Woxcon NPG-EX80 Benutzerhandbuch
Quick Operation Guide
NPG-EX80
HDMI Extender over CAT5e/CAT6
The NPG-EX80 is a cost-effective point-to-point extender set for HDMI V1.4 and IR signals.
The extender supports 4K@30Hz with 4:4:4 Chroma sampling along with HDMI data rates
up to 10.2Gbps and HDCP 1.4 compliant. The NPG-EX80 provides HDMI transmission up
to 393 feet (120 meters) for 4K@30Hz 4:4:4 or 1080p, over single CAT5e/6 cable. The
extender supports video resolution down-scaling allowing the 4K input to be automatically
downscale to 1080p output for compatibility with 1080p display.
Features
§ Supports HDMI V1.4, up to 4K@30Hz 4:4:4, HDCP 1.4.
§ Extends 4K or 1080p HDMI signal up to 393 feet (120m) over a single CAT5e/6 cable.
§ HDMI loop out on transmitter.
§ Bi-directional IR pass-through.
§ Supports video resolution down-scaling, the 4K input can be automatically degraded to
1080p output on receiver for compatibility with legacy 1080p display device.
§ Features visually lossless compression with no latency.
§ Smart EDID management.
§ Compact design, easy to install and simple to operate.
Packing List
§ 1x Transmitter (Tx)
§ 1x Receiver (Rx)
§ 1x IR Receiver
§ 1x IR Emitter
§ 2x Velcro Tape
§ 1x Power Adaptor (12V DC 1A)
§ 1x Quick Operation Guide
Transmitter Panel Description
1.
CATx OUT:
RJ45 port to connect the CATx IN port of receiver by CATx cable. It supports
12V PoC to power the receiver. The orange LED illuminates when there is a valid HDMI
signal input. The green LED illuminates when power is applied.
2.
IR IN:
3.5mm mini jack to connect IR receiver for IR pass-through.
3.
IR OUT:
3.5mm mini jack to connect IR emitter for IR pass-through.
4.
DISPLAY:
Type-A female HDMI port to connect HDMI display device.
5.
SOURCE:
Type-A female HDMI port to connect HDMI source device.
6.
DC 12V:
DC connector for the power adapter connection.
7.
EDID Management:
§ EDID BYPASS: Press the button with paper clip or other sharp tool to learn the
EDID from the remote display connected to the Receiver’s HDMI out.
§ EDID COPY Tx/3s: Press and hold the button for 3 seconds to copy the EDID from
the local display connected to the Transmitter’s HDMI out.
§ DEFAULT: Factory default, the source device learns EDID from the TV which has
the lowest resolution. Press and hold the button while the product is in turned-off
period, and then release the button after 6 seconds of power on can restore the
default setting.
Note:
If the standard resolution of the local display is lower than the receiver‘s, the unit
will output the video with the lower resolution to ensure video can be shown on both
displays.
1234567
Receiver Panel Description
1.
CATx IN:
RJ45 port to connect the CATx OUT port of transmitter by CATx cable. It
supports 12V PoC and the receiver can be powered from the transmitter. The orange
LED illuminates when there is a valid HDMI signal input. The green LED illuminates when
power is applied.
2.
IR IN:
3.5mm mini jack to connect IR receiver for IR pass-through.
3.
IR OUT:
3.5mm mini jack to connect IR emitter for IR pass-through.
4.
DISPLAY:
Type-A female HDMI port to connect HDMI display device.
1234
Specifications
Transmitter
Input
(1) SOURCE (19-pin type-A female HDMI)
Output
(1) DISPLAY (19-pin type-A female HDMI)
(1) CATx OUT (RJ45)
Control
(1) IR IN (3.5mm mini jack)
(1) IR OUT (3.5mm mini jack)
Receiver
Input
(1) CATx IN (RJ45)
Output
(1) DISPLAY (19-pin type-A female HDMI)
Control
((1) IR IN (3.5mm mini jack)
(1) IR OUT (3.5mm mini jack)
General
Video Resolution
Up to 4K@30Hz 4:4:4
HDMI Audio Format
Supports LPCM 2ch, LPCM 5.1ch, LPCM 7.1ch,
Dolby Digital 2ch, Dolby Digital 5.1ch, DTS 2ch, DTS
5.1ch, DTS 96/24 5.1ch.
Transmission Distance
4K/1080p ≤ 120 meters (393ft) (CAT6a/(F/FTP))
HDMI Version
Up to 1.4
HDCP Version
Up to 1.4. The HDCP of output follows the HDCP
version of display device.
EDID Management
Supported.
Power Supply
Input: 100 to 240V AC, 50/60Hz; Output: 12V DC 1A
Power Consumption
4W (Max)
Operation Temperature
-5 to +55℃ (+23° to +131°F)
Storage Temperature
-25 to +70℃ (-13° to +158°F)
Relative Humidity
10% to 90%, Non-condensing
Dimensions (W*H*D)
80mm x 16.8mm x 80mm
Net Weight
Tx: 65g, Rx: 60g
Note:
The extender set does not support HBR audio.
Connection Diagram
Resolution
CAT5e (FTP)
CAT6a (U/FTP)
1080p@60Hz
120m
120m
4K@30Hz
120m
120m
IR Emitter
Blu-Ray Remote
IR
Receiver
Bedroom TV4K Blu- Ray
Tx Rx
Living Room TV
Power:
IR:
HDMI:
Catx:
