OWNER’S MANUAL

EAU10041

5FB13.book Page 1 Monday, May 12, 2003 5:20 PM

INTRODUCTION

EAU10080

Congratulations on your purchase of the Yamaha XVS650/XVS650A/XVS650AT. This model is the re-

sult of Yamaha’s vast experience in the production of fine sporting, touring, and pacesetting racing ma-

chines. It represents the high degree of craftsmanship and reliability that have made Yamaha a leader

in these fields.

This manual will give you an understanding of the operation, inspection, and basic maintenance of this

motorcycle. If you have any questions concerning the operation or maintenance of your motorcycle,

please consult a Yamaha dealer.

The design and manufacture of this Yamaha motorcycle fully comply with the emissions standards for

clean air applicable at the date of manufacture. Yamaha has met these standards without reducing the

performance or economy of operation of the motorcycle. To maintain these high standards, it is impor-

tant that you and your Yamaha dealer pay close attention to the recommended maintenance schedules

and operating instructions contained within this manual.

5FB13.book Page 1 Monday, May 12, 2003 5:20 PM

IMPORTANT MANUAL INFORMATION

EAU10130

Particularly important information is distinguished in this manual by the following notations:

TE:

●This manual should be considered a permanent part of this motorcycle and should remain with it even if the motorcycle

is subsequently sold.

●Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most

current product information available at the time of printing, there may be minor discrepancies between your motorcycle

and this manual. If you have any questions concerning this manual, please consult your Yamaha dealer.

WARNING

EWA10010

PLEASE READ THIS MANUAL AND THE “YOU AND YOUR MOTORCYCLE: RIDING TIPS”BOOKLET CAREFULLY

AND COMPLETELY BEFORE OPERATING THIS MOTORCYCLE. DO NOT ATTEMPT TO OPERATE THIS MOTOR-

CYCLE UNTIL YOU HAVE ATTAINED ADEQUATE KNOWLEDGE OF ITS CONTROLS AND OPERATING FEATURES

AND UNTIL YOU HAVE BEEN TRAINED IN SAFE AND PROPER RIDING TECHNIQUES. REGULAR INSPECTIONS

AND CAREFUL MAINTENANCE, ALONG WITH GOOD RIDING SKILLS, WILL ENSURE THAT YOU SAFELY ENJOY

THE CAPABILITIES AND THE RELIABILITY OF THIS MOTORCYCLE.

The Safety Alert Symbol means ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!

Failure to follow WARNING instructions could result in severe injury or death to the motor-

cycle operator, a bystander or a person inspecting or repairing the motorcycle.

A CAUTION indicates special precautions that must be taken to avoid damage to the motor-

cycle.

A NOTE provides key information to make procedures easier or clearer.

WARNING

CAUTION:

NOTE:

5FB13.book Page 1 Monday, May 12, 2003 5:20 PM

IMPORTANT MANUAL INFORMATION

EAU10191

XVS650S/XVS650AS/XVS650ATS

OWNER’S MANUAL

U.S.A.

1st edition, April 2003

Any reprinting or unauthorized use

without the written permission of

Yamaha Motor Corporation, U.S.A.

is expressly prohibited.

Printed in Japan.

