ADLINK Technology AmITX-CF-I Bedienungsanleitung

Leading EDGE COMPUTING

AmITX-CF-I

User’s Manual

Mini-ITX Embedded Motherboard with

8th and 9th Gen Intel® Core™ i7/i5/i3 Processors

and Intel® Q370/H310 Chipset

Manual Rev.: 1.0

Revision Date: November 3, 2020

Part Number: 50-1X017-1000

ii Preface

Preface

All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic, or other means in

any form without prior written permission of the manufacturer.

Disclaimer

The information in this document is subject to change without prior notice in order to improve reliability, design, and

function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer

be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use

the product or documentation, even if advised of the possibility of such damages.

Environmental Responsibility

ADLINK is committed to fulfill its social responsibility to global environmental preservation

through compliance with the European Union's Restriction of Hazardous Substances (RoHS)

directive and Waste Electrical and Electronic Equipment (WEEE) directive. Environmental

protection is a top priority for ADLINK. We have enforced measures to ensure that our products,

manufacturing processes, components, and raw materials have as little impact on the

environment as possible. When products are at their end of life, our customers are encouraged

to dispose of them in accordance with the product disposal and/or recovery programs

prescribed by their nation or company.

Battery Labels (for products with battery)

廢電池請回收

California Proposition 65 Warning

WARNING: This product can expose you to chemicals including acrylamide, arsenic, benzene,

cadmium, Tris(1,3-dichloro-2-propyl)phosphate (TDCPP), 1,4-Dioxane, formaldehyde, lead, DEHP,

styrene, DINP, BBP, PVC, and vinyl materials, which are known to the State of California to cause

cancer, and acrylamide, benzene, cadmium, lead, mercury, phthalates, toluene, DEHP, DIDP, DnHP,

DBP, BBP, PVC, and vinyl materials, which are known to the State of California to cause birth defects or other

reproductive harm. For more information go to www.P65Warnings.ca.gov.

Trademarks

Product names mentioned herein are used for identification purposes only and may be trademarks and/or

registered trademarks of their respective companies.

Revision History

Revision Description Date By

1.0 Initial release 2020-11-03 JC

AmITX-CF-I

Preface iii

Table of Contents

Preface................................................................................................................................ii

List of Figures ....................................................................................................................v

List of Tables.....................................................................................................................vi

1Introduction................................................................................................................1

1.1 Packing List.....................................................................................................................1

1.2 Optional Accessories ......................................................................................................1

2Specifications............................................................................................................3

2.1 Core System ...................................................................................................................3

2.2 Rear I/O Connectors .......................................................................................................3

2.3 Internal Headers and Connectors ...................................................................................4

2.4 Form Factor.....................................................................................................................4

2.5 Video...............................................................................................................................4

2.6 Audio...............................................................................................................................4

2.7 LAN .................................................................................................................................4

2.8 Trusted Platform Module (TPM)......................................................................................5

2.9 Power Specification.........................................................................................................5

2.10 Power Consumption........................................................................................................5

2.11 Temperatures..................................................................................................................6

2.12 Environmental .................................................................................................................6

2.13 Operating Systems..........................................................................................................6

2.14 Functional Block Diagram ...............................................................................................7

3Mechanical Layout ....................................................................................................9

3.1 Connector Locations .......................................................................................................9

3.2 Mechanical Dimensions ................................................................................................11

3.3 Thermal Solutions .........................................................................................................13

4Connectors and Jumpers .......................................................................................15

4.1 Rear IO Connectors ......................................................................................................15

4.2 Internal Connectors.......................................................................................................19

4.3 Jumper and Switch Settings..........................................................................................26

5Driver Installation....................................................................................................29

6System Resources ..................................................................................................31

6.1 System Memory Map ....................................................................................................31

6.2 I/O Map .........................................................................................................................32

6.3 Interrupt Request (IRQ) Map.........................................................................................34

7BIOS Setup...............................................................................................................35

7.1 Menu Structure..............................................................................................................35

7.2 Main ..............................................................................................................................36

7.3 Advanced ......................................................................................................................37

7.4 Chipset..........................................................................................................................48

iv Preface

7.5 Security .........................................................................................................................55

7.6 Boot...............................................................................................................................57

7.7 Save & Exit ...................................................................................................................58

Safety Instructions...........................................................................................................59

Getting Service.................................................................................................................60

AmITX-CF-I

Preface v

List of Figures

Figure 1: AmITX-CF-I Functional Block Diagram.....................................................................................7

Figure 2: AmITX-CF-I Rear I/O ................................................................................................................9

Figure 3: AmITX-CF-I Component-Side Connectors ............................................................................ 10

Figure 4: AmITX-CF-I Mechanical Dimensions..................................................................................... 12

Figure 5: Jumper and Switch Locations ................................................................................................ 26

vi Preface

List of Tables

Table 1: AmITX-CF-I Processors .............................................................................................................1

Table 2: System Memory Map .............................................................................................................. 31

Table 3: I/O Map.................................................................................................................................... 32

Table 4: IRQ Map .................................................................................................................................. 34

AmITX-CF-I

Introduction 1

1 Introduction

The AmITX-CF-I is a Mini-ITX motherboard supporting the Desktop 8th and 9th Generation Intel® Core™ i7/i5/i3

and Pentium®/Celeron® Processor with Intel® Q370/H310 Chipset. The AmITX-CF-I is specifically designed for

customers who need high-level processing and graphics performance with a long product life solution.

The AmITX-CF-I features one DisplayPort, one HDMI, one DVI-D, dual Gigabit Ethernet ports, USB 3.0 ports, USB

2.0 ports, and SATA 6 Gb/s ports. Expansion is provided by one PCIe x16, and one mini-PCIe slot. The onboard

feature connector provides GPIO, SMBus, and I2C support. The board is equipped with SPI AMI EFI BIOS,

supporting embedded features such as hardware monitor and watchdog timer

Table 1: AmITX-CF-I Processors

Model Number Chipset

AmITX-CF-I-Q370 Q370

AmITX-CF-I-H310 H310

Latest revisions of the datasheet, user’s manual, BIOS, drivers, and board support packages, can be downloaded

from the product webpage on the ADLINK web site: www.adlinktech.com

1.1 Packing List

•AmITX-CF-I Mini-ITX motherboard

•Rear I/O shield

1.2 Optional Accessories

•COM port cable, 1 port (P/N: 30-10297-0000-B0)

•USB 2.0 cable, 2 ports for AmITX-CF-I-Q370/H310 (P/N: 30-21625-0000-B0)

•USB 3.0 cable, 2 ports for AmITX-CF-I-Q370 (P/N: 30-21597-1000-A0)

2 Introduction

This page intentionally left blank.

AmITX-CF-I

Specifications 3

2 Specifications

2.1 Core System

CPU Desktop 8th Generation Intel® Core™ i7/i5/i3 and Pentium®/Celeron® Processor, LGA1151socket

Intel® Core™ i7-8700, 3.2GHz, 12M Cache, 65W TDP, LGA1151, DDR4 2666MHz support (6C/12T)

Intel® Core™ i7-8700T, 2.4GHz 12M Cache, 35W TDP, LGA1151, DDR4 2666MHz support (6C/12T)

Intel® Core™ i5-8500, 3.0GHz, 9M Cache, 65W TDP, LGA1151, DDR4 2666MHz support (6C/6T)

Intel® Core™ i5-8500T, 2.1GHz, 9M Cache, 35W TDP, LGA1151, DDR4 2666MHz support (6C/6T)

Intel® Core™ i3-8100, 3.6GHz, 6M Cache, 65W TDP, LGA1151, DDR4 2400MHz support (4C/4T)

Intel® Core™ i3-8100T, 3.1GHz, 6M Cache, 35W TDP, LGA1151, DDR4 2400MHz support (4C/4T)

Intel® Pentium® G5400, 3.7GHz, 4M Cache, 58W TDP, LGA1151, DDR4 2400MHz support (2C/4T)

Intel® Pentium® G5400T, 3.1GHz, 4M Cache, 35W TDP, LGA1151, DDR4 2400MHz support (2C/4T)

Intel® Celeron® G4900, 3.1GHz, 2M Cache, 54W TDP, LGA1151, DDR4 2400MHz support (2C/2T)

Intel® Celeron® G4900T, 2.9GHz, 2M Cache, 35W TDP, LGA1151, DDR4 2400MHz support (2C/2T)

Desktop 9th Generation Intel® Core™ i7/i5/i3 and Pentium®/Celeron® Processor, LGA1151socket

Intel® Core™ i7-9700E, 2.6GHz, 12M Cache, 65W TDP, LGA1151, DDR4 2666MHz support (8C/8T)

Intel® Core™ i7-9700TE, 1.8GHz, 12M Cache, 35W TDP, LGA1151, DDR4 2666MHz support (8C/8T)

Intel® Core™ i5-9500E, 3.0GHz, 9M Cache, 65W TDP, LGA1151, DDR4 2666MHz support (6C/6T)

Intel® Core™ i5-9500TE, 2.2GHz, 9M Cache, 35W TDP, LGA1151, DDR4 2666MHz support (6C/6T)

Intel® Core™ i3-9100E, 3.1GHz, 6M Cache, 65W TDP, LGA1151, DDR4 2400MHz support (4C/4T)

Intel® Core™ i3-9100TE, 2.2GHz, 6M Cache, 35W TDP, LGA1151, DDR4 2400MHz support (4C/4T)

Note:

Availability of features may vary between processor SKUs and operating systems

Chipset Intel® Q370/H310 Chipset

Memory Two 260-pin DDR4 non-ECC SODIMM slots, DDR4 2400/2666 MHz, up to 32 GB (CPU dependent)

Embedded

BIOS AMI® UEFI BIOS, 256Mb SPI flash memory (H310: 128Mb)

2.2 Rear I/O Connectors

Display 1x DisplayPort, 1x HDMI, 1x DVI-D

LAN Dual GbE RJ-45

USB 4x USB 3.1 Gen2 connectors (H310: USB 3.1 Gen1)

Audio 1x Line-out, 1x Line-in, 1x Mic-in connector

Serial 1x RS-232/422/485 with auto flow control connector

4 Specifications

2.3 Internal Headers and Connectors

PCI Express Slots PCIe x16 (Gen3)

1x Mini PCIe (full/half size), supports PCIe x1 Gen2, USB 2.0

USB 2x USB 3.1 Gen1 onboard header (H310: not available)

2x USB 2.0 onboard header

SATA 4x SATA 6.0 Gb/s connectors. Software RAID support 0/1/5/10 (H310: 2x SATA, no RAID support)

1x M.2 (2280)

Serial 4x RS-232 headers

LVDS 1x LVDS pin header, supports single/dual channel 24-bit LVDS up to 1920x1080 @ 60 Hz

DIO 1x 8-bit GPIO pin header

Other CPU Fan Header

Sys Fan Header

Audio Header

Front Panel Header

SPI Header

Case Open Header

CPU 12V Power Connector (4-pin)

ATX Power Connector (24-pin)

2.4 Form Factor

Mini-ITX: 170mm x 170mm

2.5 Video

GPU Feature Support Integrated Gen 9.5 Intel® Graphics with up to 24 execution units supporting the latest

graphics APIs DirectX 12 and OpenGL 4.5 for improved 3D rendering performance at low

power.

Display Interface Support •1x DVI-D, resolution up to 1920 x 1200 @ 60 Hz

•1x DP, resolution up to 4096 x 2304 @ 60 Hz

•1x HDMI, resolution up to 4096 x 2160 @ 30 Hz

•1x LVDS, supports single/dual channel 24-bit LVDS up to 1920x1080 @ 60 Hz

2.6 Audio

Audio Codec Realtek ALC888S

Interfaces 1x Line-out, 1x Line-in, 1x Mic-in connector

2.7 LAN

LAN1/2 Realtek RTL8111G Ethernet controllers

Interface 10/100/1000 Mbps RJ45 connectors

Inhaltsverzeichnis

Andere ADLINK Technology Computerhardware Handbücher

ADLINK Technology

ADLINK Technology EC-8560 Bedienungsanleitung

ADLINK Technology

ADLINK Technology SMARC MODULE LEC-EL Betriebsanleitung

ADLINK Technology

ADLINK Technology cPCI-3520 Series Bedienungsanleitung

ADLINK Technology

ADLINK Technology VPX3001 Series Bedienungsanleitung

ADLINK Technology

ADLINK Technology arm AMPERE COM-HPC-ALT Bedienungsanleitung

ADLINK Technology

ADLINK Technology Q7-AL Bedienungsanleitung

ADLINK Technology

ADLINK Technology LEC-BTS Gebrauchs- und Pflegehandbuch

ADLINK Technology

ADLINK Technology EBP-13E2 Bedienungsanleitung

ADLINK Technology

ADLINK Technology COM Express Express-BL Bedienungsanleitung

ADLINK Technology

ADLINK Technology nanoX-TCR Bedienungsanleitung

ADLINK Technology

ADLINK Technology nanoX-EL Bedienungsanleitung

ADLINK Technology

ADLINK Technology cPCI-9116 Bedienungsanleitung

ADLINK Technology

ADLINK Technology MCM-100 Bedienungsanleitung

ADLINK Technology

ADLINK Technology NuPRO-598 Series Bedienungsanleitung

ADLINK Technology

ADLINK Technology Com Express nanoX-BT Bedienungsanleitung

ADLINK Technology

ADLINK Technology ETX-BT Bedienungsanleitung

ADLINK Technology

ADLINK Technology MXM-AXe Bedienungsanleitung

ADLINK Technology

ADLINK Technology cPCI-3970 series Bedienungsanleitung

ADLINK Technology

ADLINK Technology LEC-BASE MINI Gebrauchs- und Pflegehandbuch

ADLINK Technology

ADLINK Technology NuIPC cPCI-3500A Series Bedienungsanleitung

ADLINK Technology

ADLINK Technology EGX-MXM-RTX3000 Bedienungsanleitung

ADLINK Technology

ADLINK Technology COM Express cExpress-BT2 Bedienungsanleitung

ADLINK Technology

ADLINK Technology HPERC-IBR-MC Bedienungsanleitung

ADLINK Technology

ADLINK Technology DLAP-301 Series Bedienungsanleitung

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

Intel

Intel NUC 12 Pro Bedienungsanleitung

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Intel

Intel AXXRMFBU4 Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung
