3Com AP9552 Handbuch

3Com AP9552 Dual Band 802.11n PoE

Access Point

Hardware Installation Guide

BOM: 3122A08T

3C Number: 3CRWE955275(FAT Mode)

3CRWE9552A75(FIT Mode)

Manual Version: 6PW104

www.3com.com

3Com Corporation

350 Campus Drive, Marlborough, MA, USA

01752 3064

English...1

Français...14

Italiano...28

Polski...42

Português Brazilian...56

Deutsch...69

Español Latino...82

Espanol...97

Regulatory Information...112

List of the Hazardous Substances...119

documentation may be reproduced in any form or by any means or used to make any

derivative work (such as translation, transformation, or adaptation) without written

permission from 3Com Corporation.

3Com Corporation reserves the right to revise this documentation and to make

changes in content from time to time without obligation on the part of 3Com Corporation

to provide notification of such revision or change.

3Com Corporation provides this documentation without warranty, term, or condition of

any kind, either implied or expressed, including, but not limited to, the implied

warranties, terms or conditions of merchantability, satisfactory quality, and fitness for a

particular purpose. 3Com may make improvements or changes in the product(s) and/or

the program(s) described in this documentation at any time.

If there is any software on removable media described in this documentation, it is

furnished under a license agreement included withthe product as a separate document,

in the hard copy documentation, or on the removable media in a directory file named

LICENSE.TXT or !LICENSE.TXT. If you are unable to locate a copy, please contact

3Com and a copy will be provided to you.

UNITED STATES GOVERNMENT LEGEND

If you are a United States government agency, then this documentation and the

software described herein are provided to you subject to the following:

All technical data and computer software are commercial in nature and developed

solely at private expense. Software is deliveredas “Commercial ComputerSoftware” as

defined in DFARS 252.227-7014 (June 1995) or as a “commercial item” as defined in

FAR 2.101(a) and as such is provided with only such rights as are provided in 3Com’s

standard commercial license for the Software. Technical data is provided with limited

rights only as provided in DFAR 252.227-7015 (Nov 1995) or FAR 52.227-14 (June

1987), whichever is applicable. You agree not to remove or deface any portion of any

legend provided on any licensed program or documentation contained in, or delivered

to you in conjunction with, this User Guide.

Unless otherwise indicated, 3Com registered trademarks are registered in the United

States and may or may not be registered in other countries.

3Com and the 3Com logo are registered trademarks of 3Com Corporation.

All other company and product names may be trademarks of the respective companies

with which they are associated.

ENVIRONMENTAL STATEMENT

It is the policy of 3Com Corporation to be environmentally-friendly in all operations. To

uphold our policy, we are committed to:

Establishing environmental performance standards that comply with national legislation

and regulations.

Conserving energy, materials and natural resources in all operations.

Reducing the waste generated by all operations. Ensuring that all waste conforms to

recognized environmental standards. Maximizing the recyclable and reusable content

of all products.

Ensuring that all products can be recycled, reused and disposed of safely.

Ensuring that all products are labelled according to recognized environmental

standards.

Improving our environmental record on a continual basis.

End of Life Statement

3Com processes allow for the recovery, reclamation and safe disposal of all

end-of-life electronic components.

Regulated Materials Statement

3Com products do not contain any hazardous or ozone-depleting material.

Environmental Statement about the Documentation

The documentation for this product is printed on paper that comes from sustainable,

managed forests; it is fully biodegradable and recyclable, and is completely

chlorine-free. The varnish is environmentally-friendly, and the inks are

vegetable-based with a low heavy-metal content.

About This Manual

Conventions

The manual uses the following conventions:

Symbols

Convention Description

Means reader be extremely careful. Improper operation

may cause bodily injury.

Means reader be careful. Improper operation may cause

data loss or damage to equipment.

Means a complementary description.

Obtaining Documentation

You can access the most up-to-date 3Com product documentation on the World

Wide Web at this URL: http://www.3com.com.

1 About This Guide

This Quick Hardware Install Guide describes the basic steps necessary to install and

configure your 3Com 9552 (11n 2.4+5GHz PoE) Access Point. Note: This guide refers

to these devices as the AP.

Before you install or move the AP, you must carefully read the safety information of this

manual.

AP Features

Feature Description

Ethernet Port

The Ethernet port provides a 10/100/1000 BASE-T Ethernet

connection to a switch. Use a suitable Category 5 cable with

straight-through wiring and standard RJ-45 connectors to

connect your AP to the network.

LEDs The LEDs indicate power and activity. See Checking the LED

Indicators for details.

Antenna Connectors The AP has three built-in internal antennas. In addition, three

RSMA antenna connectors allow you to connect optional

external antennas.

Reset Button To reset the AP.

RJ-45 Console Port

Provides a serial interface to the AP for diagnostic use.

Default: 9600 baud rate, 8 data bits, no parity, one stop bit.

The default username and password for console login are

admin and password (case sensitive) respectively.

Wall-Mounting

Bracket and

Table-Top Stand

The combined wall-mounting bracket and table-top stand

allows you to mount the unit ona wall or stand it on a tabletop.

Suspended Ceiling

Bracket The suspended ceiling bracket (ceiling bracket and slider)

allows you to mount the unit on a suitably ceiling tile separator.

Safety Information

This equipment must be installed in compliance with local and national building codes,

regulatory restrictions, and FCC rules. For the safety of people and equipment, only

professional network personnel should install theAP.

: Warnings contain directions that you must follow for your personal

safety. Follow all directions carefully.

You must read the following safety information carefully before you install or remove the unit.

: Exceptional care must be taken during installation and removal of the unit.

: This unit operates under SELV (Safety Extra Low Voltage) conditions

according to IEC60950-1. The conditions are only maintained if the equipment to which

it is connected also operates under SELV conditions.

: There are no user-replaceable fuses or user-serviceable parts inside

the unit. If you have a physical problem with the unit that cannot be solved with problem

solving actions in this guide, contact your supplier.

: RJ-45 ports. These are RJ-45 data sockets. They cannot be used as

standard traditional telephone sockets, or to connect the unit to a traditional PBX or

public telephone network. Only connect RJ-45 data connectors, network telephony

systems, or network telephones to these sockets.

Either shielded or unshielded data cables with shielded or unshielded jacks can be

connected to these data sockets.

: To comply with FCC radio frequency (RF) exposure limits, a minimum

body-to-antenna distance of 20 cm must be maintained when the AP is operational.

Approved Channels

Use of this product is only authorized for the channels approved by each country. For

proper installation, select your country from the country-selection list.

To conform to FCC, Canada, EU and other country restrictions, your product as

shipped may be limited in the channels that are available. If other channels are

permitted your country, please visit the 3Com web site for the latest software version.

The Appendix A lists the Software Downloads information.

2 Mounting the AP

Unpacking the AP

Make sure that you have the following items, which are included with the AP:

zOne 3Com 9552 Access Point

zWall-mounting hardware:

zOne combined wall-mounting bracket and table-top stand

zFour screws

zFour wall anchors

zSuspended ceiling bracket:

zOne ceiling bracket

zOne slider

zTwo screws

zEight adhesive rubber feet

zOne copy of this Quick Start Guide

zOne 3Com Warranty Flyer

zOne console cable

Preparing for Installation

3Com recommends that you connect and check the Ethernet cable and LEDs before

you install the AP in a hard-to-reach location. Also, observe these items before you

mount or connect theAP:

Feature Description

Switch

Port To connect your wireless network to your wired network, you need a

switch that is connected to the AP.

Cabling

Make sure that a standard Ethernet cable with straight-through wiring is

installed at the site before you install the AP.

Make sure that the cable is highly flexible and that the RJ-45 connector

has no extra covering that could prevent the cable from being routed

through the mounting bracket.

Power

Requirem

ent

Power is supplied using an 802.3af Power Over Ethernet (PoE)

compliant device such as a PoE switch or a PoE injector. For maximum

performance, 3Com recommends that you use a Gigabit link.

MAC

Address

Record the AP MAC address in a safe place before the AP is installed in

a hard-to-reach location.

The MAC address is printed on the back of the AP.

Mounting the AP

The AP can be mounted on the following types of surfaces:

zWall or electrical box (NEMA enclosure)

zTable top

zCeiling mounting

Wall or Electrical Box Mounting

To install yourAP on a wall or electrical box, use the mounting bracket that comes with

the device. Follow these steps:

1) Following these guidelines, screw the mounting bracket to a wall or electrical

box (NEMA enclosure):

zThe mounting bracket tabs should be pointing upward.

zIf mounting to drywall, use the 4 screws and 4 wall anchors.

zIf mounting to an EU electrical box (60.3mm), use 2 threaded screws and

insert into the holes marked “A” in the diagram shown below.

zIf mounting to a US electrical box (83.3mm), use 2 threaded screws and insert

into the holes marked “B” in the diagram shown below.

2) Connect the Ethernet cable (for power and network connection) to the LAN

port on the back of the AP.

