Router 3000 Family

Installation Guide

Router 3012 (3C13612)

Router 3013 (3C13613)

Router 3015 (3C13615)

Router 3016 (3C13616)

Router 3018 (3C13618)

Part No. 10014206

Published March 2004

3Com Corporation

350 Campus Drive

Marlborough, MA

01752-3064

in any form or by any means or used to make any derivative work (such as translation, transformation, or

adaptation) without written permission from 3Com Corporation.

3Com Corporation reserves the right to revise this documentation and to make changes in content from time

to time without obligation on the part of 3Com Corporation to provide notification of such revision or change.

3Com Corporation provides this documentation without warranty, term, or condition of any kind, either

implied or expressed, including, but not limited to, the implied warranties, terms or conditions of

merchantability, satisfactory quality, and fitness for a particular purpose. 3Com may make improvements or

changes in the product(s) and/or the program(s) described in this documentation at any time.

If there is any software on removable media described in this documentation, it is furnished under a license

agreement included with the product as a separate document, in the hard copy documentation, or on the

removable media in a directory file named LICENSE.TXT or !LICENSE.TXT. If you are unable to locate a copy,

please contact 3Com and a copy will be provided to you.

UNITED STATES GOVERNMENT LEGEND

If you are a United States government agency, then this documentation and the software described herein

are provided to you subject to the following:

All technical data and computer software are commercial in nature and developed solely at private expense.

Software is delivered as “Commercial Computer Software” as defined in DFARS 252.227-7014 (June 1995)

or as a “commercial item” as defined in FAR 2.101(a) and as such is provided with only such rights as are

provided in 3Com’s standard commercial license for the Software. Technical data is provided with limited

rights only as provided in DFAR 252.227-7015 (Nov 1995) or FAR 52.227-14 (June 1987), whichever is

applicable. You agree not to remove or deface any portion of any legend provided on any licensed program

or documentation contained in, or delivered to you in conjunction with, this User Guide.

Unless otherwise indicated, 3Com registered trademarks are registered in the United States and may or may

not be registered in other countries.

3Com and the 3Com logo are registered trademarks of 3Com Corporation.

Intel and Pentium are registered trademarks of Intel Corporation. Microsoft, MS-DOS, Windows, and

Windows NT are registered trademarks of Microsoft Corporation.

All other company and product names may be trademarks of the respective companies with which they are

associated.

CONTENTS

ABOUT THIS GUIDE

Conventions 5

INTRODUCING THE ROUTER 3000 FAMILY

Router 3012 7

Router 3013 and Router 3015 10

Router 3016 and Router 3018 14

INSTALLING THE ROUTER

Preparing to Install the Router 19

Mounting the Router on a Vertical Surface 22

Installing the Router on a Workbench 23

Connecting the Protection Ground Wire 23

Connecting the Power Cable 23

Connecting the Router to the Console Terminal 24

Connecting the Router to the Ethernet 24

Connecting the Router to the WAN 25

Verifying the Installation 27

BOOTING AND CONFIGURING THE ROUTER

Connecting the Router to a Local Console Terminal 29

Setting the Parameters of the Console Terminal 29

Powering on the Router 33

Startup Process 33

Configuration Fundamentals of the Router 34

MAINTAINING THE ROUTER

Software Maintenance 37

Maintaining Router Hardware 46

TROUBLESHOOTING

The Power LED is Off. 49

Nothing is Displayed on the Terminal after Power-On 49

Illegible Characters Display on the Terminal after Power-On 50

OPTIONAL CABLE SPECIFICATIONS

Console Cable 51

AUX Cable 51

Ethernet Cable 52

Serial Port Cable 53

T1 Cable 63

ISDN BRI Cables 63

OBTAINING SUPPORT FOR YOUR ROUTER

Purchase Value-Added Services 65

Troubleshoot Online 65

Access Software Downloads 65

Telephone Technical Support and Repair 66

Conventions 5

ABOUT THIS GUIDE

This guide describes the 3Com® Router 3000 Family of routers and how to install

hardware, configure and boot software, and maintain software and hardware.

This guide also provides troubleshooting and support information for your router.

This guide is intended for the system or network administrator who is responsible

for configuring, using, and managing the routers. It asumes a working knowledge

of wide area network (WAN) operations and familiarity with communication

protocols that are used to interconnect WANs.

Always download the Release Notes for your product from the 3Com World Wide

Web site for the latest updates to product documentation:

http://www.3com.com

Conventions Table 1 and Table 2 list conventions that are used throughout this guide.

Table 1 Notice Icons

Tab le 2 Text Conventions

Icon Notice Type Description

Information note Information that describes important features or

instructions.

Caution Information that alerts you to potential loss of data

or potential damage to an application, system, or

device.

Warning Information that alerts you to potential personal

injury.

Convention Description

Screen

displays

This typeface represents information as it appears on the screen.

