Xtracycle RFA 2021 Bedienungsanleitung
-
RFA assembly Manual 2021
02
Record the serial number and the Shimano key number
which can be found on the label on the side of the box. Keep
these numbers in a secure place since they might be needed
in case somethig happens to your bike or you lose your
Shimano key. The serial number is the number under the bar
code next to "Frame No:". For the RFA, this will start with RFA.
The key number is the number under the bar code next to
"Key No:".
01 - Open the bike box
Look over the box for signs of shipping damage. If damage
is present, please take pictures in case a shipping damage
report needs to be filed.
Assembling the
xtracycle rfa
2
Tools needed
3 mm Allen wrench
4 mm Allen wrench
5 mm Allen wrench
6 mm Allen wrench
Snippers / scissors for cutting zip ties
10 mm socket wrench
Pedal wrench
03
Cut away the yellow zip ties holding the box closed.
Please note: We show the bike being assembled in a
bike stand but the bike can be assembled without one.
If assembling your bike without a stand, be sure the bike
stays upright and is not turned upside down as this can
interfere with the function of the hydraulic brakes.
3
04
Open the box.
05
Inspect the contents and look again for any signs of shipping
damage.
06
Remove the small parts box, the RFA KickBack and the seat
post and set these aside.
07
Cut the string attaching the rear of the bike to the end of the
box.
4
08
Remove all of the packaging from the seat post and saddle.
With the bike still in the box, install the seat post into the
frame. Use a 5 mm Allen wrench to tighten the seat post
clamp and secure the seat post in place.
10 - Install the front wheel
The rear wheel comes pre-installed. The front wheel and
fender is zip tied to the bike frame. Cut these zip ties and
remove the wheel and fender.
09
Remove the bike from the box and secure it in your bike
stand.
11
Remove all padding and cardboard protection from the bike.
5
12
Remove the front axle from the front fork.
13
Install the front wheel onto the fork. Make sure the rotor rests
in between the brake pads. Reinstall the front axle using the
M6 Allen wrench.
14 - Install the RFA KickBack
Bring the KickBack up and under the RFA. The mounting
plate should be placed inside the two horizontal chainstays.
15
Place the KickBack so that the 2 ovalized holes on each side
line up with the bosses on the inside of the chain stay.
6
17
The reason for starting this off with just your fingers is to
insure that you do not cross thread the bolt since you may be
coming at it from a not ideal angle.
Once the first bolt is secured loosely, mount the second bolt
to the opposite front boss.
16
Place two washers on one of the M8 bolts. Starting on the
inside of the mounting plate and using just your fingers,
thread the bolt with the washers to the front boss until you
can not turn it any further. You should be able to thread the
bolt until you are certain it has engaged with the threaded
boss on the chainstay.
18
Make sure the holes in the mounting plate on the rear of the
KickBack line up with rear threaded bosses before tightening
all the way. Using the ball end of the Allen wrench, tighten the
two front bolts.
19
Place two washers on one of the M8 bolts. Starting on the
inside of the mounting plate and using just your fingers,
thread the bolt with the washers to the rear boss until you
can not turn it any further. Once the first bolt is secured
loosely, mount the second bolt to the opposite rear boss.
7
20
Using the ball end of the Allen wrench, tighten the two rear
bolts.
21
Using the shorter end of the Allen wrench, tightly secure all
bolts in place.
The RFA KickBack installation is now complete.
22 - Adjust the front light
To adjust the front light, first rotate the light so that it is front
facing.
23
Tighten the pivot bolts and secure the M6 bolt on the fender
with your 5 mm Allen wrench and 10 mm socket wrench.
8
24 - Adjust the stem and handlebars
You will now be adjusting the front stem and handlebars.
Loosen the stem bolts and rotate the stem to a forward
facing position.
25
Once the handlebars are straight, tighten down the stem
bolts to 4-6 Nm.
26
Loosen the stem faceplate bolts in order to center
handlebars onto the stem and to rotate them into the
upright position.
27
Rotate the handlebar grips into a comfortable upright
position and secure into place using a 3 mm Allen wrench.
9
28 - Connect the cycling computer
Place the wire hanging off the front of the handlebars into
the Shimano Cable Tool TL-EW300 which is located in the
small parts box. Holding the cable tool, connect the wire into
the handlebar computer.
29
You will hear a click when the wire has been attached
completely.
30
Tuck this wire into the wire wrap with the other cables to limit
the amount of wire dangling in front of the handlebars.
31 - Install the pedals
Identify the left (drive side) right (non-drive side) pedals by
the markings on the threaded axle. The drive side (the side
that the chain is on) is clockwise threaded, the non-drive
side is counter clockwise threaded. Install the pedals on the
appropriate side.
10
33
Using a 4mm Allen wrench, remove the top of the clamp
located on the back end of the FootRest. Keep the top of the
clamp and the hardware nearby.
32 - Install the RFA FootRests
Pick the RFA FootRest that corresponds to the side of the
bike you are installing it on. The flat plate is installed on the
bike frame towards the front of the bike and the clamping
ring is installed around the RearRack toward the rear of the
bike.
Right FootRest
Left FootRest
front
mounting
plate
rear
mounting
clamp
35
Locate the installation front threads on the bike frame.
34
To ensure the holes in the FootRest mounting plate line up
with the mounting holes in the frame, you will need to loosen
the bolts securing the RearRack to the frame. Using a 5 mm
Allen wrench, loosen these four bolts (two on each side).
There only needs to be a little bit of play in the rack. Do not
tighten these bolts down again until the FootRests are fully
installed.
