WUBEN T70 Bedienungsanleitung
User Manual
V 1.0
Please read user manual carefully before using the light.
Please don’t shine into eyes directly to avoid harm to eyes.
Please keep the light away from children.
Please use WUBEN or WUBEN recommended battery.
Please don’t disassemble the light or it will not be
covered by WUBEN warranty policy.
Product will generate heat while working, please be
cautious with that to avoid any possible harm.
T70 x 1（With Battery）
Before using this product, please check whether the
contents of the package are complete.
Waterproof Ring x 2 TYPE-C Charging Cable x 1 （Manual/Warranty Card
/Certificate） x 1
Holster x 1 Hand Strap x 1
WARNINGS
Product List
WUBEN T70 is a high performance flashlight specially
designed for outdoor and camping activities.Utilized Cree
XHP70.2 LED, and powered by 26650 Li-ion battery of
5000mAh, T70 emits as high as 4200 Lumens, matched
with Type-C recharging function, more convenient to use.
Product Features
Product Operation
1. Product Structure
Head Tail
Key
( battery indicator )
2. Installation
①Screw out the tail cap ②Load battery as instructed
Battery
26650
TYPE-C
Charging interface
Turn on: Single click to turn on the light.
3. Operation
When the light is off, light blinks 3 times to indicate lockout
status.Then any operations on the switch will activate the
blue light in switch to indicate lockout status, except triple
click on the switch to unlock it.
4. Lock out function
5. Charging
Blue light constant
Power 90%~41%
Power 100%~90%
Power 40%~16%
Power under 15%
Blue light flashes
Red light
Red light flashes
1
Default outputs selection: When the light is on, single
click to cycle through Low-Med-High-Turbo.Press and
hold 2s to turn off the light.
Continuous outputs selection: When the light is on, triple
click to get into continuous outputs selection, start from
low to turbo and then turbo to low, release to select the
current output, triple click again to switch into default
outputs selection mode.
Flashing mode: When the light is NOT on continuous
output brightness selection mode , double click to switch
between Strobe and SOS, then single click to exit the flash
mode
Instant turbo: Press and hold to activate turbo output,
then single click to turn off.
2
3
Please make sure the flashlight is off.
Please use 5V/2A equipment for charging.
1
2
Please insert Type-C charging cable.
3
Once charging is completed, please remove the
charge cable. Charging warning:
4
4
5
When the battery in low status, please recharge the light
or change battery in time to maintain the lifespan of the
battery.
Recommended accessories: Holster, 26650 battery,
extended tube.
Parameters
Accessories recommendation
O-ring may lose fail to keep the light water proof, please
change O-ring according to the condition to promise
waterproof performance.
Maintenance
Please use WUBEN or WUBEN recommended battery.
FL1 Standard
Turbo
Size
High Med Low Storbo SOS
/
4200 LM 100 LM
The above data tested in WUBEN laboratory, may change because
of different test instruments or other factors.
250m
15750 cd
139.7mm x 42mm ( L x D )
1m
IP68
1300 LM 400 LM 40 LM 4200 LM
2h 3.5h 7.5h 35h /
Low power warning :
Blue light constant ( Turns off after 5 seconds )
Power 79%~30%
Power 100%~80%
Power 29%~15%
Power under 15%
Blue light flashes ( Turns off after 5 seconds )
Red light
Red light flashes
Indicator is in the Switch.
It takes about 4 hours to fully charged the light.
5
6
When blue light is constant on, it means fully charged,
please pull out the charging cable right after that.
7
Please clean the conductive part with alcohol dipped cloth.
Take out the battery if put away for a long time, in case of
battery leakage or possible explosion.
If the above method has not solved your problem.Please
contact local dealers for after-sales service.
Warranty policy
1. Under Warranty
1 year free repair service: Since the purchase date,
WUBEN offers free repair service due to quality problem
within 1 year.
5 years free repair service for registered users: Since the
purchase date, for registered users, WUBEN offers free
repair service due to quality problem within 5 years.
15 days free replacement: Since the purchase date,
consumer can request to replace with same or similar
product for free due to quality problem within 15 days.
FAQs
Problem
Abnormal
flashing or
no bright
Noise
Reason
Check whether the switch is
opened properly Open the switch
Tighten the assembly
parts
Charger the battery
Remove the battery
re-assembly
Use alcohol to clean
Pour foreign body
Return to the local
dealer
Checked whether the
assembly is in the right place
Check whether the battery
is charged
Check whether the battery
is anti-loading
Check if the battery contact
points are dirty
Check whether there is a
foreign body fall
Parts damage
Solution
SHENZHEN SHENGQI LIGHTING TECHNOLOGY., LTD
Add: 209# Building C, 1970 Industrial Zone, Minzhi, Longhua
District, Shenzhen, China
Zip Code: 518131 wubenlight.com
Breakdown due to improper operation.
Breakdown due to battery leakage.
Abrasion due to normal use.
Breakdown due to irresistible reasons.
Gift.
Life time repair service: Over 5 years since the purchase
date,WUBEN offers repair service due to quality problem
but may charge some cost according to the cost may
cause.
Negotiation is opened to any possible argument.
Final interpretation is reserved to WUBEN.
2.Beyond Warranty
Breakdown due to deliberate damage.
