YellowStone 4G LTE Bedienungsanleitung

User Manual (Last Updated: February 9, 2020)

Yellowstone A.I. - 4G LTE Trail Camera

Welcome to the Yellowstone A.I. family.

We sincerely appreciate you buying a Yellowstone AI camera and we hope you enjoy it.

At Yellowstone AI, we strive to build cameras and software that are supremely user-friendly and

reliable, but we know there is always room for improvement. The user experience remains at the heart

of everything we do, and we welcome feedback on how we can improve.

Sincerely,

The Yellowstone A.I. Team

[email protected]

(970) 821-8525

Table of Contents

1. Activation Guide .................................................................................................................................... 4

1.1 Create Yellowstone AI Command Center Account ......................................................................................... 4

1.2 Activate Camera ........................................................................................................................................... 4

1.3 Prepare Camera ............................................................................................................................................ 4

1.4 Connect to the Network ............................................................................................................................... 5

1.5 Receive Your First Image .............................................................................................................................. 5

2. What’s in the Box ................................................................................................................................... 6

3. Getting to Know Your Camera ................................................................................................................ 7

3.1 Front View .................................................................................................................................................... 7

3.2 Inside View ................................................................................................................................................... 8

4. SD Card and Image Storage .................................................................................................................... 9

4.1 General Information ..................................................................................................................................... 9

4.2 Formatting Your SD Card .............................................................................................................................. 9

4.3 Viewing Images or Videos ........................................................................................................................... 10

4.4 Deleting Images or Videos .......................................................................................................................... 10

5. Camera Settings ................................................................................................................................... 11

5.1 Adjusting Your Settings .............................................................................................................................. 11

5.2 Settings Table (Cam) ................................................................................................................................... 12

5.3 Settings Table (PIR) ..................................................................................................................................... 13

5.4 Settings Table (4G) ..................................................................................................................................... 14

5.5 Settings Table (Other) ................................................................................................................................. 15

5.6 Memory Table ............................................................................................................................................ 15

6. Camera Specifications .......................................................................................................................... 16

7. Troubleshooting ................................................................................................................................... 17

1. Activation Guide

For a full video walkthrough about activating your camera, please visit the support section of our

website.

1.1 Create Yellowstone AI Command Center Account

1. Visit my.yellowstone.ai

2. Login or create a new Yellowstone AI Command Center account

1.2 Activate Camera

1. Locate the camera’s ICCID – This is a 20-digit number that should be pasted within the camera case

2. In the Command Center at my.yellowstone.ai, click ‘Activate New Camera’

3. Enter ‘Location’ label to identify where your camera will be (can be updated later)

4. Enter the ICCID (from step 1)

5. Review price agreement and accept if you wish to continue

6. Submit payment information (if you are a first-time user)

7. Your Yellowstone AI Command Center account service is now active and ready to receive photos

1.3 Prepare Camera

1. Open the camera case by flipping the latch on the side of the camera

2. Place either 6 AA batteries to fill either section (top or bottom), or 12 AA batteries to fill the entire

battery compartment

Note

: 12AA high-quality alkaline or Ni-MH are recommended (Your camera will operate on 6 batteries, but

12 will increase the camera’s lifespan). For optimal performance, please update the “Battery Type” in

camera settings.

3. Remove the two yellow caps on the top of the camera and screw in either antenna (they are both the

same) in each of the two antenna ports (left port is 4G Cellular antenna, right port is GPS Location port)

1.4 Connect to the Network

1. Underneath the LCD screen within the camera’s case, flip the switch to ‘SETUP’

2. Your camera’s screen should turn on and display the camera’s view

a. If the screen does not turn on, consult the troubleshooting section of the Yellowstone AI

website

3. While the camera is searching for signals and synching with the server, you will see ‘Searching…’ or

‘GPS Searching…’ in the top left of the screen. This process may take a couple minutes to complete

a. If several minutes go by and/or your ‘Searching…’ text changes to ‘No Signal’, consult the

troubleshooting section of the Yellowstone AI website

1.5 Receive Your First Image

1. Your camera should now be all set to take and send pictures to the Yellowstone AI Command Center

and distributed according to your account settings

2. To send a test picture, press the ‘OK’ button while the camera is in ‘SETUP’ mode and connected to the

network. Then refresh the images section of your Yellowstone AI Command Center account to verify

that your camera is up and running.

