YASKAWA Motoman DX200 Bedienungsanleitung

MANUAL NO.

HW1481939

Part Number: 165634-1CD

Revision: 0

DX200 OPTIONS

INSTRUCTIONS

FOR TWIN GUN FUNCTION

Upon receipt of the product and prior to initial operation, read these instructions thoroughly, and retain

for future reference.

MOTOMAN INSTRUCTIONS

MOTOMAN- INSTRUCTIONS

DX200 INSTRUCTIONS

DX200 OPERATOR’S MANUAL

DX200 MAINTENANCE MANUAL

The DX200 operator’s manual above corresponds to specific usage.

Be sure to use the appropriate manual.

1/16

165634-1CD

HW1481939

Twin Gun Function

MANDATORY

• This manual explains the twin gun function of the DX200 system.

Read this manual carefully and be sure to understand its contents

before handling the DX200.

• General items related to safety are listed in Chapter 1: Safety of the

DX200 INSTRUCTIONS. To ensure correct and safe operation,

carefully read the DX200 INSTRUCTIONS before reading this

manual.

CAUTION

• Some drawings in this manual are shown with the protective covers

or shields removed for clarity. Be sure all covers and shields are

replaced before operating this product.

• The drawings and photos in this manual are representative

examples and differences may exist between them and the

delivered product.

• YASKAWA may modify this model without notice when necessary

due to product improvements, modifications, or changes in

specifications. If such modification is made, the manual number will

also be revised.

• If your copy of the manual is damaged or lost, contact a YASKAWA

representative to order a new copy. The representatives are listed

on the back cover. Be sure to tell the representative the manual

number listed on the front cover.

• YASKAWA is not responsible for incidents arising from unauthorized

modification of its products. Unauthorized modification voids your

product’s warranty.

2/16

iii

165634-1CD

HW1481939

Twin Gun Function

Notes for Safe Operation

Read this manual carefully before installation, operation, maintenance, or

inspection of the DX200.

In this manual,the Notes for Safe Operationare classified as “WARNING,”

“CAUTION,” “MANDATORY,” or ”PROHIBITED.”

Even items described as “CAUTION” may result in a serious accident in

some situations.

At any rate, be sure to follow these important items.

WARNING

Indicates a potentially hazardous

situation which, if not avoided, could

result in death or serious injury to

personnel.

CAUTION

Indicates a potentially hazardous

situation which, if not avoided, could

result in minor or moderate injury to

personnelanddamagetoequipment.

It may also be used to alert against

unsafe practices.

MANDATORY

Always be sure to follow explicitly the

items listed under this heading.

PROHIBITED

Must never be performed.

NOTE

To ensure safe and efficient operation at all times, be sure

to follow all instructions, even if not designated as

“CAUTION” and “WARNING”.

3/16

165634-1CD

HW1481939

Twin Gun Function

WARNING

• Before operating the manipulator, check that servo power is turned

OFF pressing the emergency stop buttons on the front door of the

DX200 and the programming pendant.

When the servo power is turned OFF, the SERVO ON LED on the

programming pendant is turned OFF.

Injury or damage to machinery may result if the emergency stop circuit

cannot stop the manipulator during an emergency. The manipulator

should not be used if the emergency stop buttons do not function.

Figure 1: Emergency Stop Button

• Once the emergency stop button is released, clear the cell of all

items which could interfere with the operation of the manipulator.

Then turn ON the servo power.

Injury may result from unintentional or unexpected manipulator motion.

Figure 2: Release of Emergency Stop

TURN

• Observe the following precautions when performing teaching

operations within the P-point maximum envelope of the

manipulator:

– View the manipulator from the front whenever possible.

– Always follow the predetermined operating procedure.

– Keep in mind the emergency response measures against the

manipulator’s unexpected motion toward you.

– Ensure that you have a safe place to retreat in case of

emergency.

Improper or unintended manipulator operation may result in injury.

• Confirm that no person is present in the P-point maximum envelope

of the manipulator and that you are in a safe location before:

– Turning ON the power of DX200.

