Winmate G-WIN AMD Rugged Series Bedienungsanleitung

G-WIN AMD Rugged

Series Panel PC

AMD Geode LX800 3.5” SBC, Ultra Low

Power, Fanless Design with CPU, TFT LCD

and 10/100/1000 base-T Ethernet.

User Guide Version 1.1

G-WIN AMD Rugged Series Panel PC User Guide

FCC Statement

This device complies with part 15 FCC rules. Operation is

subject to the following two conditions：



This device may not cause harmful interference.



This device must accept any interference received, including interference

that may cause undesired operation.

This equipment has been tested and founded comply with the limits for "a"

digital device class, pursuant to part 15 of the FCC rules. These limits are

designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment uses

and can radiate radio frequency energy, if not installed and used in accordance

with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct

the interference at him own expense. CAUTION: Changes or modifications not

expressly approved by the party responsible for compliance could void the

user’s authority to operate the equipment.

G-WIN AMD Rugged Series Panel PC User Guide

III

No part of this document may be reproduced, copied, translated, or transmitted

in any form or by any means, electronic or mechanical, for any purpose,

without the prior written permission of the original manufacturer.

Trademark Acknowledgement

Brand and product names are trademarks or registered trademarks of

their respective owners.

Disclaimer

We reserves the right to make any product changes without notice,

including circuits and/or software described or contained in this manual in

order to improve design and/or performance. Winmate Communication

assumes no responsibility or liability for the use of the described product(s),

conveys no license or title under any patent, copyright, or masks work rights

to these products, and makes no representations or warranties that these

products are free from patent, copyright, or mask work right infringement,

unless otherwise specified. Applications that are described in this manual are

for illustration purposes only. Winmate Communication Inc. makes no

representation or warranty that such application will be suitable for the

specified use without further testing or modification.

Warranty

We warrant that each of its products will be free from material and

workmanship defects for a period of one year from the invoice date. If the

customer discovers a defect, Winmate will, at its option, repair or replace the

defective product at no charge to the customer, provided it is returned during

the warranty period of one year, with transportation charges prepaid. The

returned product must be properly packaged in its original packaging to obtain

warranty service.

If the serial number and the product shipping data differ by over 30 days,

the in-warranty service will be made according to the shipping date. In the

serial numbers the third and fourth two digits give the year of manufacture, and

the fifth digit means the month (e. g., with A for October, B for November and C

for December).

For example, the serial number 1W08Axxxxxxxx means October of year

2008.

G-WIN AMD Rugged Series Panel PC User Guide

Check List

Before using this Panel PC, please make sure that all the items listed

below are present in your package

1 x G-WIN AMD Series Rugged Panel PC

1 x G-WIN AMD Series Rugged Panel PC User Guide

1 x A831 SBC User Manual

1 x Power adapter

1 x Power cord

1 x Power wire (Optional w/ terminal block)

1 x Y cable for Keyboard and Mouse

1 x CD-ROM disc with Driver Utility and User’s Manual

1 x Touch Driver CD (Optional)

1 x WLAN Antenna (Optional)

Mounting Bracket & kits (Optional)

Make sure that all of the items listed above are present. Do not attempt to

apply power to the system if there is damage to any of its components.

Customer Service

We provide service guide for any problem as follow steps：First, visit the

website at http://www.winmate.com to find the update information about the

product. Second, contact with your distributor, sales representative, or our

customer service center for technical support if you need additional assistance.

You may have the following information ready before you call：

Product serial number

Peripheral attachments

Software (OS, version, application software, etc.)

Description of complete problem

The exact wording of any error messages

In addition, free technical support is available from our engineers every

business day. We are always ready to give advice on application requirements

or specific information on the installation and operation of any of our products.

Please do not hesitate to call or e-mail us.

Notice

1. Do not touch the LCD panel surface with sharp or hard objects.

2. Do not use abrasive cleaners, waxes or solvents for cleaning, use only a dry

or damp, soft cloth.

3. Use only with a high quality, safety-approved, AC/DC power adapter.

G-WIN AMD Rugged Series Panel PC User Guide

Safety Precautions

Warning!

