B. Always turn hood on when cooking at high heat or when cooking flaming foods.

D. Don't leave your range unattended when cooking.

E. Use proper pan size. Always use cookware appropriate for the size of the

surface element.

Never leave surface units unattended at high settings.

Boilovers cause smoke and greasy spillovers, that may ignite and spread

if hood is used. Heat oils slowly on low or medium settings.

WARNING - To reduce the risk of fire, electric shock, or injury,

observe the following:

A. Use this unit only in the manner intended by the manufacturer. If you have

questions, contact the manufacturer.

B. Before servicing or cleaning the unit, switch the power for service panel and

lock panel, to prevent power from being switched on accidentally. When the

service is disconnecting, it cannot be locked, fasten a prominent warning

device, such as a tag, to the service panel.

C. Installation work and electrical wiring must be done by a qualified person(s) in

accordance with all applicable and standard codes, including fire-rated

construction.

D. Sufficient air is needed for proper combustion and exhausting of gases

through the flue(chimney) of fuel burning equipment to prevent back drafting.

Follow the heating equipment manufacturer's guideline and safety standards

such as those published by the National Fire Protection Association (NFPA),

the American Society for Heating, Refrigeration and Air Conditioning

Engineers(ASHRAE),and the local code authorities.

E. When cutting or drilling into wall or ceiling, do not damage electrical wiring

and other hidden utilities.

F. Ducted fans must always be vented to the outdoors.

1. You know you have a extinguisher, and you already know

how to operate it.

2. The fire is small and contained in the area where it started.

3. The fire department is being called.

4. You can fight the fire with your back against the exit.

USE AN EXTINGUISHER ONLY IF:

CLASS ABC

C. including wet dishcloths or towels- a violent steam

explosion will result.

DO NOT USE WATER

B. - You may be burned.NEVER PICK UP A FLAMING PAN

WARNING - To reduce the risk of fire, use only metal duct work.

1. All electrical work must be done in accordance with local and/or national

electrical code as applicable for safety. This product must be grounded, if you

are unfamiliar with methods of installing electrical wiring, secure the services

of a qualified electrician.

2. Turn off power at service entrance before installing, wiring, or servicing this

product. (120 volt for range hood. 220 volt for electric range if any)

3. Turn off power to avoid risk of fire, electric shock, or injury for cleaning or

maintenance such as lubrication.

4. Fireplaces, gas furnaces, water heaters, require proper flow of combustion

air and exhaust. Make sure this flow is not altered when using any exhaust fan.

5. Please read specification label on product for further information and

requirements.

6. Please wear "Safety Gloves" for installation, cleaning, light bulb changing and

dismantling to reduce the risk of any injuries.

WARNING- To reduce the risk of injury in the event of a range top grease fire,

observe the following:

A. with a close- fitting lid, cookie sheet, or metal tray,

then turn off the burner. Be careful to prevent burns. If the flames do not

go out immediately,

SMOTHER FLAMES

EVACUATE AND CALL THE FIRE DEPARTMENT.

B. SAFETY NOTES

: Exhaust air should not be discharged into any chimney or flue, which may carry

combustible products from other sources. In addition, exhaust air should not be

discharged into a wall cavity or into the roof space.

NOTE

SAFETY WARNING

Wiring to Power Supply

RISK OF ELECTRICAL SHOCK. THIS RANGE HOOD MUST BE PROPERLY

GROUNDED. MAKE SURE THIS IS DONE BY SPECIALIZED ELECTRICIAN

IN ACCORDANCE WITH ALL APPLICABLE NATIONAL AND LOCAL

ELECTRICAL CODES. BEFORE CONNECTING WIRES, SWITCH POWER

OFF AT SERVICE PANEL AND LOCK SERVICE PANEL TO PREVENT

POWER FROM BEING SWITCHED ON ACCIDENTALLY.

Connect the electrical wires.

- Connect three wires (black, white and green) to house wires and cap with wire

connectors. Connect according to color :

black to black, white to white, and green to green as shown on Figure A.

- If necessary to hide the electrical wire connections, push wires back into the

wiring box. Access the wire connections underneath the hood. Make sure

wires do not slip between motor or any moving parts to prevent any damage.

Wire Connector

Figure.A

C. Ensure the mounted range hood is level when installed for optimum performance.

(Fig.5)

B. To fit the duct to the top of the chimney, slide the bottom lip under the black mounting

and then lock in to place with the 4 screws provided. (Fig. 4)

Installation and Maintenance must be carried out by qualified person only

Body Mounting

Fit the range hood body at the correct height , via the brackets to the mounting

surface. (Refer Fig.4 for mounting screw measurements). Locate the hanging

screw allowing a distance of 0.2 inch of the screw head to the wall.

Chimney Ducting

A. Use the Upper Mounting Bracket to adjust the duct to the required height

(maximum 27-1/6”)

Fig. 5

Chimney duct

Flexible hose included

7- 4/5 "

1-17/25 "

7- 2/5 "

Adjust it

flexibly to

fit the cabinet.

Fig. 4

12-1/4 "

The two holes depend on cowling bracket

position for adjusting.

The chimney duct can be adjustable

for perfect fitment.

Note:

Before replacing LED light ensure the unit is switched off, when you want to

change the LED light, please always wear working gloves. (Fig.6)

◆One common screwdriver.

◆Plier (for opening electrical knockout).

◆Electrical wire and supplies to comply with local cords.

◆Electrical power drill.

