ActionTec SBWD50A Bedienungsanleitung
Wireless Display
Receiver
Model # SBWD50A
Installation Guide
This Installation Guide will walk you through the easy steps
to set up your ScreenBeam Mini Receiver. During this
process, we’ll show you how to :
AInstall the Receiver
B1Connect Using
Windows 8.1 or Higher
B2Connect Using Intel WiDi App
B3Connect Using WiFi
Miracast-Enabled Device
Part No: 0530-0703-000
SBmini-qsg-0530-0703-000-EN v2.indd 1 2014/3/7 14:26:51
Welcome!
Step2Plug the male connector (smaller end) of the USB
cable to the ScreenBeam Mini’s micro USB port labeled
“Power”.
Step3Plug the ScreenBeam Mini Display Receiver into an
available HDMI port on your HDTV.
AInstall the Receiver
Congratulations on your purchase of a ScreenBeam Mini
Wireless Display Receiver. The Mini Wireless Display Receiver
connects to your compatible Intel WiDi or Miracast wireless
display-capable device, and displays the device’s screen on
your HDTV.
Step1Get the ScreenBeam Mini Wireless Display Receiver,
USB cable and HDMI cable from the ScreenBeam Mini box.
Step4Plug the male connector (larger end) of the USB
cable to a USB port on your HDTV.
SBmini-qsg-0530-0703-000-EN v2.indd 2 2014/3/7 14:26:51
Step5Turn on your TV and switch the input source until
you see the Ready to Connect screen.
Note: If you cannot plug the Receiver into an HDMI port on
your TV (due to other components, or a poorly accessible
port), use the supplied HDMI cable to connect the Receiver.
SBmini-qsg-0530-0703-000-EN v2.indd 3 2014/3/7 14:26:51
B1 Connect Using Windows 8.1 or Higher
Step1From the Windows desktop,
navigate to the Charms menu and
select Devices. You can also use the
shortcut keys, Windows + K.
Step2From the Charms menu,
click the Project icon.
Step3From the Project screen,
select Add a wireless display.
The ScreenBeam Mini Receiver is now connected to your
HDTV. Proceed to one of the next three sections of this Guide
(depending on the device you are using to connect to
ScreenBeam Mini) to nish the connection procedure.
SBmini-qsg-0530-0703-000-EN v2.indd 4 2014/3/7 14:26:51
Step4Select the ScreenBeam
Receiver from the list.
Step5Enter the PIN as displayed
on the television screen, then
connect and display.
Note: If you are running Windows 8.1 and the screens above
do not appear, go to http://www.actiontec.com/widi81 for
the latest software updates.
SBmini-qsg-0530-0703-000-EN v2.indd 5 2014/3/7 14:26:52
Step2The device scans for
available receivers. Select the same
receiver name as seen on the HDTV
and click Connect. (The Connect
Automatically checkbox is optional.)
Step1Find the Intel Wireless Display application on the
device and launch it. To nd the application, go to Windows
Search on your device and search for“Intel WiDi” in your apps.
2. ScreenBeam Mini only supports the 2.4GHz wireless fre-
quency. Make sure your device is not connected to a 5GHz
wireless router prior to connecting ScreenBeam Mini.
B2Connect Using Intel WiDi App
Note:
1. If your device’s OS is Windows 8.1 or higher, proceed to
section B1(“Connect Using Windows 8.1 or Higher”) for
connection instructions.
SBmini-qsg-0530-0703-000-EN v2.indd 6 2014/3/7 14:26:52
Step3Wait until the Receiver
displays a PIN on the HDTV, and a
PIN entry box on the screen of the
WiDi device. Enter the PIN in the
PIN entry box on the WiDi device,
then click Continue.
Step4The HDTV displays
messages to show the status of the
connection process.
Step5AConnection Successful
screen appears on your device’s
screen, as well as on the HDTV.
Display Tip: If the edges of the device screen cannot be
seen on the HDTV, adjust cropping. To do this, enter the
WiDi application and click Settings. Navigate to the “Picture
and Sound” section, click Adjust cropping…, and adjust the
HDTV picture by clicking plus (+) or minus (-).
SBmini-qsg-0530-0703-000-EN v2.indd 7 2014/3/7 14:26:52
CProduct Support & Additional Information
Step1On a Miracast-enabled Android device, locate and
open the Wireless Display Application.
B3Connect Using Miracast-Enabled Device
You can connect to ScreenBeam Mini from a Miracast-enabled
Android device, such as a smartphone, tablet, or game console
(nd the wireless display feature in Settings). Also, the device
should be running the latest software for best performance.
Note: The name of the Wireless Display Application depends
on the device type and model. Refer to the device’s carrier or
manufacturer user manual for more details.
Note: Make sure the device supports Intel Wireless Display
(WiDi) software version 3.5 or higher. To nd out what version
of Intel WiDi your device has, enter the Intel WiDi application
and click Help, then navigate to the “About WiDi” section. To
obtain the latest Intel WiDi software and drivers, go to:
http://www.intel.com/go/wirelessdisplayupdate
SBmini-qsg-0530-0703-000-EN v2.indd 8 2014/3/7 14:26:52
Step2The Wireless Display Application scans for available
receivers. Select the ScreenBeam Receiver from the list.
Step3Wait for the device to associate with the Receiver.
When it does, the device’s screen will be displayed on the HDTV.
Go to http://international.actiontec.com/support for prod-
uct support, updates, and more information including:
• Firmware Updates • Troubleshooting • Registration • FAQs
CProduct Support & Additional Information
B3Connect Using Miracast-Enabled Device
SBmini-qsg-0530-0703-000-EN v2.indd 9 2014/3/7 14:26:52
• Increase the separation between the equipment and receiver;
• Connect the equipment to an outlet on a circuit dierent from that to which the receiver is connected;
• Consult the dealer or an experience radio or television technician for help.
Modications
The FCC requires the user to be notied that any changes or modications made to this device that
are not expressly approved by Actiontec Electronics, Inc, may void the user’s authority to operate the
equipment.
Declaration of conformity for products marked with the FCC logo – United States only.
This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS stan-
dard(s). Operation is subject to the following two conditions:
General Regulatory and Compliance Notices
Important Safety Instructions
If applicable, when using electronic equipment, basic safety precautions should always be followed to
reduce the risk of re, electrical shock, and personal injury, including the following:
• Do not use this product near water – for example, near a bathtub, kitchen sink, laundry tub, or swim-
ming pool, or in a wet basement.
• FCC Class B Equipment
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmfulinterference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to try and correct the
interference by implementing one or more of the following measures:
• Reorient or relocate the receiving antenna;
SBmini-qsg-0530-0703-000-EN v2.indd 10 2014/3/7 14:26:52