P/N LIT-11626-17-26

AFFIX DEALER

LABEL HERE

5FB13.book Page 2 Monday, May 12, 2003 5:20 PM

TABLE OF CONTENTS

SAFETY INFORMATION ..................1-1

Location of important labels ............1-5

DESCRIPTION ..................................2-1

Left view ..........................................2-1

Right view ........................................2-3

Controls and instruments.................2-5

INSTRUMENT AND CONTROL

FUNCTIONS .......................................3-1

Main switch/steering lock ................3-1

Indicator and warning lights ............3-2

Speedometer unit ...........................3-2

Handlebar switches ........................3-3

Clutch lever .....................................3-4

Shift pedal (XVS650) .......................3-4

Shift pedal (XVS650A/AT) ...............3-4

Brake lever .....................................3-5

Brake pedal ....................................3-5

Fuel tank cap ..................................3-5

Fuel .................................................3-6

Fuel cock ........................................3-7

Starter (choke) knob .......................3-8

Seats (XVS650)...............................3-8

Seats (XVS650A/AT) ......................3-9

Helmet holder ...............................3-10

Storage compartment ...................3-11

Adjusting the shock absorber

assembly ...................................3-12

Luggage strap holders ..................3-13

Sidestand ......................................3-13

Ignition circuit cut-off system ........ 3-14

PRE-OPERATION CHECKS ............. 4-1

Pre-operation check list .................. 4-2

OPERATION AND IMPORTANT

RIDING POINTS................................. 5-1

Starting and warming up a cold

engine ......................................... 5-1

Starting a warm engine .................. 5-2

Shifting ........................................... 5-3

Engine break-in .............................. 5-4

Parking ........................................... 5-5

PERIODIC MAINTENANCE AND

MINOR REPAIR ................................. 6-1

PERIODIC MAINTENANCE ........... 6-1

Owner’s tool kit ............................... 6-1

Periodic maintenance chart for

the emission control system ....... 6-3

General maintenance and

lubrication chart .......................... 6-4

Removing and installing

panels ......................................... 6-8

Checking the spark plugs ............... 6-9

Engine oil and oil filter

element ..................................... 6-11

Final gear oil ................................. 6-13

Cleaning the air filter element ...... 6-14

Adjusting the carburetors ............. 6-15

Adjusting the throttle cable

free play .................................... 6-15

Adjusting the valve clearance ...... 6-16

Tires ............................................. 6-16

Spoke wheels .............................. 6-18

Accessories and replacement

parts ......................................... 6-18

Adjusting the clutch lever

free play .................................... 6-19

Adjusting the brake lever

free play .................................... 6-20

Adjusting the brake pedal

position and free play ............... 6-21

Adjusting the rear brake light

switch ....................................... 6-22

Checking the front brake pads

and rear brake shoes ............... 6-23

Checking the brake fluid level ...... 6-23

Changing the brake fluid .............. 6-24

Checking and lubricating the

cables ....................................... 6-25

Checking and lubricating the

throttle grip and cable ............... 6-25

Checking and lubricating the

brake and shift pedals .............. 6-25

Checking and lubricating the

brake and clutch levers ............ 6-26

Checking and lubricating the

sidestand .................................. 6-26

Checking the front fork ................. 6-26

Checking the steering .................. 6-27

5FB13.book Page 1 Monday, May 12, 2003 5:20 PM

TABLE OF CONTENTS

Checking the wheel bearings .......6-28

Battery ..........................................6-28

Replacing the fuses ......................6-29

Replacing the headlight bulb ........6-30

Replacing a turn signal light bulb

or the tail/brake light bulb ..........6-32

Supporting the motorcycle ............6-32

Front wheel ...................................6-33

Rear wheel ...................................6-34

Troubleshooting ............................6-36

Troubleshooting chart ...................6-37

MOTORCYCLE CARE AND

STORAGE ..........................................7-1

Care ................................................7-1

Storage ...........................................7-3

SPECIFICATIONS .............................8-1

CONSUMER INFORMATION.............9-1

Identification numbers ....................9-1

Reporting safety defects .................9-3

Motorcycle noise regulation ............9-4

Maintenance record ........................9-5

YAMAHA MOTOR CORPORATION,

U.S.A. STREET AND ENDURO

MOTORCYCLE LIMITED

WARRANTY ...............................9-7

YAMAHA EXTENDED SERVICE

(Y.E.S.) .......................................9-9

5FB13.book Page 2 Monday, May 12, 2003 5:20 PM

1-1

SAFETY INFORMATION

EAU10250

MOTORCYCLES ARE SINGLE

TRACK VEHICLES. THEIR SAFE USE

AND OPERATION ARE DEPENDENT

UPON THE USE OF PROPER RIDING

TECHNIQUES AS WELL AS THE EX-

PERTISE OF THE OPERATOR. EV-

ERY OPERATOR SHOULD KNOW

THE FOLLOWING REQUIREMENTS

BEFORE RIDING THIS MOTOR-

CYCLE.

HE OR SHE SHOULD:

●OBTAIN THOROUGH INSTRUC-

TIONS FROM A COMPETENT

SOURCE ON ALL ASPECTS OF

MOTORCYCLE OPERATION.

●OBSERVE THE WARNINGS AND

MAINTENANCE REQUIRE-

MENTS IN THE OWNER’S MAN-

UAL.

●OBTAIN QUALIFIED TRAINING

IN SAFE AND PROPER RIDING

TECHNIQUES.

●OBTAIN PROFESSIONAL TECH-

NICAL SERVICE AS INDICATED

BY THE OWNER’S MANUAL

AND/OR WHEN MADE NECES-

SARY BY MECHANICAL CONDI-

TIONS.

Safe riding

●Always make pre-operation

checks. Careful checks may help

prevent an accident.

●This motorcycle is designed to car-

ry the operator and a passenger.

●The failure of motorists to detect

and recognize motorcycles in traf-

fic is the predominating cause of

automobile/motorcycle accidents.

Many accidents have been caused

by an automobile driver who did

not see the motorcycle. Making

yourself conspicuous appears to

be very effective in reducing the

chance of this type of accident.

Therefore:

•Wear a brightly colored jacket.

