Quick Installation Guide

This guide contains the basic information you need to quickly setup the

Camera. For detailed information on installations or operations, please refer

to the Hardware Manual and Firmware Manual on ACTi website

(www.acti.com).

Step 1: Unpack the Device

Check the camera package and make sure all items are present. The

complete package list is shown on the camera Hardware Manual.

Step 3: Connect the Device

Basic Connection Example

Camera

Step 2: Mount the Device

Mounting varies per camera model. Check the most suitable mounting

method from the Hardware Manual or from our Mounting Accessory

Selector Tool (www.acti.com/mountingselector).

PC

Power Source

PoE Switch

Camera Camera Camera Camera Camera Camera

By IP Utility

a. Download IP Utility

from our website

(www.acti.com).

b. Run IP Utility to start

searching for network

devices.

c. Click the IP address of

the Camera.

On Network with DHCP Server / Router (Automatic IP)

1. Connect the device and the PC within the same network segment. Once

connected, an IP address will be assigned to the Camera.

2. Find the Camera via Windows Explorer or IP Utility.

3. The Web Congurator appears with the IP address of the Camera on

the URL bar. Login to access the Camera.

Note: For full functionality, it is recommended to use Microsoft Internet Explorer®.

When using non-IE browsers, free 3rd party software plug-ins may be required.

Refer to the device Firmware Manual for more information.

By Windows Explorer

a. Go to Start > My Computer >

Network.

b. Double-click on the device name.

Step 4: Access the Device

On Network without DHCP Server (Default IP)

1. If necessary, congure the IP settings of your PC to match with the

network segment of the Camera.

2. Open a web browser and type 192.168.0.100 on the URL address bar.

The Web Congurator appears. Login to access the Camera.

Camera Defaults

IP Address:

192.168.0.100

Subnet:

255.255.255.0

PC can be assigned with

IP Address (different from Camera)

Example:

192.168.0.99

Subnet (same with Camera):

255.255.255.0

How to congure the PC IP address?

Click Start > Control Panel > Network and Sharing Center >

Change adapter settings. Then follow the steps below:

1

2

3

4

Note: For full functionality, it is recommended to use Microsoft Internet Explorer®.

When using non-IE browsers, free 3rd party software plug-ins may be required.

Refer to the device Firmware Manual for more information.

Step 5: Log-in

Default

Account: admin

Password: 123456

1. On the Login page, type the Account and Password.

2. Select Language,

if necessary.

3. Click Login.

The Live View screen

appears.

4. Click to access the

Setup menu to modify

the Camera settings.

For more detailed instructions, please refer to the “Firmware

Manual” downloadable from the website (www.acti.com).

ACTi Connecting Vision and its logo are registered trademarks of ACTi Corporation.

Microsoft®and Windows®are registered trademarks of Microsoft Corporation.

All other products or company names mentioned in this document are trademarks or

registered trademarks of their respective owners.

Copyright © 2014, ACTi Corporation All Rights Reserved

V.2014.05.30
