Wisenet SDC-79446BF Bedienungsanleitung

SDC-79446BF

2M AHD Analog Bullet Camera

Quick Guide

Trademark

Each of trademarks herein is registered. The name of this product and other

trademarks mentioned in this manual are the registered trademark of their

respective company.

Restriction

reproduced, distributed or changed, partially or wholly, without formal authorization.

Disclaimer

Hanwha Techwin makes the best to verify the integrity and correctness of the contents in this

document, but no formal guarantee shall be provided. Use of this document and the subsequent results

shall be entirely on the user’s own responsibility. Hanwha Techwin reserves the right to change the

contents of this document without prior notice.

Design and specications are subject to change without prior notice.

2_ overview

overview

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean the contaminated area on the product surface with a soft, dry cloth or a damp cloth.

(Do not use a detergent or cosmetic products that contain alcohol, solvents or surfactants or oil constituents

as they may deform or cause damage to the product.)

7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and

the point where they exit from the apparatus.

11. Only use attachments/ accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,

or sold with the apparatus. When a cart is used, use caution when moving the cart/

apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lighting storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus

has been exposed to rain or moisture, does not operate normally, or has been dropped.

overview

English _3

● OVERVIEW

SAFETY PRECAUTIONS

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates that dangerous voltage consisting a risk of electric shock is present within

this unit.

This exclamation point symbol is intended to alert the user to the presence of important operating

and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING

• To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

• To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation

instructions.

WARNING

1. Be sure to use only the standard adapter that is specified in the specification sheet.

Using any other adapter could cause fire, electrical shock, or damage to the product.

2. Incorrectly connecting the power supply or replacing battery may cause explosion, fire, electric shock, or

damage to the product.

3. Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause abnormal heat

generation or fire.

4. Securely plug the power cord into the power receptacle. Insecure connection may cause fire.

5. When installing the camera, fasten it securely and firmly. The fall of camera may cause personal injury.

6. Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or containers filled with water

on top of the camera. Doing so may cause personal injury due to fire, electric shock, or falling objects.

7. Do not install the unit in humid, dusty, or sooty locations. Doing so may cause fire or electric shock.

8. If any unusual smells or smoke come from the unit, stop using the product. In such case, immediately

disconnect the power source and contact the service center. Continued use in such a condition may cause

fire or electric shock.

9. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this

product in any way. (Hanwha Techwin is not liable for problems caused by unauthorized modifications or

attempted repair.)

10. When cleaning, do not spray water directly onto parts of the product. Doing so may cause fire or electric

shock.

4_ overview

overview

CAUTION

1. Do not drop objects on the product or apply strong shock to it. Keep away from a location subject to

excessive vibration or magnetic interference.

2. Do not install in a location subject to high temperature, low temperature, or high humidity. Doing so may

cause fire or electric shock.

3. If you want to relocate the already installed product, be sure to turn off the power and then move or reinstall

it.

4. Remove the power plug from the outlet when then there is a lightning. Neglecting to do so may cause fire or

damage to the product.

5. Keep out of direct sunlight and heat radiation sources. It may cause fire.

6. Install it in a place with good ventilation.

7. Avoid aiming the camera directly towards extremely bright objects such as sun, as this may damage the

CMOS image sensor.

8. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases,

shall be placed on the apparatus.

9. The Mains plug is used as a disconnect device and shall stay readily operable at any time.

10. Do not expose the camera to radioactivity. Radioactivity exposure may damage the CMOS.

Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as

vases, shall be placed on the apparatus

English _5

● OVERVIEW

CONTENTS

OVERVIEW

2Important Safety Instructions

3Safety Precautions

5Contents

INSTALLATION

6Part Names and Functions

6Precautions

6Installing the camera

7Protection of Cable from Water

7Connecting the DVR

APPENDIX

8Product Specification

9Product Overview

10 Troubleshooting

6_ installation

installation

PRECAUTIONS

Ensure you read out the following instructions before installing the camera:

•Select an area (ceiling or wall) that can withstand 5 times the camera weight

•Stuck-in or peeled-off cables can cause damage to the product or a fire.

•For safety purposes, keep anyone else away from the installation site.

