ABBA SPB05 Bedienungsanleitung

SPB05

www.ABBALightingUSA.com

INSTALLATION GUIDE

IMPORTANT SAFETY INSTRUCTIONS

LIGHTEN LAMP IS HOT!

WARNING: TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS:

Please exercise caution when using the lamp, as it tends to HEAT up rapidly.

We recommend taking necessary safety measures to ensure optimal usage.

For your safety, please refrain from touching the HOT lens, guard, or enclosure.

We recommend waiting for the product to cool down before handling it.

To prevent any fire hazards, please ensure that the lamp is kept away from

materials that may easily catch fire. We appreciate your cooperation in

maintaining a safe and secure environment.

RATED VOLTAGE 12V AC/DC

Congratulations on your purchase of this high-quality product! We want to ensure

that you have the best possible experience with it, so we kindly ask that you take a

moment to carefully read and follow all instructions before assembly, installation,

and use. By doing so, you'll not only guarantee correct function and safety, but also

optimize the full potential of this exceptional product. Thank you for choosing us as

your trusted provider of top-notch products - we truly appreciate your business!

WARRANTY

We stand behind the quality of our product and offer a Lifetime warranty. Kindly ensure that you

keep the proof of purchase as it will be required for any warranty claims.

Warranty will be void if there is any damage due to improper usage or

modification to the fixture.

Failure to comply with the instruction in this manual may increase the risk of

damage or injury and will void warranty.

For safety reasons, we recommend that only a qualified professional install

this electrical product.

Before attempting to install this unit, ensure all power connections are off for

your own safety.

www.ABBALightingUSA.com

Do not instal within 10 feet of a pool, spa or fountain

CAUTION:

fixture(s) must be installed in accordance with all local codes and ordinances.

INSTALLATION INSTRUCTION

www.ABBALightingUSA.com

FIXTURE

LENS

BULB

FIXTURE

LENS

5.

6.

7.

To ensure optimal performance and safety, it is important to

use our fixtures ONLY with a low voltage landscape

transformer. This transformer reduces the voltage from

120V to 12V, making it safe and suitable for outdoor use.

When installing the fixture(s), please follow these

instructions carefully:

1. Before installation, please ensure that the power is turned

off for your safety.

2.To establish a dependable and enduring electrical

connection between fixture wires and the main line in

outdoor or underground installations, it is essential to select

a suitable main cable connector designed for direct burial.

This connector should be chosen based on its ability to

withstand environmental conditions, resist moisture and

corrosion, and provide robust insulation. By adhering to

industry standards and best practices, including proper wire

stripping and secure fastening techniques, a reliable

connection can be established, ensuring optimal

performance, safety, and longevity of the system.

We recommend using WN12 waterproof wire nuts (sold

separately) for optimal connectivity.

3. Attach the fixture(s) wires to the main cable connector

suitable for direct burial and use waterproof wire nuts.

WN12 (Sold separately).

4. For a secure and stable mounting, dig a small hole and

insert the spike into the ground, ensuring it is vertical and

firm.

5. Remove the lens from the fixture.

6. Insert the bulb with the correct wattage.

CAUTION: Do not exceed maximum

wattage on the fixture.

7. Place the lens back onto the fixture.

8. Adjust the light angle.

9. Turn on the power.

We strongly recommend that the main cable from the transformer be buried

underground for safety reasons. Additionally, please be sure to avoid

exceeding the maximum wattage on the fixture(s) to prevent any damage or

hazards.

WN12 (Sold separately)

Main Line

Connect the wires using

www.ABBALightingUSA.com
