Yealink CPW90 Bedienungsanleitung
CP Wireless Microphones
CPW90
Quick Start Guide (V1.3)
www.yealink.com
Mute Button
Built-in Microphone
Battery Indicator
Charging Slot
1
2
1
2
Package Contents
Component Instruction
Charging the Wireless Microphones
The following items are included in your package. If you find anything
missing, contact your system administrator.
1.8m Micro USB Cable
Put the wireless microphones on the
charging cradle.
Connect to the power source.
During charging, the battery indicator glows red. When the battery capacity
reaches 100%, the battery indicator glows green.
When you charge the wireless microphones, the wireless microphones will
start automatically. You can also long tap the mute button on the wireless
microphone for 3 seconds to turn it on.
1
USB Dongle
Charging Cradle 1.8m
Micro USB Cable
Power Adapter
DD10
CPW90 Wireless
Mic×2
Note: If it is the first time you use the
wireless microphones
, you need to
fully charge them.
If the wireless microphones are not in use, we still recommend you to
charge them even when the battery is full.
Quick Start Guide
2
If you purchase video conferencing system and wireless microphones
together, they are already paired. Just turn the wireless microphones on to
use them. Make sure a DD10 USB dongle is connected before you use the
wireless microphones.
If you purchase wireless microphones separately, you need to pair them with
video conferencing system manually.
To pair wireless microphones with video conferencing system:
1. On your remote control, navigate to More->Setting->Video &
Audio->Wireless Micphone.
2. Select Add Wireless Micphone.
3. Place the wireless microphones on the charger and long press the mute
button for 5 seconds until the mute LED indicator fast flashes yellow.
The wireless microphones are paired with the video conferencing system.
If you want to pair new wireless microphones with your video conferencing
system, you need to unbind old microphones.
1. On your remote control, navigate to More->Setting->Video &
Audio->Wireless Micphone.
2. Select the desired wireless microphone and press the OK key.
3. Select Unbind.
The screen prompts ”Unbind device?”
4. Select OK.
1. On your remote control, navigate to More->Setting->Video &
Audio->Wireless Micphone.
2. Select the desired wireless microphone and press the OK key.
3. Select Find.
The mute LED indicator flashes red and green alternately.
4. Select Cancel.
1. Tap the mute button to mute it.
The mute LED indicator glows red.
2. Tap the mute button again to unmute it.
Finding the Paired Wireless Microphones
Muting or Unmuting the Wireless Microphones
Unbinding the Paired Wireless Microphones
Pairing with the Video Conferencing System
YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD.
Web: www.yealink.com
Addr: 309, 3rd Floor, No.16, Yun Ding North Road,
Huli District, Xiamen City, Fujian, P.R. China
Copyright © 2018 Yealink Inc. All rights reserved.
C P W9 0 - V CS
About Yealink
Yealink is a global leading provider of enterprise communication and collaboration solutions, offering
video conferencing service to worldwide enterprises. Focusing on research and development, Yealink also
insists on innovation and creation. With the outstanding technical patents of cloud computing , audio,
video and image processing technology, Yealink has built up a panoramic collaboration solution of audio
and video conferencing by merging its cloud services with a series of endpoints products. As one of the
best providers in more than 140 countries and regions including the US, the UK and Australia, Yealink
ranks No.1 in the global market share of SIP phones shipments.
Technical Support
Visit Yealink WIKI (http://support.yealink.com/) for the latest firmware, guides, FAQ, Product documents, and more.
For better service, we sincerely recommend you to use Yealink Ticketing system (https://ticket.yealink.com) to
submit all your technical issues.