And put aside personal belongings from the site, just in case.

INSTALLING THE CAMERA

The camera can be installed on the wall, ceiling, shelf or a desired position using the provided mounting bracket.

1. Choose an installation site that can

sufficiently support the weight of the

camera to be installed.

2. Adhere the installation template onto the

ceiling and use it as installation locating

tool.

3. Attach the camera mount to the wall using

the supplied screws.

4. Adjust the direction of the camera to the desired direction, and tighten the bracket.

CAMERA FRONT

PART NAMES AND FUNCTIONS

Name Description

aLens 3.6mm focal length enables you to monitor at a wider field of view

bIllumination Sensor Detects incoming light to control the IR LED.

cPower Cable Use to power the camera.

dBNC Cable BNC terminal for video signal output.

English _7

●INSTALLATION

5. Adjust camera angle as needed.

6. Connect the camera cable to the camera.

Take caution when installing the camera

outdoors because the cable connectors

may be wet with moisture or pile up with

impurities.

Although the camera is IP66 rated, direct

exposure to water or moisture may cause

problem such as condensation.

PROTECTION OF CABLE FROM WATER

If this product is mounted outdoor, water leakage may occur at gap between cables. As shown below, butyl rubber

(available on the market) shall be used to protect from water.

1. Connect power supply and BNC power source.

2. Cover black sheath of the cable (Zone A), and ensure half of

butyl rubber can cover the cable joint.

J `Poor water protection at the cable sheath may cause water

leakage. Make sure to wrap tightly.

`The water-proof butyl rubber is made of rubber that expands to

twice the original length.

`If you do not use cable joint, it must be covered with water-proof tape.

CONNECTING THE DVR

Connect the BNC connector of the camera to the enclosed 60ft camera cable, and then connect the BNC

connector of the camera cable to the BNC Video Input port of the DVR.

12V

CAUTION

RISKOFELECTRI SHOCK

DONOTOPEN

CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK

DO NOT OPEN COVERS. NO USER SERVICEABLE

PARTS INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

WARNING:TO PREVENT FIRE OR SHOCK HAZARD. DO NOT

EXPOSEUNITS NOT SPECIFICALLYDESIGNED

FOROUTDOOR USE TO RAIN OR MOISTURE.

VIDEO INPUT

VGA

HDMI

LAN

8_ appendix

appendix

PRODUCT SPECIFICATION

Item Details

Video

Imaging Device 2 Megapixel, 1/2.9” CMOS

Total Pixels 1920(H) x 1080(V)

Effective Pixels 1920(H) x 1080(V)

Scanning System Progressive Scan

Min. Illumination 0 Lux (IR LED ON)

Video Output AHD

Resolution 1080p

Max, Framerate 30fps@1080p(NTSC), 25fps@1080p(PAL)

Focal Length (Zoom Ratio) 3.6mm fixed

Max. Aperture Ratio F2.4

Angular Field of View D:103°

Min. Object Distance 0.2m

Lens Type Fixed Lens

Operational

IR Viewable length 25m

Day & Night Auto

Digital Noise Reduction 2DNR

Gain Control Auto

White Balance ATW

Electronic Shutter Speed 1/25sec~ 1/50,000sec

Video Transmission Distance Basic cable x 1pc + SEA-C104 x 2pcs

Environmental

Operating Temperature / Humidity -30°C ~ +50°C (-22°F ~ +122°F) / Less than 90% RH

Ingress Protection IP66

Electrical

Input Voltage/Current 12V DC

Power Consumption IR ON : 3W, IR OFF : 0.6W

Mechanical

Color / Material White / Plastic

Dimension Ø71.1 mm (2.79") x 131.6 mm (5.18")

Weight 170g

English _9

●APPENDIX

PRODUCT OVERVIEW

unit : mm [inch]

Ø68 mm [2.67"]

64.1mm [2.52"]

131.6 mm [5.18"]

Ø71.1 mm [2.79"]

10_ appendix

appendix

TROUBLESHOOTING

Please refer to the following table if you have problems during camera operation.

Please contact with the authorized technicians if your problem cannot be solved through the guidance.

Problem Troubleshooting

There is no content displayed on

the screen.

yCheck whether the power cable and the cable between camera and

monitor are connected correctly.

yCheck whether BNC cable is connected to the camera correctly.

yCheck if video system is the same as of DVR.

The image on the screen is dim.

yWhether the lens is stained with dust. Clean the lens with soft and

clean cloth.

ySet suitable condition for the monitor or DVR.

yIf the camera is pointed to the strong light, please change the position

of camera.

The image on the screen is dark.

yAdjust the contrast ratio of monitor or DVR.

yIf there is intermediate equipment, please set 75Ω/Hi-z correctly.

The camera fails to work normally and the surface is

hot.

yPlease check whether the camera is connected to suitable power

supply correctly.

The color is incorrect.

yPlease check the setting of white balance setting menu.

The screen flickers constantly.

yPlease ensure that the camera is not pointed to the sun.

When the coaxial communication is not available

yPlease ensure that the camera and monitor are installed in the

recommended distance.

yIf they exceed the recommended installation distance, please use

coaxial and equivalent video amplifier.

Inhaltsverzeichnis

Andere Wisenet Sicherheitskamera Handbücher

Wisenet

Wisenet HCD-7010RA Bedienungsanleitung

Wisenet

Wisenet TNU-6320 Bedienungsanleitung

Wisenet

Wisenet XNP-9300RW Bedienungsanleitung

Wisenet

Wisenet PNO-A9081R Bedienungsanleitung

Wisenet

Wisenet PNM-9321VQP Bedienungsanleitung

Wisenet

Wisenet TNF-9010 Bedienungsanleitung

Wisenet

Wisenet SND-5084R Bedienungsanleitung

Wisenet

Wisenet PNM-9085RQZ PNM-9084RQZ1 Bedienungsanleitung

Wisenet

Wisenet TNO-3010T Bedienungsanleitung

Wisenet

Wisenet HCV-7010R Bedienungsanleitung

Wisenet

Wisenet XNV-C8083R Bedienungsanleitung

Wisenet

Wisenet QND-7012R Bedienungsanleitung

Wisenet

Wisenet XNZ-6320 Bedienungsanleitung

Wisenet

Wisenet TNV-7011RC Bedienungsanleitung

Wisenet

Wisenet ANV-L6023R Bedienungsanleitung

Wisenet

Wisenet SLA-T4680D Bedienungsanleitung

Wisenet

Wisenet XNV-8082R Bedienungsanleitung

Wisenet

Wisenet PNM-9320VQP Bedienungsanleitung

Wisenet

Wisenet SNV-6013 Bedienungsanleitung

Wisenet

Wisenet XNV-6083Z Referenzhandbuch

Wisenet

Wisenet QND-6070R Bedienungsanleitung

Wisenet

Wisenet PNM-C12083RVD Bedienungsanleitung

Wisenet

Wisenet TNO-P9072EPT1-Z Bedienungsanleitung

Wisenet

Wisenet XNZ-L6320 Bedienungsanleitung

Beliebte Sicherheitskamera Handbücher anderer Marken

Okina USA

Okina USA SIR36-870VF650LP Bedienungsanleitung

Divio

Divio NDR155PA Bedienungsanleitung

Canon

Canon VB-C500D Bedienungsanleitung

Easy Access

Easy Access EasyGuard Bedienungsanleitung

Vivotek

Vivotek FD9389-EHV-v2 Bedienungsanleitung

TUYA

TUYA COSMO W2 Bedienungsanleitung

Eusso

Eusso UNC7500-IR Einrichtungshandbuch

urmet domus

urmet domus 1096/204 Bedienungsanleitung

VC VC20 series Bedienungsanleitung

Axis

Axis Q1614 Bedienungsanleitung

ieGeek

ieGeek DD201 Bedienungsanleitung

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Bedienungsanleitung

Vicon

Vicon V662-D-1 Betriebsanleitung

Grundig

Grundig GCH-K0274P Bedienungsanleitung

Lorex

Lorex VANTAGE LBC7032 Bedienungsanleitung

4xem

4xem WPT Bedienungsanleitung

Samsung

Samsung SCV-3082 Bedienungsanleitung

Vitek

Vitek VTC-C544 Bedienungsanleitung
