Yard force YF7302 Bedienungsanleitung







IMPORTANT: This manual provides complete instructions for safely operating and

maintaining your Edger. Read and save these instructions. Refer to this manual each

time before using your Edger. Keep this manual for future reference.

WARNING:

This product contains one or more chemicals known to the State of California to cause

cancer and birth defects or other reproductive harm. Wash hands after handling.



SAFETY DEFINITIONS……………………………………………...............…….…..3

IMPORTANT SAFETY INFORMATION………………………...............……………5

PRODUCT SPECIFICATIONS……………………………….............……………….9

PARTS & FEATURES……………………………………………...............………….10

ASSEMBLY………………………………………………….................………………11

ENGINE PREPARATION………………………………………...............…………..13

OPERATION……………………………………………………...............…………...15

MAINTENANCE……………………………………………………...............……….18

TROUBLESHOOTING…………………………………………..........………………23

WARRANTY…………………………………………………………...........………….24

EMISSION CONTROL SYSTEM WARRANTY…………………...........…………..27





The following symbols are used on the product and in this manual to alert the

operator of potential safety hazards. Read them carefully, and understand their

meaning.

 Indicates an imminently hazardous situation which, if not

avoided, will result in death or serious injury.

Indicates a potentially hazardous situation which, if not

avoided, could result in death or serious injury.

Indicates a potentially hazardous situation which, if not

avoided, may result in minor/moderate injury or equipment/property

damage.

The following symbols can be found on your edger. Carefully read and

understand their meaning.



Indicates

WARNING,

DANGER, or

CAUTION.

Wear eye protection

complying with ANSI

Z87.1 and hearing

protection.

Read operator’s

manual before

operating this

machine. Failure

to follow directions

could result in

serious injury.

Disconnect spark plug

wire when not in use

or before servicing,

cleaning, or performing

maintenance on the

unit.

Thrown objects.

Remove all rocks,

stones, and foreign

objects which

could be thrown by

machine

Engine exhaust

contains carbon

monoxide, an odorless

and deadly gas. NEVER

run unit indoors or in a

poorly ventilated area.

Do not use

if children or

bystanders are

present.

Do NOT touch hot

mufer or cylinder.

These parts are

extremely hot from

opera¬tion and may

remain hot for a short

time after operation.

Rotating parts

can cause serious

injury. Keep hands

and feet away.

To reduce risk of re,

clean spilled gas and

oil and keep unit free

from debris. Gasoline

is extremely ammable.

Allow machine to cool

before refueling.



Oil Fill Location

Do Not Overll

Gasoline Fill Location

Depth Control

Lever START

Position is

the furthest

FORWARD

position Move lever

REARWARD to

increase cutting

depth

Start Lever

Release lever to stop

engine

Engage lever to start/

run engine

Choke/Cold Start Run/Warm Start

Always check that

the ground wires

are connected

before running the

unit





1. Carefully read and follow these safety instructions. Failure to do so can result

in serious injury.

2. Know your product. Read and understand this manual before use. Compare

the illustrations to unit. Learn location and function of all controls. Thoroughly

understanding the unit before use will result in the best performance and

safety.

3. Follow all instructions when assembling the unit. If the unit was purchased in

assembled condition, the operator must check the unit carefully to make sure

it was assembled according the instructions in the manual before use.

4. Regularly inspect the edger. Make sure parts are not bent, damaged, or

loose.

5. Use this equipment for its intended purpose only.

6. Operate the unit only with guards, shields, and other safety items in place

and working correctly.

7. Service the unit only with authorized or approved replacement parts.

8. Complete all unit maintenance and adjustments according to the instruction

in this manual.



Look for this symbol to point out important safety precautions. It means: “

Attention! Become Alert! Your Safety Is Involved.”



Engine exhaust, some of its constituents, and certain vehicle

components contain or emit chemicals known to the State of California to

cause cancer and birth defects or other reproductive harm.



To prevent accidental starting when setting up, transporting, adjusting or

making repairs, always disconnect spark plug wire and put wire where it

cannot contact the spark plug.





• Read, understand, and follow all instructions on the machine and in

this manual. Be thoroughly familiar with the controls and the proper use

of the edger before starting. Know how to stop the engine quickly.

• Familiarize yourself with all the safety and operating decals on this

equipment.



• Thoroughly inspect the area where the edger is to be used and remove

all foreign objects. Your equipment can propel small objects at high

speed causing personal injury or property damage. Stay away from

breakable objects, such as house windows, auto glass, greenhouses,

etc.

• Check that all nuts and bolts are tight and equipment is in good

condition.



• Always check that the ameout wire is connected before starting

engine.





• Never allow children or young teenagers to operate the edger.



• Keep area of operation clear of all bystanders, particularly small

children and pets.

• Only allow responsible individuals, who are familiar with the

instructions, to operate the edger.



• Do not operate the edger while under the inuence of alcohol, drugs,

or other medication which can cause drowsiness or affect your ability

to operate this machine safely.

• Do not use this machine if you are mentally or physically unable to

operate the machine safely.

• Always wear ANSI compliant safety goggles or safety glasses with side

shields when operating edger to protect your eyes from foreign objects,

which can be thrown from the unit.

• Wear appropriate clothing such as a long sleeved shirt or jacket. Also

wear long trousers or slacks. Do NOT wear shorts. Do NOT wear loose

clothing, which could get caught in this equipment.

• Always wear work gloves and sturdy footwear such as leather work

shoes or short boots. These will protect ankles and shins from small

sticks, splinters, and other ying debris, and improve traction.

• It is advisable to wear protective headgear to protect against being

struck by small ying particles, or being struck by low hanging

branches, twigs, or other objects, which may be unnoticed by the

operator.



• Do not put hands or feet near or under rotating parts.

• Exercise extreme caution when operating on or crossing gravel drives,

walks, or roads. Stay alert for hidden hazards or trafc.



• Exercise caution to avoid slipping or falling. Always be sure of your

footing; keep a rm hold on the handle and walk; never run. Never

operate the edger at high transport speeds on slippery surfaces.

• Look behind and use care when backing.

• Never operate the edger without good visibility or light.



• Do not run the engine indoors or inside a closed area. The exhaust

fumes are dangerous, containing CARBON MONOXIDE, an

ODORLESS AND DEADLY GAS.

• Never leave the edger unattended when the engine is running. Stop

the engine and make sure all moving parts have stopped. Remove the

wire from the spark plug.

• Do not overload the edger capacity by attempting to till too deep at too

fast a rate.

• If the edger should start to vibrate abnormally, stop the engine,

disconnect the spark plug wire and prevent it from touching the spark

plug. Check immediately for the cause. Vibration is generally a warning

of trouble.

• Watch for holes, ruts, bumps, or other rough ground. Tall grass can

hide obstacles.





• Gasoline is extremely ammable, and gasoline vapors can explode if

ignited. Handle with care.

• Use an approved container.

• Check fuel supply before each use, allowing space for expansion as

the heat of the engine and/or sun can cause fuel to expand.

• Fill fuel tank outdoors with extreme care. Never ll fuel tank indoors.

• Never remove gas cap or add fuel with the engine running. Allow

engine to cool before refueling.



• Do not smoke while refueling.

• After refueling, replace fuel tank cap securely and wipe up spilled fuel.

• Never store fuel or edger with fuel in the tank inside a building where

fumes may reach an open ame.





• Always refer to the operator’s manual instructions for important details

if the edger is to be stored for an extended period.

• Never store the edger with fuel in the fuel tank inside a building where

ignition sources are present such as water heaters, space heaters,

clothes dryers, etc.

• To reduce re hazard, keep edger free of grass, leaves, or other debris

build-up.

• Allow the engine to cool before storing in any enclosure.





• After striking a foreign object, stop the engine. Remove the wire

from the spark plug and keep the wire away from the plug to prevent

accidental starting. Thoroughly inspect the edger for any damage. If

damaged, have the equipment repaired by a trained technician before

restarting and operating.

• Stop the engine before cleaning, repairing, or inspecting the unit. Make

sure all moving parts have stopped. Let the engine cool, disconnect

the spark plug wire and move it away from the spark plug.

• Never attempt to make any adjustments while the engine is running

except when specically recommended by the manufacturer.

• Keep the edger in safe working condition. Check all fasteners at

frequent intervals for proper tightness.

• When servicing or repairing the edger, do not tip the machine over or

up unless specically instructed to do so in this Manual. Service and

repair procedures can be done with the edger in an upright position.

Some procedures will be easier if the machine is lifted on a raised

platform or working surface.

• Use only original equipment or authorized replacement parts.



• Never tamper with safety devices. Check their proper operation

regularly.

• Do not change the engine governor setting or over-speed engine.

• Clean and replace safety and instruction decals as necessary.

• To guard against engine over-heating, always have engine debris lter

mounted and clean.





• Tragic accidents can occur if the operator is not alert to the presence

of children. Children are often attracted to the edger and the edging

activity.

• Keep children out of the edging area and under the watchful care of a

responsible adult.

• Never assume that children will remain where you last saw them.

• Be alert and turn edger off if children enter the area.

• Before and while moving backwards, look behind and down for small

children.

• Never allow children to operate the edger.

• Use extra care when operating near blind corners, shrubs, trees, or

other objects that may obstruct vision.



Unit Weight.....................................................................................50.3 lb. (22.8kg)

Cutting Depths.............................................................-2 1/2 - 3/4 in. (-63 - 20 mm)

Blade Diameter.....................................................................9 in. (228 mm), 2 point

Gasoline Capacity.................................................................................1.7 qt. (1.6L)

Oil Type (API SG-SL) 10W-30 is recommended for all service temperatures. See

page 7 for additional information.

Oil Capacity........................................................................................12 oz (355 ml)

Spark Plug Model................................................................................Torch E7RTC

Spark Plug Gap...........................................................0.024-0.028 in. (0.6-0.7 mm)

Engine Type........................................................................................4 Stroke OHV

Displacement.....................................................................................................79cc

RPM ........................................................................................................3600 RPM

Torque Rating.........................................................3.5 ft-lbs torque per SAE J1940



  Lever on handle which allows the engine to run. When lever is

released, engine will stop.

 Restricts the air intake. This allows for an enriched fuel-air

mixture which helps to start the engine.

  Location of engine exhaust.

  The engine is equipped with an easy pull recoil

starter.

  Rotating cutting element.

  Prevents stones and debris from being thrown at the operator.

  Provides spark to ignite air/ fuel mixture. The

Spark Plug Wire must be disconnected and moved away from the Spark Plug

when servicing the unit.

  Removes debris and contaminates from intake air, allowing engine

to run smoothly with low exhaust.

 

 

  Used to control the edging depth of cut.

  Must be connected for the Start Lever to function.

Inhaltsverzeichnis

Andere Yard force Rasenmäher Handbücher

Yard force

Yard force NX 60i Bedienungsanleitung

Yard force

Yard force NX 60i Bedienungsanleitung

Yard force

Yard force YF21-SD-TW Bedienungsanleitung

Yard force

Yard force X50i Firmware-Update

Yard force

Yard force GM A46 Bedienungsanleitung

Yard force

Yard force HM A30 Bedienungsanleitung

Yard force

Yard force SA650B Bedienungsanleitung

Yard force

Yard force Y0LMX21P300 Bedienungsanleitung

Yard force

Yard force YF22-3N1SP-SC Bedienungsanleitung

Yard force

Yard force MB 400 Firmware-Update

Yard force

Yard force LM G46D Bedienungsanleitung

Yard force

Yard force YF22-2N1 Bedienungsanleitung

Yard force

Yard force YF56vRX-RER38-Li50 Bedienungsanleitung

Yard force

Yard force LM G40B Bedienungsanleitung

Yard force

Yard force YF-SC600ECO Bedienungsanleitung

Yard force

Yard force GM B41A Bedienungsanleitung

Yard force

Yard force GR40 Bedienungsanleitung

Yard force

Yard force AMIRO 350 Bedienungsanleitung

Yard force

Yard force LUV600Ri Bedienungsanleitung

Yard force

Yard force MB 400 Bedienungsanleitung

Yard force

Yard force EasyMow 260B Firmware-Update

Yard force

Yard force ROBOMOWER SA800PRO Bedienungsanleitung

Yard force

Yard force Y2GMB41PC00 Montageanleitung

Yard force

Yard force LM F23 Bedienungsanleitung

Beliebte Rasenmäher Handbücher anderer Marken

RHINO

RHINO 1958 Bedienungsanleitung

Wolf Garten

Wolf Garten Compact plus 40 B Bedienungsanleitung

Cub Cadet

Cub Cadet LTX 1045 Bedienungsanleitung

Craftsman

Craftsman 917.378461 Bedienungsanleitung

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Bedienungsanleitung

Challenge

Challenge CH18V2 Betriebsanleitung

TALEN TOOLS

TALEN TOOLS AVR HGM30 Bedienungsanleitung

DEWEZE

DEWEZE ATM-725 Bedienungsanleitung

Weed Eater

Weed Eater 180083 Bedienungsanleitung

Husqvarna

Husqvarna Poulan Pro PP185A42 Bedienungsanleitung

Better Outdoor Products

Better Outdoor Products Quick Series Bedienungsanleitung

Cub Cadet

Cub Cadet 23HP Z-Force 60 Betriebsanleitung

MTD

MTD 795, 792, 791, 790 Bedienungsanleitung

Toro

Toro Groundsmaster 3505-D Bedienungsanleitung

Dennis

Dennis FT 610 Bedienungsanleitung

AIRFORCE

AIRFORCE F-15 Gen 3 Bedienungsanleitung

MTD

MTD 126-220-000 Bedienungsanleitung

Toro

Toro 74806 Bedienungsanleitung