Keyboard key

names

If you must press two or more keys simultaneously, the key names are

linked with a plus sign (+), for example:

Press Ctrl+Alt+Del

The words “enter”

and type”

When you see the word “enter” in this guide, you must type

something, and then press Return or Enter. Do not press Return or

Enter when an instruction simply says “type.”

6CHAPTER : ABOUT THIS GUIDE

Words in italics Italics are used to:

Emphasize a point.

Denote a new term at the place where it is defined in the text.

Identify menu names, menu commands, and software button names.

Examples:

From the Help menu, select Contents.

Click OK.

Words in bold Boldface type is used to highlight command names. For example,

“Use the display user-interface command to...”

1INTRODUCING THE ROUTER 3000

FAMILY

Routers in the 3Com®Router 3000 Family provides the following types of ports:

■Ethernet port

■Synchronous/asynchronous serial port

■Auxiliary (AUX) port

■ISDN BRI S/T and U port

■CT1/PRI port

■E1/CE1/PRI port

These features allow you to combine the various networking technologies, such as

PSTN/ISDN, FR (Frame Relay), X.25, leased line, and T1 line. These multiple ports

also allow Router 3000 series routers to interoperate with the products of other

manufacturers.

Router 3000 routers use three types of memory:

■Synchronous Dynamic Random Access Memory (SDRAM) — Saves router

operation system software

■Flash memory — Saves router program files, configuration files and so on

■Boot ROM — Saves the boot and initialization programs of the router

Router 3012 Figure 1 illustrates the Router 3012.

Figure 1 Router 3012

Power LED

100M Ethernet LED

SERIAL0 LED

SERIAL1 LED

AUX LED

System LED

8CHAPTER 1: INTRODUCING THE ROUTER 3000 FAMILY

Figure 2 illustrates the back panel of the Router 3012.

Figure 2 Back Panel of the Router 3012

System Specifications Table 3 lists system specifications for the Router 3012.

LEDs Table 4 lists and describes the LEDs on the front panel of the Router 3012.

Power

switch Power

input

socket

Console

port

AUX

port

100M

Ethernet

port

Grounding

screw

SERIAL0 SERIAL1

Tabl e 3 System Specifications for the Router 3012

Item Description

Fixed ports 1 10/100 Mbps Ethernet port

2 synchronous/asynchronous serial ports

1 AUX port

1 console port

Processor MPC860T 50M Hz

SDRAM 64 MB

Flash memory 8 MB

Maximum power 20 W

Power supply (external) Input voltage and frequency: 100 to 240V AC (the actual range can

be 80 to 264 V) 50/60 Hz

Input current: 0.5 A to 1 A

Output voltage: 12 V

Output current: 4 A

Dimensions (W X H X

D, highest arc points of

the plastic panel)

251 X 42.5 X 187 mm (9.9X 1.7 X 7.4 in)

Weight 0.75 kg (1.65 lb)

Operating temperature 0 to 400 C (32 to 1040 F)

Relative humidity 5 to 85% (noncondensing)

Tabl e 4 Router 3012 LEDs

LED Description

POWER Off —The power is off.

Green — The power is on.

100M ETH Off — The link is not connected.

Flashing green — Data is being transmitted through the Ethernet

port.

SERIAL0 Off — The link is not connected.

Green — The link is connected.

Flashing green — Data is being transmitted through serial port 0.

Router 3012 9

Port Attributes The Router 3012 provides a console port, an AUX port, a 10/100M Ethernet port

and a synchronous/asynchronous serial port. The attributes of these ports are

described in the following sections.

Console Port

Table 5 lists attributes of the console port.

AUX Port

Table 6 lists attributes of the AUX port.

SERIAL1 Off — The link is not connected.

Green — The link is connected.

Flashing green — Data is being transmitted over serial port 1.

AUX Off — The link is not connected.

Green — The link is connected.

Flashing green — Data is being transmitted over the AUX port.

SYSTEM Flashing green — The system is operating normally.

Always green or off — The system is not operating normally.

Table 4 Router 3012 LEDs (continued)

LED Description

Tab le 5 Attributes of the Console Port

Attribute Description

Connector RJ-45

Port standard Asynchronous EIA/TIA-232

Baud rate 9.6 to 115.2 kbps (the default is 9.6 kbps)

Services Connects with character terminal

Connects with the serial ports of the local PCs and runs the terminal

emulation program on the PCs

Command line interface

Tab le 6 Attributes of the AUX Port

Attribute Description

Connector RJ-45

Port standard Asynchronous EIA/TIA-232

Baud rate 300 bps to 115.2 kbps

Services Modem dial-up

Backup

Protocols PPP (Point to Point Protocol)

SLIP (Serial Line Internet Protocol)

MP (Multilink PPP)

10 CHAPTER 1: INTRODUCING THE ROUTER 3000 FAMILY

Ethernet Port

Table 7 lists attributes of the Ethernet port.

