Getting Familiar with your Computer

1-1

This computer combines high-performance,

versatility, power management features and

multimedia capabilities with unique style and

ergonomic design. Work with unmatched

productivity and reliability with your new power

computing partner.

This chapter gives an in-depth “tour” of the

computer’s many features.

Getting Familiar with your Computer

1-2

1.1 Features

This computer was designed with the user in

mind. Here are just a few of its many features:

Performance

Intel Pentium®processor with MMX™

technology

64-bit main memory and external (L2) cache

memory

Large LCD display and PCI local bus video

with graphics acceleration

Internal CD-ROM drive and external 3.5-inch

floppy drive, or internal 3.5-inch floppy drive

High-capacity, Enhanced-IDE hard disk

Lithium-Ion or Nickel Metal-Hydride battery

pack

Power management system with standby and

hibernation power saving modes

Multimedia

16-bit high-fidelity stereo audio with 3-D

sound

Built-in dual speakers

Ultra-slim, high-speed CD-ROM drive

Getting Familiar with your Computer

1-3

Connectivity

High-speed fax/data modem port1(on some

models)

Fast infrared wireless communication

USB (Universal Serial Bus) port

Human-centric Design and Ergonomics

Lightweight and slim

Sleek, smooth and stylish design

Full-sized keyboard

Wide and curved palm rest

Ergonomically-centered touchpad pointing

device

Expansion

CardBus PC card (formerly PCMCIA) slots

(two type II/I or one type III) with ZV (Zoomed

Video) port support

Port replicator option for one-step

connect/disconnect from peripherals

User-upgradeable memory and hard disk

1This feature is available only in the U.S., Canada, Japan and

Taiwan. For other regions, you can connect a PC Card modem.

Consult your dealer for details.

Getting Familiar with your Computer

1-4

1.2 Display

The large graphics display offers excellent viewing,

display quality and desktop performance graphics.

The computer supports two different display

configurations — DSTN or TFT.

Video Performance

PCI local bus video with graphics accelerator and

2MB EDO video RAM boost video performance.

Simultaneous Display

The computer’s large display and multimedia

capabilities are great for giving presentations. If

you prefer, you can also connect an external

monitor when giving presentations. This computer

supports simultaneous LCD and CRT display.

Simultaneous display allows you to control the

presentation from your computer and at the same

time face your audience. You can even connect an

LCD projection panel for large-audience

presentations.

Power Management

The power management system incorporates an

“automatic LCD dim” feature that automatically

decides the best settings for your display and at

the same time conserve power. See section 2.2 for

more information on power management.

Getting Familiar with your Computer

1-5

Opening and Closing the Display

To open the display, slide the display lid latch to

the left and lift up the lid. Then tilt it to a

comfortable viewing position. The computer

employs a microswitch that turns off the display

(and enters standby mode) to conserve power

when you close the display cover, and turns it

back on when you open the display cover.

Note: If an external monitor is connected, the

computer turns off the display (but does not enter

standby mode) when you close the display cover.

To close the display cover, fold it down gently until

the display cover latch clicks into place.

Warning: To avoid damaging the display, do not

slam it when closing. Do not place any object

on top of the computer when the display is

closed.

Getting Familiar with your Computer

1-6

1.3 Indicators

The computer has six easy-to-read indicator lights

(LEDs) near the display cover.

Two of these LEDs, Power and Standby, are visible

even when you close the display cover so you can

see the status of the computer while the cover is

closed.

Getting Familiar with your Computer

1-7

# Icon Function Description

1Power Lights when the computer is

on.

2Standby Lights when the computer

enters Standby mode.

3 Media Activity Lights when the floppy drive,

hard disk or CD-ROM drive

is active.

4Battery Charge Lights when the battery is

being charged.

5Caps Lock Lights when Caps Lock is

activated.

6Num Lock Lights when Num Lock is

activated.

Getting Familiar with your Computer

1-8

1.4 Keyboard

The keyboard has full-sized keys that includes an

embedded keypad, separate cursor keys, two

Windows 95 keys and twelve function keys.

1.4.1 Special Keys

Lock Keys

The keyboard has three lock keys which you can

toggle on and off.

Lock Key Description

Caps

Lock When Caps Lock is on, all alphabetic characters

typed are in uppercase.

Fn-

NumLk When Num Lock is on, the embedded keypad is

in numeric mode. The keys function as a

calculator (complete with arithmetic operators

+, -, *, and /). Use this mode when you need to

do a lot of numeric data entry. A better solution

would be to connect an external keypad.

Fn-ScrLk When Scroll Lock is on, the screen moves one

line up or down when you press ↑or ↓

respectively. Scroll lock does not work with

some applications.

Getting Familiar with your Computer

1-9

Embedded Keypad

The embedded keypad functions like a desktop

numeric keypad. It is indicated by small

characters located on the upper right corner of the

keycaps. To simplify the keyboard legend, cursor-

control key symbols are not printed on the keys.

Desired Access Num Lock On Num Lock Off

Number keys on

embedded keypad Type numbers in a

normal manner.

Cursor-control

keys on

embedded keypad

Hold Shift while

using cursor-

control keys.

Hold Fn while

using cursor-

control keys.

Main keyboard

keys Hold Fn while

typing letters on

embedded keypad.

Type the letters

in a normal

manner.

Note: If an external keyboard or keypad is

connected to the computer, the numlock feature

automatically shifts from the internal keyboard to

the external keyboard or keypad.

Getting Familiar with your Computer

1-10

Windows 95 Keys

The keyboard has two keys that perform Windows

95-specific functions.

Key Description

Windows

logo key Start button. Combinations with this key

performs special functions. Below are a few

examples:



Windows + Tab Activate next Taskbar

button



Windows + E Explore My Computer



Windows + F Find Document



Windows + M Minimize All



Shift + Windows + M Undo Minimize All



Windows + R Display Run dialog box

Application

key Opens the application’s context menu (same

as right-click).
