ACTi I98 Bedienungsanleitung

Outdoor Speed Dome

Hardware Manual

I98

2015/11/24

www.acti.com

Hardware Manual

Table of Contents

Precautions.............................................................4

Safety Instructions .................................................................................... 6

Introduction.............................................................7

List of Models............................................................................................. 7

Package Contents...................................................................................... 8

Physical Description ................................................................................. 9

Mounting Options.....................................................................................11

Other Mounting Accessories................................................................. 12

Before Installation.................................................13

Insert the Memory Card (Optional)......................................................... 13

Attach the Safety Strap ........................................................................... 15

Installation Procedures........................................16

Mount the Camera ................................................................................... 16

Attach the Ferrite Cores.......................................................................... 18

Waterproof the Cable Connections........................................................ 20

Using the Cable Gland.......................................................................... 21

Using the Conduit Gland....................................................................... 25

Using the Junction Box ......................................................................... 29

Connect to Network................................................................................. 31

Other Cable Connections.....................................32

How to Use the Power Adapter............................................................... 32

www.acti.com

Hardware Manual

How to Replace the Fuse...................................................................... 33

How to Connect Digital Input / Digital Output Devices......................... 34

Connecting DI/DO Devices................................................................... 35

How to Connect Audio Devices.............................................................. 39

Accessing the Camera .........................................40

Configure the IP Addresses.................................................................... 40

Access the Camera.................................................................................. 44

www.acti.com

Hardware Manual

Precautions

Read these instructions

You should read all the safety and operating instructions before using this product.

Heed all warnings

You must adhere to all the warnings on the product and in the instruction manual. Failure to follow

the safety instructions given may directly endanger people, cause damage to the system or to

other equipment.

Servicing

Do not attempt to service this video device yourself as opening or removing covers may expose

you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

Trademarks

All names used in this manual are probably registered trademarks of respective companies.

Liability

Every reasonable care has been taken during the writing of this manual. Please inform your local

office if you find any inaccuracies or omissions. We cannot be held responsible for any

typographical or technical errors and reserve the right to make changes to the product and

manuals without prior notice.

www.acti.com

Hardware Manual

Federal Communications Commission Statement

This equipment has been tested and found to comply with the limits for a class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications to the equipment that are not expressly approved by the

responsible party for compliance could void the user’s authority to operate the equipment.

European Community Compliance Statement

This product has been tested and found to comply with the limits for Class B

Information Technology Equipment according to European Standard EN 55022

and EN 55024. In a domestic environment, this product may cause radio interference in which

cause the user may be required to take adequate measures.

www.acti.com

Hardware Manual

Safety Instructions

Cleaning

Disconnect this video product from the power supply before cleaning.

Attachments

Do not use attachments or accessories not recommended by the video product manufacturer as

they may cause hazards.

Water and Moisture

Install other devices (such as PoE injector, alarm, etc.) that will be used with the camera in a dry

place protected from weather.

Servicing

Do not attempt to service this video product yourself. Refer all servicing to qualified service

personnel.

Damage Requiring service

Disconnect this video product from the power supply immediately and refer servicing to qualified

service personnel under the following conditions:

1) When the power-supply cord or plug is damaged.

2) If liquid has been spilled or objects have fallen into the video product.

3) If the inner parts of the video product have been directly exposed to rain or water.

4) If the video product does not operate normally by following the operating instructions in this

manual. Adjust only those controls that are covered by the instruction manual, as an improper

adjustment of other controls may result in damage, and will often require extensive work by a

qualified technician to restore the video product to its normal operation.

Safety Check

Upon completion of any service or repairs to this video product, ask the service technician to

perform safety checks to determine if the video product is in proper operating condition.

www.acti.com

Hardware Manual

Introduction

List of Models

This hardware manual contains the following model:

I98

2MP Video Analytics Outdoor Speed Dome with D/N, Adaptive IR,

Extreme WDR, SLLS, 33x Zoom lens

www.acti.com

Hardware Manual

Package Contents

Check if the following items come with the camera package. If any of them is missing, please

contact your local sales agents or the Customer Help Desk (CHD).

Camera

Power Cord

Power Adapter

Universal Converter

Cable Gland

Conduit Gland

Ferrite Core (x3)

Safety Strap

DI/DO Terminal

Blocks (x2)

Screws

Quick Installation

Guide

Warranty Card

NOTE: The above pictures are for reference only; actual items may slightly vary.

www.acti.com

Hardware Manual

Physical Description

No.

Item

Description

Power LED

The Power LED lights red when the camera is powered up and

goes off when the boot up process is complete.

Reset Button

The reset button is used to restore the factory default settings

of the camera, including the administrator’s password.

To reset the camera, do the following: Press and hold the reset

button for at least 5 seconds or until the Power LED turns on.

Memory Card Slot

Insert a memory card into this slot for local recording purposes.

See Insert the Memory Card (Optional) on page 13 for more

information.

NOTE: Supports microSDHC cards only.

Audio Output

This jack connects to an audio output device, such as a

speaker. See How to Connect Audio Devices on page 39.

Audio Input

This jack connects to an audio input device, such as a

microphone with built-in amplifier. See How to Connect Audio

Devices on page 39.

NOTE: Make sure that the connected audio input device has a

built-in amplifier. Connecting an ordinary microphone will dwarf

sounds and will result in inaudible recording.

www.acti.com

Hardware Manual

No.

Item

Description

Digital Input / Output

The two (2) connectors connect to digital input or output

devices, such as an alarm trigger, panic button, etc. Digital

Input (DI) and Digital Output (DO) devices are used for

applications like motion detection, event triggering, alarm

notifications, etc. See How to Connect Digital Input / Digital

Output Devices on page 34 for information.

AC 24V Power Input

This jack connects to the power adapter and power cord to

supply power to the camera. See How to Use the Power

Adapter on page 32.

Ethernet Port

The Ethernet port connects to a network using a standard

Ethernet cable.