3) To mount the AP onto the mounting bracket, insert the mounting-bracket tabs

into the slots on the back of the AP.

: If you are mounting the AP on a wall, you cannot use the slots on the

bottom narrow edge of the device. Instead, you must use the slots on back of the AP.

Tabletop Mounting

To install the AP on a flat surface such as a table or desktop, follow these steps:

1) Insert the tabs on the table stand into the slots on the side of the AP, as shown

in the illustration. Align the cable routing cut out toward the upper part of the

stand.

2) To lock the stand to the AP, slide the stand back and the AP forward, as

shown here:

3) Place the AP and table stand on the table.

4) Connect the Ethernet cable for power and network connection to the LAN port

on the back of the AP.

Ceiling Mounting

To install your AP on the ceiling, use the ceiling bracket kit that comes with the device.

Follow these steps:

1) Attach the metal slider to the back of the AP using the two small screws. The

slider should still be able to slide after the screws are tightened, Make sure

that the slide is left in the same position as shown below so that the slots are

accessible.

2) Clip the metal ceiling bracket to a suitably located ceiling tile separator.

3) Slide the moveable section into place and tighten the screw (found

underneath) to secure it.

4) Position the AP so that the two tabs from the ceiling bracket can be inserted in

the slots in the AP.

Andere Handbücher für AP9552

Inhaltsverzeichnis

Andere 3Com Drahtloser Zugangspunkt Handbücher

3Com

3Com AP3850 Bedienungsanleitung

3Com

3Com 8000 Bedienungsanleitung

3Com

3Com MAP 2750 Bedienungsanleitung

3Com

3Com 3950 Bedienungsanleitung

3Com

3Com OfficeConnect 3CRWE454A72 Bedienungsanleitung

3Com

3Com AirProtect Sensor 5750 Bedienungsanleitung

3Com

3Com 3CRWEASYA73 / WL-575 Bedienungsanleitung

3Com

3Com 7250 Bedienungsanleitung

3Com

3Com AirConnect Bedienungsanleitung

3Com

3Com 3CRWE825075A Bedienungsanleitung

3Com

3Com WL-607 Bedienungsanleitung

3Com

3Com 8500 Bedienungsanleitung

3Com

3Com 8760 - Wireless Dual Radio 11a/b/g PoE Access... Bedienungsanleitung

3Com

3Com 3CRWE675075 - 11a/b/g Wireless LAN Workgroup... Bedienungsanleitung

3Com

3Com 8200 Bedienungsanleitung

3Com

3Com AirConnect 9550 Bedienungsanleitung

3Com

3Com 7608 Bedienungsanleitung

3Com

3Com OfficeConnect 3CRWE454G72 Bedienungsanleitung

3Com

3Com OfficeConnect 3CRWE41196 Bedienungsanleitung

3Com

3Com AP9552 Bedienungsanleitung

3Com

3Com 3CRWX275075A - Wireless LAN Managed Access Point... Bedienungsanleitung

3Com

3Com 3CRWX385075A - Wireless LAN Managed Access Point... Bedienungsanleitung

3Com

3Com 3CRWE776075 Bedienungsanleitung

3Com

3Com 3CRWE920G73 Bedienungsanleitung

Beliebte Drahtloser Zugangspunkt Handbücher anderer Marken

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Bedienungsanleitung

Ubiquiti

Ubiquiti NanoStation NSM2 Bedienungsanleitung

Cisco

Cisco Aironet 1550 Series Bedienungsanleitung

Aruba

Aruba IAP-335 Bedienungsanleitung

Advantek Networks

Advantek Networks AWN-AP-54MR Bedienungsanleitung

IP-COM

IP-COM AP355 Bedienungsanleitung

Buffalo

Buffalo AirStation WLA-L11G Bedienungsanleitung

EnGenius

EnGenius EnStationACv2 Bedienungsanleitung

D-Link

D-Link DAP-3662 Bedienungsanleitung

xG Technology

xG Technology xMax CN1300 Bedienungsanleitung

Widelink

Widelink ezWave WAP-1100 Series Bedienungsanleitung

Edimax

Edimax CAP1200 Bedienungsanleitung

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Bedienungsanleitung

Aruba

Aruba AP-203R Bedienungsanleitung

LuXout Shades

LuXout Shades LUXSHADE MOTION Bedienungsanleitung

CreatComm

CreatComm TB5F Bedienungsanleitung

SineDigital

SineDigital MW-1500AP(H) Bedienungsanleitung

TP-Link

TP-Link AP9650 V1 Bedienungsanleitung
