Adaptec ASA-7211C Bedienungsanleitung

ASA-7211C/F iSCSI ADAPTER

FOR INITIATOR APPLICATIONS

INSTALLATION GUIDE

ASA-7211 IG.book Page 1 Tuesday, February 11, 2003 10:04 AM

reproduced, stored in a retrieval system, or transmitted in any form or by any

means, electronic, mechanical, photocopying, recording or otherwise, without the

prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.

Trademarks

Adaptec, the Adaptec logo, and ASA are trademarks of Adaptec, Inc., which may be

registered in some jurisdictions.

Windows NT and Windows 2000 are trademarks of Microsoft Corporation in the US

and other countries, used under license.

All other trademarks are the property of their respective owners.

Changes

The material in this document is for information only and is subject to change

without notice. While reasonable efforts have been made in the preparation of this

document to assure its accuracy, Adaptec, Inc. assumes no liability resulting from

errors or omissions in this document, or from the use of the information contained

herein.

Adaptec reserves the right to make changes in the product design without

reservation and without notification to its users.

Disclaimer

IF THIS PRODUCT DIRECTS YOU TO COPY MATERIALS, YOU MUST HAVE

PERMISSION FROM THE COPYRIGHT OWNER OF THE MATERIALS TO AVOID

VIOLATING THE LAW WHICH COULD RESULT IN DAMAGES OR OTHER

REMEDIES.

ASA-7211 IG.book Page ii Tuesday, February 11, 2003 10:04 AM

iii

Regulatory Compliance Statements

Federal Communications Commission Radio Frequency Interference Statement

WARNING: Changes or modifications to this unit not expressly approved by the party

responsible for compliance could void the user’s authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses, and

can radiate radio frequency energy, and if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. However, if this

equipment does cause interference to radio or television equipment reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

■Reorient or relocate the receiving antenna.

■Increase the separation between equipment and receiver.

■Connect the equipment to an outlet on a circuit different from that to which the receiver is

connected.

■Consult the dealer or an experienced radio/television technician for help.

■Use a shielded and properly grounded I/O cable and power cable to ensure compliance of

this unit to the specified limits of the rules.

This device complies with part 15 of the FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference and (2) this device must accept

any interference received, including interference that may cause undesired operation.

European Union Compliance Statement

This Information Technology Equipment has been tested and found to comply with

EMC Directive 89/336/EEC, as amended by 92/31/EEC and 93/68/EEC, in

accordance with:

■EN55022 (1998) Emissions

■EN55024 (1998) Immunity:

– EN61000-4-2 (1998) Electrostatic discharge: ±4 kV contact, ±8 kV air

– EN61000-4-3 (1998) Radiated immunity

– EN61000-4-4 (1995) Electrical fast transients/burst: ±1 kV AC, ±0.5 kV I/O

– EN61000-4-5 (1995) Surges ±1 kV differential mode, ±2 kV common mode

– EN61000-4-6 (1996) Conducted immunity: 3 V

– EN61000-4-11 (1994) Supply dips and variation: 30% and 100%

In addition, all equipment requiring U.L. listing has been found to comply with EMC

Directive 73/23/EEC as amended by 93/68/EEC in accordance with EN60950 with

amendments A1, A2, A3, A4, A11.

Australian/New Zealand Compliance Statement

This device has been tested and found to comply with the limits for a Class B digital

device, pursuant to the Australian/New Zealand standard AS/NZS 3548 set out by

the Spectrum Management Agency.

Adaptec, Inc. ASA-7211C

Tested to Comply

With FCC Standards

FOR HOME OR OFFICE USE

ASA-7211F

ASA-7211 IG.book Page iii Tuesday, February 11, 2003 10:04 AM

Canadian Compliance Statement

This Class B digital apparatus meets all requirements of the Canadian Interference-

Causing Equipment Regulations.

Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur

le matériel brouilleur du Canada.

