Adaptec RAID 2405 Bedienungsanleitung

SAS RAID Controllers

Quick Start Guide

Quick Start-Handbuch

Guide de démarrage rapide

Guida di avvio rapida

Guía de inicio rápido

クィックスタートガイド

Controller Illustrations

RAID Controllers

Quick Start Guide

English

Introduction

This Quick Start Guide describes how to install your Adaptec RAID

controller, create a bootable RAID 1 or RAID 5 array, and then install

your Microsoft® Windows® 2003/2008/XP/Vista™ or Red Hat Linux®

operating system and controller driver on that array. For other

installation options, refer to the Adaptec RAID Controllers Installation and

User’s Guide included on the RAID Installation CD. For controller

illustrations, refer to the last section of this document.

Note: For the latest information about the products described in this

Guide, the support for operating systems listed, and to download drivers,

visit www.adaptec.com.

Kit Contents

Adaptec RAID controller

Embedded in the controller’s BIOS are these utilities:

●Array Configuration Utility (ACU): Used to create, configure

and manage arrays

●SerialSelect: Used to modify your controller and disk drive settings

●Disk Utilities: Used to format and verify disk drives

Adaptec RAID Installation CD

●Drivers for the Adaptec RAID controller

●Product documentation for the Adaptec RAID controller

Adaptec Storage ManagerTM Installation CD

●Adaptec Storage Manager: User-friendly application that you can

use to create and manage arrays.

●Adaptec RAID Controller Configuration (ARCCONF) Utility:

Used to perform basic array and configuration management

functions

●User Guides for Adaptec Storage Manager and ARCCONF Utility

Cables (type and quantity vary, depending on controller; cables are

included only with Adaptec Kit product, not Adaptec Single product)

Low-profile bracket (depending on controller)

Quick Start Guide (this document)

Step 1 Install the Controller

Caution: Electrostatic discharge (ESD) can damage your controller.

Follow standard anti-ESD precautions to avoid exposing the

controller to static charge.

aIf you have a low-profile controller and a low-profile computer

cabinet, replace the original full-height bracket on the controller card

with the low-profile bracket supplied in the controller kit.

bTurn off the computer and disconnect the power cord.

cOpen the cabinet. Refer to the manufacturer’s instructions as needed.

dInsert the controller into an available PCIe slot that’s compatible with

your controller and secure the controller bracket to the chassis.

eOptional—Connect your computer’s disk activity LED cable to the

LED connector on your controller (not available on some models).

Attach the positive lead to pin 1.

Optional

—Connect the controller’s I2C connector (not available on

some models) to an I2C connector on an internal SAS backplane or

enclosure. Use an I2C cable (typically included with the backplane).

gInstall and connect any internal drives using the appropriate cable(s),

then close the computer cabinet.

Note: To build a RAID 1, you must install two disk drives. To build a

RAID 5, you must install at least three disk drives.

hConnect any external cables and disk drives to the controller.

●Do not attach a cable to the controller unless the other end of the

cable is attached to at least one drive. Doing so can cause unstable

operation.

●

Use high-quality cables—poor quality cables degrade reliability.

English

Step 2 Create a RAID Array

RAID 1 and RAID 5 arrays are used here as an example. Create a RAID 1

if your controller does not support RAID 5. You can create a different

level array in a similar manner.

aTurn on the computer, then when prompted press Ctrl+A to enter the

BIOS-based configuration utility. The Menu Options screen displays.

Note: If you have more than one of the same type of controller

installed, select your controller, then press Enter.

bSelect Array Configuration Utility, then press Enter. The ACU Menu

displays.

cSelect Initialize Drives, then press Enter.

dSelect at least three disk drives for a RAID 5 array or two disks for a

RAID 1. Press Insert for each selected disk drive, then press Enter.

ePress Y, then press Enter. The selected drives are initialized, then the

ACU Menu displays.

Warning: Initializing disk drives deletes all data stored on these

drives. Back up any data you want to keep before initializing the

disk drives.

fSelect Create Array, then press Enter.

gSelect the disk drives you just initialized, press Insert for each selected

disk drive, then press Enter.

hOn the Array Properties screen, respond as follows:

iWhen a cache warning message is displayed, type Y.

jOnce the array is created, a message tells you that the array can now be

used. Press any key to return to the ACU Menu.

Note: Although you can start using the array now, performance is

reduced until the build process is complete.

kPress Esc until the Exit Utility window appears.

lSelect Ye s , then press Enter. The computer restarts.

Step 3 Set up the Boot Sequence

The process you use to access your computer’s BIOS Setup program and

set the boot sequence varies by computer manufacturer. Refer to the

instructions provided with your specific computer. Steps may be similar to:

aDuring startup, press the key combination (for example, <F2>, <F1>,

<DEL>) that starts the BIOS Setup program.

bGo to the menu used to specify the boot sequence. Put the CD drive

first—this allows you to perform Step 4 on page 5.

cGo to the menu used to specify the boot priority for disk drives. Put

the Adaptec RAID controller first in this sequence.

dSave your changes, exit Setup, and restart the computer.

Array Type Select RAID 5 or RAID 1, then press Enter.

Array Label Type a name, then press Enter.

Array Size Press Enter, then press Enter again to use the

default granularity of GB.

Stripe Size Press Enter to use the default (256KB).

Read Caching Press Enter to use the default (Yes).

Write Caching Press Enter to use the default (Enable always).

Create RAID via Press Enter to use the default (Build/Verify).

[Done] Press Enter.

English

Step 4 Create the Driver Disk

aInsert the Adaptec RAID Installation CD and turn on the computer to

boot from the CD.

bFollow the on-screen instructions to display the CD’s menu.

cClick Create Driver Disk, then select your operating system. If you

selected Linux, you may also need to select an architecture (depending

on the type of Linux you selected).

dSelect your floppy disk drive letter, then select the format you want.

You need a full format only if your floppy disk is unformatted.

eInsert the floppy disk, then click OK. The computer creates the driver

disk.

fRemove and label the driver disk.

gContinue with the installation of the operating system and controller

driver, as described in Step 5 below. If your operating system is not

listed in Step 5, refer to the Adaptec RAID Controller Users Guide on

the RAID Installation CD.

Step 5 Install the Controller Driver with

the Operating System

Windows 2003/XP

aInsert your Windows CD, then restart the computer.

bFollow the on-screen instructions to begin the Windows installation.

cWhen prompted to install a third-party driver, press F6.

Note: When F6 is active, a prompt appears at the bottom of the screen

for only 5 seconds. If you miss your chance to press F6, restart your

computer.

dInsert the driver disk, then wait until prompted to install the driver.

Press Sto specify that the driver is on the floppy disk, then press

Enter. The computer reads the disk.

eWhen the driver is found, press Enter. Follow the on-screen

instructions to complete the installation.

Windows 2008/Vista

aInsert your Windows CD, then restart the computer.

bFollow the on-screen instructions to begin the Windows installation.

cWhen prompted to specify a location for Windows, select Load

Driver.

dInsert the driver disk, then click OK.

eWhen the driver is found, press Next.

fClick Next again to accept the default partition configuration, or refer

to your Windows documentation to configure partitions manually.

gFollow the on-screen instructions to complete the installation.

Red Hat Linux

For SuSE Linux, refer to the Adaptec RAID Controllers Installation and

User’s Guide on the RAID Installation CD.

Note: For the most up-to-date information on Linux support, visit

www.adaptec.com.

aInsert the first Red Hat installation CD.

bRestart the computer.

cWhen the Red Hat Welcome screen appears, type

linux dd

at the

Boot: prompt.

dWhen prompted, insert the driver disk, then select OK.

eFollow the prompts to set up the environment you want.

fIf you are installing other third-party devices, install them now.

Otherwise, select Done.

gContinue with the Linux installation, according to the Red Hat

instructions.

Step 6 Install Adaptec Storage Manager

Before installing Adaptec Storage Manager, ensure that you are logged in

with administrator or root privileges. Also, remove any previous version

of Adaptec Storage Manager. Any customization files you created using

the previous version are saved and used in the upgrade.

●To remove Adaptec Storage Manager from Linux, type the command

rpm --erase StorMan

English

●To remove Adaptec Storage Manager from Windows, use the Add/

Remove Programs option in the Control Panel.

Windows Installation

aInsert the Adaptec Storage Manager

. The Installation wizard

starts. If this does not occur, browse the CD and click Autorun.

bFollow the on-screen instructions to complete the installation. When

prompted to install SNMP (Simple Network Management Protocol),

do not install unless you have a specific requirement for Adaptec

Storage Manager to work with SNMP gets and traps.

Linux Installation

On Linux, Adaptec Storage Manager includes the Java Runtime

Environment (JRE).

Note: For the most up-to-date information on Linux support, visit

www.adaptec.com.

aInsert the Adaptec Storage Manager CD.

bMount the Adaptec

Storage Manager

CD:

mount /dev/cdrom /mnt/cdrom

cChange to the cdrom directory:

cd /mnt/cdrom/linux/manager

dExtract the RPM package and install it:

rpm --install./StorMan*.rpm

eUnmount the Adaptec

Storage Manager

umount /mnt/cdrom

More Information

For more information about Adaptec RAID controllers, specifications,

user guides, and updates, visit www.adaptec.com.

To find detailed information about the controllers described in this Quick

Start Guide, refer to these documents:

●Readme—Text files located on the Adaptec RAID Installation CD and

on the Adaptec Storage Manager Installation CD. These files provide

late-breaking technical information.

●Adaptec RAID Controllers Installation and User’s Guide—PDF file

located on the RAID Installation CD. It provides complete

Andere Handbücher für RAID 2405

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Adaptec Computerhardware Handbücher

Adaptec

Adaptec SCSI 58300 Bedienungsanleitung

Adaptec

Adaptec ASR-2130SLP Anleitung zur Verwendung

Adaptec

Adaptec 2100S - SCSI RAID Controller Bedienungsanleitung

Adaptec

Adaptec 4000SAS Bedienungsanleitung

Adaptec

Adaptec ICP 5045BL Bedienungsanleitung

Adaptec

Adaptec SBC-596 Bedienungsanleitung

Adaptec

Adaptec SAS RAID Controllers Bedienungsanleitung

Adaptec

Adaptec AAA-130SA SERIES Montageanleitung

Adaptec

Adaptec RAID 5085 Bedienungsanleitung

Adaptec

Adaptec 2940U2W - Storage Controller U2W SCSI 80... Bedienungsanleitung

Adaptec

Adaptec 2010S - SCSI RAID Storage Controller Bedienungsanleitung

Adaptec

Adaptec PowerDomain 29160 Bedienungsanleitung

Adaptec

Adaptec PM3332UW Bedienungsanleitung

Adaptec

Adaptec ACB-2010A Bedienungsanleitung

Adaptec

Adaptec AFM-600 Bedienungsanleitung

Adaptec

Adaptec RAID 2405 Bedienungsanleitung

Adaptec

Adaptec RAID 5405Z Bedienungsanleitung

Adaptec

Adaptec P Class 733/800/866MHz / 1GHz Bedienungsanleitung

Adaptec

Adaptec PowerDomain 2940UW Bedienungsanleitung

Adaptec

Adaptec AHA-2940 - SCSI Card Bedienungsanleitung

Adaptec

Adaptec AAR-1420SA Bedienungsanleitung

Adaptec

Adaptec SATA RAID FOR ADAPTEC Bedienungsanleitung

Adaptec

Adaptec Serial Attached SCSI (SAS) Expander Card Bedienungsanleitung

Adaptec

Adaptec 2100S - SCSI RAID Controller Bedienungsanleitung

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

Intel

Intel NUC 12 Pro Bedienungsanleitung

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Intel

Intel AXXRMFBU4 Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung
