USER INSTRUCTIONS &

CUSTOMER CARE GUIDE

6 720 611 927-00.1O

THE APPLIANCE IS FOR USE

WITH NATURAL GAS OR L.P.G.

(Cat II 2H3P TYPE C13 & C33)

25CDi GC-Number 47-311-92

30CDi GC-Number 47-311-93

35CDi GC-Number 47-311-94

40CDi GC-Number 47-311-95

GREENSTAR CDi

WALL HUNG RSF GAS-FIRED CONDENSING

COMBINATION BOILER

FOR SEALED CENTRAL HEATING SYSTEMS AND MAINS FED

DOMESTIC HOT WATER

Greenstar CDi (Combi) User.qxd 17.02.2005 9:50 Uhr Seite 1

CONTACT INFORMATION

WORCESTER BOSCH:

TECHNICAL: 08705 266241

SERVICE: 08457 256206

SPARES: 01905 752571

LITERATURE: 01905 752556

TRAINING: 01905 752526

SALES: 01905 752640

WEBSITE:

www.worcester-bosch.co.uk

WATER TREATMENT:

FERNOX 01799 550811

www.fernox.com

SENTINEL 0151 420 9595

www.betzdearborn.com/sentinel

FLUE TERMINAL GUARDS:

TOWER FLUE COMPONENTS

Vale Rise, Tonbridge TN9 1TB

USER INSTRUCTIONS & CUSTOMER

CARE GUIDE

PLEASE READ THESE INSTRUCTIONS

CAREFULLY BEFORE OPERATING YOUR

APPLIANCE

THESE INSTRUCTIONS ARE APPLICABLE TO

THE WORCESTER BOSCH APPLIANCE

MODEL(S) STATED ON THE FRONT COVER

OF THIS MANUAL ONLY AND MUST NOT BE

USED WITH ANY OTHER MAKE OR MODEL

OF APPLIANCE.

THE INSTRUCTIONS APPLY IN THE UK ONLY

AND SHOULD BE FOLLOWED EXCEPT FOR

ANY STATUTORY OBLIGATION.

IF YOU ARE IN ANY DOUBT CONTACT THE

WORCESTER BOSCH TECHNICAL HELPLINE.

DISTANCE LEARNING AND TRAINING COUR-

SES ARE AVAILABLE FROM WORCESTER

BOSCH.

THIS APPLIANCE MUST BE INSTALLED BY A

COMPETENT PERSON. FAILURE TO INSTALL

CORRECTLY COULD LEAD TO

PROSECUTION.

PLEASE LEAVE THIS GUIDE, THE INSTALLA-

TION INSTRUCTIONS AND THE COMPLETED

BENCHMARK LOG BOOK WITH THE USER OR

AT THE GAS METER AFTER INSTALLATION.

ABBREVIATIONS USED IN THIS BOOK:

NG - Natural Gas

LPG - Liquid Petroleum Gas

CH - Central Heating

SEDBUK - Seasonal Efficiency of Domestic

Boilers in the United Kingdom

USER INSTRUCTIONS &

CUSTOMER CARE GUIDE

WORCESTER BOSCH GREENSTAR 25CDi/30CDi/35CDi/40CDi

6 720 611 928a (02/05)

Greenstar CDi (Combi) User.qxd 17.02.2005 9:50 Uhr Seite 2

GUARANTEEMAINTENANCE ENERGY

SAVING

USING YOUR

APPLIANCE INTRODUCTION

CONTENTS

INTRODUCTION

EXCELLENCE COMES AS STANDARD 4

SAFETY PRECAUTIONS 5-7

GENERAL NOTES 8-11

USING YOUR APPLIANCE

CONTROLS 12

OPERATING THE APPLIANCE 13-15

Switching the appliance on/off 13

Setting the central heating temperature 13

Controlling central heating 13

Frost protection 14

Controlling domestic hot water 14-15

Fault condition 15

ENERGY SAVING

TIPS ON ENERGY SAVING 16-17

MAINTENANCE

MAINTAINING YOUR APPLIANCE 18

FAULT FINDING 19

FAULT OR BREAKDOWN 20-21

GUARANTEE

YOUR GUARANTEE 22

GUARANTEE REGISTRATION 23

CONTENTS

WORCESTER BOSCH GREENSTAR 25CDi/30CDi/35CDi/40CDi

6 720 611 928a (02/05)

Greenstar CDi (Combi) User.qxd 17.02.2005 9:50 Uhr Seite 3

EXCELLENCE COMES

AS STANDARD

WORCESTER BOSCH GREENSTAR 25CDi/30CDi/35CDi/40CDi

6 720 611 928a (02/05)

EXCELLENCE COMES AS

STANDARD

Thank you for purchasing a Greenstar

25CDi/30CDi/35CDi/40CDi gas-fired

condensing combination boiler manu-

factured by Worcester Bosch. The com-

pany prides itself on manufacturing boi-

lers to the strictest quality control stan-

dards throughout every stage of produc-

tion. Worcester Bosch has led the field

in innovative appliance design and per-

formance for more than 40 years. This

heritage means all products are of

exceptional quality and proven reliability.

The Greenstar range in particular is

extremely energy efficient, converting up

to 97% of gas consumed into heat, offe-

ring you economical running costs and

value for money. It sits in SEDBUK

Band A, and is therefore amongst the

top energy rated appliances available.

There is also the reassurance of our no-

nonsense 2 years parts and labour gua-

rantee - backed up by Worcester Total

Cover, an optional complete maintenan-

ce scheme to keep your boiler operating

at peak condition and efficiency.

To find out more about Worcester

Bosch log onto www.worcester-

bosch.co.uk.

INTRODUCTION

Greenstar CDi (Combi) User.qxd 17.02.2005 9:50 Uhr Seite 4

INTRODUCTION

SAFETY PRECAUTIONS

SAFETY

PRECAUTIONS

WORCESTER BOSCH GREENSTAR 25CDi/30CDi/35CDi/40CDi

6 720 611 928a (02/05)

IF YOU SMELL GAS:

6DON’T SMOKE OR STRIKE

MATCHES

6DON’T TURN ELECTRICAL

SWITCHES ON OR OFF

4DO PUT OUT NAKED FLAMES

4DO OPEN DOORS AND

WINDOWS

4DO KEEP PEOPLE AWAY FROM

THE AREA AFFECTED

4DO TURN OFF THE CONTROL

VALVE AT THE METER

4TELEPHONE YOUR GAS

COMPANY

BENCHMARK STANDARD

‘Benchmark’ is a code of practice for

correctly installing, commissioning and

servicing of domestic water heating

appliances.

A Benchmark Checklist is provided by

the manufacturer for the installer to

complete ALL details together with their

CORGI registration number and sign to

confirm that the boiler has been instal-

led and commissioned according to the

manufacturer’s instructions.

IMPORTANT: The completed

Benchmark Checklist will be required in

the event of any warranty work and may

be required by the local Building

Control Inspector.

HEALTH & SAFETY

The appliance contains no asbestos and

no substances used in the construction

process that contravene the COSHH

Regulations (Control of Substances

Hazardous to Health Regulations 1988).

Greenstar CDi (Combi) User.qxd 17.02.2005 9:50 Uhr Seite 5

SAFETY

PRECAUTIONS

WORCESTER BOSCH GREENSTAR 25CDi/30CDi/35CDi/40CDi

6 720 611 928a (02/05)

COMBUSTIBLE AND CORROSIVE

MATERIALS

Do not store or use any combustible

materials (paper, thinners, paints etc.)

inside or within the vicinity of the appli-

ance.

Chemically aggressive substances, such

as halogenated hydrocarbons containing

chlorine or fluorine compounds can cor-

rode the appliance and invalidate any

warranty.

FITTING & MODIFICATIONS

Fitting the appliance, any controls to the

appliance and removal of the outer

casing may only be carried out by a

competent engineer in accordance with

the Gas Safety (Installation and Use)

Regulations.

Flue systems must not be modified in

any way other than as described in the

Installation Instructions and any misuse

or unauthorised modifications to the

appliance, flue or associated compo-

nents and systems could invalidate the

warranty. The manufacturer accepts no

liability arising from any such actions.

This does not affect your statutory rights.

SAFETY PRECAUTIONS

INTRODUCTION

Greenstar CDi (Combi) User.qxd 17.02.2005 9:50 Uhr Seite 6

SAFETY

PRECAUTIONS

WORCESTER BOSCH GREENSTAR 25CDi/30CDi/35CDi/40CDi

6 720 611 928a (02/05)

SERVICING

The user is recommended to have the

system regularly serviced by a compe-

tent, qualified engineer (such as British

Gas or CORGI registered personnel)

using original spares, to help maintain

the economy, safety and reliability of the

appliance and to have the Service

Record completed in the Benchmark

Checklist.

The appliance should be serviced annu-

ally after installation unless the particular

installation conditions and usage

demand more frequent services.

IMPORTANT - ensure that the service

engineer completes the Service Record

in the Benchmark Checklist after each

service.

SAFETY PRECAUTIONS

INTRODUCTION

Greenstar CDi (Combi) User.qxd 17.02.2005 9:50 Uhr Seite 7

GENERAL NOTES WORCESTER BOSCH GREENSTAR 25CDi/30CDi/35CDi/40CDi

6 720 611 928a (02/05)

INTRODUCTION

GENERAL NOTES

To get the best from your appliance plea-

se read these instructions carefully.

SEALED HEATING SYSTEMS

This appliance is fitted to a sealed hea-

ting system which is pre-pressurised.

Your installer will advise you of the mini-

mum and maximum pressure which

should be indicated on the pressure

gauge.

Check regularly that the pressure is

maintained and contact your installer or

maintenance engineer if a permanent

significant drop in pressure is indicated

on the pressure gauge. If the system

loses pressure it should be re-pressuri-

sed and the cause of the fall investiga-

ted.

CENTRAL HEATING SYSTEMS

During the first few hours of operation of

the central heating system, check that all

radiators are being heated at an even

rate. If the top of a radiator is at a lower

temperature than the bottom then it

should be vented by releasing air

through the venting screw at the top of

the radiator. Ask your installer to show

you how this is done.

This boiler is fitted to a sealed system;

repeated venting will reduce the quantity

of water in the system and this must be

Greenstar CDi (Combi) User.qxd 17.02.2005 9:50 Uhr Seite 8

GENERAL NOTES

WORCESTER BOSCH GREENSTAR 25CDi/30CDi/35CDi/40CDi

6 720 611 928a (02/05)

replenished for safe and satisfactory

operation of the appliance.

Should water leaks be found in the

system or if excessive venting is requi-

red, then a service engineer must be

contacted to inspect the installation and

rectify any fault.

Only additives that are compatible with

aluminium may be used in the system.

Any incompatible additive used will inva-

lidate the guarantee.

CONDENSATE DRAIN

This is a condensing appliance and the

terminal will, at times give out a plume of

water vapour. This is quite normal.

The appliance also produces quantities

of condensate which is discharged regu-

larly by a siphon within the boiler via a

pipe to drain. This pipe must not be

blocked or altered in any way.

CLEARANCES - VENTILATED

COMPARTMENT

Your installer will have provided adequa-

te space around the appliance for safety

and servicing access. Do not restrict this

space with the addition of cupboards,

shelves etc. next to the appliance.

*600 mm service clearance required to a

fixed surface

(**20 mm from removable door or panel)

GENERAL NOTES

1450mm

mm mm

+ 30mm

above elbow

5mm

600mm

200mm

*600mm

(**20mm)

INTRODUCTION

Greenstar CDi (Combi) User.qxd 17.02.2005 9:50 Uhr Seite 9

+ 250mm

above elbow

100mm*

300mm

100mm**

to removable door

600mm***

front clearance

for service

GENERAL NOTES WORCESTER BOSCH GREENSTAR 25CDi/30CDi/35CDi/40CDi

6 720 611 928a (02/05)

BOILER CLEARANCES -

UNVENTILATED COMPARTMENT

The diagrams (A and B) opposite show

two options for the minimum space

required to install and service the boiler

inside an unventilated compartment.

* This space can be reduced to 50 mm

for one side only as long as both the

side clearances add up to the total of

both the side measurements shown or

more.

** Space required for unventilated areas

with a removable door or panel.

*** 600 mm clearance required to a fixed

surface for servicing.

ROOM THERMOSTAT

A room temperature controller and pro-

grammer should be fitted to control the

central heating. Refer to the instructions

supplied with the thermostat for informa-

tion on siting and setting.

THERMOSTATIC RADIATOR VALVES

It is recommended that this type of valve

is fitted to all but one of the radiators (or

at least those in the sleeping accommo-

dation). The remaining radiator, which

must be where the room thermostat is

located, should be uncontrolled and

must be left open. The thermostatic

radiator valves should conform to the

requirements of BS2767:10.

+ 30mm

above elbow

200mm*

100mm**

600mm***

200mm

GENERAL NOTES

INTRODUCTION

Greenstar CDi (Combi) User.qxd 17.02.2005 9:50 Uhr Seite 10

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Worcester Kessel Handbücher

Worcester

Worcester danesmoor 50/70 Bedienungsanleitung

Worcester

Worcester 28Si Benutzerhandbuch

Worcester

Worcester Greenstar 36LXi Bedienungsanleitung

Worcester

Worcester GREENSTAR HIGHFLOW 440CDI ERP Bedienungsanleitung

Worcester

Worcester GREENSTAR CDi CLASSIC REGULAR ErP Bedienungsanleitung

Worcester

Worcester 12/18 Bedienungsanleitung

Worcester

Worcester Greenstar Si Compact Series Bedienungsanleitung

Worcester

Worcester GREENSTAR 25Si Bedienungsanleitung

Worcester

Worcester danesmoor 12/14 Bedienungsanleitung

Worcester

Worcester 240 Combi RSF Betriebsanleitung

Worcester

Worcester GREENSTAR 27CDI GC 47-406-12 Bedienungsanleitung

Worcester

Worcester GR8700iW 30 S NG Bedienungsanleitung

Worcester

Worcester 240 Combi BF Betriebsanleitung

Worcester

Worcester Highflow 400 BF Benutzerhandbuch

Worcester

Worcester GREENSTAR 25CDi GC Bedienungsanleitung

Worcester

Worcester Greenstar Heatslave 12/18 Bedienungsanleitung

Worcester

Worcester Greenstar Heatslave II ErP 12/18 Benutzerhandbuch

Worcester

Worcester Greenstar 8000 Style Series Bedienungsanleitung

Worcester

Worcester GREENSTAR 24i junior Bedienungsanleitung

Worcester

Worcester Greenstar Si Compact ErP Series Bedienungsanleitung

Worcester

Worcester GREENSTARHIGHFLOW 440 CDi Bedienungsanleitung

Worcester

Worcester Highflow 400 BF Benutzerhandbuch

Worcester

Worcester GREENSTAR 35CDi Classic System ErP 41-406-39 Benutzerhandbuch

Worcester

Worcester ZSBR 7-28 ICS1 Installations- und Betriebshandbuch

Beliebte Kessel Handbücher anderer Marken

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Bedienungsanleitung

Radijator

Radijator BIO max 23.1 Bedienungsanleitung

Brunner

Brunner BSV 20 Bedienungsanleitung

Buderus

Buderus Logamax GB062-24 KDE H V2 Bedienungsanleitung

Potterton

Potterton 50e Datenblatt

UTICA BOILERS

UTICA BOILERS TriFire Bedienungsanleitung

Joannes

Joannes LADY Series Handbuch

ECR International

ECR International UB90-125 Gebrauchsanweisung

Froling

Froling FHG Turbo 3000 Bedienungsanleitung

Froling

Froling P4 Pellet 8 - 105 Bedienungsanleitung

U.S. Boiler Company

U.S. Boiler Company K2 Bedienungsanleitung

Henrad

Henrad C95 FF Bedienungsanleitung

NeOvo

NeOvo EcoNox EF 36 Bedienungsanleitung

Potterton

Potterton PROMAX SL 12 Bedienungsanleitung

Eco Hometec

Eco Hometec EC 25 COMPACT Bedienungsanleitung

Viessmann

Viessmann VITODENS 200 Leitfaden

Baxi

Baxi Prime 1.24 Bedienungsanleitung

REXNOVA

REXNOVA ISA 20 BITHERMAL Bedienungsanleitung
