Wolf Garten Loopo S150 Bedienungsanleitung

www.WOLF-Garten.com

Industriestraße 23 • 66129 Saarbrücken • Germany

Fon/Phone +49 6805 79-202 • Fax +49 6805 79-442

www.WOLF-Garten.com • [email protected]

DOC9043W_EN

Loopo S150 / S300

Your safety is important to us -

Please review this Manual carefully for all safety warnings and

take extra caution to keep both children and pets off the lawn

when Robotic Mower is in operation.

Safety rst..................... 2

Installation................... 13

Quick reference.............. 33

2 3

Safety rst

IMPORTANT!

READ CAREFULLY BEFORE USE

KEEP FOR FUTURE REFERENCE

Warning decal denitions

Safety warnings & precautions

Safety features

Do not allow children to use or operate the mower.

Children must be supervised at all times.

Warning

decal denitions

2 3

This symbol indicates that the mains electricity is double

insulated.

This symbol indicates that the product is designed for

indoor use only.

1 2 3 4 5 6 7

1. This is a dangerous power tool. Exercise care when operating

and follow all safety instructions and warnings.

2. Read the Safety Manual carefully before operating your mower.

3. Be careful of thrown objects during operation.

4. Keep a safe distance from the mower while it is operating.

Keep people, especially children, pets and bystanders away

from the area where the mower is operating.

5. CAUTION - Do not touch rotating blade. Keep hands and feet

away and do not lift the mower from the ground.

6. Remove the disabling device before working on or lifting the

mower (see Section 3.b).

7. Do not ride the mower.

Donotdisposeofthemoweroranyofitspartsasunsorted

municipal waste. It should be collected separately.

This product conforms to applicable EU directives.

4 5

A. Before you begin

1. Read this Safety Manual carefully before operating

the mower to become familiar with its controls and

proper use.

2. Never allow children, persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge or people unfamiliar with these

instructions to use the machine. Local regulations

may restrict the age of the operator.

3. You are responsible for accidents or for harm to

other people or their property.

4. It is your responsibility to inform your neighbors

about the risks, and that it is forbidden to enter your

lawn while the mower is operating.

5. If your lawn is open to the street and/or your

neighbors, you must be present during the mower’s

operation to prevent others from accessing your

lawn. Alternatively, you must protect / fence your

lawn so that others will not be able to access the

mower during operation.

B. Preparations

1. Ensure the correct installation of the Perimeter

Wire, as instructed.

2. Inspect periodically the area where the mower is

used and remove all stones, sticks, cones, wires

and other foreign objects.

3. Periodically visually inspect to verify that the blade is

not worn or damaged. Replace a worn or damaged

blade (Part No. MRK9100A/MRK9100W). Switch the

mower off when inspecting or replacing the blade.

Safety warnings &

precautions

4 5

C. Operation

IMPORTANT SAFETY WARNING!

Do not leave the mower to operate unattended if

you know that there are pets, children or people

in the vicinity. Never mow while people (especially

children) or pets are nearby.

1. Do not operate the mower if any safety feature or any part is

damaged, worn or inoperable.

2. Keep hands and feet away from the cutting blade and other

moving parts.

3. Always switch the mower off before lifting it or planning to

operate any adjustments.

4. Never pick up or carry the mower while the motors are running.

5. Do not touch the blade before it has completely stopped rotating.

6. Do not use the mower for any purpose other than cutting lawn.

7. Keep all guards, shields, safety devices, and sensors in place.

Repair or replace damaged parts, including decals.

8. Set the weekly program at times when there are no people on

the grass.

9. Do not connect a damaged power cord to the supply, or touch

a damaged cord before it is disconnected from the supply as it

can lead to contact with live parts.

10. Keep the extension power cord away from the blade to prevent

the mower from damaging it. A damaged power cord can lead

to contact with live parts.

11. If the power cord becomes damaged or entangled during use,

detach it from the mains by pulling the plug from the socket.

12. In the event of accident or breakdown whilst the mower is

operating, immediately press the red STOP button.

6 7

IMPORTANT! It is recommended to keep the original

packaging for shipping purposes.

D. Transportation

Within the working area:

1. Press the STOP button to

stop the mower.

2. Switch the mower off,

and carry it by its carrying

handle as shown in the

picture to the right.

Over long distances:

When transporting your

mower over long distances,

make sure it is switched off.

6 7

E. Using the remote control (manual mowing)

1. Mow only in daylight or in good artiﬁcial light, and avoid

operating on wet grass.

2. Do not operate the mower barefoot or wearing open

sandals. Always wear substantial footwear and long

trousers; always make sure of your footing on slopes.

3. Use extreme caution when reversing the direction of the

mower towards you.

4. Always switch on the motor according to the instructions

while standing away from the blade.

5. Do not mow manually in slopes greater than 15 degrees

or where a ﬁrm footing is not possible.

F. Batteries

1. Do not open or damage the battery pack.

2. The Battery Pack contains electrolytes. In case of an

electrolyte leakage from the Battery Pack, the following

actions should be taken:

• Skin contact: Wash the contact areas off immediately

with water and soap.

• Eye contact: Flush the eyes with plenty of clean water

for at least 15 minutes immediately, without rubbing.

• Get medical assistance.

3. Ensure that the battery is charged using the correct

charger recommended by the manufacturer. Incorrect

use may result in electric shock, overheating or leakage of

corrosive liquid from the battery.

8 9

G. Maintenance and special instructions

1. Always switch the mower off and remove the

Disabling Device before clearing blockage/

checking/cleaning/working on it, or after striking a

foreign object to inspect the machine for damage.

Never attempt to service or adjust the mower while

it is in operation.

2. In case of abnormal vibrations, stop the mower,

switch it off and check for any damage of the

blade. Replace a worn or damaged blade (Part No.

MRK9100A/MRK9100W) to preserve balance. If the

vibration continues, call for service.

3. Use heavy gloves when inspecting or servicing the blade.

4. Do not perform maintenance barefoot or wearing

open sandals. Always wear suitable work shoes

and long trousers.

5. Replace worn or damaged parts for your safety.

6. Use only original equipment and accessories. It is

not permitted to modify the original design of the

mower. All modiﬁcations are made at your own risk.

7. Ensure that only replacement cutting means of the

right type(PartNo.MRK9100A/MRK9100W)areused.

8. Maintenance/servicing/cleaning of the mower

shouldbeaccordingtomanufacturer’sinstructions.

9. Keep all nuts, bolts and screws tight to be sure the

machine is in safe working condition.

WARNING!

When there is a risk of a lightning storm, disconnect

the Perimeter Wire from the Base Station and the

Power Supply 230 V/120 V plug from the power outlet.
