Xilinx SmartLynq Plus Bedienungsanleitung
Table of Contents
Revision History...............................................................................................................2
Chapter 1: Overview......................................................................................................5
Features........................................................................................................................................5
Description................................................................................................................................... 5
Chapter 2: Connectors................................................................................................. 8
Host Side.......................................................................................................................................8
Target Side................................................................................................................................... 9
Front View.................................................................................................................................. 10
Chapter 3: Installing the SmartLynq+ Module.............................................11
Chapter 4: USB 3.0 Host Connection.................................................................. 12
Minimum Host System Requirements....................................................................................12
Default USB 3.0 IP Setting........................................................................................................ 12
Windows USB 3.0 Driver Setup................................................................................................13
Linux USB 3.0 Setup.................................................................................................................. 16
Changing the USB 3.0 IP Setting............................................................................................. 18
Chapter 5: Ethernet Connection...........................................................................19
Changing the Ethernet IP Settings..........................................................................................19
Chapter 6: SmartLynq+ Module Display.......................................................... 20
Chapter 7: JTAG Target Interface......................................................................... 21
Chapter 8: GPIO Target Interface........................................................................ 25
Chapter 9: HSDP Target Interface....................................................................... 28
Chapter 10: Parallel Debug Interface................................................................35
Appendix A: Regulatory and Compliance Information........................... 38
UG1514 (v1.0) March 8, 2021 www.xilinx.com
SmartLynq Module+ 3
Send Feedback
Appendix B: Additional Resources and Legal Notices............................. 39
Xilinx Resources.........................................................................................................................39
Documentation Navigator and Design Hubs.........................................................................39
References..................................................................................................................................39
Please Read: Important Legal Notices................................................................................... 40
UG1514 (v1.0) March 8, 2021 www.xilinx.com
SmartLynq Module+ 4
Send Feedback
Chapter 1
Overview
The Xilinx® SmartLynq+ Module is a high-speed debug and trace module, primarily targeng the
Versal™ adapve compute acceleraon plaorm (ACAP). It drascally improves conguraon and
trace speed. For trace capture, the SmartLynq+ module is capable of speeds up to 10 Gb/s by
means of its high-speed debug port (HSDP), which is 100 mes faster than standard JTAG. Faster
iteraons and repeve downloads increase development producvity and reduce the design
cycle.
Features
The SmartLynq+ Module provides the following features:
• Super-fast download speed, maximize development producvity for faster iteraons
• High-speed trace with enhanced visibility, up to 14 GB of trace memory for execuon history
• Full visibility for heterogeneous architectures, in-depth debug for Hard IP and Engines in
Versal ACAP
• Cohesive and me-related debug of all subsystems
• Flexible and smart debug plaorm with features such as smart ltering and a soware-
programmable built-in debugger
• Sharable debug plaorm with unied view for remote, mul-user environment
Note: The SmartLynq+ Module is not supported by Xilinx ISE® tools.
Description
The SmartLynq+ Module oers high-bandwidth connecvity to allow heterogenous system
debug and trace of Versal ACAP-based applicaons. It provides all of the desired connecons for
programming, debug and trace. JTAG can be a direct connecon with PC4 connector,
MICTOR-38 connector, or via USB-C when used along with HSDP.
Chapter 1: Overview
UG1514 (v1.0) March 8, 2021 www.xilinx.com
SmartLynq Module+ 5
Send Feedback
The contents of the SmartLynq+ Module kit are shown in the following gure.
Figure 1: SmartLynq+ Module Kit Contents
Physical Description
The SmartLynq+ module circuitry is housed in a plasc enclosure with an OLED display, as shown
in the following gure. The enclosure and heat sink assembly aenuates internally generated
emissions and protects against suscepbility to radiated emissions.
Chapter 1: Overview
UG1514 (v1.0) March 8, 2021 www.xilinx.com
SmartLynq Module+ 6
Send Feedback
Figure 2: SmartLynq+ Module
CAUTION! The SmartLynq+ module is designed to operate in the temperature range of 10°C to 26°C
(50°F to 80°F). Operang outside of this range might cause malfuncon or permanent damage to the
device.
Chapter 1: Overview
UG1514 (v1.0) March 8, 2021 www.xilinx.com
SmartLynq Module+ 7
Send Feedback
Chapter 2
Connectors
Connectors on the SmartLynq+ Module are located as follows.
Host Side
The DC power, USB 3.0, and Ethernet connectors are located on the le side of the SmartLynq+
Module, as shown in the following gure.
Figure 3: Host-Side Connections
Chapter 2: Connectors
UG1514 (v1.0) March 8, 2021 www.xilinx.com
SmartLynq Module+ 8
Send Feedback
Power to the SmartLynq+ Module is supplied by a 12V / 2A DC module connected to the Power
connector. Note that when the DC module is connected to the power connector, the SmartLynq+
Module turns on. The Ethernet connector is always acve when the cable is powered. When an
ethernet cable is connected to the SmartLynq+ module, the cable inializes the ethernet port and
a host can communicate with it by using the IP address shown on the display screen. The USB
3.0 is an alternate host interface that can be used for host communicaon. The USB 3.0 interface
is also acve upon power up and inializes on connecon to an acve USB connecon.
Target Side
The GPIO, JTAG, HSDP, and MICTOR connectors are on the right side of the SmartLynq+
Module, as shown in the following gure.
Figure 4: Target-Side Connections
For standard HSDP communicaon use the HSDP connector. Typically, this is the only
connecon required to a target board such as the Versal ACAP VCK190 evaluaon board. For
target boards without the HSDP connector use the 14 pin JTAG connector using a ribbon cable
or ying leads. The GPIO cable provides addional low-speed signals for controlling the target or
other instruments used alongside the board under test.
Chapter 2: Connectors
UG1514 (v1.0) March 8, 2021 www.xilinx.com
SmartLynq Module+ 9
Send Feedback
Front View
The reset pin, mode selector switch, and micro-SD card slot are located on the front of the
SmartLynq+ Module, as shown in the following gure.
Figure 5: Front View Connections
The SmartLynq+ Module MODE switch seng determines the source from which the module
boots. When the mode is set towards MICRO SD, the module boots using the SD card image.
When the MODE switch is set away from MICRO SD, the module boots from the EMMC image.
Note that you must have wrien an image to the eMMC for the system to boot properly.
Chapter 2: Connectors
UG1514 (v1.0) March 8, 2021 www.xilinx.com
SmartLynq Module+ 10
Send Feedback
