YOKOGAWA CA310 Bedienungsanleitung
User’s
Manual
IM CA310-02EN
3rd Edition
CA310 Volt mA Calibrator
CA320 TC Calibrator
CA330 RTD Calibrator
Getting Started Guide
IM CA310-02EN 1
3rd Edition: October 2017 (YMI)
All Rights Reserved, Copyright © 2015, Yokogawa Test & Measurement Corporation
Printed in Japan
Thank you for purchasing the CA310 Volt mA Calibrator, CA320 TC Calibrator, or CA330 RTD Calibrator. This operation guide focuses
on the handling precautions, basic operations, and specifications of the CA310/CA320/CA330.
To ensure correct use, please read this manual thoroughly before beginning operation. Keep this manual in a safe place for quick
reference in the event that a question arises.
List of Manuals
The following five manuals, including this one, are provided as manuals for the CA310/CA320/CA330.
Please read all manuals.
Manual Title Manual No. Description
CA310 Volt mA Calibrator
CA320 TC Calibrator
CA330 RTD Calibrator
Getting Started Guide
IM CA310-02EN This guide. The guide explains the handling precautions and basic
operations of the CA310/CA320/CA330 and provides a list of
specifications.
CA310 Volt mA Calibrator
User’s Manual
IM 310-01Z2 This manual explains how to use CA310.
CA320 TC Calibrator
User’s Manual
IM 320-01Z2 This manual explains how to use CA320.
CA330 RTD Calibrator
User’s Manual
IM 330-01Z2 This manual explains how to use CA330.
CA310/CA320/CA330 User’s Manual IM CA310-92Z1 For China
Contact information of Yokogawa offices worldwide is provided on the following sheet.
Manual No. Description
PIM113-01Z2 List of worldwide contacts
2IM CA310-02EN
Notes
• The contents of this manual are subject to change without prior notice as a result of continuing improvements to the instrument’s
performance and functionality. The figures given in this manual may differ from those that actually appear on your screen.
• Every effort has been made in the preparation of this manual to ensure the accuracy of its contents. However, should you have any
questions or find any errors, please contact your nearest YOKOGAWA dealer.
• Copying or reproducing all or any part of the contents of this manual without the permission of YOKOGAWA is strictly prohibited.
Trademarks
• Adobe, Acrobat, and PostScript are either registered trademarks or trademarks of Adobe Systems Incorporated.
• In this manual, the ® and TM symbols do not accompany their respective registered trademark or trademark names.
• Other company and product names are trademarks or registered trademarks of their respective companies.
Revisions
November 2015 1st Edition
October 2016 2nd Edition
October 2017 3rd Edition
IM CA310-02EN 3
Product Registration
Thank you for purchasing YOKOGAWA products.
YOKOGAWA provides registered users with a variety of information and services.
Please allow us to serve you best by completing the product registration form accessible from our
homepage.
http://tmi.yokogawa.com/
4IM CA310-02EN
Checking the Contents of the Package
Unpack the box and check the contents before operating the instrument. If the wrong items have been delivered, if items are missing, or
if there is a problem with the appearance of the items, contact your nearest YOKOGAWA dealer.
CA310/CA320/CA330
Check that the product that you received is what you ordered by referring to the model name on the name plate on the rear panel of the
main unit. For reference, the model name and specifications of the products are listed below.
Model Suffix Code Specifications
CA310 Volt mA Calibrator
CA320 TC Calibrator
CA330 RTD Calibrator
For products whose suffix code contains “Z,” an exclusive manual may be included. Please read it along with the standard manual.
IM CA310-02EN 5
Standard Accessories
The following accessories are included. Make sure that all accessories are present and undamaged.
Item Model or
Component Number
Quantity Notes
CA310 CA320 CA330
Lead cable 98064 1 — — For the CA310 1 red, 1 black
Lead cable 98040 — 1 — For the CA320 1 red, 1 black
Lead cable 98035 — — 1 For the CA330 3 red, 1 black
Binding post (red-black pair) 99045 — 1 1 One short plate included
Binding post (red-red pair) 99046 — — 1 One short plate included
Batteries — 4 4 4 AA alkaline batteries (LR6)
Portable case B9108NK 1 1 1
Antiskid rubber — 1 1 1 Antiskid rubber for the bottom panel
Manuals IM CA310-02EN 1 1 1 Getting Started Guide
For CA310, CA320, and CA330
IM CA310-02JA 1 1 1 Japanese manual
For CA310, CA320, and CA330
IM CA310-02Z2 1 — — User’s manual for the CA310
IM CA320-02Z2 — 1 — User’s manual for the CA320
IM CA330-02Z2 — — 1 User’s manual for the CA330
IM CA310-92Z1 1 1 1 Document for China
PIM 113-01Z2 1 1 1 List of contacts
* Standard accessories are not covered by warranty of this instrument.
6IM CA310-02EN
Optional Accessories (Sold separately)
The following optional accessories are available for purchase separately. For information about ordering accessories, contact your
nearest YOKOGAWA dealer.
