Zhehan Technology ZH-C110B Bedienungsanleitung

Thank you and your family for choosing this dehumidifier as your professional dehumid-

ifier. This manual will explain to you the correct use and maintenance of this dehumidifi-

er. Please take a few minutes to read through this article to become familiar with the

operation and performance of this dehumidifier.

This dehumidifier will remove excess moisture from the air, creating a comfortable

environment for your home and various places. Its lightweight and convenient design

allows you to move it easily.

PLEASE KEEP THIS MANUAL IN A SAFE PLACE FOR REFERENCE

THANK YOU!

DEHUMIDIFIER

INSTRUCTION MANUAL

www.zhehanclub.com

Tel: 400-004-3019

Web: www.zjehanclub.com

Shanghai ZheHan Intelligent Technology Co., LTD

CATALOG

Specifications

Characteristic

Safety Warning

Product Icon

Instructions

Preparation

Maintenance & Repair

Dehumidifier Storage

Troubleshooting

CHARACTERISTIC

01 Powerful Dehumidification 02 Simple design

03 Air Purification Function

05 Easy To Maintain

07 Fully Automatic Drainage

09 Easy To Move

11 Wind Flows From All Sides

10 Low Power Consumption

Fault Alarm And Shutdown

Protection

06 Automatic Defrost

04 Humidity Adjustable

Based on the principle of refrigeration

technology, this dehumidifier can

Remove the right amount of moisture

to keep the room dry and comfortable.

Can effectively solve air quality

problems.

Simple and smooth design, suitable

for all environment and place.

Different dehumidification levels can

be selected according to different

room needs.

Subtle design allows quickest and

easiest repairs.

Natural weathering frost, safer and

more efficient.

Built-in high-lift water pump, automatic

detection of water level and drainage. Automatic detection fault alarm

display, to solve your problems.

Equipped with 2-inch universal wheels,

move freely.

Let every corner of the space feel the

comfortable air. 11 Industrial Application

Built-in mechanical control mode,

durable and use in harsh working

conditions.

The machine has passed the EU

authoritative certification, and the

energy efficiency exceeds the

national level.

SPECIFICATIONS

Motor

Power

Drainage Method Fully automatic drainage

N.W. (KG)

Dimension (W x D X H)

Note: This dehumidification ability is obtained by testing at

room temperature of 27°C and relative humidity of 60%.

SAFE USE WARNING

When using this machine,

please pay attention to the following safety warnings.

• Unplug this dehumidifier before cleaning or storing it

• Do not immerse the machine in or near water

• Do not place the machine near heat generating devices or flammable

hazards

• Do not stuff your fingers or other objects into the air vents or air outlets

• Do not sit on this table

• Please drain as required

• Before moving the machine, please use the manual drain button to

drain the accumulated water in the consumption

• Make sure the drain hose is not broken so that condensate can drain

continuously

• If the power cord is damaged, please purchase a power cord of the

same specification for replacement

• Do not alter or modify your dehumidifier in any way, please contact

your authorized dealer for assistance

• Prevent electric shock hazard. Equipment must be grounded

OUTLET

CONNECTOR

POWER CABLE

UNIVERSAL

WHEEL

GRAVITY

WHEEL

PRODUCT ICON INSTRUCTIONS

FRONT

BACK

HUMIDITY

ADJUSTMENT

SWITCH

AIR INLET

AIR OUTLET

BACK PANEL

FILTER COVER

FRONT PANEL

FILTER

1. Humidity regulation

2. Automatic defrost

3. Recoverable overload protection switch

Adjust the indoor humidity by

setting the desired humidity

through the control panel of the

humidifier. The machine can also

be switched off via the control

panel.

When the room temperature is below 15°C, the heat exchanger freezes during the

dehumidification process. The device will then automatically defrost. The duration of

the defrost process depends on the room temperature. The lower the temperature, the

longer the thawing time.

Please check whether the overload switch is turned on when starting up, otherwise it

cannot be powered on. It is also protected when the current is too large, and it is turned

on after troubleshooting.

MAINTENANCE & REPAIR

PREPARATION

Wipe the machine panel with a soft, slightly damp cloth

1. Place the machine in the position shown in the figure below to fully

utilize the machine performance.

2. Take out the water outlet pipe well and connect it to the water outlet port

for connection, and place the water pipe at a height of not more than 4.5

meters. If the water outlet pipe is entangled or in a flat state, it will affect

the smoothness of the water outlet and even cause the machine to not

work properly.

3. Take out the power cord and insert the power cord plug into the power

socket safely and securely

Step 1: Unscrew the water connec-

tor and set it into the water pipe.

Step 2: Connect

the water pipe to

the faucet and

tighten the water

connector

MAINTENANCE

1. Machine surface cleaning

a. Take out the filter

1. Prepare a Phillips screwdriver

2. Unscrew 3 screws and take off

the filter cover

3. Pull out the filter

b. Clean the filter

Use a vacuum cleaner to gently absorb the dust on the surface of the

filter. If the filter is very dirty, use a brush to remove the surface dust.

c. Put the cleaned filter back into the air inlet panel.

2. Filter cleaning

REPAIR

ELECTRIC

CONTROL BOX

1. In the power-on state, press the drain button, wait for a while, and

press it again until the water is drained.

2. Roll up the power cord and water hose and secure them in place.

3. Clean the filter.

4. Place in a cool, dry, relatively dust-free environment. Do not place in

chemical environment.

a. Remove the 8 fixing screws of the electric control cover of the

machine, and use a wrench to unscrew the faucet fixing ring.

b. Open the electric control cover to repair the electrical part.

1. Electronic control maintenance

The following maintenance requires professional or qualified maintenance

personnel to perform maintenance

If the following conditions occur, please confirm the following conditions

before requesting customer service:

When you do not use this product for a long time and

plan to store or collect it, pay attention to the following steps:

DEHUMIDIFIER STORAGE

TROUBLESHOOTING

DESCRIPTION

Machine

Not Running

Does Not

Dehumidify

No Wind Enters

Loud Noise

When Running

Does Not

Turn On After

Humidity Setting

Defrost Time

Too Long

Water Leakage

Is the power cord properly

connected?

Is the room temperature above 5°C

or within 38°C?

Is the filter blocked?

Are the air inlets or

air outlets blocked?

Machine must operate at normal

operating temperature

Clean the filter

Is the filter blocked?

Is the machine placed at an angle?

Mechanical sensor failure or

disconnected wiring

The temperature switch is faulty

and the temperature is low

Clean the filter

Is the filter blocked? Clean the filter

Replace accessories or check

wiring and connect

First judge whether it is caused

by the ambient temperature for

too long or better to sense the

temperature switch

Discounted or clogged water pipes Check the connection and status

of water pipes

Move the machine to a flat,

sturdy location

Clear the blockage from the

air inlet or outlet

Connect the plug and socket

POTENTIAL CAUSE SOLUTION
