Z GRILLS ZPG-550B2 Bedienungsanleitung
VN102023
WOODPELLETGRILLS
ZPG-550B2
OWNER’S MANUAL
MONTOFRI,8:00A.M.-5:00P.M.PACIFICSTANDARDTIME
SERVICECONTACT:1-833-947-4557/1-833-ZGRILLS
EMAIL:support@zgrills.com
WEBSITE:www.zgrills.com
1
CONTENTS
IMPORTANT SAFETY INFO 3
COMPONENT LIST 6
ASSEMBLY INSTRUCTIONS 8
INITIAL FIRING INSTRUCTIONS 14
SUBSEQUENT START-UP 15
OPERATING TIPS 16
MAINTENANCE & CLEANING 17
TROUBLESHOOTING 19
DIGITAL THERMOSTAT CONTROL WIRING DIAGRAM 21
Z GRILLS SUPPORT 22
3-Y LIMITED WARRANTY 23
2
SAVE THIS MANUAL FOR FUTURE REFERENCE
3
IMPORTANT SAFETY INFO
GENERAL WARNINGS
Please read this entire manual before installation and use of the pellet fuel-burning
appliance. Failure to follow these instructions could result in property damage, bodily
injury or even death.
Contact local building or fire officials about restrictions and installation inspection
requirements in your area.
This grill is for outdoor use only. DO NOT use it in any enclosed area.
DO NOT store or use combustible materials or liquids near this appliance.
Keep children away while it is in use.
Maintain a safe distance between your grill and any combustible material.
DO NOT move your grill while operating or while it is hot. Wait until the grill is
completely cold.
If a grease fire occurs, turn “off”and leave lid closed until the fire is extinguished. DO
NOT unplug the power cord. DO NOT throw water on it. DO NOT try to smother the
fire.
Clean and maintain your grill after each use.
DO NOT use your grill on rainy days.
DO NOT touch any part of your grill while it is hot. Serious bodily injury could result.
We suggest the use of heat-resistant gloves when operating this grill.
We suggest that you should wrap the Grease Drain Pan with heavy-duty aluminum
foil before using because it is easy to clean.
For convenient and safe assembly, use at least two people to assemble the grill.
Make sure the power cord is disconnected before performing any service or
maintenance.
4
DO NOT place anything heavy on top of hopper lid. It is not a shelf and is a tip hazard.
Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or
similar liquids to start or ‘freshen up’ a fire in this appliance. Keep all such liquids
well away from the appliance when in use.
Do not use accessories not specified for use with this appliance.
NOTE: A MAJOR CAUSE OF FIRES IS FAILURE TO MAINTAIN REQUIRED
CLEARANCES (AIR SPACES) TO COMBUSTIBLE MATERIALS. IT IS OF
UTMOST IMPORTANCE THAT THIS PRODUCT BE INSTALLED ONLY IN
ACCORDANCE WITH THESE INSTRUCTIONS.
5
PELLET RESTRICTIONS
This grill is designed for use of wood pellets only designed for burning in wood pellet
grills. Do Not Use Pellet Fuel Labeled As Having Additives.
We suggest that you use Z GRILLS BBQ WOOD PELLETS, which are specifically
made to work in our grills. There is no guarantee that other brands of pellets are
suitable for use in Z GRILLS. And Z GRILLS assumes no liability for any loss, damage
or injury caused by the use of any other brands of pellets.
Always keep the Pellet Hopper dry, the wood pellets will expand greatly, break apart
and even jam the feed system if the pellets get wet or are exposed to high humidity.
CARBON MONOXIDE WARNING
Follow these guidelines to prevent this colorless, odorless gas from poisoning you,
your family or others.
Know the symptoms of carbon monoxide poisoning: headache, dizziness, weakness,
nausea, vomiting, sleepiness, and confusion. Carbon monoxide reduces the blood’s
ability to carry oxygen. Low blood oxygen levels can result in loss of consciousness
and death.
See a doctor if you or others develop cold or flu-like symptoms while cooking or in
the vicinity of this appliance. Carbon monoxide poisoning, which can easily be
mistaken for a cold or flu, is often detected too late.
Alcohol consumption and drug use increase the effects of carbon monoxide
poisoning.
Carbon monoxide is especially toxic to mother and child during pregnancy, infants,
the elderly, smokers, and people with blood or circulatory system problems, such as
anemia, or heart disease.
COMPONENT LIST
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 Grill Chamber Assembly 23 2 Foot Pad
2 1 Hopper Assembly 24 1 Left Front Leg
3 1 Warming Rack 25 1 Hopper Lid
4 1 Porcelain Grills 26 1 Hopper Shell
5 1 Grease Drain Pan 27 1 Digital Control
6 1 Heat Baffle 28 1 Hopper Side Handle
7 1 RTD Temperature Probe 29 1 Hopper Guard
8 1 RTD Guard 30 1 Auger Drive Motor
9 1 Lid Handle 31 1 Auger Nylon Ring
10 2 Handle Guide 32 1 Auger
11 1 Lid 33 1 Foam Glue
12 2 Hinge Assembly 34 1
Hot Rod (Ignitor)
13 1 Chimney Cap 35 1
Feeder Assembly
14 1 Smoke Stack Assembly 36 1 Fan
15 1 Smoke Stack Gasket 37 1 Power Cord
16 1 Grease Bucket 38 1
Hopper Insulation Gasket
17 1 Right Rear Leg 39 1
Fire pot Welding Assembly
18 1 Right Front Leg 40 1 Cable Clip
19 2 Wheels 41 1 Upper Safety Grate
20 1 Axle 42 2 Hinged axle
21 1 Bottom Plate 43 1 Nameplate
22 1 Left Rear Leg
6
7
HARDWARE PACKAGE LIST
ITEM
QTY
DESCRIPTION
ITEM
QTY
DESCRIPTION
A
1
Screwdriver
E
2
Hex Nut 1/4-20
B
2
Open End Wrench
F
2
Bolt 1/4-20×0.59
C
20
Bolt 1/4-20×0.5
G
2
Cap Nut 5/16-18UNC
D
2
Gasket (OD0.79×ID0.26)
8
ASSEMBLY INSTRUCTIONS
PARTS DIAGRAM
