ZKTeco FR1200 Bedienungsanleitung

ZKTecoFR1200UserManual

Version:1.0.1

Date: Dec. 2011

Introduction:

Thisdocumentmainlyintroducestheuser’soperationof ZKTeco FR1200.Aboutthe

deviceinstallation,pleaserefertotheInstallationGuide.

TableofContents

1.UsingInstruction ............................................................................ 1

1.1FingerPlacement .................................................................. 1

1.2InstructionforCardUsing .................................................... 2

1.3Precautions............................................................................ 2

2.DeviceIntroduction ........................................................................ 3

3.DeviceOperations.......................................................................... 6

4Appendix........................................................................................ 11

4.1ListofParameters ............................................................... 11

4.2StatementonHumanRightsandPrivacy ........................... 12

4.3EnvironmentFriendlyUseDescription.............................. 14

1. Using Instruction

 1

1.UsingInstruction

1.1FingerPlacement

Enrollfingerprintbypressingindexfinger,middlefingerorringfinger(thumband

littlefinger areclumsy).

1.Properpress:

2.Improperpress:

Makefingercenterpressedonthe

sensorwindow.

Slant Too low

Upright Toolean

Pleaseadoptthecorrectwaytoplacethefingertoavoidimproperoperation

ledtotheidentificationperformancedegradation.

ZKTeco FR1200UserManualV1.0.1

 2

1.2InstructionforCardUsing

Integrated with a noncontact RF card reader module, this reader supports the ID

cards andMifare cards (Optional and only usedas ID cards). Byoffering multiple

verificationmodessuchasFP,card,FPpluscard,FPorcardverification,thisreader

canaccommodatetodiversifieduserneeds.

Swipe your card across the sensor area following the light and beep prompts and

removeyourcardafterthereaderhassensedit.Forthecardsensorarea,pleaserefer

to 2DeviceIntroduction.

1.3Precautions

Protect the reader from exposure to direct sunlight or strong beam, for the strong

sunlightgreatlyaffectsthefingerprintcollectionandleadstofingerprintverification

failure.

Itisrecommendedtousethereaderunderatemperatureof0–50°Csoastoachieve

theoptimalperformance.Intheeventofexposureofthereadertotheoutdoorsfor

long periods of time, it is recommended to adopt sunshade and heat dissipation

facilities because excessively high or low temperature may slow down the reader

operation and result in high false rejection rate (FRR) and false acceptance rate

(FAR).

Wheninstallingthereader,pleaseconnectthepowercableafteralltheotherwiring.

Ifthereaderdoesnotoperateproperly,besuretoshutdownthepowersupplybefore

performing necessary inspection. Be aware that any liveline working may cause

damagetothereader,andthatdamageisbeyondthescopeofournormalwarranty.

For mattersthat are not covered in this document, pleaserefertorelated materials

includingtheInstallationGuide,FPReaderSoftwareUserManual.

2. DeviceIntroduction

 3

LEDIndicator

FingerprintSensor

CardSensor Area

2.DeviceIntroduction

FR1200, a fingerprint reader with RS485 communication interface works with

biometricaccesscontrollersandfingerprintstandaloneaccesscontrol.Itoffersthe

function of capturing and transferring fingerprint samples to access control panel

insidetomatch.WithitsIP65ratedruggedstructure. Thisreaderoperationissimple

andflexible.Thelightandbeeppromptswillguideyouthroughalltheoperations

without screen display or keyboard. Featuring a compact and simple design, this

readerisanewconceptofinBIOfingerprintreader.

ProductAppearance:

Frontview:

² LEDindicator:TheLEDindicatorisusedtodisplayreaderoperationresults

andexceptionalstatuseswhicharedefinedasfollows:

ZKTeco FR1200UserManualV1.0.1

 4

DipSwitch

WiringTerminal

ResetButton

Operation succeeds: The green indicator issolid on for one second, at the

sametimethespeakerplayonelongbeep.

Operation failed: The redindicatoris solid on for one second, at thesame

timethespeakerplaytwoshortbeep.

Verificationstate:ThegreenLEDblinksonceeverytwosecond,thebeeper

withnosound.

² CardSensorArea:Referstotheareainthereddashedlineasshowninthe

figureabove.

² FingerprintSensor: Usedtoenrollandmatchfingerprints.

Bottomview:

² ResetButton: Usedtorestartthereader.

Backview:

DipSwitch:14switchesareusedtosettheRS485communicationaddress(device

ID).Number5switchisidle.Andthenumber6switchisusedtosettheterminal

2. DeviceIntroduction

 5

resistancestate.

WiringTerminal: Forconnectionterminals.

ZKTeco FR1200UserManualV1.0.1

 6

3.DeviceOperations

Afterthereaderispoweredon,thereadercannotidentifythefingerprintorcard.In

other words, the reader can not receive data or send data without access control

panelconnection.

Only whenthe reader connected withthe access control panel that the reader can

promptifthecardorfingerprintisenrolledornot,andverifytheuseraccordingto

thereturningresultofbackgroundaccesscontrolpanel.

Userverificationoperations:

1.Whenthereaderconnectedwiththeaccesscontrolpanel,itisinverificationstate,

thebeepwithnosound,andthegreenLEDblinkonceeverytwosecondtoprompt

verification.

2. Start user verification. The reader supports four verifications modes: only

fingerprint, only card, fingerprint plus card, fingerprint or card verification. The

process include press fingerprint first or swipe card first, the operation areas the

follows:

Pressfingerprintfirst:

(1) Press your finger on the fingerprint sensor inaproper way. The device beeps

once,andthentheLEDoff,switchtothebackgroundverification.

(2)Theaccesscontrolpaneldetermineswhetherthecontrolorderistimeout.Ifitis

timeout,thedevicebeeps3soundsandtheredLEDsolidon.Otherwise,itwillget

thesystemverificationmodessetting.

Onlyfingerprint/cardorfingerprintverification:Sendthefingerprinttemplateto

the access control panel, and wait for the result. If it is waitingtime out, beep 3

sounds and the red LED solid on. If the reader get the verification result in the

3. DeviceOperations

 7

settingtime,2beepandredLEDsolidonforverificationfailed,1beepandgreen

LEDsolidonforverification succeed.

Card plus fingerprint verification: Determine if there is the card data. If you

swipecardneartothecardreader,thensendthefingerprinttemplateandcarddata

totheaccesscontrolpanel,andwaitfortheresult.Ifitiswaitingtimeout,beep3

sounds and the red LED solid on. If the reader get the verification result in the

settingtime,2beepandredLEDsolidonforverificationfailed,1beepandgreen

LEDsolidonforverificationsucceed.

Onlycardverification:Nosendingofthedatatoaccesscontrolpanel,thedevice

beeps2sounds,andredLEDsolidon.

ZKTeco FR1200UserManualV1.0.1

 8

Theverificationoperationsareasfollows:

ReaderStart

Gettingcontrol

ordertimeout?

OnlyFP

verification？

FPorcard

verification？

FPandcard

verification？

Sendcardnumber

andFPtemplateto

accesscontrolpanel

Prompt:1 beep,

greenLEDon

Verification

resulttimeout？

N

Y

N

GetFPtemplate,1

beep, lightoff,

switchto 485

Onlycard

verification？

Getcardnumber

already?？

Y

SendFPtemplateto

accesscontrolpanel

Passthe

verification?

Prompt:2beeps,

redLEDon

Readerstop

Prompt:3beeps,

greenLEDon

N

YN

N

Y
