UPS Management
Introducon
Features
NetAgent is a new generaon SNMP (Simple Network Management Protocol) monitoring product. Not only
can you remotely control the UPS and get the current status of it, the SNMP-3PEX also can provide other func-
ons, such as connecng via Modem or GSM Modem to make monitoring possible when there is no permanent
internet connecon and send SMS nocaon . The SNMP-3PEX can also bee used to connect to SNMP-EMP, to
get the temperature, humidity and water condions. Smoke detector, gas detector, door and window detector
opons are also available.
This product is compable with Contact Closure and RS232 interface UPS. The communicaon protocol includes
the Contact Closure, RS232 [MegaTec], RS232 [Phoenixtec], SEC 2400, SEC 9600, Three Phase, Powerware, Smart
APC, EMERSON. User could also provide their own protocol to build in. NetAgent provides a simple and easy
installaon procedure. The CD included with the NetAgent cards oer several soware programs to allow the
user to congure IP address; central monitoring and mul client shutdown on dierent operang systems. Other
advance conguraons can be accomplished via a Web browser.
Features:
• Provide SNMP MIB to monitor & control UPS
• Auto-sense 10M/100M Fast Ethernet
• Manage and congure via Telnet, Web Browser or NMS
• Support TCP/IP, UDP, SNMP, Telnet, SNTP, PPP, HTTP, SMTP Protocol
• Providing easy setup and upgrade tools via MS-Windows, just a few seconds to nish IP seng, about
1.5 minutes to upgrade rmware.
• Send SNMP TRAP; E-mail and SMS for events nocaon.
• Auto email daily UPS history report
• Client shutdown soware for computer’s le saving and graceful shut down.
• SNMP-3PEX: Environment Measurement (Oponal Kits), External modem dial in/out via PPP protocol or
GSM/GPRS Modem
Applicaons
NetAgent Connects your UPS to the Network
When the UPS is equipped with a NetAgent Web/SNMP card, the system manager can monitor and check the
state of each and every UPS via a Web browser. The manager can monitor and control the UPS by simply brows-
ing the IP address of the NetAgent Web/SNMP card in to the UPS. When an abnormal power condion happens,
the NetAgent can also send trap informaon or an email to the system manager to take proper acon.
NetAgent Provides Shutdown Ulies
When a computer on the network has the NetAgent ulity installed, it can locate all of the NetAgent Web/SNMP
cards on the network. When the registered UPS of this NetAgent is in AC failure condion or Baery Low condi-
on, the operang system can close all the les on the system, and perform a gracefully shutdown. This could
avoid system corrupon when the UPS baery runs low.
NetAgent for Surrounding Monitoring
SNMP-3PEX can be used to connect the environmental monitoring ulity, SNMP-EMP, to get the temperature/
humidity/smoke/re indicaons. This informaon can also be displayed on the NetAgent Web page. When an
abnormal condion happens, it can also be sent as a trap to the system manager.