•Use extra caution when ap-

proaching and passing through

intersections, since intersec-

tions are the most likely places

for motorcycle accidents to oc-

cur.

•Ride where other motorists can

see you. Avoid riding in another

motorist’s blind spot.

●Many motorcycle accidents in-

volve inexperienced operators. In

fact, many operators who have

been involved in accidents do not

even have a current motorcycle li-

cense.

•Make sure that you are qualified

and that you only lend your

motorcycle to other qualified op-

erators.

•Know your skills and limits.

Staying within your limits may

help you to avoid an accident.

•We recommend that you prac-

tice riding your motorcycle

where there is no traffic until you

have become thoroughly famil-

iar with the motorcycle and all of

its controls.

●Many motorcycle accidents have

been caused by error of the motor-

cycle operator. A typical error

made by the operator is veering

5FB13.book Page 1 Monday, May 12, 2003 5:20 PM

SAFETY INFORMATION

1-2

wide on a turn due to EXCESSIVE

SPEED or undercornering (insuffi-

cient lean angle for the speed).

•Always obey the speed limit and

never travel faster than warrant-

ed by road and traffic conditions.

•Always signal before turning or

changing lanes. Make sure that

other motorists can see you.

●The posture of the operator and

passenger is important for proper

control.

•The operator should keep both

hands on the handlebar and

both feet on the operator foot-

rests during operation to main-

tain control of the motorcycle.

•The passenger should always

hold onto the operator, seat

strap, or grab bar, if equipped,

with both hands and keep both

feet on the passenger footrests.

•Never carry a passenger unless

he or she can firmly place both

feet on the passenger footrests.

●Never ride under the influence of

alcohol or other drugs.

●This motorcycle is designed for on-

road use only, therefore, it is not

suitable for off-road use.

Protective apparel

The majority of fatalities from motor-

cycle accidents are the result of head

injuries. The use of a safety helmet is

the single most critical factor in the pre-

vention or reduction of head injuries.

●Always wear an approved helmet.

●Wear a face shield or goggles.

Wind in your unprotected eyes

could contribute to an impairment

of vision which could delay seeing

a hazard.

●The use of a jacket, heavy boots,

trousers, gloves, etc., is effective in

preventing or reducing abrasions

or lacerations.

●Never wear loose-fitting clothes,

otherwise they could catch on the

control levers, footrests, or wheels

and cause injury or an accident.

●Never touch the engine or exhaust

system during or after operation.

They become very hot and can

cause burns. Always wear protec-

tive clothing that covers your legs,

ankles, and feet.

●Passengers should also observe

the precautions mentioned above.

Modifications

Modifications made to this motorcycle

not approved by Yamaha, or the re-

moval of original equipment, may ren-

der the motorcycle unsafe for use and

may cause severe personal injury.

Modifications may also make your

motorcycle illegal to use.

Loading and accessories

Adding accessories or cargo to your

motorcycle can adversely affect stabili-

ty and handling if the weight distribution

of the motorcycle is changed. To avoid

the possibility of an accident, use ex-

treme caution when adding cargo or

accessories to your motorcycle. Use

extra care when riding a motorcycle

that has added cargo or accessories.

Here are some general guidelines to

follow if loading cargo or adding acces-

sories to your motorcycle:

5FB13.book Page 2 Monday, May 12, 2003 5:20 PM

SAFETY INFORMATION

1-3

The total weight of the operator, pas-

senger, accessories and cargo must

not exceed the maximum load limit of

XVS650 180.0 kg (397 lb)

XVS650A 200.0 kg (441 lb)

XVS650AT 200.0 kg (441 lb). When

loading within this weight limit, keep the

following in mind:

●Cargo and accessory weight

should be kept as low and close to

the motorcycle as possible. Make

sure to distribute the weight as

evenly as possible on both sides of

the motorcycle to minimize imbal-

ance or instability.

●Shifting weights can create a sud-

den imbalance. Make sure that ac-

cessories and cargo are securely

attached to the motorcycle before

riding. Check accessory mounts

and cargo restraints frequently.

●Never attach any large or heavy

items to the handlebar, front fork,

or front fender. These items, in-

cluding such cargo as sleeping

bags, duffel bags, or tents, can

create unstable handling or slow

steering response.

Accessories

Genuine Yamaha accessories have

been specifically designed for use on

this motorcycle. Since Yamaha cannot

test all other accessories that may be

available, you must personally be re-

sponsible for the proper selection, in-

stallation and use of non-Yamaha

accessories. Use extreme caution

when selecting and installing any ac-

cessories.

Keep the following guidelines in mind,

as well as those provided under “Load-

ing”when mounting accessories.

●Never install accessories or carry

cargo that would impair the perfor-

mance of your motorcycle. Care-

fully inspect the accessory before

using it to make sure that it does

not in any way reduce ground

clearance or cornering clearance,

limit suspension travel, steering

travel or control operation, or ob-

scure lights or reflectors.

•Accessories fitted to the handle-

bar or the front fork area can

create instability due to improper

weight distribution or aerody-

namic changes. If accessories

are added to the handlebar or

front fork area, they must be as

lightweight as possible and

should be kept to a minimum.

•Bulky or large accessories may

seriously affect the stability of

the motorcycle due to aerody-

namic effects. Wind may at-

tempt to lift the motorcycle, or

the motorcycle may become un-

stable in cross winds. These ac-

cessories may also cause

instability when passing or being

passed by large vehicles.

•Certain accessories can dis-

place the operator from his or

her normal riding position. This

improper position limits the free-

dom of movement of the opera-

tor and may limit control ability,

therefore, such accessories are

not recommended.

●Use caution when adding electri-

cal accessories. If electrical acces-

sories exceed the capacity of the

motorcycle’s electrical system, an

electric failure could result, which

could cause a dangerous loss of

lights or engine power.

5FB13.book Page 3 Monday, May 12, 2003 5:20 PM

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Yamaha Motorrad Handbücher

Yamaha

Yamaha CRYPTON T110C Bedienungsanleitung

Yamaha

Yamaha Star XV250H 2016 Bedienungsanleitung

Yamaha

Yamaha XN125 2000 Bedienungsanleitung

Yamaha

Yamaha 2008 Fazer FZ1-N Bedienungsanleitung

Yamaha

Yamaha TDM TWIN 900 Bedienungsanleitung

Yamaha

Yamaha VIRAGO XV250V Bedienungsanleitung

Yamaha

Yamaha YZ250F 2016 Anwendungshandbuch

Yamaha

Yamaha Road Star XV1600AT 2004 Bedienungsanleitung

Yamaha

Yamaha V Star xvs1100n(c) Bedienungsanleitung

Yamaha

Yamaha YZ450F Anwendungshandbuch

Yamaha

Yamaha FAZER FZS600 Bedienungsanleitung

Yamaha

Yamaha YZ250F(R) Anwendungshandbuch

Yamaha

Yamaha 2002 FJR1300 Handbuch

Yamaha

Yamaha Rhino YXR66FAV 2006 Bedienungsanleitung

Yamaha

Yamaha 2008 YW50X Bedienungsanleitung

Yamaha

Yamaha YZFR6A Bedienungsanleitung

Yamaha

Yamaha YZ85(A) Bedienungsanleitung

Yamaha

Yamaha TT-R230 Bedienungsanleitung

Yamaha

Yamaha MX360 Handbuch

Yamaha

Yamaha DRAG STAR XVS1100A Bedienungsanleitung

Yamaha

Yamaha FAZER FZ1-S Bedienungsanleitung

Yamaha

Yamaha YZF-R1P 2001-2003 Bedienungsanleitung

Yamaha

Yamaha XT1200Z 2010 Bedienungsanleitung

Yamaha

Yamaha 1992 FJ1200 Bedienungsanleitung

Beliebte Motorrad Handbücher anderer Marken

OHVALE

OHVALE GP-0 Stücklistenhandbuch

KTM

KTM 350 XCF-W USA Bedienungsanleitung

HYOSUNG

HYOSUNG ST7 Bedienungsanleitung

Husqvarna

Husqvarna FC 250 2016 Bedienungsanleitung

Ducati

Ducati SCRAMBLER 800 Gebrauchsanweisung

MOTO GUZZI

MOTO GUZZI QUOTA 1100 ES Bedienungsanleitung

APRILIA

APRILIA ETV MILLE CAPONORD - PART1 02-2001 Bedienungsanleitung

KTM

KTM Freeride E-XC 2021 Bedienungsanleitung

Fantic

Fantic Enduro 125 Bedienungsanleitung

Ducati

Ducati Supersport 750 desmodue Bedienungsanleitung

MV Agusta

MV Agusta 2008 F4 312RR 1078 Gebrauchsanweisung

Ducati

Ducati 748 monoposto strada Bedienungsanleitung

ATK

ATK 1988 250 Bedienungsanleitung

Excelsior-HENDERSON

Excelsior-HENDERSON 1999 HCX Bedienungsanleitung

Triumph

Triumph Thunderbird Bedienungsanleitung

Ducati

Ducati 996 Bedienungsanleitung

BMW

BMW MOTORRAD K 1200 R Sport Installations- und Wartungshandbuch

BMW Motorrad

BMW Motorrad G 650 GS 2007 Installations- und Wartungshandbuch
