YASKAWA VIPA HMI cloudPanel H41-L1A41-0 Bedienungsanleitung

TP-cloud | H41-L1A41-0 | Manual

HB160 | TP-cloud | H41-L1A41-0 | en | 18-02

VIPA HMI

cloudPanel - TP104-CL

www.vipa.com/en/service-support/manuals

VIPA GmbH

Ohmstr. 4

91074 Herzogenaurach

Telephone: +49 9132 744-0

Fax: +49 9132 744-1864

Email: [email protected]

Internet: www.vipa.com

Table of contents

1 General.................................................................................................................... 4

1.2 About this manual............................................................................................. 5

1.3 Safety information............................................................................................. 6

2 Hardware description............................................................................................. 7

2.1 Safety information for users.............................................................................. 7

2.2 Properties......................................................................................................... 8

2.3 Structure........................................................................................................... 9

2.3.1 Overview........................................................................................................ 9

2.3.2 Interfaces..................................................................................................... 10

2.3.3 Memory management.................................................................................. 11

2.4 Dimensions..................................................................................................... 12

2.5 General data................................................................................................... 13

2.6 Technical data................................................................................................. 15

3 Deployment........................................................................................................... 18

3.1 Installation...................................................................................................... 18

3.2 Commissioning............................................................................................... 19

3.2.1 Web browser............................................................................................... 19

3.2.2 System Settings........................................................................................... 22

3.2.3 Firmware update.......................................................................................... 30

3.3 Connection to a PLC system.......................................................................... 31

4 Installation Guidelines......................................................................................... 32

4.1 Basic rules for the EMC-equitable assembly of installations.......................... 32

4.2 EMC-equitable assembly................................................................................ 35

4.3 EMC-equitable cabling................................................................................... 36

4.4 Special precautions providing high noise immunity........................................ 39

4.5 Checklist for the EMC-compliant installation of controllers............................. 40

VIPA HMI Table of contents

HB160 | TP-cloud | H41-L1A41-0 | en | 18-02 3

1 General

This document contains proprietary information of VIPA and is not to be disclosed or used

except in accordance with applicable agreements.

This material is protected by the copyright laws. It may not be reproduced, distributed, or

altered in any fashion by any entity (either internal or external to VIPA), except in accord-

ance with applicable agreements, contracts or licensing, without the express written con-

sent of VIPA and the business management owner of the material.

For permission to reproduce or distribute, please contact: VIPA, Gesellschaft für Visuali-

sierung und Prozessautomatisierung mbH Ohmstraße 4, D-91074 Herzogenaurach, Ger-

many

Tel.: +49 9132 744 -0

Fax.: +49 9132 744-1864

EMail: [email protected]

http://www.vipa.com

Every effort has been made to ensure that the information contained in

this document was complete and accurate at the time of publishing. Nev-

ertheless, the authors retain the right to modify the information.

This customer document describes all the hardware units and functions

known at the present time. Descriptions may be included for units which

are not present at the customer site. The exact scope of delivery is

described in the respective purchase contract.

Hereby, VIPA GmbH declares that the products and systems are in compliance with the

essential requirements and other relevant provisions. Conformity is indicated by the CE

marking affixed to the product.

For more information regarding CE marking and Declaration of Conformity (DoC), please

contact your local VIPA customer service organization.

VIPA, SLIO, System 100V, System 200V, System 300V, System 300S, System 400V,

System 500S and Commander Compact are registered trademarks of VIPA Gesellschaft

für Visualisierung und Prozessautomatisierung mbH.

SPEED7 is a registered trademark of profichip GmbH.

SIMATIC, STEP, SINEC, TIA Portal, S7-300 and S7-400 are registered trademarks of

Siemens AG.

Microsoft and Windows are registered trademarks of Microsoft Inc., USA.

Portable Document Format (PDF) and Postscript are registered trademarks of Adobe

Systems, Inc.

All other trademarks, logos and service or product marks specified herein are owned by

their respective companies.

Contact your local VIPA Customer Service Organization representative if you wish to

report errors or questions regarding the contents of this document. If you are unable to

locate a customer service centre, contact VIPA as follows:

CE Conformity Declaration

Conformity Information

Trademarks

Information product sup-

port

VIPA HMI

General

HB160 | TP-cloud | H41-L1A41-0 | en | 18-02 4

VIPA GmbH, Ohmstraße 4, 91074 Herzogenaurach, Germany

Telefax: +49 9132 744-1204

EMail: [email protected]

Contact your local VIPA Customer Service Organization representative if you encounter

problems with the product or have questions regarding the product. If you are unable to

locate a customer service centre, contact VIPA as follows:

VIPA GmbH, Ohmstraße 4, 91074 Herzogenaurach, Germany

Tel.: +49 9132 744-1150 (Hotline)

EMail: [email protected]

1.2 About this manual

This manual describes the cloudPanel H41-L1A41-0 from VIPA. It contains a description

of the structure, project engineering and deployment.

Product Order number as of state:

HW FW OS

TP 104-CL H41-L1A41-0 01 V1.0.0 LinuxÒ 3.12

The manual is targeted at users who have a background in automation technology.

The manual consists of chapters. Every chapter provides a self-contained description of a

specific topic.

The following guides are available in the manual:

nAn overall table of contents at the beginning of the manual

nReferences with page numbers

The manual is available in:

nprinted form, on paper

nin electronic form as PDF-file (Adobe Acrobat Reader)

Important passages in the text are highlighted by following icons and headings:

DANGER!

Immediate or likely danger. Personal injury is possible.

CAUTION!

Damages to property is likely if these warnings are not heeded.

Technical support

Objective and contents

Target audience

Structure of the manual

Guide to the document

Availability

Icons Headings

VIPA HMI General

About this manual

HB160 | TP-cloud | H41-L1A41-0 | en | 18-02 5

Supplementary information and useful tips.

1.3 Safety information

The system is constructed and produced for:

ncommunication and process control

ngeneral control and automation tasks

nindustrial applications

noperation within the environmental conditions specified in the technical data

ninstallation into a cubicle

DANGER!

This device is not certified for applications in

– in explosive environments (EX-zone)

The manual must be available to all personnel in the

nproject design department

ninstallation department

ncommissioning

noperation

CAUTION!

The following conditions must be met before using or commis-

sioning the components described in this manual:

– Hardware modifications to the process control system should only be

carried out when the system has been disconnected from power!

– Installation and hardware modifications only by properly trained per-

sonnel.

– The national rules and regulations of the respective country must be

satisfied (installation, safety, EMC ...)

National rules and regulations apply to the disposal of the unit!

Applications conforming

with specifications

Documentation

Disposal

VIPA HMI

General

Safety information

HB160 | TP-cloud | H41-L1A41-0 | en | 18-02 6

2 Hardware description

2.1 Safety information for users

VIPA modules make use of highly integrated components in MOS-Technology. These

components are extremely sensitive to over-voltages that can occur during electrostatic

discharges. The following symbol is attached to modules that can be destroyed by elec-

trostatic discharges.

The Symbol is located on the module, the module rack or on packing material and it indi-

cates the presence of electrostatic sensitive equipment. It is possible that electrostatic

sensitive equipment is destroyed by energies and voltages that are far less than the

human threshold of perception. These voltages can occur where persons do not dis-

charge themselves before handling electrostatic sensitive modules and they can damage

components thereby, causing the module to become inoperable or unusable. Modules

that have been damaged by electrostatic discharges can fail after a temperature change,

mechanical shock or changes in the electrical load. Only the consequent implementation

of protection devices and meticulous attention to the applicable rules and regulations for

handling the respective equipment can prevent failures of electrostatic sensitive modules.

Modules must be shipped in the original packing material.

When you are conducting measurements on electrostatic sensitive modules you should

take the following precautions:

nFloating instruments must be discharged before use.

nInstruments must be grounded.

Modifying electrostatic sensitive modules you should only use soldering irons with

grounded tips.

CAUTION!

Personnel and instruments should be grounded when working on electro-

static sensitive modules.

Handling of electrostatic

sensitive modules

Shipping of modules

Measurements and altera-

tions on electrostatic sen-

sitive modules

VIPA HMI Hardware description

Safety information for users

HB160 | TP-cloud | H41-L1A41-0 | en | 18-02 7

2.2 Properties

The VIPA cloudPanel allows you to visualize and alter operating states and recent

process values of a connected PLC. The cloudPanel is a compact and modular

embedded PC based on LinuxÒ. WEB-based projects are displayed via a WEB browser.

