ADF Web HD67595-A1 Bedienungsanleitung

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

Ether

et/IP / CAN

Converter

Document code: MN67595_ENG Revision 1. 12 Pagina 1 di 27

User Manual

Revision 1. 12

English

EtherNet/IP / CAN - Converter

(Order Code: HD67595-A1)

for Website information:

www.adfweb.com?Product=HD67595

for Price information:

www.adfweb.com?Price=HD67595-A1

Benefits and Main Features:

Very easy to configure

Electrical isolation

Two EtherNet/IP ports

Temperature range: -4 °C/85°C (-4 °F/185°F)

For others EtherNet/IP products see also the following link:

Converter EtherNet/IP to

www.adfweb.com?Product=HD67 77 (M-Bus)

www.adfweb.com?Product=HD67597 (DeviceNet Master)

www.adfweb.com?Product=HD67598 (DeviceNet S ave)

www.adfweb.com?Product=HD67599 (J1939)

www.adfweb.com?Product=HD67589 (NMEA2000)

www.adfweb.com?Product=HD6759 (Seria RS232)

www.adfweb.com?Product=HD6759 (Seria RS485)

www.adfweb.com?Product=HD67591 (Modbus Master RS232)

www.adfweb.com?Product=HD67591 (Modbus Master RS485)

www.adfweb.com?Product=HD67592 (Modbus S ave RS232)

www.adfweb.com?Product=HD67592 (Modbus S ave RS485)

Do you have an your customer protocol?

www.adfweb.com?Product=HD67 3

Do you need to choose a device? do you want help?

www.adfweb.com?Cmd=helpme

Other

Products

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

Ether

et/IP / CAN

Converter

Document code: MN67595_ENG Revision 1. 12 Pagina 2 di 27

INDEX:

Page

INDEX 2

UPDATED DOCUMENTATION 2

REVISION LIST 2

WARNING 2

TRADEMARKS 2

SECURITY ALERT 3

EXAMPLE OF CONNECTION 4

CONNECTION SCHEME 5

CHARACTERISTICS 6

CONFIGURATION 6

POWER SUPPLY 7

FUNCTION MODES 8

LEDS 9

ETHERNET/IP 1

USB 1

CAN 11

USE OF COMPOSITOR SW67595 12

NEW PROJECT / OPEN PROJECT 12

SET COMMUNICATION 13

RECEIVE FRAMES 14

INFO RECEIVE 15

SEND FRAME 16

INFO SEND 17

UPDATE DEVICE 18

MECHANICAL DIMENSIONS 2

ORDERING INFORMATIONS 21

ACCESSORIES 21

PLC CONFIGURATION 22

DISCLAIMER 26

OTHER REGULATIONS AND STANDARDS 26

WARRANTIES AND TECHNICAL SUPPORT 27

RETURN POLICY 27

PRODUCTS AND RELATED DOCUMENTS 27

UPDATED DOCUMENTATION:

Dear customer, we thank you for your attention and we remind you that

you need to check that the following document is:

Updated

Related to the product you own

To obtain the most recently updated document, note the “document code”

that appears at the top right-hand corner of each page of this document.

With this “Document Code” go to web page www.adfweb.com/download/

and search for the corresponding code on the page. Click on the proper

“Document Code” and download the updates.

To obtain the updated documentation for the product that you own, note

the “Document Code” (Abbreviated written "Doc. Code" on the label on the

product) and download the updated from our web site

www.adfweb.com/download/

REVISION LIST:

WARNING:

ADFweb.com reserves the right to change information in this manual about

our product without warning.

ADFweb.com is not responsible for any error this manual may contain.

TRADEMARKS:

All trademarks mentioned in this document belong to their respective

owners.

Revision

Date Author Chapter

Description

1. 1 29/1 /2 12

Fl All Software changed (v1. )

1. 11 17/12/2 12

Fl All Revision

1. 12 9/ 1/2 13

Nt All Added new chapters

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

Ether

et/IP / CAN

Converter

Document code: MN67595_ENG Revision 1. 12 Pagina 3 di 27

SECURITY ALERT:

ENERAL

NFORMATION

To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for

each individual application, legal and safety regulation. The same applies also when using accessories.

NTENDED

Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e. independent limit

switches, mechanical interlocks, etc.).

UALIFIED

ERSONNEL

The device can be used only by qualified personnel, strictly in accordance with the specifications.

Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and who

have appropriate qualifications for their job.

ESIDUAL

ISKS

The device is state of the art and is safe. The instrument can represent a potential hazard if they are inappropriately installed and operated

by personnel untrained. These instructions refer to residual risks with the following symbol:

This symbol indicates that non-observance of the safety instructions is danger for people to serious injury or death and / or the

possibility of damage.

CONFORMITY

The declaration is made by us. You can send an email to support@adfweb.com or give us a call if you need it.

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

Ether

et/IP / CAN

Converter

Document code: MN67595_ENG Revision 1. 12 Pagina 4 di 27

EXAMPLE OF CONNECTION:

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

Ether

et/IP / CAN

Converter

Document code: MN67595_ENG Revision 1. 12 Pagina 5 di 27

CONNECTION SCHEME:

Figure 1: Connection scheme for HD67595-A1

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

Ether

et/IP / CAN

Converter

Document code: MN67595_ENG Revision 1. 12 Pagina 6 di 27

CHARACTERISTICS:

The HD67595-A1 is a EtherNet/IP / CAN Converter.

It allows the following characteristics:

Up to 5 bytes in reading and 5 bytes in writing;

Triple isolation between CAN - Power Supply, CAN - Ethernet, Power Supply - Ethernet.

Two-directional information between CAN bus and EtherNet/IP bus;

Mountable on 35mm Rail DIN;

Wide power supply input range: 8…24V AC or 12…35V DC;

Wide temperature range: -4 °C / 85°C [-4 °F / +185°F].

CONFIGURATION:

You need Compositor SW67595 software on your PC in order to perform the following:

Define the parameter of EtherNet/IP line;

Define the parameter of CAN line;

Define the CAN frames that the Converter can accept;

Define the CAN frames that the Converter sends trough the CAN line;

Define the map of CAN byte that must be written in the EtherNet/IP array;

Define the map of which EtherNet/IP bytes must be written in CAN frames;

Update the device.

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

Ether

et/IP / CAN

Converter

Document code: MN67595_ENG Revision 1. 12 Pagina 7 di 27

POWER SUPPLY:

The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.

VAC

VDC

Vmin Vmax Vmin Vmax

8V 24V 12V 35V

Consumption at 24V DC:

Device Consumption [W/VA]

HD67595-A1 3.5

HD67595

Caution: Not reverse the po arity power

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

Ether

et/IP / CAN

Converter

Document code: MN67595_ENG Revision 1. 12 Pagina 8 di 27

FUNCTION MODES:

The device has got two functions mode depending of the position of the ‘Dip2 of Dip-Switch B’:

The first, with ‘Dip2 of Dip-Switch B’ at “OFF” position, is used for the normal working of the device.

The second, with ‘Dip2 of Dip-Switch B’ at “ON” position, is used for upload the Project and/or Firmware.

For the operations to follow for the updating, see ‘UPDATE DEVICE’ section.

According to the functioning mode, the LEDs will have specifics functions, see ‘LEDS’ section.

Warning:

Dip1 of ‘Dip-Switch B’ must be at ON position for working even if the Ethernet cable isn’t inserted.

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

Ether

et/IP / CAN

Converter

Document code: MN67595_ENG Revision 1. 12 Pagina 9 di 27

LEDS:

The device has got four LEDs that are used to give information of the functioning status.

The various meanings of the LEDs are described in the table below.

LED Norma Mode Boot Mode

1: Device State (green) Blinks slowly (~1Hz) B inks quick y: Boot state

B inks very s ow y (~0.5Hz): update in progress

2: CAN comm. (green) Change state when receive a CAN

frame defined in the Compositor

B inks quick y: Boot state

B inks very s ow y (~0.5Hz): update in progress

3: Ethernet1 Tx (green) Blinks quickly for a short time

when sends Ethernet frames

ON: Ethernet cable connected

OFF: Ethernet cable disconnected

4: Ethernet2 Tx (green) Blinks quickly for a short time

when sends Ethernet frames

ON: Ethernet cable connected

OFF: Ethernet cable disconnected

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

Ether

et/IP / CAN

Converter

Document code: MN67595_ENG Revision 1. 12 Pagina 1 di 27

ETHERNET/IP:

The EtherNet/IP connection must be made using Connector3 and/or Connector4 of HD67595-A1 with at least a Category 5E cable. The

maximum length of the cable should not exceed 1 m. The cable has to conform to the T568 norms relative to connections in cat.5 up to

1 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is

recommended the use of a cross cable.

USB:

The USB connection, must be made with a USB cable with a USB Mini B plug.

Note:

The USB port is not used in this moment.
