ZTE USB Modem

User Manual

Contents

1 Modem Introduction....................................................4

1.1 Introduction..........................................................4

1.2 Warning and Notice..............................................4

1.3 Declaration...........................................................5

1.4 Applicability Scope ..............................................8

1.5 System requirements...........................................8

1.6 Functions..............................................................8

1.7 Specification ........................................................8

2 Installation...................................................................10

2.1 Outline and Parts................................................10

2.2 Hardware Installation ........................................10

2.3 Software Installation..........................................12

2.4 Run the Application Software............................15

2.5 Hardware Uninstall ............................................16

2.6 Software Uninstall..............................................17

3 Functions & Operation.............................................19

3.1 Interface introduction........................................19

3.1.1 Main Interface.......................................................19

3.1.2 Description of Mini Icons .....................................22

3.2 Connecting Internet ...........................................23

3.3 SMS.....................................................................26

3.3.1 Read Short Message..............................................28

3.3.2 Create new message..............................................28

3.3.3 Operating Guide....................................................30

3.4 PhoneBook..........................................................32

3.4.1 Creating a new contact..........................................33

3.4.2 Modifying contacts................................................34

3.4.3 Deleting contacts...................................................34

3.4.4 Sending SMS to a contact .....................................35

3.4.5 Searching for a contact..........................................35

3.5 Settings ..............................................................35

3.5.1 Connection Settings ..............................................36

3.5.2 Security Settings....................................................38

3.5.3 Network Settings...................................................39

3.5.4 Message Settings...................................................41

3.5.5 Alert settings .........................................................43

3.6 MicroSD card......................................................43

3.7 Help.....................................................................44

4 FAQ & Answers...........................................................45

1 Modem Introduction

1.1 Introduction

Thank you for using ZTE MF633 USB Modem.

To guarantee the modem always in its best condition, please

read this manual carefully and keep it for further use.

The pictures, symbols and contents in this manual are just for

your reference. They might not be completely identical with your

modem. We operate a policy of continuous development. We

reserve the right to update the technical specifications in this

document at any time without prior notice.

The ZTE MF633 USB modem is a multi-mode 3G USB modem,

working in HSPA/UMTS/EDGE/GPRS/GSM networks. With

USB interface connecting to a laptop or a desktop PC, it

integrates the functionality of a modem and a mobile phone

(SMS), and combines mobile communication with Internet

perfectly. It supports data and SMS services through the mobile

phone network, enabling you to communicate anytime and

anywhere.

1.2 Warning and Notice

To the owner

Some electronic devices are susceptible to electromagnetic

interference sent by modem if inadequately shielded, such as

electronic system of vehicles. Please consult the

manufacturer of the device before using the modem if

necessary.

Operating of laptop and desktop PC and modem may

interfere with medical devices like hearing aids and

pacemakers. Please always keep them more than 20

centimeters away from such medical devices when they are

turned on. Turn the modem off if necessary. Consult a

physician or the manufacturer of the medical device before

using the modem.

Be aware of the usage limitation when using a modem at

places such as oil warehouses or chemical factories, where

there are explosive gases or explosive products being

processed. Therefore, turn off your modem if required.

Don’t touch the inner antenna area if not necessary.

Otherwise it will affect your modem’s performance.

Store the modem out of the reach of little children. The

modem may cause injury if used as a toy.

Modem

Please use original accessories or accessories that are

authorized. Using any unauthorized accessories may affect

your modem’s performance, and violate related national

regulations about telecom terminals.

Avoid using the modem near metallic structure device or

establishment that can emit electromagnet wave. Otherwise it

may influence receiving signals.

The modem is non-waterproof type, please keep it dry and

store in shady and cool place.

Don’t use the modem immediately after a sudden

temperature change. In such case, it will produce dew inside

and outside the modem, so don’t use it until it becomes dry.

Take the modem carefully. Don’t lose, bend or cause it struck.

Otherwise it will lead to destruct damage.

No dismantling by non-professional and only qualified

maintainer can undertake repair work.

1.3 Declaration

Radio Frequency (RF) Energy

This model MF633 meets the government’s requirements for

exposure to radio waves.

This device is designed and manufactured not to exceed the

emission limits for exposure to radio frequency (RF) energy set

by the Federal Communications Commission of the U.S.

Government:

The exposure standard for wireless devices employs a unit of

measurement known as the Specific Absorption Rate, or SAR.

The SAR limit set by the FCC is 1.6W/kg. *Tests for SAR are

conducted using standard operating positions accepted by the

FCC with the device transmitting at its highest certified power

level in all tested frequency bands. Although the SAR is

determined at the highest certified power level, the actual SAR

level of the device while operating can be well below the

maximum value. This is because the device is designed to

operate at multiple power levels so as to use only the poser

required to reach the network. In general, the closer you are to a

wireless base station antenna, the lower the power output.

