Xtreme P91 Leitfaden
P91 External Baery Pack
User & Installaon Manual
www.xpcc.com | © 2022 Xtreme Power Conversion Corporaon. All rights reserved. (Rev 10/12/22)
Xtreme Power Conversion Corporaon
P91 External Baery Pack User’s Manual
Page 2
Uninterrupble Power Supply
Important Safety Warnings
Please comply with all warnings and operang instrucons in this manual. Save this manual and read
carefully the following instrucons before installing the unit. Do not operate this unit before reading
through all safety informaon and operang instrucons carefully.
• Do not try to repair the unit yourself, contact your local supplier or your warranty will be void.
• To eliminate any overheang of the baery pack, keep all venlaon openings free from
obstrucon and do not place any foreign objects on top of the baery pack. Keep the baery pack
at least 8 inches away from the wall.
• Make sure the baery pack is installed within the proper environment as specied. (0-40°C and 30-
90% non-condensing humidity)
• Do not install the baery pack under direct sunlight. Your warranty will be void if the baeries fail
due to overheang.
• This baery pack is not designed for use in dusty, or corrosive environments.
• The warranty for this baery pack will be void if water or other liquid is spilled or poured directly
onto the baery pack. Similarly we do not warrant any damage to the baery pack if foreign objects
are deliberately or accidentally inserted into the baery pack enclosure.
• The baery will discharge naturally if the system is unused for a period of me.
• It should be recharged every 2-3 months if unused. If this is not done, then the warranty will be null
and void. During normal operaon, the baeries will be automacally charged.
• Servicing of baeries should be performed or supervised by trained personnel with knowledge of
baeries and the required precauons.
• When replacing baeries, it is necessary to replace ALL baeries with the same quanty, type &
capacity.
• CAUTION – Do not dispose of baery or baeries in a re. The baery may explode.
• CAUTION – Do not open or mulate the baeries. The electrolyte from the baeries is toxic and
harmful to the skin and eyes.
• CAUTION – Risk of Electric Shock –Hazardous voltage may exist between baery terminals and
ground.
• CAUTION – A baery can present a risk of electrical shock and high short circuit current. The
following precauon should be observed when working on baeries:
1. Remove watches, rings, or other metal objects.
2. Use tools with insulated handles.
3. Wear rubber gloves and boots.
4. Do not lay tools or metal parts on top of baeries.
5. Disconnect charging source prior to connecng or disconnecng baery terminals.
• Do not plug or unplug the baery connector if UPS is in DC (discharging) mode.
Xtreme Power Conversion Corporaon
P91 External Baery Pack User’s Manual
Page 3
Uninterrupble Power Supply
Product Overview and Setup
NOTE: Before installaon, please inspect the unit. Be sure that nothing inside the package is damaged.
Please keep the original packaging in a safe place for future use.
Rear Panel View
2U Battery Pack Rear Panel
3U Battery Pack Rear Panel
1. DC connector cable : connects to either UPS or additional battery pack
2. DC connection point for additional pattery pack
3. DC breaker: Battery over-current protection breaker
Xtreme Power Conversion Corporaon
P91 External Baery Pack User’s Manual
Page 4
Uninterrupble Power Supply
Installaon and Setup with UPS
Unpacking & Inspecon
1. Remove the baery pack from the packaging
Note: The baery pack is very heavy, be cauous when unpacking and liing the unit to avoid injury.
Selecng Installaon Posion
It is necessary to select a proper environment to install the unit, in order to minimize the possibility of damage to
the baery pack and extend the life of the baeries. Please follow the instrucons below:
1. Keep at least 20cm (8 inches) clearance from the rear panel of the unit to the wall or other obstrucons.
2. Do not block the air-ow to the venlaon openings of the unit.
3. Please ensure the installaon site environmental condions are in accordance with the unit’s working speci-
caons to avoid overheang and excessive moisture.
4. Do not place the unit in a dusty or corrosive environment or near any ammable objects.
5. This unit is not designed for outdoor use.
2. Check the inside package
• Battery pack unit
• Quick guide
• Battery connection cable x 1
• Ear x 2 & screw x 8
• Extended stand
Battery connection cable
Detection cable
Screws
Ears
Extended Stand
Xtreme Power Conversion Corporaon
P91 External Baery Pack User’s Manual
Page 5
Uninterrupble Power Supply
Rack Installaon
Tower Installaon
2U Battery Pack Rack Installation
3U Battery Pack Rack Installation
2U Battery Pack Tower Installation
3U Battery Pack Tower Installation
1. Install rack rails (supplied separately) into the rack.
2. Install mounting ears in accordinance with drawing below.
3. Slide battery pack onto rack rails and secure to rack with mounting ears.
1. Using the supplied extended stand, place the UPS and battery pack adjacent to each other in
the stand as shown in the drawing below.
Xtreme Power Conversion Corporaon
P91 External Baery Pack User’s Manual
Page 6
Uninterrupble Power Supply
Connecng with UPS and Other Baery Pack
Follow below installaon chart to connect with UPS and other baery pack with included cable.
Type of Baery Required
This baery pack has been designed to operate with the following types of baeries:
240V/9Ah Version: 20pieces of 12V 9Ah baeries
UPS
1st battery pack
2nd battery pack
2U Battery Pack
UPS
1st battery pack
2nd battery pack
3U Battery Pack
Xtreme Power Conversion Corporaon
P91 External Baery Pack User’s Manual
Page 7
Uninterrupble Power Supply
Wiring Diagram
3U Baery Pack 240V 2U Baery Pack 240V
front front
Storage & Maintenance
The unit contains no user-serviceable parts. If the baery service life (3~5 years at 25°C ambient temperature)
has been exceeded, the baeries must be replaced. In this case, please contact your dealer.
Storage
Before storing, charge the unit 4 hours. Store the unit covered and upright in a cool, dry locaon. During storage,
recharge the baery in accordance with the following table:
Storage Temperature Recharge Frequency Charging Duration
-25°C - 40°C Every 3 months 1-2 hours
40°C - 45°C Every 2 months 1-2 hours