If you are having issues sending or viewing pictures, please visit the troubleshooting section of our

website.

2. What’s in the Box

Camera

2x 4G Antennas

4G LTE SIM Card

32 GB SD Card

Mounting Strap

USB Cable

Quick-Start

Guide

3. Getting to Know Your Camera

3.1 Front View

Lens

Latch

PIR Sensor

GPS Antenna Port

IR LED Array (x27)

IR LED Array (x30)

Indicator Light

Day/Night Sensor

4G LTE Service Antenna Port

3.2 Inside View

To open camera, flip the latch on the side of the camera case

USB Port

SD Card Slot

Navigation Buttons

Power Switch

(ON/OFF/SETUP)

Menu Button

LCD Screen

SIM Card Slot

AA Battery Slots

12V Input

for Solar

4. SD Card and Image Storage

4.1 General Information

• The SD slot of the camera has a maximum capacity of 32 GB (larger SD cards use a different file transfer

protocol, which will not function with your camera)

• Before inserting or removing the memory card, the camera must be switched to "OFF"

o Failing to do so may cause loss of pictures & videos and damage the camera and memory card

• When the SD card is full, the viewing screen shows "Memory Full"

Note:

By default, the cameras will delete the oldest images when your SD card fills up, so that your camera

can continue functioning. For more information, please visit the camera settings and optimization section of our

website.

4.2 Formatting Your SD Card

Warning:

Formatting your SD card will result in a loss of all data on the card.

Note:

SD card must be formatted as FAT32. All cameras ship with a SD card that is pre-formatted correctly.

There are three ways to format your SD card:

Option 1:

With the SD card inserted in your camera

1. Switch camera to setup mode

2. Press the up arrow to access images

3. Press menu to access SD card options

4. Format > Yes > Yes

Option 2:

Insert SD card into the SD port on your computer

1. Locate the SD card among your files

2. Right click on the SD Card and select Format

3. Ensure FAT32 is selected

Option 3:

Connect Camera to computer via USB cable

(same steps as #2 above)

4.3 Viewing Images or Videos

On Your Computer

1. Insert SD card into computer or connect camera to computer via USB cord

2. Access the DCIM folder within the SD card

Windows

a. Use windows explorer to find the name of your SD card (or camera)

b. Click the associated icon to display the contents of the SD card

c. Open the ‘DCIM’ folder

d. Open the ‘MEDIA’ folder

Mac

a. Find the mounted icon on your desktop (or in Finder) with the name of your SD card (or camera)

b. Click the associated icon to display the contents of the SD card

c. Open the ‘DCIM’ folder

d. Open the ‘MEDIA’ folder

On Your Camera

(with SD card inserted)

1. Switch camera to ‘SETUP’ mode

2. Press the up arrow to access images

3. Use arrow buttons to cycle through the images

4.4 Deleting Images or Videos

By default, your camera will be set to delete the oldest pictures on the card to make room for new pictures when space

is needed. Your pictures will be saved in the cloud when they are sent to your Yellowstone AI Command Center, and will

be viewable (in the quality by which they are sent) even after they are deleted from the SD Card.

Formatting

Formatting your SD card (see 4.2) will delete all images and videos on the card

On Your Computer

While viewing images on your computer (see 4.3), you can delete or transfer pictures from the SD card as you view them

On Your Camera

1. While viewing images on your camera (see 4.3)

2. Press the ‘MENU’ button

3. Select the ‘Del’ option by pressing the ‘OK’ button (‘Del’ should be selected by default)

4. Choose to delete either the currently viewed picture (‘One’) or all pictures on the SD card (‘All’)
