WOOSIM PORTI-PC40 Bedienungsanleitung

http://www.woosim.com

MODEL PORTI-PC40

WOOSIM SYSTEMS Inc.

#501, Daerung Technotown 3th,

448, Gasan-Dong, GeumChun-Ku,

Seoul, Korea

Tel : +82-2-2107-3700

Fax : +82-2-2107-3707

URL: http://www.woosim.com

(Desk Top Printer)

Rev. 2.0

All specifications are subjected to change without notice

Porti-PC40 Rev. 2.0

http://www.woosim.com 2

Porti-PC40 Desk Top printer operator’s manual.

The information contained in this manual is the property of Woosim

System Inc. and may not be reproduced in whole or in part without

the prior written permission of Woosim System Inc.

Trademark

a registered trademark of Woosim Systems Inc.

All other trademark are the properties of their respective companies.

Caution

Some semiconductor devices are easily damaged by static electricity. You should

turn the printer “OFF”, before you connect or removed the cable on the rear side, in

order to guard the printer against the static electricity.

If the printer is damaged by the static electricity, you should turn the printer “OFF”

Notice

The contents of this manual are subject to change without notice.

Porti-PC40 Rev. 2.0

http://www.woosim.com 3

Introduction

The Porti-PC40 is the ideal solution for Mobile banking system , Retail,

point of sales, Credit card Transaction, other traveling and mobile computing etc.

The general features of Porti-PC40 printer are as follows:

uPocket size(105 x 80.4 x 45.7mm)

uLight weight(286g) for true mobility.

uVery silent printing thru direct thermal printing method.

uHigh speed(50mm/sec, MAX)

uHigh resolution(203dpi : 8dots/mm).

uUART(RS-232C or TTL) interface

uSupport text and graphic printing.

uMagnetic Stripe Reader included.

uEasier paper loading by CLAMSHELL design.

uEasier maintenance with self-diagnostics

uIn field programming – Update Firmware, Download Fonts and Logos

uFlow control : Software (XON/XOFF)

※Hardware flow control not supported in printer.

uAgency Approvals

Porti-PC40 Rev. 2.0

http://www.woosim.com 4

Operating Precautions

Please follow the precautions below to enjoy and maintain the full

performance of the printer.

Using the Printer

● Be careful not to drop or bump the printer on a hard surface.

● Do not install the printer in direct sunlight or such areas.

Suitable environment for the use of the printer is as follows:

◆Operating temperature :-10°C to 50°C

◆Relative humidity : 10% to 90% (No condensation)

● Do not install the printer near devices that generate strong

electromagnetic fields such as a copy machine.

● Do not open the platen cover during printing .

● Do not remove or reinstall the communication cable during printing

or transmission.

● Do not touch the connectors of the communication during printing.

● Switch the POWER OFF when not in use.

● Do not use alcohol or other solvent.

●The AC adapter, the battery charger and the battery pack may

become warm when in use. This is normal and is not a malfunction.

● When the battery pack is used at low temperature, the length of time

the printer can be used may be shortened.

uThermal Paper Handling

● Store the thermal paper in a cool, dry and dark place.

● Do not rub the paper with hard object.

● Do not leave the paper with hard object.

● Do not allow plastic film, erasers, or adhesive tape to touch the paper

for long periods.

● Do not stack the thermal paper with diazo copies immediately

after copying or wet-type copies.

● Do not use chemical glue.

●Always use the clean thermal paper.

Porti-PC40 Rev. 2.0

http://www.woosim.com 5

Note

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference

in a residential installation.

These equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation.

If this equipment does cause harmful interference to radio or television reception ,

which can be determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

--Reorient or relocate the receiving antenna.

--Increase the separation between the equipment and receiver.

--Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

--Consult the dealer or an experienced radio/TV technician for help.

Porti-PC40 Rev. 2.0

http://www.woosim.com 6

CONTENTS

1. Outline .............................................................................................................................................7

1.1. Model classifications ............................................................................................................7

1.2. Product Part Number System................................................................................................7

1.3. Specifications........................................................................................................................8

2. Setting up the printer .......................................................................................................................9

2.1. Printer & Accessories............................................................................................................9

2.2. Printer Features...................................................................................................................10

2.3. Dimensions .........................................................................................................................11

2.4. Replacing the paper roll......................................................................................................12

2.5. Power supply ......................................................................................................................13

3. Interface.........................................................................................................................................14

4. Using the printer ............................................................................................................................16

4.1. Control panel ......................................................................................................................16

4.2. The self test.........................................................................................................................16

5. Consumable Parts ..........................................................................................................................17

5.1. Recommended paper...........................................................................................................17

5.2. Printing position..................................................................................................................18

Porti-PC40 Rev. 2.0

http://www.woosim.com 7

1. Outline

PORTI–PC40

( ) ( )

Model name

Interface

None: UART

Power

None : DC 12~24V

Model name / Interface Spec.

Example) 1. Porti-S40 Serial/Bluetooth Part No. ⇒S40/A1

2. Porti-SC30 Bluetooth Only Part No. ⇒SC30/Z1

S40

SC30

W25

Wired Wireless

A RS-232C 1 Bluetooth

B TTL 2 IrDA

C USB 0 None

D RS-482

E Parallel

Z None

Porti-PC40 Rev. 2.0

http://www.woosim.com 8

Item Description

Printing method Direct thermal line printing

Characters per line 42cpl (MAX)

Character size Eng. : 9*24dots, 12*24dots Kor. : 16*24dots, [24*24dots]

Optional Characters Simplified/Traditional Chinese, Arabic, Cyrillic, Russian, Tukish,

Greek, Japanese, Persian, Latin9 and Others upon request.

Resolution 203dpi, 8dots/mm

Print width 2-inch (48mm, 384dots)

Printing speed 50mm / sec (MAX)

Dimensions 105 x 80.4 x 45.7 mm

Weight 286g (Including roll paper)

Interface UART(RS-232C or TTL)

Paper supplied Thermal roll paper (57mm wide, 40ø)

Barcode supplied

dimension : Code128, Code39, I2/5, Code93 UPC, EAN,

KAN, JAN, CODABAR

2-dimension : PDF417, QR Code, DATA Matrix

Receive buffer size 10K bytes

Input Power 12~24V DC, Standby 60mA and Max 3A

MSR ISO 7810 / 7811 / 7812 1&2 or 2&3 Track Reading

Environment

Conditions

Temperature -10°C ~ 50°C (operating)

-10°C ~ 70°C (storage)

Humidity 30% - 80% (operating)

10% - 90% (storage)

MCBF (Mean Cycle

Between failure)

Mechanical 37,000,000 lines

Head Approximately 50 Km

< Table 1 >

Porti-PC40 Rev. 2.0

http://www.woosim.com 9

2. Setting up the printer

When unpacking your printer box make sure it contains the printer and all accessories.

If any accessories are missing or damage, please contact your dealer for assistance.

PORTI-PC40

Thermal roll paper

Porti-PC40 Rev. 2.0