Always completely disconnect the power cord from

your chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge

before touching the CPU card. Modern electronic devices

are very sensitive to static electric charges. As a safety

precaution, use a grounding wrist strap at all times. Place all

electronic components in a static-dissipative surface or

static-shielded bag when they are not in the chassis.

G-WIN AMD Rugged Series Panel PC User Guide

Safety and Warranty

1. Please read these safety instructions carefully.

2. Please keep this user’s manual for later reference.

3. Please disconnect this equipment from any AC outlet before cleaning. Do

not use liquid or spray detergents for cleaning. Use a damp cloth.

4. For pluggable equipment, the power outlet must be installed near the

equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or

letting it fall could cause damage.

7. The openings on the enclosure are for air convection. Protect the

equipment from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting

the equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place

anything over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power

source to avoid damage by transient over-voltage.

12. Never pour any liquid into an opening. This could cause fire or electrical

shock.

13. Never open the equipment. For safety reasons, only qualified service

personnel should open the equipment.

14. If any of the following situations arises, get the equipment checked by

service personnel:

A. The power cord or plug is damaged.

B. Liquid has penetrated into the equipment.

C. The equipment has been exposed to moisture.

D. The equipment does not work well, or you cannot get it to work

according to the user’s manual.

E. The equipment has been dropped and damaged.

F. The equipment has obvious signs of breakage.

15. Do not leave this equipment in an uncontrolled environment where the

storage temperature is below -20°C (-4°F) or above 60°C (140°F). It may

damage the equipment.

G-WIN AMD Rugged Series Panel PC User Guide

VII

Revision History

Version Date Note Author

1.0 2008.01.25 First Version Martin Chen

1.1 2008.07.15 Second Version Sarah Su

Contents

CHAPTER 1 GENERAL INFORMATION ....................................................1

1-1 Introduction .................................................................................................... 1

1-2 G-WIN RUGGED Series Panel PC System Mother-Board Specifications .2

1-3 Panel PC Selection Guide ............................................................................. 3

CHAPTER 2 GETTING STARTED ..............................................................4

2-1 Input / Output Devices ................................................................................... 4

2-1-1 8.4-Inch Input / Output Devices................................................4

2-1-2 10.4-Inch Input / Output Devices..............................................5

2-2 Starting the Panel PC& O/S Installation ....................................................... 6

2-3 Driver Installation........................................................................................... 6

CHAPTER 3 TOUCH DRIVER INSTALLATION..........................................7

3-1 Introduction .................................................................................................... 7

3-2 The ELO AccuTouch/ CarrollTouch infrared Driver Installation ................ 8

3-2-1 Configuration Utility ..................................................................9

3-3 The Premier Touch Driver Installation ....................................................... 11

3-3-1 Install Touch-Kit ...................................................................... 11

3-3-2 Configuration Utility .................................錯誤

錯誤錯誤

錯誤! 尚未定義書籤

尚未定義書籤尚未定義書籤

尚未定義書籤。

。。

。

CHAPTER 4 G-WIN RUGGED SERIES PANEL PC MOUNTING GUIDE 14

4-1 Vehicle Mounting.......................................................................................... 15

4-2 VESA Mounting ............................................................................................ 17

KNOWN ISSUES .......................................................................................18

NOTICES ...................................................................................................19

G-WIN AMD Rugged Series Panel PC User Guide

Chapter 1 GENERAL INFORMATION

1-1 Introduction

G-WIN AMD® Rugged Panel PCs with fanless, low power platform

design, sunlight readable panel, WLAN integration, great ability for

anti-shock & vibration, IP65 protection and anti-corrosion coating with

aluminum alloy housing. Both of great mobility and robust design are

fitting the demands for every harsh environment applications such as

logistics, transportation/ fleet management, heavy vehicles, utility and

also outdoor usage.

