VMGB-200

User’s Manual

2019/10/21

www.acti.com

VMGB-200 USER’S MANUAL

Physical Description

Item

Description

BTS Camera

Behavior Tracking Sensor camera

Power Button

To power on

If the device does not automatically turn on when

the power cable is plugged in, long press the

power button for 4 seconds to power On the

device.

To power off

To power off or restart the device, long press for 2

seconds.

To shut down the device, long press for 6 seconds

(RED LED will be lit)

Reset Button

Press to reset the device to default settings.

COM Port

Reserved port to control large format display

(currently not supported)

USB 2.0 Ports

Use for USB keyboard, mouse, and other external

input devices

Memory Card Slot

Plug in microSD card for storage purposes

LAN Port

OUT: For internet connection

IN: For local network connection

HDMI Ports

To connect monitor via HDMI connection

Power Connector

Plug in the power cable. Device will auto power on

www.acti.com

VMGB-200 USER’S MANUAL

Installation

Recommended Installation

Place the device as close as possible to eye level. If tilting the device is unavoidable, limit

the tilt up to 15° only to ensure accuracy.

Place the device on the center and above the point of interest. For instance, place the

device at the top center of a screen frame. If placing on top will cause the camera to

deviate from being eye level, try to place it instead on the bottom frame of the screen.

The distance between the camera and the point of interest should be within 2 to 4

meters.

Position the camera towards the main flow of traffic.

Avoid During Installation

Dark location: Low light slows down the frame rate which affects accuracy.

Harsh backlight conditions: This may cause sever loss of contrast of captured image

Strong directional light on the face may affect detection

Outdoor shop windows, since direct sunlight, rain drops, night conditions, and vehicles in

the background may make detection less efficient.

Any element that would create visual anomalies (e.g. lights reflection on a window). If you

plan on installing on a shop window in a mall, we recommend placing the device directly

against the window.

www.acti.com

VMGB-200 USER’S MANUAL

User Interface

Connect and use a USB mouse to operate the device. Input the password “admin” to open the

user interface.

Left-click mouse to go to apps program list.

Right-click mouse to go back the previous page.

Back to Home Screen: Mouse over and click the Oicon to go back to the Home screen.

Apps Menu: Click the ^icon to launch the apps menu.

Network Status: Shows the network connection status.

Internet connected: Internet cable is connected (using the OUT port)

Wi-Fi connected: Connected to Wi-Fi AP

www.acti.com

VMGB-200 USER’S MANUAL

Calibrate the Device

Launch the Camera app to calibrate the device Behavior Tracking Sensor (BTS).

7F, No. 1, Alley 20, Lane 407, Sec. 2, Ti-Ding Blvd., Neihu District, Taipei, Taiwan 114, R.O.C.

TEL : +886-2-2656-2588 FAX : +886-2-2656-2599

Email: sales@acti.com