Japanese Compliance (Voluntary Control Council Initiative)

This equipment complies to class B Information Technology equipment based on

VCCI (Voluntary Control Council for Interface). This equipment is designed for home

use but it may causes radio frequency interference problem if used too near to a

television or radio. Please handle it correctly per this documentation.

ASA-7211 IG.book Page iv Tuesday, February 11, 2003 10:04 AM

Contents

1 Introduction

Read This First 1-2

Adaptec iSCSI Adapter Features 1-2

Kit Contents 1-2

Adapter Illustrations 1-3

System Requirements 1-4

Hardware Requirements 1-4

Supported iSCSI targets 1-4

Operating System Requirements 1-4

Using the Adaptec iSCSI Installation CD 1-5

About the Documentation 1-6

Overview of the Installation Process 1-7

2 Installing the Adaptec iSCSI Adapter

3 Installing the Initiator Mode Driver

Windows 2000 3-2

Installing the Driver in Windows 2000 3-2

Updating the Driver in Windows 2000 3-3

Windows NT 4.0 3-5

Installing the Driver in Windows NT 4.0 3-5

Updating the Driver in Windows NT 4.0 3-5

Red Hat Linux 3-7

Installing the Red Hat Module 3-7

Removing the Red Hat Module 3-8

Enabling Multi-LUN Support in Linux 3-9

ASA-7211 IG.book Page v Tuesday, February 11, 2003 10:04 AM

ASA-7211C/F Installation Guide

4 Configuring Your iSCSI System

Running iConfig on Windows 4-2

Running iConfig on Red Hat Linux 4-3

Using Express Setup to Configure Your iSCSI Adapter 4-4

Changing Your iConfig Password 4-5

Configuration Tasks 4-5

ALEDs

ASA-7211 IG.book Page vi Tuesday, February 11, 2003 10:04 AM

1-1

Introduction

In this Chapter

The Adaptec

Storage Accelerator (ASA) 7211 iSCSI storage adapter is

a PCI Host Bus Adapter (HBA) that enables servers and storage

systems to be used in iSCSI SANs using an Ethernet interconnect. The

adapter provides efficient, high-performance TCP/IP and iSCSI

protocol offload, with throughput up to 2 Gigabits/sec at full duplex.

Read This First 1-2

Adaptec iSCSI Adapter Features 1-2

Kit Contents 1-2

Adapter Illustrations 1-3

System Requirements 1-4

Using the Adaptec iSCSI Installation CD 1-5

About the Documentation 1-6

Overview of the Installation Process 1-7

ASA-7211 IG.book Page 1 Tuesday, February 11, 2003 10:04 AM

1-2

ASA-7211C/F Installation Guide

Read This First

This chapter is an important guide to the rest of the documentation

and provides a summary of the hardware and software installation

process. Additional chapters describe how to:

■Install the adapter.

■Install, remove, or update the device driver.

■Install the iConfig utility and configure your adapter (an

initiator) and targets.

For details to help you monitor your connections, display statistics and

event logs, and add and delete targets, see the

iConfig Utility User’s

Guide

Adaptec iSCSI Adapter Features

The Adaptec iSCSI adapter features are summarized below:

■Full iSCSI and TCP/IP protocol processing

■PCI 2.2 compliant; compatible with 3.3/5-V, 32/64-bit, 33/66-

MHz slots

■Supports flashable firmware upgrades

■Available in two connector configurations:

■ASA-7211C—Copper connector

■ASA-7211F—Fibre connector

Kit Contents

Your Adaptec iSCSI kit includes:

■ASA-7211 adapter card, shown on page 1-3.

■Adaptec iSCSI installation CD containing:

■Operating system drivers

■Initiator Configuration (iConfig) utility

■SNMP extension agents

■Readme files

■This Installation Guide and the iConfig Utility User’s Guide in

PDF format

■This Installation Guide as a printed document.

Note: You need a copper (CAT 5 or CAT 6), or fibre, Ethernet

cable. The cable is not included in the kit.

ASA-7211 IG.book Page 2 Tuesday, February 11, 2003 10:04 AM

1-3

Introduction

Adapter Illustrations

The Adaptec iSCSI adapters are illustrated below. Note the

difference in external connectors. One adapter has a copper

connector; the other, a fibre connector.

ASA-7211C Adapter Card

ASA-7211F Adapter Card

Note: Some ASA-7211 adapters are manufactured with

jumpers “hanging,” but not installed, on jumper connectors J4

and J5. Do not install these jumpers.

Copper

connector

For LED

details, see

Appendix A,

LEDs

Fibre

connector

For LED

details, see

Appendix A,

LEDs

ASA-7211 IG.book Page 3 Tuesday, February 11, 2003 10:04 AM

1-4

ASA-7211C/F Installation Guide

System Requirements

The following system requirements are discussed:

■Hardware requirements

■Supported iSCSI targets

■Operating system requirements

Hardware Requirements

Your computer must meet the following requirements:

■Intel Pentium, or equivalent, computer

■An available PCI slot

■At least 128 MB of RAM

■CD-ROM drive

■Copper (CAT 5 or CAT 6), or fibre, Ethernet cable. (Visit

www.adaptec.com for cables.)

Supported iSCSI targets

For the latest support information, refer to

www.adaptec.com

Operating System Requirements

Your computer must have one of the following compatible

operating systems:

Windows

■Windows NT 4.0, Service Pack 6a

■Windows 2000, Service Pack 3 and above

Note:

Windows 2000 only

—The Adaptec iSCSI adapter does not

support power management. If power management is enabled,

you must disable it. Refer to Windows Help for details.

Red Hat Linux

■Version 7.2 with kernel version 2.4.7-10

■Advanced Server (release 2.1AS) with kernel version 2.4.9-e.3

ASA-7211 IG.book Page 4 Tuesday, February 11, 2003 10:04 AM

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Adaptec Computerhardware Handbücher

Adaptec

Adaptec RAID 51245 Anleitung zur Verwendung

Adaptec

Adaptec 2940U2W - Storage Controller U2W SCSI 80... Bedienungsanleitung

Adaptec

Adaptec SAS RAID Controllers Bedienungsanleitung

Adaptec

Adaptec RAID 2405 Bedienungsanleitung

Adaptec

Adaptec 2045 Bedienungsanleitung

Adaptec

Adaptec Series 6 Referenzhandbuch

Adaptec

Adaptec AAA-130SA SERIES Montageanleitung

Adaptec

Adaptec FireWire 1394 Bedienungsanleitung

Adaptec

Adaptec 2100S - SCSI RAID Controller Sicherheitsleitfaden

Adaptec

Adaptec SATA RAID FOR ADAPTEC Bedienungsanleitung

Adaptec

Adaptec 2045 Bedienungsanleitung

Adaptec

Adaptec 2410SA - Serial ATA RAID Controller Bedienungsanleitung

Adaptec

Adaptec P Class 733/800/866MHz / 1GHz Bedienungsanleitung

Adaptec

Adaptec PM1564U3 Bedienungsanleitung

Adaptec

Adaptec ACB-2010A Bedienungsanleitung

Adaptec

Adaptec GDT8114RZ Bedienungsanleitung

Adaptec

Adaptec 1200A Bedienungsanleitung

Adaptec

Adaptec RAID Solutions Handbuch

Adaptec

Adaptec RAID 5085 Bedienungsanleitung

Adaptec

Adaptec PowerDomain 2940UW Bedienungsanleitung

Adaptec

Adaptec 2045 Bedienungsanleitung

Adaptec

Adaptec 2025ZCR - SCSI RAID Storage Controller Bedienungsanleitung

Adaptec

Adaptec ACB-5500 Bedienungsanleitung

Adaptec

Adaptec AUA-3100LP Handbuch

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

Intel

Intel NUC 12 Pro Bedienungsanleitung

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Intel

Intel AXXRMFBU4 Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung
