WTI SW720 Bedienungsanleitung
Sidewinder SW720 Series Analog Cameras
Installation and Operation Manual
24VAC Power Models
Including:
Standard Definition x36 Zoom
High Definition 720p/1080p x20 Zoom
High Definition 720p/1080p x30 Zoom
Optional Electric Brakes (ENG)
REVISION 04/06/2015
TABLE OF CONTENTS
INFORMATION.................................................................................................................................3
FCC NOTICE .................................................................................................................................. 3
READ THIS MANUAL...................................................................................................................3
PRODUCT WARRANTY AND REPAIR ...........................................................................................4
PRODUCT WARRANTY.............................................................................................................. 4
REPAIR AUTHORIZATION....................................................................................................... 5
RETURNS ....................................................................................................................................... 5
WARNING......................................................................................................................................6
SAFEGUARDS....................................................................................................................................7
MODELS AND FEATURES............................................................................................................. 8
GENERAL DESCRIPTION..............................................................................................................9
INSTALLATION..............................................................................................................................10
RECOMMENDED TOOLS FOR PROPER INSTALLATION.............................................. 10
INSTALLATION PLANNING ................................................................................................... 10
DIMENSIONS AND MOUNTING...................................................................................................11
MECHANICAL DIMENSIONS ................................................................................................. 11
MOUNTING .................................................................................................................................12
MOUNTING ACCESSORIES ........................................................................................................ 13
15-4-913 – 6”Round Riser Mounting Base SIDE EGRESS 24VAC MS STYLE PINOUTS ....17
15-4-913 – 6”Round Riser Mounting Base SIDE EGRESS 24VAC MS STYLE PINOUTS ....18
SIDE EGRESS 24VAC MS STYLE PINOUTS............................................................................. 19
SIGNAL DESCRIPTIONS.............................................................................................................. 20
AC POWER CONNECTIONS.................................................................................................... 20
ANALOG VIDEO CONNECTIONS..........................................................................................20
PTZ SERIAL CONTROL PORT ...............................................................................................20
SURGE PROTECTION...................................................................................................................21
SURGE PROTECTION...............................................................................................................21
SPECIFICATIONS ..........................................................................................................................22
X20 ZOOM IMAGE SENSOR AND LENS............................................................................... 22
X30 ZOOM HIGH DEFINITION 720p/1080p IMAGE SENSOR AND LENS..................... 22
36 TIMES ZOOM STANDARD DEFINITION COLOR IMAGE SENSOR AND LENS.... 23
CAMERA HOUSING MODULE ...............................................................................................24
PAN AND TILT DRIVE ASSEMBLIES ...................................................................................24
ELECTRICAL.............................................................................................................................. 25
ENVIRONMENTAL.................................................................................................................... 25
MECHANICAL............................................................................................................................26
REVISION HISTORY.....................................................................................................................26
SW720 Series 24VAC WTI ~ Page 2 of 26
SW720 Series 24VAC WTI ~ Page 3 of 26
INFORMATION
FCC NOTICE
This device complies with Part 15 of the FCC
Rules.
Operation is subject to the following two
conditions:
1.) This device may not cause harmful
interference.
2.) This device must accept any interference
that may be received, including interference
that may cause undesired operation.
READ THIS MANUAL
Every effort has been made to insure that this
WTI system is of the highest quality. This
product has been carefully inspected to
comply with rigid quality standards before
shipment to you. In consideration of your
investment and the desire to obtain full
performance capability engineered into your
new WTI product, we recommend that you
read this manual before attempting to operate
your system.
FOR MORE ASSISTANCE OR MORE
INFORMATION
WTI (Wireless Technology, Inc.)
2064 Eastman Avenue, Suite 113
Ventura, CA 93003-7787
TOLL FREE. 866/gotowti (468-6984)
TEL. 805/339-9696
FAX. 805/339-0932
EMAIL: [email protected]
INTERNET: http://www.gotowti.com
The software / firmware furnished with the
equipment is confidential to and is
copyrighted by Wireless Technology, Inc.
(WTI) It is not to be copied or disclosed in any
manner without the consent of Wireless
Technology, Inc. (WTI). The
software/firmware is furnished to the
purchaser under a license for use on a single
system.
Information furnished by Wireless
Technology, Inc. (WTI) is believed to be
accurate and reliable. However, no
responsibility is assumed by Wireless
Technology, Inc. (WTI) for its use or for any
infringements of other rights of third parties,
which may result from its use. No license is
granted by implications or otherwise under
any patent or patent rights of Wireless
Technology, Inc. (WTI)
©2011 Wireless Technology, Inc. (WTI)
All rights reserved.
PRODUCT WARRANTY AND REPAIR
PRODUCT WARRANTY
We appreciate your purchase of Wireless Technology, Inc. (WTI) security products. We
take pride in the quality of our products and have manufactured each new WTI product to
exacting quality standards. In normal use, it will provide you with years of satisfactory
performance. However, should you experience difficulty; you are protected under the
provisions of this warranty.
WTI warrants to the original user a product that is free of defects in materials and
workmanship in normal use. WTI warrants to the original user that WTI’s products will
be free of defects in materials and workmanship in normal use for a period of 24 months
from the date of sale. WTI’s obligation under this warranty shall be limited to the repair,
including all necessary parts and the cost of labor connected therewith, or at our option,
the replacement of any product that shows evidence of a manufacturing defect within the
warranty period. This warranty is extended to all WTI products purchased and used
within the United States of America and is valid only when service is rendered by the
authorized WTI (Wireless Technology, Inc.) Warranty Station.
This warranty shall not apply to appearance or accessory items including, but not limited
to, knobs, connectors, cabinets and connecting cables. This warranty shall not, in
addition, apply to repairs or replacements necessitated by any cause beyond the control of
WTI including, but not limited to, acts of nature, improper installation, misuse, lack of
proper maintenance, accident, voltage fluctuations, unauthorized repairs or modifications.
This warranty becomes void in the event serial numbers are altered, defaced or removed,
or an attempt is made to field service or alter performance of any WTI products.
WTI reserves the right to make changes in design, or to make additions to, or
improvements upon, products without incurring any obligation to install the same on
products previously manufactured.
The foregoing is in lieu of all other warranties expressed or implied and WTI neither
assumes nor authorizes any person to assume for it any other obligation or liability in
connection with the sale of our products. In no event shall WTI or its Authorized Dealers
be liable for special or consequential damage arising from the use of this product, or any
delay in the performance of this warranty due to causes beyond its control.
SW720 Series 24VAC WTI ~ Page 4 of 26
PRODUCT WARRANTY AND REPAIR
REPAIR AUTHORIZATION
Please contact Wireless Technology, Inc. (WTI), to obtain a repair authorization number
(RA) and provide the following information:
1.) Product Model & Serial Numbers
2.) Date of shipment, purchase order number, sales order number or WTI invoice
number.
3.) Details of the defect or malfunction. If there is a dispute regarding the warranty or
product, which does not fall under the warranty conditions stated within the
description of the written warranty, please include a written explanation with the
product when returned.
SHIP FREIGHT PRE-PAID TO:
WTI (Wireless Technology, Inc.)
2064 Eastman Avenue, Suite 113
Ventura, CA 93003-7787
TEL 805/339-9696
FAX 805/339-0932
RETURNS
No unauthorized returns will be accepted. All returns must have an authorized (RA)
number issued by the factory (CA number if returned for credit and RA number if
returned for repair). Products returned for repair or credit will be rejected if no
authorization number has been issued or freight has not been pre-paid. All merchandise
returned for credit will be subject to a 20% restocking and refurbishing charge.
SW720 Series 24VAC WTI ~ Page 5 of 26
PRODUCT WARRANTY AND REPAIR
WARNING
The Sidewinder series of IP66/IP67 rated cameras provide a fully sealed, moisture free
environment for the internal electronic and mechanical components. If the camera
housing cover or seals become compromised due to being struck by objects or damaged
during handling, the cameras should be taken out of service IMMIDIATELY, so that the
camera can be returned to WTI for repair. This will help prevent further EXPENSIVE
internal corrosion damage from occurring. Below are some examples of Damage that will
compromise the sealing integrity of the camera.
SW720 Series 24VAC WTI ~ Page 6 of 26
SAFEGUARDS
IMPORTANT SAFEGUARDS
1.) Read Instructions. It is important to read all safety and operating instructions
before installing or using this equipment.
2.) Retain Instructions. Retain this manual and any supplements for future reference.
3.) Follow Instructions. Follow all instructions herein for use of this equipment.
4.) Heed all warnings. Adhere to all warnings on the equipment, and in this manual.
5.) To reduce the risk of electric shock or equipment damage, work on the unit only
when the power is shut off and is unplugged from its power source to prevent
accidental activation. Also take precautions to avoid contact between the
equipment and other electrical wires or power sources that may be present at the
installation site.
SW720 Series 24VAC WTI ~ Page 7 of 26
MODELS AND FEATURES
The Sidewinder SW720 Analog camera series with 24VAC power is available in
Standard Definition color versions with x36 optical zoom and High Definition
720p/1080p models with x20 and x30 optical zoom. The 24VAC camera series
incorporate a side egress 18 Pin MS style power and signal connector. Optional electric
brakes for securing the camera during transport are also available. The following table
provides a quick reference to the major features available in each camera model.
MODEL
X36 ZOOM COLOR CAMERA
X20 ZOOM 1080P HD CAMERA
X30 ZOOM 1080p HD CAMERA
ELECTRIC BRAKES
SW720 x
SW720-ENG x x
SW720HD x
SW720HD-ENG x x
SW720HD30 x
SW720HD30-ENG x x
SW720 Series 24VAC WTI ~ Page 8 of 26
GENERAL DESCRIPTION
The Sidewinder SW720 24VAC Series is a pan-tilt-zoom camera system that provides
standard definition or High Definition 720p/1080p color video over 75 Ohm video
coaxial cables. The camera provides 360 degree continuous rotation in both the pan and
tilt axes, and provides an optical zoom magnification of 36 times in the standard
definition model and 20 times or 30 times in the high definition model. A self-cleaning
hydrophilic coating is provided on the front lens window of the camera to ensure clear,
crisp video images and to reduce maintenance. An electrically conductive Indium-Tin-
Oxide coating is provided on the inside of the front lens window to heat it and prevent
fogging.
The Sidewinder SW720 series of 24VAC cameras operates on AC power within a
voltage range of 18VAC to 30VAC measured at the camera and an operating frequency
of 47Hz to 63Hz. Power, control and video signals are brought out of the side of the
camera on an 18 Pin MS style male connector.
Camera PTZ control is implemented using an RS-485 serial data port which supports
several industry standard camera control protocols, including Pelco D protocol and
COHU protocol. Standard definition models are provided with an NTSC 1Vpp video
output. High definition models are provided with 3 75 Ohm 1Vpp analog video outputs in
Y-Pb-Pr format.
The Sidewinder SW720 series of 24VAC cameras are also available with an electric
brake option to hold the camera in position during transport.
SW720 Series 24VAC WTI ~ Page 9 of 26
INSTALLATION
RECOMMENDED TOOLS FOR PROPER INSTALLATION
1) Tie wraps to secure cable runs.
2) Set of open end wrenches including 7/16” for mounting bolts.
3) Cordless power drill for mounting some brackets.
4) Safety cable recommended (prevents camera falling during overhead
installations).
5) Self-sealing connector tape to weatherproof all cable connections.
INSTALLATION PLANNING
1) The maximum cable length that should be planned for is
2) The Sidewinder SW720 camera draws up to 50 Watts maximum, which translates
to about 3.0 Amps at the low line voltage limit of 18VAC. The maximum cable
run using 4 x #20 power wiring is 150 feet.
3) Be sure to verify that there are no physical obstructions that might prevent the
camera from turning freely in all directions.
4) Be sure to verify that there are no physical obstructions in the way of any required
viewing directions.
UNPACKING
Please examine the equipment carefully when unpacking the shipping container. If any
damage is noted please be sure to file a claim with the carrier. WTI is not responsible for
any damage that occurs during shipping. Please verify that all of the contents are present
and carefully check the packing material for any loose items before recycling it.
EQUIPMENT SUPPLIED WITH UNIT
1.) Camera
2.) 4 each ¼-20 x ¾” mounting screws with washers
3.) Quick Start Manual
EQUIPMENT THAT MAY BE REQUIRED, BUT NOT SUPPLIED WITH UNIT
1.) Mating connector and strain relief for umbilical extension cable
2.) Camera mounting bracket
3.) Interconnect cables
4.) Video monitor
5.) PC or laptop computer
6.) Setup software
SW720 Series 24VAC WTI ~ Page 10 of 26
Dieses Handbuch passt für folgende Modelle
5
Inhaltsverzeichnis
Andere WTI Sicherheitskamera Handbücher