The highest SAR value for the model device as reported to the

FCC when worn on the body, as described in this user guide, is

1.17 W/kg (Body-worn measurements differ among device

models, depending upon available enhancements and FCC

requirements.)

While there may be differences between the SAR levels of

various devices and at various positions, they all meet the

government requirement.

The FCC has granted an Equipment Authorization for this model

MF633 with all reported SAR levels evaluated as in compliance

with the FCC RF exposure guidelines. SAR information on this

model is on file with the FCC and can be found under the Display

Grant section of http://www.fcc.gov/oet/fccid after searching on

FCC ID: Q78-ZTEMF633.

For body worn operation, this modem has been tested and

meets the FCC RF exposure guidelines for use when plugged

into a laptop PC, positions the handset a maximum of 0.5 cm

from the body. Use of other enhancements may not ensure

compliance with FCC RF exposure guidelines.

FCC Compliance

zThis device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2)

this device must accept any interference received,

including interference that may cause undesired

operation.

zThis device has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential

installation. This equipment generates uses and can radiate

radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation If this equipment does cause harmful interference

to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following

measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for

help.

Caution:

Changes or modifications not expressly approved by the party

responsible for compliance could void the user‘s authority to

operate the equipment.

zThe antenna(s) used for this transmitter must not be co-located

or operating in conjunction with any other antenna or

transmitter.

1.4 Applicability Scope

ZTE USB Modem supports the present mainstream types of

laptops and desktop PCs, such as HP, IBM, Toshiba, Lenovo,

Dell, Sony, etc.

1.5 System requirements

Operating System：Windows 2000 / XP / Vista

Configuration (Recommended):

CPU 1GHz Pentium or above

Hard Disk 50M or above

RAM 512M or above

The performance of the modem may be influenced if

configuration is under the recommended requirement.

1.6 Functions

Functions: SMS service, data service, applied management,

data concurrence, support MicroSD card etc.

1.7 Specification

Interface Type USB2.0

Systems supported Supports most types of laptop and desktop PC.

Operating systems

supported

Windows 2000, XP SP2, Vista

MAC OS

Functions

SMS service, Data service, Applications

management, Data concurrent, support MicroSD

card, etc.

Network Standards HSPA/UMTS/EDGE/GPRS/GSM

Transmission speed

(Max)

HSUPA 2.0Mbps UL

HSDPA 7.2Mbps DL

Temperature

Storage: -20°C ~ +60°C

Operation: -10°C ~ +55°C

Dimension 85 mm×25 mm×9.6 mm

Weight About 30g

T-Flash capability Support up to 4GB MicroSD card

2 Installation

2.1 Outline and Parts

The following figure shows the appearance of the MF633. It is

only for your reference. The actual product may be different.

1. USB Connector

2. Indicator

3. Back Cover

4. MicroSD card slot

5. SIM/USIM card slot

2.2 Hardware Installation

Note: Before the hardware installation, please make sure that

your (U)SIM supports data service, GPRS, EDGE, UMTS or

HSPA etc. If you have questions on this, please consult your

service supplier.

1. Slide the back cover and remove it.

Inhaltsverzeichnis

Beliebte Modem Handbücher anderer Marken

Davicom

Davicom DM562AP Bedienungsanleitung

EpiValley

EpiValley TATA indicom SXC-1080 Bedienungsanleitung

Intelimax

Intelimax MA-2060 Bedienungsanleitung

SMC Networks

SMC Networks D3CM1604V Gebrauchs- und Pflegehandbuch

Telstra

Telstra Wi-Fi 4G Advanced Pro X Bedienungsanleitung

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Bedienungsanleitung

Samsung

Samsung AceLink SAM-335A Bedienungsanleitung

Enfora

Enfora Enabler-G Kurzanleitung zur Einrichtung

iRZ

iRZ ATM2-232 Bedienungsanleitung

Zhone

Zhone 6310 Bedienungsanleitung

Paradyne

Paradyne Hotwire 7976 Bedienungsanleitung

US Robotics

US Robotics 3453C Bedienungsanleitung

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Bedienungsanleitung

Four-Faith

Four-Faith F1403 Bedienungsanleitung

Sierra Wireless

Sierra Wireless AIRLINK MP595W Bedienungsanleitung

Gemtek

Gemtek WiMAX WIXFBR-103 Bedienungsanleitung

Zoom

Zoom 1070 Series Bedienungsanleitung

Aztech

Aztech HW831 Bedienungsanleitung