– Moving the manipulator with the programming pendant.

– Running the system in the check mode.

– Performing automatic operations.

Injury may result if anyone enters the P-point maximum envelope of the

manipulator during operation. Always press an emergency stop button

immediately if there is a problem. The emergency stop buttons are

located on the right of the front door of the DX200 and the programming

pendant.

4/16

165634-1CD

HW1481939

Twin Gun Function

Definition of Terms Used Often in This Manual

The MOTOMAN is the YASKAWA industrial robot product.

The MOTOMAN usually consists of the manipulator, the controller, the

programming pendant, and supply cables.

In this manual, the equipment is designated as follows:

CAUTION

• Perform the following inspection procedures prior to conducting

manipulator teaching. If problems are found, repair them

immediately, and be sure that all other necessary processing has

been performed.

– Check for problems in manipulator movement.

– Check for damage to insulation and sheathing of external wires.

• Always return the programming pendant to the hook on the DX200

cabinet after use.

The programming pendant can be damaged if it is left in the

manipulator’s work area, on the floor, or near fixtures.

• Read and understand the Explanation of the Warning Labels in the

DX200 Instructions before operating the manipulator.

Equipment Manual Designation

DX200 Controller DX200

DX200 Programming Pendant Programming Pendant

Cable between the manipulator and the

controller Manipulator cable

5/16

165634-1CD

HW1481939

Twin Gun Function

Descriptions of the programming pendant, buttons, and displays are

shown as follows:

Description of the Operation Procedure

In the explanation of the operation procedure, the expression "Select • • • "

means that the cursor is moved to the object item and the SELECT key is

pressed, or that the item is directly selected by touching the screen.

Registered Trademark

In this manual, names of companies, corporations, or products are

trademarks, registered trademarks, or bland names for each company or

corporation. The indications of (R) and

are omitted.

Equipment Manual Designation

Programming

Pendant Character Keys

/Symbol Keys The keys which have characters or its

symbol printed on them are denoted with [ ].

ex. [ENTER]

Axis Keys

/Numeric Keys [Axis Key] and [Numeric Key] are generic

names for the keys for axis operation and

number input.

Keys pressed

simultaneously When two keys are to be pressed

simultaneously, the keys are shown with a

“+” sign between them,

ex. [SHIFT]+[COORD]

Displays The menu displayed in the programming

pendant is denoted with { }.

ex. {JOB}

6/16

vii

165634-1CD

HW1481939

Twin Gun Function

Table of Contents

1 Twin Gun Function..........................................................................................................................1-1

1.1 Twin Gun Function.............................................................................................................1-1

1.2 Outline of Twin Gun Function............................................................................................1-2

2 Twin Gun Setup..............................................................................................................................2-1

2.1 Home Position Calibration for Twin Gun............................................................................2-1

2.2 Settings of Gun Condition File...........................................................................................2-2

2.3 Settings of Tool File of when a Twin Gun is Mounted on the Manipulator.........................2-3

2.4 Settings of Tool File of when Twin Gun is Fixed................................................................2-4

3 Preparing of Twin Gun Job.............................................................................................................3-1

3.1 Registration of MOVE Instructions.....................................................................................3-1

3.2 Operation Flow Chart of Hit Points Teaching ....................................................................3-1

3.3 Job Example for a Twin Gun Mounted on the Manipulator................................................3-2

3.4 Job Example for Fixed Twin Gun.......................................................................................3-2

7/16

1 Twin Gun Function

1.1 Twin Gun Function

1-1

165634-1CD

HW1481939

Twin Gun Function

1 Twin Gun Function

1.1 Twin Gun Function

As illustrated in the figure below, a twin gun has one operating axis and

two pairs of electrodes which apply pressure.

Twin gun function is the function that maximizes and controls

twin gun performance.

Movable

Operating axis

Fixed

Movable

8/16

1-2

165634-1CD

HW1481939

Twin Gun Function

1 Twin Gun Function

1.2 Outline of Twin Gun Function

In the DX200, a twin gun is treated as a station with one axis, and the

station is configured with two guns.

