WUBEN T70 Bedienungsanleitung

User Manual V3.2

CONTENTS

(EN) English

(DE) Deutsch

(CN) 中文

(JP) 日本語

(KR) 한국어

(FR) Français

(ES) Español

(IT) Italia

(AR)

ﺔﯾﺑرﻌﻟا

WARNINGS

Please read user manual carefully before using the light.

Product will generate heat while working, please be

cautious with that to avoid any possible harm.

Please don’t shine into eyes directly to avoid harm to eyes.

Please keep the light away from children.

Please use WUBEN or WUBEN recommended batteries.

Please don’t disassemble the light or it will not be

covered by WUBEN warranty policy.

Please don't throw the product into ﬁre.

This is not a diving product, please don't use it underwater

for a long time.

- 03 -

Before using this product, please check whether the contents

of the package are complete.

Package List

26650 Li-ion

Battery × 1

Holster × 1

T70 × 1

Spare O-ring × 2Lanyard × 1

4Type-C charging

cable × 1

5 6

(Manual, warranty card,

quality certiﬁcate) × 1

2 3

WUBEN T70 is a high performance ﬂashlight specially

designed for outdoor and camping activities. Utilized

1 × CREE XHP70.2 LED, and powered by 26650 Li-ion battery

of 5000mAh, T70 emits as high as 4200 lumens, matched

with Type-C recharging function, more convenient to use.

1. About product

Product Operation

- 04 -

3. Operation

1Turn on: Single click to turn on the light.

2. Installation

Please remove the insulation plate before using.

Head Tail

Type-C

charging port

Switch

( battery indicator )

- 05 -

4. Lock and unlock

When the light is oﬀ, light blinks 3 times to indicate lockout

status.Then any operations on the switch will activate the

blue light in switch to indicate lockout status, except triple

click on the switch to unlock it.

5. Charging

Please make sure the light is oﬀ before charging. Connect

Type-C charging cable with the light and adapter of 5V /2A

to charge. It takes about 4h to fully charge the light ( based

on 5V /2A adapter ) .

Default output selections: When the light is on, single

click to cycle through Low-Med-High-Turbo. Press and

hold 2s to turn oﬀ the light.

Continuous output selections: When the light is on, triple

click to get into continuous output selections, start from

Low to Turbo and then Turbo to Low, release to select

thecurrent output, triple click again to switch into

default output selections mode.

Flashing mode: When the light is NOT on continuous

output brightness selection mode , double click to

switch between Strobe and SOS, then single click to exit

the ﬂash mode.

Instant Turbo: Press and hold to activate turbo output,

then single click to turn oﬀ.

- 05 -

Blue light constant on

Power 91%~100%

Power 41%~90% Blue light ﬂashes

Power 15%~40% Red light constant on

Power under 15% Red light ﬂashes

Make sure the batteries with protection circuit board.

Make sure rubber cap covered well after charging ﬁnished to promise

the IP68 waterproof level.

4200 1300

Low power warning :

All data from experiments of WUBEN lab according to the ANSI/NEMA FL1

standard, may vary because of diﬀerent experimentequipment, experiment

environment or other factors. Experimentsare based on WUBEN 26650 Li-ion

battery（5000mAh）.

The O-Ring may be damaged for a long time use, please

replace the O-Ring in time to ensure the waterproofness

of the product.

Please use WUBEN battery or WUBEN recommended

batteries.

Holster, ABT500C battery, extended tube.

Maintenance

Accessories recommendation

- 06 -

Parameters

FL1

Standard

250m

15750cd

164g/ 5.78oz (without battery) | 261g/9.21oz (with battery )

IP68 （2m underwater for 1h)

3.5h 7.5h 35h /

Turbo High

1300LM

Med Low Strobe SOS

1+120mins

139.7mm × 42mm | 5.5in × 1.65in (L × D)

400LM 40LM 4200LM 100LM

Red light ﬂashes

Power under 15%

Power 29%~15% Red light constant on (oﬀ after 5s)

Power 79%~30% Blue light ﬂashes (oﬀ after 5s)

Power 100%~80% Blue light constant on (oﬀ after 5s)

When the ﬂashlight indicates low power, please charge

or replace the battery in time to avoid aﬀecting the

durability of the battery.

Please use alcohol and rag to clean the conductive parts

of the ﬂashlight in time.

When not in use for a long time, please remove the

battery to prevent the battery from leaking or exploding,

store the ﬂashlight in a dry and ventilated place.

FAQs

If your problems still not solved yet, please contact your local dealer for

after-sales service.

1 year warranty: Within 1 year from the date of purchase,

if the product has quality problems, WUBEN will oﬀer free

repair.

15 days replacement: Within 15 days from the date of

purchase, if the product has quality problems, customers

can request free replacement.

1. Warranty coverage

Warranty policy

- 07 -

Problems

Abnormal

ﬂash or

failure

to turn on

Abnormal

noise

Check if the switch is

turned on correctly

Check if it is assembled

in place

Check if the battery is

no power

Check if the battery is

reversed

Check if the conductive

position is dirty

Check if foreign matter falls

in the tube

Part damage

Turn on the switch

Check if the ﬂashlight

is lockout Unlock the ﬂashlight

Tighten the assembly parts

Use the charger to check

the battery

Remove the battery and

reassemble it correctly

Clean the surface with

alcohol

Pour out possible foreign

matterl

Return the light to local

distributor

Causes Solutions

5 years warranty: Within 5 years from the date of

purchase, if the product (accessories excluded) has

quality problems, WUBEN will oﬀer free repair for WUBEN

registered customers.

Lifetime maintenance: From the date of purchase, if the

product has problem after 5 years, WUBEN will oﬀer paid

repair for WUBEN registered customers.

Battery warranty: WUBEN oﬀers a 1-year warranty for the

rechargeable batteries but other included accessories are

not covered by the warranty.

- 08 -

If proof of purchase cannot be provided, it will be

counted on the date of manufacture.

If there is any dispute, the two parties will coordinate to

solve.

The ﬁnal interpretation right is reserved by WUBEN.

Man-made damage.

Damage caused by not following the instructions.

Damage caused by improper use of the battery.

Abnormal wear and tear.

Damage caused by irresistible factors.

Gifts.

2. Beyond warranty

SHENZHEN SHENGQI LIGHTING TECHNOLOGY CO., LTD.

Add.: 202#, Building A, Jihe E-Business Park,

No. 33 Yangmei Road, Bantian Street,

Longgang District, Shenzhen, China

E-mail: info@wubenlight.com

Web: www.wubenlight.com

FacebookWUBEN website

Bevor Sie dieses Produkt verwenden, überprüfen Sie bitte,

ob der Inhalt der Verpackung vollständig ist.

Paketliste

Warnhinweise

Bitte lesen Sie die Bedienungsanleitung sorgfältig durch, bevor Sie

das Licht verwenden.

Das Produkt erzeugt während der Arbeit Wärme, bitte seien Sie

vorsichtig, um mögliche Schäden zu vermeiden.

Scheinen Sie bitte nicht direkt in die Augen, um Augenschäden zu

vermeiden.

Bitte halten Sie das Licht von Kindern fern.

Bitte verwenden Sie WUBEN oder WUBEN empfohlene Batterien.

Bitte zerlegen Sie das Licht nicht, da dies nicht durch die WUBEN

Garantiebestimmungen abgedeckt ist.

Bitte werfen Sie das Produkt nicht ins Feuer.

Dies ist kein Tauchprodukt, bitte verwenden Sie es längere Zeit

nicht unter Wasser.

- 09 -

26650 Li-Ionen-

Batterie × 1

Holster × 1T70 × 1

Ersatz-O-Ring × 2Schlüsselband × 1

4Type-C -Ladekabel

× 1

5 6

Karte mit manueller

Garantie, Qualitätszertiﬁkat × 1

2 3

1. Über das produkt

Produktbetrieb

- 10 -

3. Betriebsmethode

Start: Klicken Sie auf den Schalter, um die Taschenlampe

anzuzünden.

Moduseinstellung: Klicken Sie im eingeschalteten Zustand

auf den Schalter, um die Helligkeit der Taschenlampe zu

wählen: Turbo - High - Med - Low Zyklus.

Drücken und halten Sie den Schalter für 2 Sekunden, um

die Taschelampe auszuschalten.

Bitte entfernen Sie die Isolierplatte vor dem Einsatz.

Lampenkopf Lampenheck

Type-C

Ladeanschluss

2. Installation

Taste

( Batterieanzeige )
