YORKVILLE COLISEUM CA1 Bedienungsanleitung

➲

6 Channel Installation

Amplifier

➲

180 watts

➲

70-volt or 4-ohm output configuration

➲

Versatile input mixing capabilities

➲

XLR / TRS balanced combi-jack / attenuated RCA unbalanced inputs

➲

Individual volume control, clip & activity LED's per channel

➲

User selectable phantom power (available on three channels)

The Coliseum CA1 public address amplifier has been designed specifically for installations where a

versatile paging system with high quality music playback is required.

Ideal for restaurants, small clubs, offices and retail environments where a simple and reliable system

capable of servicing multiple paging zones is required. Multiple inputs for microphone or source material,

and voice activated paging from either a microphone or telephone matrix means the CA1 can be used in

virtually any application.

XLR / TRS balanced combi-jack inputs and attenuated RCA unbalanced inputs ensure the CA1 system can

interface with any source (CD, Cassette, Satellite Tuner, DVD or video system) your installation may require.

Capable of driving either a 4-ohm speaker load, or four separate 70-volt speaker systems (one ‘system’

per zone), the CA1 system delivers 180 watts (mono). A pre-amp output is available to feed an auxiliary

power amplifier or active subwoofer to enhance the system, or to feed video or audio recording equipment.

Coliseum CA1

Features:

Overview:

yorkville.com

70-Volt Installation Amplifier

NUMBER OF CHANNELS 6

INPUTS - 1/4" / XLR COMBI 3

INPUTS - RCA (UNBAL) 2

PHANTOM POWER Yes

HEADPHONE MONITOR FEATURES Yes - main Output

RECORD OUTPUTS Yes

MIXER - SIGNAL TO NOISE RATIO (dB) Greater than 55dB

MIXER - FREQUENCY RESPONSE 50 - 15kHz

AMP A - POWER OUTPUT @ 4 Ohms 180 Watts

AMP A - POWER OUTPUT -OTHER 180 Watts 70-volts

THD - 1kHz (dB) Less than 1%

COOLING Passive

FINISH Black

CHASSIS CONSTRUCTION Steel

RACKMOUNT Yes

OTHER FEATURES Zone Paging /

Telephone interface

DIMENSIONS (DWH, inches) 12 x 19 x 6

DIMENSIONS (DWH, cm) 320 x 480 x 150

WEIGHT (lbs/kg) 24 / 9

CA1 Specifications:
