ADF Web HD67752-A1 Bedienungsanleitung

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

IEC 61850 Server /

PROFINET S

lave

Document code: MN67752_ENG Revision 1. Page 1 of 28

User Manual

Revision 1.

English

IEC 61850 Server / PROFINET Slave - Converter

(Order Code: HD67752-A1)

For Website information:

www.adfweb.com?Product=HD67752

For Price information:

www.adfweb.com?Price=HD67752-A1

Benefits and ain Features:

Very easy to configure

Triple Electrical isolation

Temperature range: -4 °C/+85°C (-4 °F/+185°F)

For other IEC 6185 Server products see also the following link:

Converter IEC 61850 Server to

www.adfweb.com?Product=HD67733 ( odbus aster)

www.adfweb.com?Product=HD67734 ( odbus Slave)

www.adfweb.com?Product=HD67735 ( odbus TCP aster)

www.adfweb.com?Product=HD67736 ( odbus TCP Slave)

www.adfweb.com?Product=HD67737 (BACnet aster)

www.adfweb.com?Product=HD67738 (BACnet Slave)

www.adfweb.com?Product=HD67739 (CAN)

www.adfweb.com?Product=HD6774 (CANopen)

www.adfweb.com?Product=HD67741 (DeviceNet aster)

www.adfweb.com?Product=HD67742 (DeviceNet Slave)

www.adfweb.com?Product=HD67743 (EtherNet/IP aster)

www.adfweb.com?Product=HD67744 (EtherNet/IP Slave)

www.adfweb.com?Product=HD67745 (J1939)

www.adfweb.com?Product=HD67746 (KNX)

www.adfweb.com?Product=HD67747 ( QTT)

www.adfweb.com?Product=HD67748 (N EA 0183)

www.adfweb.com?Product=HD67749 (N EA 2000)

www.adfweb.com?Product=HD6775 (PROFIBUS aster)

www.adfweb.com?Product=HD67751 (PROFIBUS Slave)

www.adfweb.com?Product=HD67753 (SN P anager)

www.adfweb.com?Product=HD67754 (SN P Agent)

www.adfweb.com?Product=HD67755 (Serial)

www.adfweb.com?Product=HD67756 (Ethernet)

www.adfweb.com?Product=HD67B82 (PROFINET aster)

www.adfweb.com?Product=HD67C65 (EnOcean)

Do you have your customer protocol? Then go to:

www.adfweb.com?Product=HD67 3

Do you need to choose a device? Do you want help?

www.adfweb.com?Cmd=helpme

User Manual

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

IEC 61850 Server /

PROFINET S

lave

Document code: MN67752_ENG Revision 1. Page 2 of 28

INDEX:

Page

INDEX 2

UPDATED DOCUMENTATION 2

REVISION LIST 2

WARNING 2

TRADEMARKS 2

SECURITY ALERT 3

EXAMPLE OF CONNECTION 4

CONNECTION SCHEME 5

CHARACTERISTICS 6

CONFIGURATION 6

POWER SUPPLY 7

FUNCTION MODES 8

LEDS 9

ETHERNET 1

USE OF COMPOSITOR SW67752 11

NEW CONFIGURATION / OPEN CONFIGURATION 12

SOFTWARE OPTIONS 13

SET COMMUNICATION 15

IEC 6185 ACCESS 17

TLS KNOWN CERTIFICATE 18

PROFINET XML 19

UPDATE DEVICE 2

PLC CONFIGURATION 22

MECHANICAL DIMENSIONS 25

ORDERING INFORMATIONS 26

ACCESSORIES 26

DISCLAIMER 27

OTHER REGULATIONS AND STANDARDS 27

WARRANTIES AND TECHNICAL SUPPORT 28

RETURN POLICY 28

UPDATED DOCU ENTATION:

Dear customer, we thank you for your attention and we remind you that

you need to check that the following document is:

Updated

Related to the product you own

To obtain the most recently updated document, note the “document code”

that appears at the top right-hand corner of each page of this document.

With this “Document Code” go to web page www.adfweb.com/download/

and search for the corresponding code on the page. Click on the proper

“Document Code” and download the updates.

REVISION LIST:

WARNING:

ADFweb.com reserves the right to change information in this manual about

our product without warning.

ADFweb.com is not responsible for any error this manual may contain.

TRADE ARKS:

All trademarks mentioned in this document belong to their respective

owners.

Revision

Date Author Chapter

Description

1. 18/ 9/2 19

Ff All First Release

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

IEC 61850 Server /

PROFINET S

lave

Document code: MN67752_ENG Revision 1. Page 3 of 28

SECURITY ALERT:

ENERAL

NFOR ATION

To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and

safety regulation are required for each individual application. The same applies also when using accessories.

NTENDED

Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.

independent limit switches, mechanical interlocks, etc.).

UALIFIED

ERSONNEL

The device can be used only by qualified personnel, strictly in accordance with the specifications.

Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and

who have appropriate qualifications for their job.

ESIDUAL

ISKS

The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and

operated by untrained personnel. These instructions refer to residual risks with the following symbol:

This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or

death and / or the possibility of damage.

CONFOR ITY

The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

IEC 61850 Server /

PROFINET S

lave

Document code: MN67752_ENG Revision 1. Page 4 of 28

EXA PLES OF CONNECTION:

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

IEC 61850 Server /

PROFINET S

lave

Document code: MN67752_ENG Revision 1. Page 5 of 28

CONNECTION SCHE E:

Figure 1: Connection scheme for HD67752-A1

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

IEC 61850 Server /

PROFINET S

lave

Document code: MN67752_ENG Revision 1. Page 6 of 28

CHARACTERISTICS:

The HD67752-A1 is IEC 6185 Server / PROFINET Slave - Converter.

It allows for the following characteristics:

Isolation between Ethernet - Power Supply;

Two-directional information between IEC 6185 bus and PROFINET bus;

Mountable on 35mm Rail DIN;

Wide power supply input range: 8…24V AC or 12…35V DC;

Wide temperature range: -4 °C / 85°C [-4 °F / +185°F].

CONFIGURATION:

You need Compositor SW67752 software on your PC in order to perform the following:

Define the parameters of IEC 6185 line;

Define the parameters of PROFINET line;

Define IEC 6185 variables that contains the data to read from PROFINET side;

Define IEC 6185 variables that contains the data to write from PROFINET side;

Update the device.

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

IEC 61850 Server /

PROFINET S

lave

Document code: MN67752_ENG Revision 1. Page 7 of 28

POWER SUPPLY:

The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.

VAC

VDC

Vmin Vmax Vmin Vmax

8V 24V 12V 35V

Consumption at 24V DC:

Device Consumption [W/VA]

HD67752-A1 3.5

HD67752-A1

Caution:

Do n

ot reverse the polarity power

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

IEC 61850 Server /

PROFINET S

lave

Document code: MN67752_ENG Revision 1. Page 8 of 28

FUNCTION ODES:

The device has got two function modes depending on the position of the ‘Dip1 of Dip-Switch A’:

The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.

The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for uploading the Project and/or Firmware.

For the operations to follow for the updating, see ‘UPDATE DEVICE’ section.

According to the functioning mode, the LEDs will have specific functions, see ‘LEDS’ section.

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

IEC 61850 Server /

PROFINET S

lave

Document code: MN67752_ENG Revision 1. Page 9 of 28

LEDS:

The device has got six LEDs that are used to give information about the functioning status.

The various meanings of the LEDs are described in the table below.

LED Normal ode Boot ode

1: ON [supply voltage ]

(green)

ON: Device powered

OFF: Device not powered

ON: Device powered

OFF: Device not powered

2: MT [maintenance display]

(yellow)

ON: Maintenance Problem is present

OFF: No maintenance are present

Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

3: BF [bus fault] (red)

ON: The Ethernet connection is defective; the IP

address exists several times in the network; the own

NameOfStation exists several times in the network; no

IP address has been set

Flashing: At least one configured AR is no longer in

the data exchange

OFF: No errors are present

Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

4: SF [group error] (red) ON: At least one AR is not in the data exchange

OFF: No errors are present

Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

5: Ethernet1 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

6: Ethernet2 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

IEC 61850 Server /

PROFINET S

lave

Document code: MN67752_ENG Revision 1. Page 1 of 28

ETHERNET:

IEC 6185 connection, PROFINET connection and the updating of the converters must be made using Connector3 and/or Connector4 of the

HD67752-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 1 m. The cable has to conform to the

T568 norms relative to connections in cat.5 up to 1 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight

cable, to connect the device to a PC/PLC/other is recommended the use of a cross cable.
