Zetronix CRESCENDO Bedienungsanleitung
CRESCENDO
SPEAKER CAMERA
MANUAL
HDSmartIPC
B
E
D
C
A
F
G
A. 1x Speaker Camera
B. 1x USB cable
C. 1X Driver CD
D. 1x This manual
E. 1x Micro USB adapter
F. 1X USB AC Wall Charger
G. 1X Reset Pin
IN THE BOX
❶ WiFi Camera ON/OFF
❷ Reset pinhole
❸ USB Interface Port
❹ Bluetooth Search Switch
❺ Wifi Indicator Light
❻ MicroSD Card slot
❼ Intercom Speaker
❽ Loud Speaker
❾ Hidden IR LEDs
❿ Hidden Camera
❽ Speaker
1. Download the App
Download and install the HDSmartIPC app
from Google Play or the App Store.
2. Power up the CRESCENDO
Connect one end of the USB cord (B) to the
USB port on the CRESCENDO ❸ and the
other end to the USB AC Wall Charger (F).
3. Turn on the CRESCENDO’s WiFi
Flip the WiFi switch ❶ on the back of the
CRESCENDO to the ON position. Wait
about 1 minute for the device to start up.
When ready the Wifi indicator light ❺ will
flash red/blue.
HDSmartIPC
4. Connect to the CRESCENDO’s WiFi
Open your smartphone settings, search and
connect the device's wireless signal name
starting with the letters "LM..." or "AI...",wait
for Wi-Fi to connect, and phone status bar
shows the Wi-Fi symbol in blue.
████████████
____________
LM065-A7X2430009
zWeatherStation-500w
Enter the App, and the app will add just the
connected camera automatically.
if you dont see any listed press the plus sign
(+) to add a new camera. On the next screen
hit LAN search device, then you will be shown
a list of all detected cameras. You should see
at least one. Hit Add to add the camera
____________
________
5.Connect the phone to the CRESCENDO.
6. Add the camera
Back on the App's main screen you will see a
video preview display of the added camera.
Press the gear icon to open settings then
select Device settings.
_____ ___
_______ ____
Quit and restart the App, and the device will
start up with the WiFi connected within 30
secods.
You can now go back to your phone settings
as in the previous section and connect your
phone back to your local Wifi network.
The app will now stream live videos from
anywhere as long as your phone has internet
access.
Select Wi-Fi Config (Network configuration on Andoid
phones) then look for your local WiFi network name
(SSID). You will be prompted for your local network
Password. The App will now connect to the camera.
_____________
Camera UID / Name
Camera status
Recorded videos in memory card
Camera setting
Message: Alarm messages
(Please insert micro sd card to
get alarm pictures)
Files: Snapshots and Recorded
videos