Item Model or
Component Number
Applicable To Notes
CA310 CA320 CA330
Rubber boots193060 PPPFor protecting the main unit
AC adapter 94012 PPPInput:100 VAC
Operating temperature range: -10°C to 40°C
94013 PPPInput:120 VAC
Operating temperature range: -10°C to 40°C
94016 PPPInput: 220 VAC
Operating temperature range: -10°C to 40°C
RJ sensor 90080 — P— PT100 JIS AA class or equivalent
Thermometer operating temperature range:
-10°C to 55°C
8-polar miniDin connector
Shielded cable 1.5 m
Y terminal (compatible with M3 terminal blocks)
TC mini plug set 90040 — P— 10 types
K/T/J/E/R(S)/G/C/D/N/B(U)
90045 — P— 4 types
K/T/J/E
Grabber clip 98025 P P2P2Red-black pair, separate type (2 m)
Strap 97040 PPPFor rubber boots
Accessory case B9108XA PPP
* Optional accesories(sold separately) are not covered by warranty of this instrument.
1 When rubber boots are attached, the CA310/CA320/CA330 cannot be stored in the portable case.
2 Cannot be used simultaneously with the included binding post (99045/99046).
IM CA310-02EN 7
Safety Precautions
This product is designed to be used by a person with specialized knowledge.
The general safety precautions described herein must be observed during all phases of operation. If the product is used in a manner
not specified in this guide, the protection provided by the product may be impaired. YOKOGAWA assumes no liability for the customer’s
failure to comply with these requirements.
This manual is part of the product and contains important information. Store this manual in a safe place close to the instrument so that
you can refer to it immediately. Keep this manual until you dispose of the instrument.
Failure to comply with the precautions below could lead to injury or death or damage to the instrument.
WARNING
Use the Instrument Only for Its Intended Purpose
This instrument is a calibrator for the voltage/current measuring instrument (CA310), thermocouple/measuring
instrument (CA320), and RTD/measuring instrument (CA330). Use this instrument only as a calibrator.
Check the Physical Appearance
Do not use the instrument if there is a problem with its physical appearance.
The following symbols are used on this instrument.
Warning: handle with care. Refer to the user’s manual or service manual.
This symbol appears on dangerous locations on the meter which require
special instructions for proper handling or use. The same symbol appears in
the corresponding place in the manual to identify those instructions.
Direct current
Functional ground
French
Avertissement : À manipuler délicatement. Toujours se reporter aux manuels
d’utilisation et d’entretien. Ce symbole a été apposé aux endroits dangereux
de l’instrument pour lesquels des consignes spéciales d’utilisation ou
de manipulation ont été émises. Le même symbole apparaît à l’endroit
correspondant du manuel pour identifier les consignes qui s’y rapportent.
Courant direct
Borne de terre fonctionnelle
8IM CA310-02EN
AC adapter
Only use the dedicated AC adapter for the instrument.
Batteries
• Do not mix new and old batteries or mix different brands or types of batteries. The batteries may leak, heat up, or
burst due to their characteristic differences.
• Never replace the batteries while measurement is in progress.
Do Not Operate in an Explosive Atmosphere
Do not use this instrument in the presence of flammable gases or vapors. Doing so is extremely dangerous.
Do Not Remove Covers or Disassemble or Alter the Instrument
Only qualified YOKOGAWA personnel may remove the covers and disassemble or alter the instrument.
Measurement Category
The measurement category of this instrument’s signal input terminals is Other (O). Do not use it to measure the main
power supply or for Measurement Categories II, III, and IV.
Install or Use the Instrument in Appropriate Locations
• Do not install the instrument outdoors or in locations subject to rain or water. Or, use the instrument in such locations.
• Install the instrument so that you can immediately turn off the power if an abnormal or dangerous condition occurs.
Wiring
• Be sure to use the included lead cables.
• The maximum voltage application between all I/O terminals and earth is 50 VDC (measurement terminal of CA310)
or 42 VDC (other than the measurement terminal of CA310). Do not apply voltages that exceed 50 VDC or 42 VDC .
Doing so may cause electric shock or burns or may damage the instrument.
• Always turn off the power of the device under measurement before connecting it. Connecting or disconnecting lead
cables without turning off the device under measurement is extremely dangerous.
• Do not connect current circuits to the CA310 voltage input terminal. Likewise, do not connect voltage circuits to the
current input terminal. Improper connection may cause electric shock or burns or may damage the device under
measurement or the instrument.
• Do not apply currents that exceed the maximum allowable input current to the CA310 current input terminal.
IM CA310-02EN 9
CAUTION
Operating Environment Limitations
This product is a Class A (for industrial environment) product. Operation of this product in a residential area may cause
radio interference in which case the user will be required to correct the interference.
French
AVERTISSEMENT
Ne faites de cet équipement que l’utilisation pour laquelle il a été conçu
Cet équipement est un calibreur pour l’équipement de mesure de tension/courant (CA310), pour l’équipement de
termocouple/mesure (CA320) et pour l’équipement de RTD/mesure (CA330). Utilisez cet équipement à des fins de
calibrage uniquement.
Inspecter l’apparence physique
Ne pas utiliser l’instrument si son intégrité physique semble être compromise.
Adaptateur c.a.
Utiliser exclusivement l’adaptateur c.a. dédié pour l’instrument.
Batteries
• Ne pas mélanger des batteries neuves et des batteries usagées, ni des batteries de marques ou de types différents.
Les batteries risquent de fuir, de chauffer ou d’éclater en raison de leurs différentes caractéristiques.
• Ne jamais remplacer les batteries lorsque la mesure est en cours.
Ne pas utiliser dans un environnement explosif
Ne pas utiliser l’instrument en présence de gaz ou de vapeurs inflammables. Cela pourrait être extrêmement
dangereux.
Ne pas retirer le capot, ni démonter ou modifier l’instrument
Seul le personnel YOKOGAWA qualifié est habilité à retirer le capot et à démonter ou modifier l’instrument.
