WORKZONE TITANIUM CDLID20 Bedienungsanleitung
Xfinity Li-ION 20V
Instruction Manual
IMPORTANT
Read carefully before use
Keep for future reference
20V Li-Ion Cordless Auto
Buffer / Polisher
M
ODEL
NUMBER
CDLID20
Version number:
003
1300 889 028
03/2019
63520CDLID20
2
AFTERSALESSUPPORT e-mail: [email protected]m
1300 889 028 (toll free) MODEL No.: CDLID20 • 63520 • 03/2019
Welcome
Congratulations in choosing to buy a Workzone® Titanium 20V Li-Ion
Cordless Auto Buffer / Polisher.
All products bought to you by Workzone® Titanium are manufactured
to the highest standards of performance and safety and, as part of
our philosophy of customer service and satisfaction, are backed by our
comprehensive 5 Year Warranty. We hope you will enjoy your purchase
for many years to come.
When you open your packaging, first remove all items and check there
are no parts damaged or missing. If you find anything wrong, do not
operate the product until the parts have been replaced or the fault has
been rectified. Failure to do so could result in serious personal injury.
1
1
AFTERSALESSUPPORT e-mail: [email protected]m
1300 889 028 (toll free) MODEL No.: CDLID20 • 63520 • 03/2019
Contents
Application
Package Contents
Parts description
Description of symbols
General safety warnings
Safety notes for battery/charger
Important information-Product care
Assembly
Operation
Maintenance, Storage and Cleaning
Warranty
Disposal and environmental protection
Accessories and After Sales parts
FAQ/Troubleshooting
Technical Specifications
2
2
4
5
7
12
14
15
17
21
21
22
23
24
25
2
2
AFTERSALESSUPPORT e-mail: [email protected]m
1300 889 028 (toll free) MODEL No.: CDLID20 • 63520 • 03/2019
1.Application
First time users or inexperienced operators pay particular attention
to the operation of the 20V Li-Ion Cordless Auto Buffer / Polisher,
including details of starting and stopping and correct use of the 20V
Li-Ion Cordless Auto Buffer / Polisher on pages 14-20, as well as the
maintenance instructions on pages 21.
Intended use of 20V Li-Ion Cordless Auto Buffer / Polisher
NOTE: This product is for private domestic DIY use only. It is not
suitable for commercial or trade use.
This 20V Li-Ion Cordless Auto Buffer / Polisher is used for polishing
and buffing cars, boats, recreational vehicles , floors and other coated
surfaces.
2.Package Contents
1 x Auto Buffer / Polisher
1 x 20V Li-Ion Battery
1 x 20V Charger Adapter
1 x Plug Pack Charger
1 x Polishing / Buffing Bonnet
1 x Terry Towel Bonnet
1 x Instruction Manual
1 x Warranty Card
• Remove all packing materials
• Ensure all parts on the contents list are present
• Check the appliance, and all accessories for transportation damages
WARNING! Please read and understand this instruction manual
before use and keep it for your future reference. Your power tool
should only be passed on together with this instruction manual.
3
3
AFTERSALESSUPPORT e-mail: [email protected]m
1300 889 028 (toll free) MODEL No.: CDLID20 • 63520 • 03/2019
WARNING! To reduce risk of injury, only use the supplied battery
and charger OR any 20V Xfinity Plus battery pack or chargers.
Other type of battery packs may burst causing personal injury and
damage. The battery pack must be recharged only with the supplied
charger OR any 20V Xfinity Plus battery charger.
NOTE: This appliance (charger) must be used with a residual current
device with a rated residual current of 30mA or less.
4
4
AFTERSALESSUPPORT e-mail: [email protected]m
1300 889 028 (toll free) MODEL No.: CDLID20 • 63520 • 03/2019
3.Parts description
Plastic handle/s
On/Off switch
Battery pack release button
Battery pack
Foam pad base
Polishing / Buffing bonnet
Terry towel bonnet
Charger adaptor (SEE FIG. A)
Plug pack charger (SEE FIG. A)
3
4
1
2
1
5
67
9
8
7
5
2
6
3
4
1
5
5
AFTERSALESSUPPORT e-mail: [email protected]m
1300 889 028 (toll free) MODEL No.: CDLID20 • 63520 • 03/2019
4.Description of Symbolssymbols
To reduce the risk of injury, user must read instruction manual
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Regulatory Compliance Mark. Appliance complies with
requirements of electrical approval & EMC in Australia.
For indoor use only (only for charger)
Do not charge the battery pack if the ambient temperature is
less then 0°C or greater than 45°C.
Li-Ion battery. This product has been marked with a symbol
relating to ‘separate collection’ for all battery packs and battery
pack. It will then be recycled or dismantled in order to reduce
the impact on the environment. Battery packs can be hazardous
for the environment and for human health since they contain
hazardous substances.
The instruction manual, rating plate, or on the product itself, may show
these symbols. These represent important information about the product or
instructions on its use.
max45 C
6
6
AFTERSALESSUPPORT e-mail: [email protected]m
1300 889 028 (toll free) MODEL No.: CDLID20 • 63520 • 03/2019
Do not crush, disassemble, short terminals or dispose in fire;
there is a risk of burns explosion or fire.
Do not put in water.
Positive terminal
Negative terminal
Double insulation (only for charger) There are two independent
barriers of insulation to protect you from the possibility of
electrical shock.
Polarity
Fuse
60 Months Warranty
MEPS
T2A
60
7
7
AFTERSALESSUPPORT e-mail: [email protected]m
1300 889 028 (toll free) MODEL No.: CDLID20 • 63520 • 03/2019
5. General safety warnings
General Power Tool Safety Warnings
WARNING Read all safety warnings , instructions,
illustrations and specifications provided with this power
tool.
Failure to follow the warnings and instructions may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
1). Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
b) Do not operate power tools in explosive atmospheres, such
as in the presence of flammable liquids, gases or dust. Power
tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power
tool. Distractions can cause you to lose control.
2). Electrical safety
a) Power tool plugs must match the outlet. Never modify the
plug in any way. Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators. There is an
increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away from
8
8
AFTERSALESSUPPORT e-mail: [email protected]m
1300 889 028 (toll free) MODEL No.: CDLID20 • 63520 • 03/2019
heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for outdoor
use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable,
use a residual current device (RCD) protected supply. Use of an
RCD reduces the risk of electric shock.
3). Personal safety
a) Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power tool while
you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the
off-position before connecting to power source and/or
battery pack, picking up or carrying the tool. Carrying power
tools with your finger on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the
power tool on. A wrench or a key left attached to a rotating part
of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all
times. This enables better control of the power tool in unexpected
situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep
your hair and clothing away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