Here the cloudPanel can simply be configured, controlled and remoted.

nOperating system LinuxÒ 3.12

nProcessor ARM Cortex A8 1GHz

nFlash memory 4GB, RAM 512MB DDR

nRS232/RS422/RS485 (not available for WebVisu projects),

USB-A and Ethernet interface

nRobust plastic case

nDisplay resolution 272 x 480 / 480 x 272, 64K colors

nBattery backed clock

nResistive analog touch screen

nEasy mounting via mounting clips

nProtection class IP66, Type 2 and 4X (Front) / IP20 (Back)

Order data

Type Order number Description

TP 104-CL H41-L1A41-0 4.3'' TFT color, RS232/RS422/RS485, USB-A, Ethernet RJ45

General

VIPA HMI

Hardware description

Properties

HB160 | TP-cloud | H41-L1A41-0 | en | 18-02 8

2.3 Structure

2.3.1 Overview

1 Interfaces

2 Display with touch sensitive area (Touch-Screen)

1 USB-A interface USB 2.0

2 RJ45 jack for Ethernet communication LAN

3 RS232/RS422/RS485 interface COM

4 Slot for DC 24V voltage supply

Front view

Bottom view

VIPA HMI Hardware description

Structure > Overview

HB160 | TP-cloud | H41-L1A41-0 | en | 18-02 9

2.3.2 Interfaces

Using the "Host"-USB-A interface USB mouse, keyboard, stick or USB hard discs can be

connected.

The RJ45 jack provides the interface to the twisted pair cable, required for Ethernet. The

Ethernet interface has got two LEDs for status display.

LEDs

green yellow

Description

on off no link

blinks on 100Mbit/s link

blinks off 10Mbit/s link

9 pin SubD plug

nInterface is compatible to the COM interface of a PC

nLogical signals as voltage levels

nPoint-to-point links with serial full-duplex transfer in two-wire technology up to 15m

distance

nData transfer rate up to 115.2kbit/s

"Host"-USB-A

Ethernet connection

RS232 interface

VIPA HMI

Hardware description

Structure > Interfaces

HB160 | TP-cloud | H41-L1A41-0 | en | 18-02 10

Inhaltsverzeichnis

Andere YASKAWA Steuereinheit Handbücher

YASKAWA

YASKAWA VIPA System 200V Bedienungsanleitung

YASKAWA

YASKAWA MP2000 Series Bedienungsanleitung

YASKAWA

YASKAWA S-II Series Bedienungsanleitung

YASKAWA

YASKAWA U1000 Series Bedienungsanleitung

YASKAWA

YASKAWA SI-EM3 Bedienungsanleitung

YASKAWA

YASKAWA GPD 506/P5 Bedienungsanleitung

YASKAWA

YASKAWA VIPA IM 053IP Bedienungsanleitung

YASKAWA

YASKAWA V1000 SI-EM3D/V Bedienungsanleitung

YASKAWA

YASKAWA CANopen SI-S3 Bedienungsanleitung

YASKAWA

YASKAWA FM 050 Bedienungsanleitung

YASKAWA

YASKAWA SI-ES3 Bedienungsanleitung

YASKAWA

YASKAWA AC Drive V1000 Option SI-EM3/V Bedienungsanleitung

YASKAWA

YASKAWA System 300S CP 342-1DA70 Bedienungsanleitung

YASKAWA

YASKAWA VIPA System SLIO Bedienungsanleitung

YASKAWA

YASKAWA FM 054 Bedienungsanleitung

YASKAWA

YASKAWA CANopen SI-S3/V Bedienungsanleitung

YASKAWA

YASKAWA MP2000 Series Bedienungsanleitung

YASKAWA

YASKAWA Profibus-DP SGDH Series Bedienungsanleitung

YASKAWA

YASKAWA MP2000 Series Bedienungsanleitung

YASKAWA

YASKAWA IM 208-1DPx1 Bedienungsanleitung

YASKAWA

YASKAWA CM092 Bedienungsanleitung

YASKAWA

YASKAWA JEPMC-OP3C01-E Bedienungsanleitung

YASKAWA

YASKAWA IM 053PN Bedienungsanleitung

YASKAWA

YASKAWA Varispeed f7 Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
