OWNER’S MANUAL

60H-9-E1 Hyoshi 4/9/02 1:09 PM Page 1 (2,1)

67K-9-14-1 2/28/02 11:23 AM Page 2

EMU01449

TO THE OWNER

Thank you for choosing a Yamaha outboard

motor. This Owner s manual contains infor-

mation needed for proper operation, main-

tenance and care. A thorough understand-

ing of these simple instructions will help you

obtain maximum enjoyment from your new

Yamaha. If you have any question about

the operation or maintenance of your out-

board motor, please consult a Yamaha

dealer.

In this Owner s Manual particularly impor-

tant information is distinguished in the fol-

lowing ways.

QThe Safety Alert Symbol means

ATTENTION! BECOME ALERT!

YOUR SAFETY IS INVOLVED!

Failure to follow WARNING instructions

could result in severe injury or death to

the machine o erator, a bystander, or a

erson ins ecting or re airing the out-

board motor.

A CAUTION indicates s ecial recau-

tions that must be taken to avoid dam-

age to the outboard motor.

NOTE:

A NOTE provides key information to make

procedures easier or clearer.

* Yamaha continually seeks advancements

in product design and quality. Therefore,

while this manual contains the most cur-

rent product information available at the

time of printing, there may be minor dis-

crepancies between your machine and

this manual. If there is any question con-

cerning this manual, please consult your

Yamaha dealer.

NOTE:

The E115AE, E115AMH, E115AWH,

200AET, L200AET, and their standard

accessories are used as a base for the

explanations and illustrations in this manu-

al. Therefore, some items may not apply to

every model.

EMU01447

E115A, 115B, 140B, 150A, L150A,

175A, 200A, L200A

OWNER’S MANUAL

1st Edition, March 2002

Any re rinting or unauthorized use

without the written ermission of

Yamaha Motor Co., Ltd.

is ex ressly rohibited.

Printed in Ja an

60H-9-E1-1 3/1/02 9:25 PM Page 1

60H-9-E1-1 3/1/02 9:25 PM Page 2

GENERAL INFORMATION

BASIC COMPONENTS

OPERATION

MAINTENANCE

TROUBLE RECOVERY

INDEX

EMU00003

CONTENTS E

READ THIS OWNER’S MANUAL CAREFULLY

BEFORE OPERATING YOUR OUTBOARD MOTOR.

60H-9-E1-1 3/1/02 9:25 PM Page 3

60H-9-E1-1 3/1/02 9:25 PM Page 4

EMU00004

Cha ter 1

GENERAL

INFORMATION

IDENTIFICATION NUMBERS

RECORD ............................................... 1-1

Outboard motor serial number ............ 1-1

Key number ........................................ 1-1

LABELS ................................................ 1-2

EC label .............................................. 1-2

EPA label ............................................ 1-2

EMISSION CONTROL

INFORMATION ..................................... 1-3

SAFETY INFORMATION ...................... 1-4

FUELING INSTRUCTIONS ................... 1-6

Gasoline............................................... 1-7

Engine oil ............................................ 1-7

BATTERY REQUIREMENT .................. 1-8

PROPELLER SELECTION .................... 1-8

START-IN-GEAR PROTECTION .......... 1-9

60H-9-E1-1 3/4/02 11:30 AM Page 5

1-1

YAMAHA MOTOR CO., LTD.

MADE IN JAPAN

PAYS D'ORIGINE JAPON

401012

000319

123

YAMAHA

EMU00005

IDENTIFICATION NUMBERS

RECORD

EMU00007

OUTBOARD MOTOR SERIAL

NUMBER

The outboard motor serial number is

stamped on the label attached to the port

side of the clamp-bracket.

Record your outboard motor serial number

in the spaces provided to assist you in

ordering spare parts from your Yamaha

dealer or for reference in case your out-

board motor is stolen.

1Outboard motor serial number

EMU00008

KEY NUMBER

If a main key switch is equipped with the

motor, the key identification number is

stamped on your key as shown in the illus-

tration. Record this number in the space

provided for reference in case you need a

new key.

1Key number

60H-9-E1-1 3/1/02 9:25 PM Page 6

1-2

EMU01532

LABELS

EMU01526

EC LABEL

Engines affixed with this label conform to

certain portions of the European Parliament

directive relating to machinery. Refer to the

label and the EC Declaration of Conformity

for more details.

EMU01527

EPA LABEL

Engines affixed with this label conform to

U.S. Environmental Protection Agency

(EPA) regulations for marine SI engines.

Refer to the label for more details.

000769

YAMAHA MOTOR CO.,LTD.

2500 SHINGAI,IWATA,

SHIZUOKA,JAPAN

NOMINAL POWER

MASS

EMISSION CONTROL INFORMATION

ENGINE FAMILY :

THIS ENGINE CONFORMS TO 2001 U.S. EPA REGULATIONS FOR MARINE SI ENGINES.

FELs :

SPARK PLUG :

IDLE SPEED : rpm IN NEUTRAL

SPARK PLUG GAP (mm) :

g/kw-hr

000762

60H-9-E1-1 3/1/02 9:25 PM Page 7

1-3

EMU01385

EMISSION CONTROL

INFORMATION

EMU01390

U.S. INSULAR AREAS

Engines affixed with the label pictured

below conform to U.S. Environmental

Protection Agency (EPA) regulations for

marine SI engines. See the label affixed to

your engine for details.

1Emission control information label

A roval label of Emission control cer-

tificate

This label is attached to the bottom cowling.

Existing Technology ; N/A

001336

EMISSION CONTROL INFORMATION

ENGINE FAMILY :

THIS ENGINE CONFORMS TO 2001 U.S. EPA REGULATIONS FOR MARINE SI ENGINES.

FELs :

SPARK PLUG :

IDLE SPEED : rpm IN NEUTRAL

SPARK PLUG GAP (mm) :

g/kw-hr

000762

Manufactured:

2Manufactured date label

Manufactured date label

This label is attached to the clamp bracket

or the swivel bracket.

60H-9-E1-1 3/1/02 9:25 PM Page 8