Use an S-axis key to perform JOG operation, etc. since the twin gun is a

station with one axis.

For MOVE instructions, register the instructions in the same manner as a

station with one axis.

When applying pressure, select either gun of the twin gun, that applies

pressure.

The following show an example of use of the twin gun function in the

system with one manipulator and one twin gun.

GUN 1

GUN 2

S-

X- S+

X+

L-

Y- L+

Y+

U-

Z- U+

Z+

7- 7+

R-

X- R+

X+

B-

Y- B+

Y+

T-

Z- T+

Z+

Programming Pendant

NOP

MOVJ

SVSPOTMOV GUN# (1)

SVSPOTMOV GUN# (2)

Configuration of Control Group

R1 : ES200N-A0*

S1 : TWIN-GUN

Operates S1 with MOVE instruction.

Selects a gun No. to apply pressure.

Twin gun

Selects S1 to perform JOG operation with S-axis key.

9/16

2 Twin Gun Setup

2.1 Home Position Calibration for Twin Gun

2-1

165634-1CD

HW1481939

Twin Gun Function

2 Twin Gun Setup

2.1 Home Position Calibration for Twin Gun

For setting of home position of a twin gun, move the twin gun in the

direction of "S -(minus)" as shown in the figure below by JOG operation,

and set the position, where one tip is aligned with another tip, as home

position.

SUPPLE-

MENT

Home position can also be set to a desired position.

If there are means such as an alignment mark, etc. to

specify the position of a gun, use the mean and set home

position at this position.

SUPPLE-

MENT

For home position settings, refer to Section 8.1 “Home

Position Calibration" of the "DX200 INSTRUCTIONS”

(Part No.165557-1CD).

Home position

10/16

Andere Handbücher für Motoman DX200

Inhaltsverzeichnis

Andere YASKAWA Controller Handbücher

YASKAWA

YASKAWA FSDrive-MV1000 Series Bedienungsanleitung

YASKAWA

YASKAWA SI-ET3 Bedienungsanleitung

YASKAWA

YASKAWA PG-X3 Bedienungsanleitung

YASKAWA

YASKAWA CIMR-JC4A0002BAA Bedienungsanleitung

YASKAWA

YASKAWA Sigma II Series Bedienungsanleitung

YASKAWA

YASKAWA MP23 Series Bedienungsanleitung

YASKAWA

YASKAWA MP2000 Series Bedienungsanleitung

YASKAWA

YASKAWA PROFINET V1000 Bedienungsanleitung

YASKAWA

YASKAWA MOTOMAN Series Bedienungsanleitung

YASKAWA

YASKAWA V1000 Series Installations- und Betriebshandbuch

YASKAWA

YASKAWA J1000 CIMR-JC series Bedienungsanleitung

YASKAWA

YASKAWA Z1000 CIMR-ZU*A Series Bedienungsanleitung

YASKAWA

YASKAWA Motoman DX200 Bedienungsanleitung

YASKAWA

YASKAWA Motoman DX200 Bedienungsanleitung

YASKAWA

YASKAWA Motoman DX200 Bedienungsanleitung

YASKAWA

YASKAWA motoman NX100 Bedienungsanleitung

YASKAWA

YASKAWA YRC1000micro Bedienungsanleitung

YASKAWA

YASKAWA J1000 CIMR-JC series Bedienungsanleitung

YASKAWA

YASKAWA L1000E Bedienungsanleitung

YASKAWA

YASKAWA YASNAC 3000G Bedienungsanleitung

YASKAWA

YASKAWA AC Drive-A1000 Bedienungsanleitung

YASKAWA

YASKAWA 1000 Series Bedienungsanleitung

YASKAWA

YASKAWA CIPR-GA50C series Bedienungsanleitung

YASKAWA

YASKAWA motoman NX100 Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung

3M MicroTouch EX113 Bedienungsanleitung