C. TOOLS AND MATERIALS REQUIRED

D. REPLACEMENT LED LIGHT

1. Using suitable tool (small slotted screw driver) gently pry off the LED light set.

2. Taking off the wire connecter with LED light set.

3. Replace a new LED light set and reconnect the wire to the connector.

4. Before push back the original LED light position, test the LED light.

NOTE : For LED light replacement, you may not find the appropriate LED lights from

market, please contact with distributor(s)/dealer(s).

LED light: 1W

Model: HP-15A

LED driver:

Model: HP1500-36

input: 100~240vdc

output: 3.6vdc=1500maH

Fig. 6

OPERATION

MANUAL

RA-1430C

Pleasereadand save this guide through before using your range hood

Storetheguide away in a safe place so that you will know where it is

whenyouwant to refer to it

Item Part Description Spec. Q'ty

Manual 1

Spare Parts Contents

Round Collar 1

Item Part Description Spec. Q'ty

Spare Parts Contents

Screws

Screws Ø4x8

1/4"

Duct Cover-

Mounting Bracket

Plastic Screws

Ø4x32

Screws Package

6" 7"

E. ACCESSORIES

F. TROUBLESHOOTINGS

Correction

Symptom

Fan are not operatable.

Illuminating LED light

does not work

A. Check power source to see if it is normal.

A. Disconnect the power source.

Hood vibrates.

A. Check for damaged vanes.

B. Check power inlet plug to see if it is

plugged firmly into it's socket.

B. Check LED light, replace it with a new

one if it is burned out.

B. Check if exhaust duct is secured.

G. MAINTENANCE AND CLEANING

Regular maintenance and cleaning will ensure good performance and reliability,

while extending the working-life of the Range hood.

H. MAINTENANCE INSTRUCTION

A. Maintenance should be important than repair. Please take care of the needed

maintenance in order to secure and extend the excellent functions and using life.

: Before repairing the range hood. Disconnect the power source.

B. After using the machine, wipe the machine by neutral detergent in order to keep

it clean and maintain the appearance with brightness and sanitation.

NOTE

Range hood should be turn on either before or the same time when cooking

begins. After cooking, range hood should be kept on for about 3 more minutes

for complete ventilation of cooking odor.

Care Instruction:

Exterior: Can be clean with any type of non-abrasive detergent and a clean cloth.

"Green Pad" or any metal type cleaning pad is not recommended for exterior.

Note:

Please always pull the plug out before cleaning or dismantling, wear 'Safety gloves'

to reduce the risk of any injuries.

Note: Operate switches (Fig.7)

Switch 1 : LED Fan speed indicator.

Switch 2 : Speed switch (Three speed fan)

- - High speedLow speed

Switch 3 : Light switch

Switch 4 : Power switch and delay switch.

Push once : Delayed shut off.

Push twice : Immediate shut off.

Fig.7

I. USE AND CARE

①②③④

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Windster Dunstabzugshaube Handbücher

Windster

Windster RA35U30SS Bedienungsanleitung

Windster

Windster H Bedienungsanleitung

Windster

Windster WS-69TB42 Bedienungsanleitung

Windster

Windster WS-58 series Bedienungsanleitung

Windster

Windster N Montageanleitung

Windster

Windster WS-96TB30SS Bedienungsanleitung

Windster

Windster LINER WS-69TB36 Bedienungsanleitung

Windster

Windster LINER WS-69TB30 Bedienungsanleitung

Windster

Windster WS-62N Series Bedienungsanleitung

Windster

Windster RA-7630SS Bedienungsanleitung

Windster

Windster RA-7730SS Bedienungsanleitung

Windster

Windster WS-50E Series Bedienungsanleitung

Windster

Windster WSC-4630SS Bedienungsanleitung

Windster

Windster WS-5530SS Bedienungsanleitung

Windster

Windster WS-4830SS Bedienungsanleitung

Windster

Windster HI30SS Bedienungsanleitung

Windster

Windster RA-76 Series Bedienungsanleitung

Windster

Windster WS-96TB Bedienungsanleitung

Windster

Windster RA-280 Bedienungsanleitung

Windster

Windster WALL MOUNT Series Bedienungsanleitung

Windster

Windster RA-7630SS Bedienungsanleitung

Windster

Windster WS-63TB36SS ISLAND SERIES Bedienungsanleitung

Windster

Windster WS-38 Series Bedienungsanleitung

Windster

Windster RA-3030SS Bedienungsanleitung

Beliebte Dunstabzugshaube Handbücher anderer Marken

emmeti

emmeti RECUPA MED A-140 Leitfaden

Nibe

Nibe F135 Bedienungsanleitung

Kuppersberg

Kuppersberg INTRO 60 Montage- und Wartungsanleitung

Zephyr

Zephyr Spruce AK9834BS Installationsanleitung

Hisense

Hisense MH6INBG Bedienungsanleitung

Miele

Miele DA 1255 Bedienungsanleitung

Broan

Broan 46000 Bedienungsanleitung

GE Profile PV977 Originalbetriebsanleitung

FALMEC

FALMEC FFRIA24W5FS Bedienungsanleitung

Whirlpool

Whirlpool RH2600XL-1 SERIES Bedienungsanleitung

Küppersbusch

Küppersbusch DX ISLA Bedienungsanleitung

ETNA

ETNA AV360RVS Bedienungsanleitung

JUNO

JUNO JDF603E6 Bedienungsanleitung

Miele

Miele DA 6708 D Bedienungsanleitung

Tricity Bendix

Tricity Bendix LE 150 Handbuch

AEG

AEG X68163BV1 Bedienungsanleitung

AEG

AEG 125 D Bedienungsanleitung

Smeg

Smeg KSEV97X Bedienungsanleitung