G-WIN AMD Rugged Series Panel PC User Guide

1-2 G-WIN RUGGED Series Panel PC System Mother-Board

Specifications

Form Factor 3.5”

CPU AMD Geode LX 800 500MHz

Chipset AMD CS5536 Companion Device

Memory One 200-pin SODIMM socket supports up to 1GB DDR 400

SDRAM

BIOS Award 4Mbit

VGA Controller On-board VGA/LCD Controller

VGA Memory Shared memory max.64MB

LCD Support TTL and Available to support LVDS interface LCD

Ethernet Realtek RTL8100CL-LF Chipset, 10/100 Mbps

Optional Dual Realtek 8110cs, Giga bit Ethernet

Audio Realtek ALC203 AC97 Chipset + AC97 codec

SATA Build-in SATA connector, supports 2 SATA1.0 ports

Serial 4x RS-232 (4 x pin-header)

USB 4 x USB (2 x Rear I/O, 2 x pin-header)

KB / Mouse

Connector

Mini-DIN PS/2 interface

Expansion Slots 1 x Mini PCI (Optional), 1 x CF Type I/II socket

Power Adapter DC IN 12V or 24V (Optional)

Storage 8.4” PPC 10.4” PPC

（Default）4G Compact Flash Card 2.5” 40G HDD

（Optional）Industrial Compact Flash Card

2.5” Flash Disk(SSD)

Compact Flash Card

Industrial Compact Flash Card

O/S(Optional) Windows XP Embedded / Windows XP Professional Embedded/

WinCE5.0 / Linux 2.6.11

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Winmate Touchscreen Handbücher

Winmate

Winmate R19IK3S-SPM169 Bedienungsanleitung

Winmate

Winmate M-Series Bedienungsanleitung

Winmate

Winmate W10IH3S-GCH1(HB) Bedienungsanleitung

Winmate

Winmate R15FA3S-PCC3-PoE Bedienungsanleitung

Winmate

Winmate W24IB3S-SPA269 Bedienungsanleitung

Winmate

Winmate R17IK3S-SPM1 Bedienungsanleitung

Winmate

Winmate W07IB3S-POT1 Bedienungsanleitung

Winmate

Winmate R05FA3S-OFD1HMHB Bedienungsanleitung

Winmate

Winmate P-CAP SERIES Bedienungsanleitung

Winmate

Winmate W07IB3S-PCM1AC Bedienungsanleitung

Winmate

Winmate R15IK3S-POC3 Bedienungsanleitung

Winmate

Winmate W10IE3S-MRH2FP Bedienungsanleitung

Winmate

Winmate M185D Bedienungsanleitung

Winmate

Winmate W10IB3S-GSH1 Bedienungsanleitung

Winmate

Winmate W07RK3S-PCO1-POE Bedienungsanleitung

Winmate

Winmate W10IB3S-GSH1HB Bedienungsanleitung

Winmate

Winmate R15IB7T-POC3 Bedienungsanleitung

Winmate

Winmate W22IK3S-SPA369 Bedienungsanleitung

Winmate

Winmate GC Series Bedienungsanleitung

Winmate

Winmate R17IK7T-POM1 Bedienungsanleitung

Winmate

Winmate R15IK3S-67C3(HB) Bedienungsanleitung

Winmate

Winmate R15IW3S-SPC3 Bedienungsanleitung

Winmate

Winmate R15IH3S-67A3HB Bedienungsanleitung

Winmate

Winmate 7'' S-Series Bedienungsanleitung

Beliebte Touchscreen Handbücher anderer Marken

FlowLine

FlowLine Data loop Bedienungsanleitung

ALPEX

ALPEX AEx-8 P Series Bedienungsanleitung

Ltech

Ltech E5S Bedienungsanleitung

Harman

Harman AMX MODERO S MSD-701-L2 Bedienungsanleitung

Acnodes

Acnodes PC 1150 Bedienungsanleitung

AIS

AIS IP10IA99 series Bedienungsanleitung

IBASE Technology

IBASE Technology ASTUT-152-RE1S Bedienungsanleitung

YASKAWA

YASKAWA TP 610C Bedienungsanleitung

B&R

B&R Power Panel C Series Bedienungsanleitung

Beijer Electronics

Beijer Electronics X2 control Bedienungsanleitung

AXIOMTEK

AXIOMTEK GOT321W-521 Bedienungsanleitung

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Bedienungsanleitung

Qomo

Qomo QIT1386 Bedienungsanleitung

DFI

DFI KS104-CD Bedienungsanleitung

AMX

AMX AXP-PPC Leitfaden

Sartorius

Sartorius X3 PR 5410 Bedienungsanleitung

AMX

AMX Modero X Series Bedienungsanleitung

Advantech

Advantech TPC-30 Series Bedienungsanleitung
