ACTi A416 Bedienungsanleitung

Zoom Bullet Camera

Hardware Manual

A416, A418

2020/01/03

www.acti.com

Hardware Manual

Table of Contents

Precautions 4

Safety Instructions............................................................................6

Introduction 7

List of Models....................................................................................7

Package Contents.............................................................................8

Physical Description.........................................................................9

Installation Procedures 10

Step 1: Install the Camera..............................................................10

Step 2: Waterproof the Ethernet Cable .........................................12

Using the Cable Gland.................................................................12

Step 3: Connect to Network...........................................................15

Step 4: Access the Camera Live View...........................................15

Other Connections 16

Connecting a Power Adapter (Optional).......................................16

Connecting Digital Input / Output Devices (Optional) .................17

Connecting Audio Devices.............................................................18

Other Accessories 19

How to Install / Remove the Memory Card ...................................19

Accessing the Camera 20

Configure the IP Addresses...........................................................20

Using DHCP Server to Assign IPAddresses................................20

Using the Default Camera IPAddress..........................................22

Access the Camera.........................................................................24

www.acti.com

Hardware Manual

www.acti.com

Hardware Manual

Precautions

Read these instructions

Read all the safety and operating instructions before using this product.

Heed all warnings

Adhere to all the warnings on the product and in the instruction manual. Failure to follow the

safety instructions given may directly endanger people, cause damage to the system or to

other equipment.

Servicing

Do not attempt to service this product yourself as opening or removing coversmay expose you

to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

Trademarks

ACTi and ACTi logo are registered trademarks of ACTi Corporation. All other names and

products used in this manual are registered trademarks of their respective companies.

Liability

Every reasonable care has been taken during the writing of this manual. Please inform your

local office if you find any inaccuracies or omissions. ACTi will not be held responsible for any

typographical or technical errors and reserves the right to make changes to the product and

manuals without prior notice.

www.acti.com

Hardware Manual

Federal Communications Commission Statement

This equipment has been tested and found to comply with the limits for a

class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications to the equipment that are not expressly approved by the

responsible party for compliance could void the user’s authority to operate the equipment.

European Community Compliance Statement

This product has been tested and found to comply with the limits for Class B

Information Technology Equipment according to European Standard EN 55022

and EN 55024. In a domestic environment, this product may cause radio interference in which

cause the user may be required to take adequate measures.

www.acti.com

Hardware Manual

Safety Instructions

Cleaning

Disconnect this product from the power supply before cleaning.

Accessories and Repair Parts

Use only the accessories and repair parts recommended by the manufacturer. Using other

attachments not recommended by the manufacturer may cause hazards.

Water and Moisture

Install other devices (such as PoE injector, alarm, etc.) that will be used with the camera in a

dry place protected from weather.

Servicing

Do not attempt to service this product yourself. Refer all servicing to qualified service

personnel.

Damage Requiring service

Disconnect this product from the power supply immediately and refer servicing to qualified

service personnel under the following conditions.

1) When the power-supply cord or plug is damaged

2) If liquid has been spilled, or objects have fallen into the product.

3) If the inner parts of product have been directly exposed to rain or water.

4) If the product does not operate normally even by following the operating instructions in this

manual.Adjust only those controls that are covered by the instructionmanual, as improper

adjustment of other controls may result in damage, and will often require extensive work

by a qualified technician to restore the product to its normal operation.

Safety Check

Upon completion of any service or repairs to this product, ask the service technician to perform

safety checks to determine if the product is in proper operating condition.

www.acti.com

Hardware Manual

Introduction

List of Models

This hardware manual contains the following models:

A416

4MP Zoom Bullet with D/N, Adaptive IR, Extreme WDR, SLLS,

5x Zoom Lens

A418

6MP Zoom Bullet with D/N, Adaptive IR, Superior WDR, SLLS,

5x Zoom Lens

www.acti.com

Hardware Manual

Package Contents

Camera

Mounting Screw Kit

Cable Gland with Washer

Wrench

Drill Template

Quick Guide &

Warranty Card

Drill Template

Warranty Card

www.acti.com

Hardware Manual

Physical Description

Item

Description

Ethernet Port

Connects to a network using a standard Ethernet cable.

Digital Input/ Output

Connects to digital input and output device, such as an alarm

trigger, panic button, LED light, etc.

Audio Input / Output

Connects to an audio input and output device, such as a

microphone and speaker.

DC 12V Power

Connects to an external DC 12V power adapter.

Reset Button

Press and hold the reset button to restore the camera factory

default settings.

Analog Video Output

Connects to a video output device, such as a camera installation

kit or monitor for testing. Use the bundled video output connector

to connect to an external monitor.

Memory Card Slot

Insert a memory card into the slot for local recording.

www.acti.com

Hardware Manual

Installation Procedures

Step 1: Install the Camera

1. Mark the screw holes or attach the bundled drill template on the target surface.

NOTE: Depending on the surface where you will install the camera, it may be necessary to

drill four (4) holes and use the supplied screw tox.

2. If the cable will pass through the surface, drill the cable hole as indicated on the drill

template. If the cable will be routed along the surface, route the cable through the gap

on the bracket. For outdoor installations, you may need to purchase the optional junction

box to protect the cables, contact ACTi Sales for details.

3. Mount the camera to the surface using four (4) screws.

4. Loosen the screw to tilt, pan, or adjust the camera orientation.