Synchronous/Asynchronous Serial Port

Table 8 lists attributes of the serial port.

Router 3013 and

Router 3015

The Router 3013 and Router 3015 offer ISDN BRI support. The Router 3013 has an

ISDN BRI S/T port and the Router 3015 has an ISDN BRI U port.

Figure 3 illustrates the Router 3013 and Router 3015 routers.

Tabl e 7 Attributes of the Fast Ethernet Port

Attribute Description

Connector RJ-45

Frame format Ethernet_II

Ethernet_SNAP

IEEE 802.2

IEEE 802.3

Operating mode 10/100 Mbps autosensing

Full duplex/half duplex

Network protocol IP (Internet Protocol)

Novell IPX (Internet Packet Exchange)

Tabl e 8 Attributes of the Serial Port

Attribute

Description

Synchronous Asynchronous

Connector DB50

Port standard and

operating mode

V.24

(EIA/TIA-23

V.35 EIA/TIA-449, X.21 and

EIA-530

V.24 (EIA/TIA-232)

DTE, DCE DTE, DCE DTE DCE

Minimum baud

rate (bps)

1200 1200 1200 1200 300

Maximum baud

rate (bps)

64 k 2.048 M 2.048 M 2.048 M 115.2 K

Services DDN leased line

Terminal access

Backup

Modem dial-up

Backup

Protocols PPP

LAPB (Link Access Protocol-Balanced)

HDLC (High-level Data Link Control)

SDLC (Synchronous Data Link Control)

X.25

Frame Relay

PPP

SLIP

Andere Handbücher für Router 3012

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere 3Com Netzwerk-Router Handbücher

3Com

3Com 3C6090 - NETBuilder II Dual Processor Engine... Bedienungsanleitung

3Com

3Com Switch 4500 PWR 26-Port Bedienungsanleitung

3Com

3Com 3C13701 Bedienungsanleitung

3Com

3Com OfficeConnect Bedienungsanleitung

3Com

3Com VG Series Bedienungsanleitung

3Com

3Com OfficeConnect WX4400 Installationshandbuch

3Com

3Com OfficeConnect 3CRWDR200A-75 Bedienungsanleitung

3Com

3Com 3CWE820A Bedienungsanleitung

3Com

3Com Router 5012 Bedienungsanleitung

3Com

3Com Router 3012 Bedienungsanleitung

3Com

3Com OfficeConnect WL-542 Bedienungsanleitung

3Com

3Com 3C13886 - Router OC-3 ATM SML Flexible Interface... Bedienungsanleitung

3Com

3Com 3C13640 Bedienungsanleitung

3Com

3Com 5000/6000 Bedienungsanleitung

3Com

3Com SuperStack II 32x Bedienungsanleitung

3Com

3Com Router 3031 Betriebsanleitung

3Com

3Com WL-602 Bedienungsanleitung

3Com

3Com OfficeConnect 3CRWDR101A-75 Bedienungsanleitung

3Com

3Com 3CRWE754G72-A Bedienungsanleitung

3Com

3Com NJ220 - IntelliJack Switch Bedienungsanleitung

3Com

3Com OfficeConnect 3C612 Bedienungsanleitung

3Com

3Com Router 3032 Bedienungsanleitung

3Com

3Com 3C8S400 - SuperStack II PathBuilder S400... Bedienungsanleitung

3Com

3Com OfficeConnect 3CP4144 Technisches Datenblatt

Beliebte Netzwerk-Router Handbücher anderer Marken

Allnet

Allnet ALL0333AU Bedienungsanleitung

HomeSeer

HomeSeer HT-SEL Bedienungsanleitung

Sercomm

Sercomm Genesis OC3505D Bedienungsanleitung

Billion

Billion BIPAC 5102 Series Bedienungsanleitung

TP-Link

TP-Link TD-8817 Bedienungsanleitung

Motorola

Motorola MR1900 Bedienungsanleitung

Digi

Digi IX14 Bedienungsanleitung

Cisco

Cisco NCS 540 Handbuch

XAVi

XAVi X8821e Bedienungsanleitung

BEC

BEC 6200WZL Bedienungsanleitung

MikroTik

MikroTik hAP ac3 Series Bedienungsanleitung

Korenix

Korenix JetNet 5428G Series Bedienungsanleitung

NETGEAR

NETGEAR FS526T - Switch Bedienungsanleitung

Korenix

Korenix JetNet 5710G Series Bedienungsanleitung

Automated Logic

Automated Logic ZN551 Betriebsanleitung

Cisco

Cisco ASR 1000 Series Bedienerhandbuch

EnGenius

EnGenius ESR-9710 Bedienungsanleitung

Cisco

Cisco 805 Series Bedienungs- und Sicherheitshinweise
