ActionTec Wireless-Ready Bedienungsanleitung

User Manual

Wireless–Ready

DSL Gateway

Table of Contents

Introduction 1

Package Contents 1

Minimum System Requirements 1

Technical Support 2

Connecting the Gateway 3

Connecting the Power and DSL Cable 3

Connecting to a Computer 5

Connecting the Phone Filters 7

Connecting Network Computers 8

Configuring the Gateway 11

Using Qwest DSL 15

Connecting to the Internet 15

Disconnecting from the Internet 15

Basic Setup 17

Gateway Features 19

Advanced Setup 23

Accessing Advanced Setup 23

WAN IP Address 24

Wireless Settings 27

LAN IP Address 29

DHCP Server 30

Services Blocking 31

Website Blocking 32

VPN Pass Through 32

Remote Management 33

Port Forwarding 34

DMZ Hosting 34

MAC Address Cloning 35

Status 35

Utilities 37

Web Activity Log 37

DSL Settings 38

Restore Default Settings 38

Upgrade Firmware 38

Troubleshooting 41

Reference 43

Locating Computer Information 43

Locating Windows Operating System Files 44

Wiring Information 46

Computer Security 49

Securing the Gateway and Computer 49

Specifications 53

General 53

Wireless Operating Range 54

LED Indicators 54

Environmental 55

Glossary 57

Notices 61

Regulatory Compliance Notices 61

Modifications 61

Limited Warranty 63

Introduction

Thank you for purchasing the Actiontec Wireless-Ready Gateway. The Gateway is

the simplest way to connect a multiple number of computers to a single high-

speed broadband connection. This easy-to-use product is perfect for the home

office or small business. If you want to take your computing to the next level, the

Actiontec Wireless-Ready DSL Gateway is one of the keys to your success.

Package Contents

Four-port Actiontec Wireless-Ready DSL Gateway

Power adapter

Ethernet cable

USB cable

Installation CD

User guide and quick start guide

Warranty and registration card

Minimum System Requirements

Active DSL service

Computer with an 10 Mbps or 10/100 Mbps Ethernet connection

Microsoft Windows 95, Windows 98, Windows 98 Second Edition (SE),

Windows Millennium Edition (Me), Windows NT 4.0, Windows 2000,

Windows XP,MacOS 7.1+, Mac OS 8.0+, Mac OS 9.0+, or Mac OS X+

☞Note:USB LAN port is not supported with Microsoft Windows

95, Windows NT 4.0, and Mac OS

Internet Explorer 4.0 or higher (5.x recommended) or Netscape Navigator

4.0 or higher (4.7 recommended)

TCP/IP network protocol installed on each computer

Actiontec Wireless-Ready DSL Gateway

Technical Support

Actiontec Electronics prides itself on making high-quality, durable, high-perform-

ance products. If you need assistance, the Actiontec Technical Support Department is

available every day from 6 A.M. to 11 P.M. (MST) to provide professional support.

Actiontec Electronics, Inc.

760 N. Mary Avenue

Sunnyvale, CA 94085

Technical Support

Phone: 719-884-8300

E-mail: techsupp@actiontec.com

Internet: www.actiontec.com/support

Connecting

the Gateway

The instructions that follow parallel closely with the steps contained in the Installation

Buddy, which provides a visual guide to setting up the Gateway. It is recommended

that the user run the Installation Buddy first, before attempting any other procedures.

To set up the Gateway, the user must first connect it to a computer via USB or

Ethernet cable. After connecting this first computer, other computers can be added

to the home network via USB,Ethernet, or wirelessly (see “Connecting Additional

Computers on page xx).

Connecting the Power and DSL Cable

1. Get the DSL Gateway from your DSL Quick Start Kit and take it out of the bag.

2. Get the Power Cord out of the Black Bag and plug the smaller end of the

Power Cord into the Black Port located on the back of the DSL Gateway.

Actiontec Wireless-Ready DSL Gateway

3. Confirm that the Power Light on the DSL Gateway is green.

4. Get the Phone Line Splitter out of the Black Bag.and plug the thin, rectan-

gular end of the Splitter into the Phone Jack closest to your computer

5. Get the Black DSL Cable out of the Black Bag.and plug one end of the DSL

Cable into the DSL Port located on the back of the DSL Gateway.

6. Plug the other end of the DSL Cable into one of the two ports on the Splitter

plugged into the Phone Jack closest to your computer.

Chapter 2 Connecting the Gateway

7. Confirm that the Power and Internet Lights on the DSL Gateway are solid

green.

☞

Note:Ifthe Internet Light continues to blink, confirm you have

received notification from your DSL Service Provider that your

DSL service is on. Otherwise, contact your DSL Service Provider

immediately.

Connecting to a Computer

There are two ways to connect the Gateway to a computer: Ethernet or USB cable.

Ethernet

1. Get the Ye l l o w C a b l e from the Ye l l o w Bag,and plug one end of the Yellow

Cable into one of the Ye l l o w Po r t s on the back of the DSL Gateway. The

Yellow Cable can be plugged into any of the Yellow Ports.

Actiontec Wireless-Ready DSL Gateway

2. Plug the loose end of the Ye l l o w C a b l e into the Ethernet Port on the back of

the computer.

3. Confirm that one of the four Ethernet Network Lights on the DSL Gateway

is green (this may take a few moments).

☞

Note:Ifnone of the Ethernet Network Lights glows green,

check the Yellow Cable and ensure it has been connected prop-

erly.

USB

1. Get the Purple Cable from the Purple Bag and plug one end of the Purple

Cable into the Purple Port on the back of the Gateway.

Chapter 2 Connecting the Gateway

2. Plug the loose end of the Purple Cable into the USB Port on the front or

back of your computer.

Connecting the Phone Filters

Phone filters separate the DSL signal from the voice signal on the phone line to

allow the user to talk on the phone and be online at the same time. All devices

using the same phone line (the same phone number) as the DSL connection

require phone filters, including telephones, fax machines, caller ID boxes, and

answering machines.

To install a phone filter:

1. Unplug the device (telephone, answering machine, etc.) from the phone jack.

Caution:DO NOT unplug the black DSL Line from the phone

jack near your computer.

2. Open the Clear Bag and remove the phone filters.The bag should contain

four small phone filters and one wall-mount phone filter.

If a wall-mount telephone needs a phone filter, use the wall mount phone filter.

Take the telephone off of the wall and install the wall-mount phone filter in the

phone jack, securing it with the screws (see the figure on the next page, after Step

3). For other devices that need phone filters, use the small phone filters.
